change time CADILLAC ESCALADE ESV 2004 2.G Owner's Guide

{CAUTION:
Rust or dirt on a wheel, or on the parts to
which it is fastened, can make wheel nuts
become loose after a time. The wheel could
come off and cause an accident. When you
change a wheel, remove any rust or dirt from
places where the wheel attaches to the vehicle.
In an emergency, you can use a cloth or a
paper towel to do this; but be sure to use a
scraper or wire brush later, if you need to, to
get all the rust or dirt off. See “Changing a Flat
Tire” in the Index.
When It Is Time for New Tires
One way to tell when it’s
time for new tires is to
check the treadwear
indicators, which will
appear when your tires
have only 1/16 inch
(1.6 mm) or less of tread
remaining. Some
commercial truck tires may
not have treadwear
indicators.
You need a new tire if any of the following statements
are true:
You can see the indicators at three or more places
around the tire.
You can see cord or fabric showing through the
tire’s rubber.
The tread or sidewall is cracked, cut or snagged
deep enough to show cord or fabric.
The tire has a bump, bulge or split.
The tire has a puncture, cut or other damage that
can’t be repaired well because of the size or
location of the damage.
5-79

{CAUTION:
Rust or dirt on the wheel, or on the parts to
which it is fastened, can make the wheel nuts
become loose after a time. The wheel could
come off and cause an accident. When you
change a wheel, remove any rust or dirt from
the places where the wheel attaches to the
vehicle. In an emergency, you can use a cloth
or a paper towel to do this; but be sure to use
a scraper or wire brush later, if you need to, to
get all the rust or dirt off.
{CAUTION:
Never use oil or grease on studs or nuts. If
you do, the nuts might come loose. Your wheel
could fall off, causing a serious accident.6. After mounting the
spare, put the wheel
nuts back on with
the rounded end of the
nuts toward the
wheel. Tighten each
wheel nut by hand.
Then use the wheel wrench to tighten the nuts until
the wheel is held against the hub.
7. Turn the wheel wrench counterclockwise to lower
the vehicle. Lower the jack completely.
5-95

Scheduled Maintenance
When the CHANGE ENGINE OIL message comes on, it
means that service is required for your vehicle. Have your
vehicle serviced as soon as possible within the next
600 miles (1 000 km). It is possible that, if you are driving
under the best conditions, the engine oil life system may
not indicate that vehicle service is necessary for over a
year. However, your engine oil and lter must be changed
at least once a year and at this time the system must be
reset. Your GM Goodwrench dealer has GM-trained
service technicians who will perform this work using
genuine GM parts and reset the system.
If the engine oil life system is ever reset accidentally,
you must service your vehicle within 3,000 miles
(5 000 km) since your last service. Remember to reset
the oil life system whenever the oil is changed. See
Engine Oil on page 5-14for information on the Engine
Oil Life System and resetting the system.When the CHANGE ENGINE OIL message appears,
certain services, checks and inspections are required.
Required services are described in the following for
“MaintenanceI” and “MaintenanceII.” Generally,
it is recommended that your rst service be
MaintenanceI, your second service be MaintenanceII
and that you alternate MaintenanceIand MaintenanceII
thereafter. However, in some cases, MaintenanceII
may be required more often.
MaintenanceI— Use MaintenanceIif the CHANGE
ENGINE OIL message comes on within ten months
since vehicle was purchased or MaintenanceII
was performed.
MaintenanceII— Use MaintenanceIIif the previous
service performed was MaintenanceI. Always use
MaintenanceIIwhenever the message comes on ten
months or more since the last service or if the message
has not come on at all for one year.
6-5

