Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
406 VEHICLE CARE
(3) Aspect Ratio:A 2-digit
number that indicates the tire
height-to-width measurements.
For example, if the tire size aspect
ratio is 75, as shown in item (3) of
the illustration, it would mean
that the tire's sidewall is
75 percent as high as it is wide.
(4) Construction Code
:A letter
code is used to indicate the type
of ply construction in the tire. The
letter "R" means radial ply
construction; the letter "D" means
diagonal or bias ply construction.
(5) Rim Diameter
:Diameter of
the wheel in inches.
(6) Service Description
:These
characters represent the load
index and speed rating of the tire.
The load index represents the load
carrying capacity a tire is certified
to carry. The speed rating is the
maximum speed a tire is certified
to carry a load.
Tire Terminology and
Definitions
Air Pressure:The amount of air
inside the tire pressing outward
on each square inch of the tire.
Air pressure is expressed in kPa
(kilopascal) or psi (pounds per
square inch).
Accessory Weight
:The combined
weight of optional accessories.
Some examples of optional
accessories are automatic
transmission, power windows,
power seats, and air conditioning.
Aspect Ratio
:The relationship of
a tire's height to its width.
Belt
:A rubber coated layer of
cords between the plies and the
tread. Cords may be made from
steel or other reinforcing
materials. Bead
:The tire bead contains steel
wires wrapped by steel cords that
hold the tire onto the rim.
Bias Ply Tire
:A pneumatic tire in
which the plies are laid at
alternate angles less than
90 degrees to the centerline of the
tread.
Cold Tire Pressure
:The amount
of air pressure in a tire, measured
in kPa (kilopascal) or psi (pounds
per square inch) before a tire has
built up heat from driving. See
Tire Pressure 0409.
Curb Weight
:The weight of a
motor vehicle with standard and
optional equipment including the
maximum capacity of fuel, oil, and
coolant, but without passengers
and cargo.

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
444 VEHICLE CARE
Appearance Care
Exterior Care
Locks
Locks are lubricated at the factory.
Use a de-icing agent only when
absolutely necessary, and have the
locks greased after using. See
Recommended Fluids and Lubricants
0464.
Washing the Vehicle
To preserve the vehicle's finish, wash
it often and out of direct sunlight.
Caution
Do not use petroleum-based, acidic,
or abrasive cleaning agents as they
can damage the vehicle's paint,
metal, or plastic parts. If damage
occurs, it would not be covered by
the vehicle warranty. Approved
cleaning products can be obtained
from your dealer. Follow all
manufacturer directions regarding
correct product usage, necessary
(Continued)
Caution (Continued)
safety precautions, and appropriate
disposal of any vehicle care
product.
Caution
Avoid using high-pressure washes
closer than 30 cm (12 in) to the
surface of the vehicle. Use of power
washers exceeding 8 274 kPa
(1,200 psi) can result in damage or
removal of paint and decals.
If using an automatic car wash, follow
the car wash instructions. The
windshield wiper and rear window
wiper, if equipped, must be off.
Remove any accessories that may be
damaged or interfere with the car
wash equipment.
Rinse the vehicle well, before washing
and after, to remove all cleaning
agents completely. If they are allowed
to dry on the surface, they could stain. Dry the finish with a soft, clean
chamois or an all-cotton towel to
avoid surface scratches and water
spotting.
Cleaning Underhood Components
Caution
Do not power wash any component
under the hood that has this
e
symbol.
This could cause damage that
would not be covered by the vehicle
warranty.
Solvents or aggressive cleaners may
harm underhood components. The
usages of these chemicals should be
avoided.
Recommend water only.
A pressure washer may be used, but
care must be utilized. The following
criteria must be followed:
.Water pressure must be kept below
14,000 KPa (2,000 PSI).
.Water temperature must be below
80 °C (180 °F).

