CADILLAC ESCALADE 2000 1.G Owners Manual

2-53
Mirrors
Electrochromic Inside Rearview Mirror
with Compass, Temperature Display and
Headlamp Delay
Your vehicle has electrochromic inside and outside
rearview mirrors. Your vehicle also has a headlamp
delay feature. See ªHeadlamp Delayº in the Index for
more information.
When on, an electrochromic mirror automatically dims
to the proper level to minimize glare from lights behind
you after dark.
The mirror also includes an eight-point compass display
in the upper right corner of the mirror face. When on,
the compass automatically calibrates as the vehicle
is driven.
The display can also be used to indicate outside
air temperature.

2-54
Temperature Display
The temperature can be displayed by pressing the TEMP
button. Pressing the TEMP button once briefly will
toggle the temperature reading on and off. To alternate
the temperature reading between Fahrenheit and Celsius,
press and hold the TEMP button for about eight seconds
until the display shows only F
or C
. Press and release
the TEMP button to toggle between the Fahrenheit and
Celsius readings. After five seconds of inactivity, the
display will return to normal in the temperature scale
you have selected.
The normal display will show a temperature reading in
degrees Fahrenheit or Celsius. If an abnormal reading is
displayed, please consult your dealer.
Electrochromic Mirror Operation
The TEMP side of the button, located at the bottom of
the mirror, also turns the electrochromic inside and
outside mirrors on and off. An indicator light, located to
the right of the TEMP button, will come on when the
electrochromic mirrors are turned on. To turn the
mirrors on, press and hold the TEMP button for about
15 seconds. The mirrors will darken and remain dark
until the button is released. To turn the mirrors off, press
and hold the TEMP button for about 15 seconds.Compass Operation
Press the COMP button once briefly to turn the compass
on or off.
When the ignition and the compass feature are on, the
compass will show two character boxes for
approximately two seconds. After two seconds, the
mirror will display the compass heading.
Cleaning the Mirror
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray
glass cleaner directly on the mirror as that may cause the
liquid cleaner to enter the mirror housing.
Compass Calibration
The compass may need calibration if:

After five seconds, the display does not show a
compass (ªNº for North, for example), there may be
a strong magnetic force interfering with the compass.
Such interference may be caused by a magnetic
antenna, magnetic note pad holder or a similar
magnetic item.

The compass does not display the correct heading
and the compass zone variance is set correctly.

2-55
In order to calibrate, the letter ªCº must be displayed in
the mirror compass windows. If ªCº is not displayed,
push in the ªCOMPº button for approximately eight
seconds or until the letter ªCº is displayed.
The compass can be calibrated in one of two ways:

Drive the vehicle in circles at 5 mph (8 km/h) or less
until the display reads a direction, or

Drive the vehicle on your everyday routine and after
several turns the compass will become calibrated and
will display a direction.
Compass Variance
The mirror is set in zone eight upon leaving the factory.
It will be necessary to adjust the compass to compensate
for compass variance if you live outside zone eight.
Under certain circumstances, as during a long distance
cross
-country trip, it will be necessary to adjust for
compass variance. Compass variance is the difference
between earth's magnetic north and true geographic
north. If not adjusted to account for compass variance,
your compass could give false readings.
To adjust for compass variance:
1. Press and hold the COMP button, located at the
bottom of the mirror, for three seconds until a zone
number appears in the display.2. Find your current location and variance zone number
on the following zone map.
3. Press the COMP button on the bottom of the mirror
until the new zone number appears in the display.
After you stop pressing the switch in, the display
will show a compass direction within a few seconds.

2-56 Electric Outside Rearview Mirrors
The electric mirrors can be adjusted to point where you
want from inside the vehicle.
Select the mirror you want
to move by turning the
center of the switch, located
on the driver's door armrest,
to L (left) or R (right).
Then, adjust the mirror angle by pressing the outer
arrows on the switch until the mirror is adjusted where
you want it. The center position turns the electric
mirrors off.
The mirrors can also be folded forward or rearward. To
fold the mirror, push forward or rearward on the
mirror head.
Electrochromic Heated Outside
Rearview Mirrors
The outside rearview mirrors feature auto-dimming and
defrost modes.
To turn on the auto
-dimming feature, press and hold the
TEMP button on the inside rearview mirror for about 15
seconds. See ªElectrochromic Inside Rearview Mirror
with Compass, Temperature Display and Headlamp
Delayº in the Index for further information.
To turn on the defrost feature, press the rear window
defrost button. See ªRear Window Defoggerº in the
Index for further information.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.

2-57
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
Storage Compartments
Your vehicle has a variety of storage compartments
designed to store small items.
Glove Box
To open your glove box, move the release button toward
the passenger's side and pull the door open.
Center Overhead Console
Your vehicle has an overhead console. It has a storage
compartment inside it. Your vehicle also has a
HomeLink transmitter. See ªHomeLink

Transmitterº
in the Index.Rear Compartment
The rear compartment can be used to store a small item,
like a book.
To open the rear compartment, press the release button
located at the rear of the compartment door.
Instrument Panel Cupholder
Your vehicle has a cupholder located in the middle of
the instrument panel.
To use the cupholder, pull
the handle and slide the
cupholder tray open.
To close the cupholder, slide it back into the
instrument panel.