Additional Program Information
Courtesy Transportation is available during the
Bumper-to-Bumper warranty coverage period, but it
is notpart of the New Vehicle Limited Warranty.
A separate booklet entitledWarranty and Owner
Assistance Informationfurnished with each new vehicle
provides detailed warranty coverage information.
Courtesy Transportation is available only at participating
dealers and all program options, such as shuttle
service, may not be available at every dealer. Please
contact your dealer for specic information about
availability. All Courtesy Transportation arrangements
will be administered by appropriate dealer personnel.
Canadian Vehicles:For warranty repairs during
the Complete Vehicle Coverage period of the General
Motors of Canada New Vehicle Limited Warranty,
alternative transportation may be available under the
Courtesy Transportation Program. Please consult
your dealer for details.
General Motors reserves the right to unilaterally modify,
change or discontinue Courtesy Transportation at
any time and to resolve all questions of claim eligibility
pursuant to the terms and conditions described
herein at its sole discretion.
Vehicle Data Collection and Event
Data Recorders
Your vehicle, like other modern motor vehicles, has a
number of sophisticated computer systems that monitor
and control several aspects of the vehicle’s
performance. Your vehicle uses on-board vehicle
computers to monitor emission control components to
optimize fuel economy, to monitor conditions for air bag
deployment and, if so equipped, to provide anti-lock
braking and to help the driver control the vehicle
in difficult driving situations. Some information may be
stored during regular operations to facilitate repair
of detected malfunctions; other information is stored only
in a crash or near crash event by computer systems
commonly called event data recorders (EDR).
7-10

Owner’s Information
Owner publications are written specically for owners
and intended to provide basic operational information
about the vehicle. The owner’s manual will include
the Maintenance Schedule for all models.
Owner’s Manual
RETAIL SELL PRICE: $25.00
Current and Past Model Order Forms
Service Publications are available for current and
past model GM vehicles. To request an order form,
please specify year and model name of the vehicle.
ORDER TOLL FREE: 1-800-551-4123
Monday-Friday 8:00 AM - 6:00 PM
Eastern Time
For Credit Card Orders Only
(VISA-MasterCard-Discover), visit Helm, Inc. on the
World Wide Web at: www.helminc.com
Or you can write to:
Helm, Incorporated
P. O. Box 07130
Detroit, MI 48207
Prices are subject to change without notice and without
incurring obligation. Allow ample time for delivery.
Note to Canadian Customers: All listed prices are
quoted in U.S. funds. Canadian residents are to make
checks payable in U.S. funds.
7-14

Fuel (cont.)
Filling a Portable Fuel Container....................5-10
Filling Your Tank........................................... 5-8
Fuels in Foreign Countries.............................. 5-7
Gage.........................................................3-49
Gasoline Octane........................................... 5-5
Gasoline Specications.................................. 5-6
Low Warning Light.......................................3-50
Fuel Information Button....................................3-54
FUEL LEVEL LOW.........................................3-64
Fuses
Fuses and Circuit Breakers.........................5-115
Windshield Wiper.......................................5-114
G
Gage
Engine Coolant Temperature.........................3-43
Fuel..........................................................3-49
Oil Pressure...............................................3-47
Speedometer..............................................3-36
Tachometer.................................................3-36
Transmission Temperature.............................3-44
Voltmeter Gage...........................................3-40
Garage Door Opener.......................................2-39Gasoline
Octane........................................................ 5-5
Specications............................................... 5-6
Gate Operator and Canadian Programming........2-41
Getting Familiar with Off-Road Driving................4-20
Glove Box.....................................................2-43
GM Mobility Program for Persons with
Disabilities.................................................... 7-6
H
Hazard Warning Flashers................................... 3-6
Head Restraints............................................... 1-8
Headlamp
Aiming.......................................................5-52
Horizontal Aiming.........................................5-54
Vertical Aiming............................................5-54
Headlamp High/Low-Beam Changer.................... 3-9
Headlamps....................................................5-57
Bulb Replacement.......................................5-56
Front Turn Signal, Sidemarker and Daytime
Running Lamps........................................5-61
Halogen Bulbs............................................5-56
High Intensity Discharge (HID) Lighting...........5-56
Headphones...................................................3-87
7