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
VEHICLE CARE 449
Interior Care
To prevent dirt particle abrasions,
regularly clean the vehicle's interior.
Before using cleaners, read and follow
all safety instructions on the label.
While cleaning the interior, open the
doors and windows to get proper
ventilation. Newspapers or dark
garments can transfer color to the
vehicle’s interior.
Caution
Immediately remove cleaners, hand
lotions, sunscreen, and insect
repellent from all interior surfaces
or permanent damage may result.
Caution
Use cleaners specifically designed
for the surfaces being cleaned to
prevent permanent damage to the
vehicle. Apply all cleaners directly
to a cleaning cloth. Do not spray
cleaners on any switches or
controls.When using liquid soap cleaners,
follow the directions on the specific
cleaner or soap solution for dilution
instructions.
Caution
To prevent damage:
.Never use a razor or any other
sharp object to remove soil from
any interior surface
.Never use a brush with stiff
bristles.
.Never rub any surface
aggressively or with too much
pressure.
.Do not get any exposed electrical
components wet.
.Do not use laundry detergents or
dishwashing soaps with
degreasers. Do not use solutions
that contain strong or
caustic soap.
.Do not heavily saturate the
upholstery when cleaning.
.Do not use solvents or cleaners
containing solvents.
(Continued)
Caution (Continued)
.Do not use disinfecting wipes
that are scented or contain
bleach. Do not use wipes or
cleaners that show a color
transfer to the wipe or change
the appearance of the interior
surface when used.
.Do not use scented or gel-type
hand sanitizers. If hand sanitizer
comes in contact with interior
surfaces of the vehicle, blot
immediately and clean with a
soft cloth dampened with a mild
soap and water solution.
Interior Glass
To clean, use a microfiber cloth fabric
dampened with water. Wipe droplets
left behind with a clean dry cloth.
If necessary, use a commercial glass
cleaner after cleaning with plain water.

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
450 VEHICLE CARE
Caution
To prevent scratching, never use
abrasive cleaners on automotive
glass. Abrasive cleaners or
aggressive cleaning may damage
the rear window defogger.
Cleaning the windshield with water
during the first three to six months of
ownership will reduce tendency to fog.
Speaker Covers
Vacuum around a speaker cover
gently, so that the speaker will not be
damaged. Clean spots with water and
mild soap.
Coated Moldings
Coated moldings should be cleaned.
.When lightly soiled, wipe with a
sponge or soft, lint-free cloth
dampened with water.
.When heavily soiled, use warm
soapy water.
Vinyl/Rubber
If equipped with vinyl floor and
rubber floor mats, use a soft cloth
and/or brush dampened with water to
remove dust and loose dirt. For more
thorough cleaning, use a mild soap
and water solution.
{Warning
Do not use cleaners that contain
silicone, wax-based products,
or cleaners that increase gloss on
vinyl/rubber floor and mats. These
cleaners can permanently change
the appearance and feel of the
vinyl/rubber and can make the floor
slippery. Your foot could slip while
operating the vehicle, and you
could lose control, resulting in a
crash. You or others could be
injured.
Fabric/Carpet/Suede
Start by vacuuming the surface using
a soft brush attachment. If a rotating
vacuum brush attachment is being
used, only use it on the floor carpet.
Before cleaning, gently remove as
much of the soil as possible:
.Gently blot liquids with a paper
towel. Continue blotting until no
more soil can be removed.
.For solid soils, remove as much as
possible prior to vacuuming.
To clean: 1. Saturate a clean, lint-free colorfast cloth with water. Microfiber cloth is
recommended to prevent lint
transfer to the fabric or carpet.
2. Remove excess moisture by gently wringing until water does not drip
from the cleaning cloth.
3. Start on the outside edge of the soil and gently rub toward the
center. Fold the cleaning cloth to a
clean area frequently to prevent
forcing the soil into the fabric.