2-58 Center Floor Console
Your vehicle has a console compartment between the
bucket seats.
To open it, insert the console key into the lock and
unlock the console. Press the button in and swing the
console lid upward.
The console key is for use on the storage
compartment only.
The console has a small storage bin covered by a lid.
When open, the lid provides a writing surface.
The console has two cupholders and two storage trays
for the front passenger and driver to use.
Your console also has a
cupholder that swings down
for the rear seat passengers
to use.
The console also contains the following components:

Rear Seat Audio System Controls

Rear Heated Seat Switches

Rear Seat Accessory Power Outlet

Six
-Disc CD Changer

Subwoofer

Audio Amplifier

Shock Sensor Adjuster

LED (Light Emitting Diode) Theft
-Deterrent
System Indicator
For more information on these components, please see
the Index for that item.

2-59 Rear Armrest Storage Compartment
Your vehicle has a center armrest storage compartment
in the rear seat.
Other Storage Compartments
Your vehicle includes a number of storage
compartments for storage of often
-used items.
Your vehicle has a storage pocket on each of the front
doors. You can use the pocket to store a variety of
small items.
Convenience Net
Your vehicle has a convenience net, which is used to
keep small loads, like grocery bags, in place during
sharp turns or quick starts and stops.
The net is not designed for larger, heavier loads.
It is stored in a pouch attached at the driver's side of the
vehicle. You can also unhook the net so that it will lie
flat when you're not using it.
Cargo Security Shade
CAUTION:
An improperly stored cargo cover could be
thrown about the vehicle during a collision or
sudden maneuver. You or others could be
injured. If you remove the cover, always store it
outside of the vehicle. When you put it back,
always be sure that it is securely reattached.
Your vehicle has a cargo security shade. You can use it
to cover items in the cargo area of your vehicle.

2-60
To use the shade:
1. Pull the shade handle toward the rear of the vehicle.
2. Latch the shade posts into the retaining sockets on
the cargo area trim panels.
To return the shade to the shade holder:
1. Pull up on the shade handle to release the shade posts
from the retaining sockets.
2. Let the shade move forward and latch the shade
posts into the front
-most retaining sockets.
To remove the shade from the vehicle:
1. Let the shade go all the way into the holder.
2. Push the shade holder toward the passenger's side of
the vehicle.
3. Lift the shade up on the driver's side.
4. Swing the shade rearward and take it out of
the vehicle.
To put the shade in the vehicle:
1. Make sure the shade slot in the holder faces rearward
with the round surface facing down.
2. Hold the shade at an angle.
3. Place the shade holder tab into the slot in the
passenger's side trim panel.

2-61
4. Move the other end of the shade forward.
5. Hold it next to the driver's side trim panel slot.
6. Push the shade holder toward the passenger's side of
the vehicle.
7. Place the tab in the driver's side trim panel slot.
Make sure the tab goes all the way in the slot.
8. Lightly pull on the shade holder to make sure it
is secure.
9. Pull the shade to the desired position and secure the
shade posts in the appropriate retaining sockets.
Cargo Tie Downs
There are cargo tie downs in
the rear cargo area that
allow you to strap cargo in
and keep it from moving
inside the vehicle.
When not using the tie downs, flip them down out of
the way.
Luggage Carrier
Your vehicle has a luggage carrier which you can use to
load things on top of your vehicle.
The luggage carrier has slats and side rails attached to
the roof, and crossrails which can be moved toward the
front or the rear in the side rails to help secure cargo. Tie
the load to the tie loops or crossrails.
NOTICE:
Loading cargo that weighs more than 200 lbs.
(90.6 kg) on the luggage carrier may damage
your vehicle. When you carry large things, never
let them hang over the rear or the sides of your
vehicle. Load your cargo so that it rests on the
slats and does not scratch or damage the vehicle.
Put the cargo against the side rails and fasten it
securely to the luggage carrier.
Don't exceed the maximum vehicle capacity when
loading your vehicle. For more information on vehicle
capacity and loading, see ªLoading Your Vehicleº in
the Index.

2-62
To prevent damage or loss of cargo as you're driving,
check now and then to make sure the luggage carrier and
cargo are still securely fastened.
Be sure the cargo is properly loaded.

If small heavy objects are placed on the roof, place
the load in the area over the rear wheels. If you need
to, cut a piece of 3/8 inch plywood to fit inside the
crossrails and side rails to spread the load.

Tie the load to the crossrails or the side rail supports.
Use the crossrails only to keep the load from sliding.

If you need to carry long items, move the crossrails
as far apart as they will go. Tie the load to the
crossrails and tie loops. Also tie the load to the
bumpers. Do not tie the load so tightly that the
crossrails or side rails are damaged.

For the purpose of wind noise reduction, locate the
front crossrail approximately 18 to 24 inches (46 cm
to 58 cm) rearward of the front supports.

After moving the crossrails, be sure to tighten all the
slider screws.
Your vehicle has a Center High
-Mounted Stoplamp
(CHMSL) located above the tailgate glass or above the
rear load doors.If items are loaded on the roof of the vehicle, care should
be taken not to block or damage the CHMSL unit.
Ashtrays and Cigarette Lighter
Front Ashtray
The front ashtray is located at the bottom of the
instrument panel. Pull on the notch in the ashtray door to
open it.
NOTICE:
If you store paper or other things that burn in
your ashtrays, they could be set on fire by
cigarettes or other smoking materials. That could
cause a fire and possibly damage your vehicle. Do
not store papers and other things that burn in
your ashtrays.
To remove the front ashtray, press the retainer spring
and pivot the ashtray toward you. To replace the ashtray,
place the bottom part of the ashtray on the pivot bar at
the bottom of its mounting on the instrument panel.
Then turn the ashtray back to its original position.