Power (cont.)
Steering Fluid.............................................5-37
Windows....................................................2-15
Power Steering...............................................4-13
Programmable Automatic Door Locks.................2-10
Programming the HomeLink
®Transmitter...........2-39
Q
Questions and Answers About Safety Belts.........1-34
R
Radio Data System (RDS)...............................3-70
Radio Messages.............................................3-77
Radios..........................................................3-69
Care of Your Cassette Tape Player...............3-104
Care of Your CD and DVD Player................3-105
Care of Your CD Player..............................3-105
Care of Your CDs and DVDs.......................3-105
CD Changer...............................................3-99
Navigation/Radio System..............................3-86
Radio with Cassette and CD.........................3-70
Rear Seat Audio..........................................3-97
Setting the Time..........................................3-70
Theft-Deterrent..........................................3-102
Understanding Reception............................3-104RDS Messages..............................................3-76
Reaching Roadside Service............................... 7-7
Reading Lamps..............................................3-18
REAR ACCESS OPEN....................................3-67
Rear Axle......................................................5-50
Rear Climate Control System............................3-30
Rear Door Security Locks................................2-12
Rear Heated Seats.........................................1-11
Rear Safety Belt Comfort Guides......................1-49
Rear Seat Armrest..........................................2-45
Rear Seat Audio (RSA)....................................3-97
Rear Seat Entertainment System.......................3-86
Rear Seat Operation......................................... 1-9
Rear Seat Outside Passenger Positions.............1-46
Rear Seat Passengers, Safety Belts..................1-46
Rear Storage Area..........................................2-45
Rearview Mirror, Automatic Dimming with OnStar
®,
Compass and Temperature Display..................2-31
Reclining Seatbacks.......................................... 1-7
Reclining the Seatbacks...................................1-27
Recommended Fluids and Lubricants.................6-13
Recreational Vehicle Towing.............................4-49
REDUCED ENGINE POWER...........................3-63
Remote Control..............................................3-91
Remote Keyless Entry System............................ 2-4
Remote Keyless Entry System, Operation............ 2-5
Removing the 50/50 Split Bench Seats..............1-18
Removing the Bench Seat................................1-24
12

Tires (cont.)
Ination - Tire Pressure................................5-74
Inspection and Rotation................................5-78
Pressure Monitor System..............................5-75
Spare Tire................................................5-104
Uniform Tire Quality Grading.........................5-81
Wheel Alignment and Tire Balance.................5-82
Wheel Replacement.....................................5-83
When It Is Time for New Tires......................5-79
To Use the Engine Coolant Heater....................2-21
Top Strap......................................................1-63
Top Strap Anchor Location...............................1-65
Torque Lock...................................................2-28
Total Weight on Your Vehicle’s Tires..................4-62
Tow/Haul Mode Light.......................................3-49
Tow/Haul Mode Selector Button........................2-25
Towing
Recreational Vehicle.....................................4-49
Towing a Trailer..........................................4-57
Your Vehicle...............................................4-49
Traction
Off Light.....................................................3-43
Road Sensing Suspension.............................. 4-9
Stabilitrak
®System......................................4-10
TRACTION ACTIVE........................................3-67
Traction Control Operation................................4-11
TRACTION SYS LIMITED................................3-68Trailer
Recommendations.......................................4-56
Trailer Brakes.................................................4-63
Trailer Wiring Harness.....................................4-67
TRANS HOT IDLE ENGINE.............................3-66
Transfer Case................................................5-49
Transmission
Fluid, Automatic...........................................5-21
Temperature Gage.......................................3-44
TRANSMISSION HOT.....................................3-65
Transmission Operation, Automatic....................2-22
Transmission, Transaxle, Transfer Case Unit
Repair Manual............................................7-13
Transportation Options...................................... 7-9
Traveling to Remote Areas...............................4-20
Trip Information Button....................................3-51
Turn and Lane Change Signals.......................... 3-8
TURN SIGNAL ON.........................................3-64
Turn Signal/Multifunction Lever........................... 3-8
Turn Signals When Towing a Trailer..................4-65U
Ultrasonic Rear Parking Assist (URPA)...............3-19
Underhood Fuse Block...................................5-119
Understanding Radio Reception.......................3-104
16