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
VEHICLE CARE 451
4. Continue gently rubbing the soiledarea until there is no longer any
color transfer from the soil to the
cleaning cloth.
5. If the soil is not completely removed, use a mild soap solution
followed only by plain water.
If the soil is not completely removed,
it may be necessary to use a
commercial upholstery cleaner or spot
lifter. Test a small hidden area for
colorfastness before using a
commercial upholstery cleaner or spot
lifter. If ring formation occurs, clean
the entire fabric or carpet.
After cleaning, use a paper towel to
blot excess moisture.
Cleaning High Gloss Surfaces
and Vehicle Information and
Radio Displays
Use a microfiber cloth on high gloss
surfaces or vehicle displays. First, use
a soft bristle brush to remove dirt that
can scratch the surface. Then gently
clean by rubbing with a microfiber
cloth. Never use window cleaners or
solvents. Periodically hand wash the
microfiber cloth separately, using mild soap. Do not use bleach or fabric
softener. Rinse thoroughly and air dry
before next use.
Caution
Do not attach a device with a
suction cup to the display. This may
cause damage and would not be
covered by the vehicle warranty.
Instrument Panel, Leather, Vinyl,
Other Plastic Surfaces, Low
Gloss Paint Surfaces, and
Natural Open Pore Wood
Surfaces
Use a soft bristle brush to remove
dust from knobs and crevices on the
instrument cluster. Use a soft
microfiber cloth dampened with water
to remove dust and loose dirt. For a
more thorough cleaning, use a soft
microfiber cloth dampened with a
mild soap and water solution.
Caution
Soaking or saturating leather,
especially perforated leather, as well
as other interior surfaces, may
cause permanent damage. Wipe
excess moisture from these surfaces
after cleaning and allow them to
dry naturally. Never use heat,
steam, or spot removers. Do not use
liquids that contain alcohol or
solvents on leather seats. Do not
use cleaners that contain silicone or
wax-based products. Cleaners
containing these solvents can
permanently change the appearance
and feel of leather or soft trim, and
are not recommended.
Do not use cleaners that increase
gloss, especially on the instrument
panel. Reflected glare can decrease
visibility through the windshield
under certain conditions.

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
SERVICE AND MAINTENANCE 459
Footnotes—Maintenance Schedule
Additional Required Services -
Normal
(1) Or every two years, whichever
comes first. More frequent passenger
compartment air filter replacement
may be needed if driving in areas with
heavy traffic, poor air quality, high
dust levels, or environmental
allergens. Passenger compartment air
filter replacement may also be needed
if there is reduced airf low, window
fogging, or odors. Your GM dealer can
help determine when to replace the
filter.
(2) Do not directly power wash the
transfer case and/or front/rear axle
output seals. High pressure water can
overcome the seals and contaminate
the transfer case fluid. Contaminated
fluid will decrease the life of the
transfer case and/or axles and should
be replaced.
(3) Or every five years, whichever
comes first. See Cooling System0378. (4)
Or every 10 years, whichever
comes first. Inspect for fraying,
excessive cracking, or damage; replace,
if needed.
(5) Replace brake fluid every five
years. See Brake Fluid 0385.
(6) Or every 12 months, whichever
comes first. See Wiper Blade
Replacement 0388.
(7) Or every 10 years, whichever
comes first. See Gas Strut(s)0389.
(8) Replace air conditioning desiccant
every seven years.

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
SERVICE AND MAINTENANCE 461
Footnotes—Maintenance Schedule
Additional Required Services -
Severe
(1) Or every two years, whichever
comes first. More frequent passenger
compartment air filter replacement
may be needed if driving in areas with
heavy traffic, poor air quality, high
dust levels, or environmental
allergens. Passenger compartment air
filter replacement may also be needed
if there is reduced airf low, window
fogging, or odors. Your GM dealer can
help determine when to replace the
filter.
(2) Do not directly power wash the
transfer case and/or front/rear axle
output seals. High pressure water can
overcome the seals and contaminate
the transfer case fluid. Contaminated
fluid will decrease the life of the
transfer case and/or axles and should
be replaced.
(3) Or every five years, whichever
comes first. See Cooling System0378. (4)
Or every 10 years, whichever
comes first. Inspect for fraying,
excessive cracking, or damage; replace,
if needed.
(5) Replace brake fluid every five
years. See Brake Fluid 0385.
(6) Or every 12 months, whichever
comes first. See Wiper Blade
Replacement 0388.
(7) Or every 10 years, whichever
comes first. See Gas Strut(s)0389.
(8) Replace air conditioning desiccant
every seven years.
Special Application
Services
.Severe Commercial Use Vehicles
Only: Lubricate chassis components
every oil change.
.Have underbody flushing service
performed. See "Underbody
Maintenance" in Exterior Care0444.
Additional Maintenance
and Care
Your vehicle is an important
investment and caring for it properly
may help to avoid future costly
repairs. To maintain vehicle
performance, additional maintenance
services may be required.
It is recommended that your dealer
perform these services —their trained
dealer technicians know your vehicle
best. Your dealer can also perform a
thorough assessment with a
multi-point inspection to recommend
when your vehicle may need
attention.
The following list is intended to
explain the services and conditions to
look for that may indicate services are
required.

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
502 INDEX
Power (cont'd)Outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Protection, Battery . . . . . . . . . . . . . . . . 158
Retained Accessory (RAP) . . . . . . . . 250
Seat Adjustment . . . . . . . . . . . . . . . . . . . 43
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Power Assist Steps . . . . . . . . . . . . . . . . . . . 27
Pregnancy, Using Seat Belts . . . . . . . . . 65
Privacy
Vehicle Data Recording . . . . . . . . . . 482
Problems with Route Guidance . . . . 191
Program Courtesy Transportation . . . . . . . . . 477
Prohibited Fuels . . . . . . . . . . . . . . . . . . . . 333
Proposition 65 Warning, California . . . . . . . . . . . . . . . . . . . . .386, 436
Publication Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . 480
R
RadioHD Radio Technology . . . . . . . . . . . . 168
Radio Data System (RDS) . . . . . . . . . . 169
Radio Frequency Statement . . . . . . . . 481
Radio Reception . . . . . . . . . . . . . . . . . . . . 170
Radios AM-FM Radio . . . . . . . . . . . . . . . . . . . . . 166
Satellite . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169 Reading Lamps . . . . . . . . . . . . . . . . . . . . . 157
Rear
Seat Infotainment (RSI)System . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
Rear Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 387 Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270
Rear Camera Mirror . . . . . . . . . . . . . . . . . 33
Rear Climate Control System . . . . . . 225
Rear Cross Traffic Alert System . . . 319
Rear Pedestrian Alert . . . . . . . . . . . . . . . 318
Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Heated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Rear Storage . . . . . . . . . . . . . . . . . . . . . . . . . 99
Rear Vision Camera (RVC) . . . .303, 304
Rear Window Washer/Wiper . . . . . . . 108
Rearview Mirrors Automatic Dimming . . . . . . . . . . . . . . . 33
Reclining Seatbacks . . . . . . . . . . . . . . . . . 44
Recognition Voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192
Recommended
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 333
Recommended Fluids and Lubricants . . . . . . . . . . . . . . . . . . . . . . . . . 464
Records
Maintenance . . . . . . . . . . . . . . . . . . . . . . 466
Recreational Vehicle Towing . . . . . . . 440 Reimbursement Program, GM
Mobility . . . . . . . . . . . . . . . . . . . . . . . . . . . . 475
Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Remote Vehicle Start . . . . . . . . . . . . . . . . 13
Replacement Glass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 389
Replacement Parts Airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Maintenance . . . . . . . . . . . . . . . . . . . . . . 465
Replacing Airbag System . . . . . . . . . . . . 77
Replacing LATCH System Parts
after a Crash . . . . . . . . . . . . . . . . . . . . . . . . 92
Replacing Seat Belt System Parts after a Crash . . . . . . . . . . . . . . . . . 66
Reporting Safety Defects
Canadian Government . . . . . . . . . . . . 481
General Motors . . . . . . . . . . . . . . . . . . . 482
U.S. Government . . . . . . . . . . . . . . . . . . 481
Restraints Where to Put . . . . . . . . . . . . . . . . . . . . . . . 83
Retained Accessory Power (RAP) . . . . . . . . . . . . . . . . . . . . . . . 250
Reverse Automatic Braking . . . . . . . . 316
Reverse Tilt Mirrors . . . . . . . . . . . . . . . . . 33
Ride Control Systems Magnetic . . . . . . . . . . . . . . . . . . . . . . . . . . 270

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
506 INDEX
WheelsAlignment and Tire Balance . . . . . 422
Different Size . . . . . . . . . . . . . . . . . . . . . . 420
Replacement . . . . . . . . . . . . . . . . . . . . . . 422
When It Is Time for New Tires . . . . 418
Where to Put the Restraint . . . . . . . . . 83
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Windshield Replacement . . . . . . . . . . . . . . . . . . . . . . 389
Wiper/Washer . . . . . . . . . . . . . . . . . . . . . 106
Winter Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240
Winter Tires . . . . . . . . . . . . . . . . . . . . . . . . . 403
Wiper Blade Replacement . . . . . . . . . . 388
Wipers Rear Washer . . . . . . . . . . . . . . . . . . . . . . 108
Wireless Charging . . . . . . . . . . . . . . . . . . 112
