Scheduled Maintenance
When the CHANGE ENGINE OIL message comes on, it
means that service is required for your vehicle. Have
your vehicle serviced as soon as possible within the next
600 miles (1 000 km). It is possible that, if you are
driving under the best conditions, the engine oil
life system may not indicate that vehicle service is
necessary for over a year. However, your engine oil and
lter must be changed at least once a year and at
this time the system must be reset. Your GM
Goodwrench
®dealer has GM-trained service technicians
who will perform this work using genuine GM parts
and reset the system.
If the engine oil life system is ever reset accidentally,
you must service your vehicle within 3,000 miles
(5 000 km) since your last service. Remember to reset
the oil life system whenever the oil is changed. See
Engine Oil Life System on page 5-16for information on
the Engine Oil Life System and resetting the system.When the CHANGE ENGINE OIL message appears,
certain services, checks, and inspections are required.
Required services are described in the following for
“MaintenanceI” and “MaintenanceII.” Generally,
it is recommended that your rst service be
MaintenanceI, your second service be MaintenanceII,
and that you alternate MaintenanceIand MaintenanceII
thereafter. However, in some cases, MaintenanceII
may be required more often.
MaintenanceI— Use MaintenanceIif the CHANGE
ENGINE OIL message comes on within 10 months since
the vehicle was purchased or MaintenanceIIwas
performed.
MaintenanceII— Use MaintenanceIIif the previous
service performed was MaintenanceI. Always use
MaintenanceIIwhenever the message comes on
10 months or more since the last service or if the
message has not come on at all for one year.
6-5

Scheduled Maintenance
Service MaintenanceIMaintenanceII
Change engine oil and lter. SeeEngine Oil on page 5-13. Reset oil life
system. SeeEngine Oil Life System on page 5-16.An Emission Control
Service.••
Lubricate chassis components.See footnote #.••
Visually check for any leaks or damage.See footnote (j).••
Inspect engine air cleaner lter or change indicator (if equipped). If necessary,
replace lter. SeeEngine Air Cleaner/Filter on page 5-18.See footnote (k).•
Rotate tires and check ination pressures and wear. SeeTire Inspection and
Rotation on page 5-69and “Tire Wear Inspection” inAt Least Once a Month on
page 6-11.••
Inspect brake system.See footnote (a).••
Check engine coolant and windshield washer uid levels and add uid
as needed.••
Perform any needed additional services. See “Additional Required Services” in
this section.••
Inspect suspension and steering components.See footnote (b).•
Inspect engine cooling system.See footnote (c).•
Inspect wiper blades.See footnote (d).•
Inspect restraint system components.See footnote (e).•
Lubricate body components.See footnote (f).•
Check transmission uid level and add uid as needed.•
6-6

(i)Drain, ush, and rell cooling system. This service
can be complex; you should have your dealer perform
this service. See Engine Coolant on page 5-23 for
what to use. Inspect hoses. Clean radiator, condenser,
pressure cap, and ller neck. Pressure test the
cooling system and pressure cap.
(j)A uid loss in any vehicle system could indicate a
problem. Have the system inspected and repaired and
the uid level checked. Add uid if needed.
(k)If you drive regularly under dusty conditions, inspect
the lter at each engine oil change.
Owner Checks and Services
These owner checks and services should be performed
at the intervals specied to help ensure the safety,
dependability and emission control performance of your
vehicle. Your GM Goodwrench
®dealer can assist
you with these checks and services.
Be sure any necessary repairs are completed at once.
Whenever any uids or lubricants are added to your
vehicle, make sure they are the proper ones, as shown
inRecommended Fluids and Lubricants on page 6-14.
At Each Fuel Fill
It is important to perform these underhood checks at
each fuel ll.
Engine Oil Level Check
Check the engine oil level and add the proper oil if
necessary. SeeEngine Oil on page 5-13for further
details.
Notice:It is important to check your oil regularly
and keep it at the proper level. Failure to keep your
engine oil at the proper level can cause damage
to your engine not covered by your warranty.
Engine Coolant Level Check
Check the engine coolant level and add DEX-COOL®
coolant mixture if necessary. SeeEngine Coolant
on page 5-23for further details.
Windshield Washer Fluid Level Check
Check the windshield washer uid level in the windshield
washer tank and add the proper uid if necessary.
6-10

At Least Once a Month
Tire Ination Check
Visually inspect your vehicle’s tires and make sure they
are inated to the correct pressures. Do not forget to
check the spare tire. SeeTires on page 5-59for further
details. Check to make sure the spare tire is stored
securely. SeeChanging a Flat Tire on page 5-77.
Tire Wear Inspection
Tire rotation may be required for high mileage highway
drivers prior to the Engine Oil Life System service
notication. Check the tires for wear and, if necessary,
rotate the tires. SeeTire Inspection and Rotation on
page 5-69.
At Least Once a Year
Starter Switch Check
{CAUTION:
When you are doing this inspection, the
vehicle could move suddenly. If the vehicle
moves, you or others could be injured.
1. Before you start, be sure you have enough room
around the vehicle.
2. Firmly apply both the parking brake and the regular
brake. SeeParking Brake on page 2-25.
Do not use the accelerator pedal, and be ready to
turn off the engine immediately if it starts.
3. Try to start the engine in each gear. The vehicle
should start only in PARK (P) or NEUTRAL (N). If
the vehicle starts in any other position, contact your
GM Goodwrench
®dealer for service.
6-11

Automatic Transmission Shift Lock
Control System Check
{CAUTION:
When you are doing this inspection, the
vehicle could move suddenly. If the vehicle
moves, you or others could be injured.
1. Before you start, be sure you have enough room
around the vehicle. It should be parked on a level
surface.
2. Firmly apply the parking brake. SeeParking Brake
on page 2-25.
Be ready to apply the regular brake immediately if
the vehicle begins to move.3. With the engine off, turn the ignition to RUN, but do
not start the engine. Without applying the regular
brake, try to move the shift lever out of PARK (P)
with normal effort. If the shift lever moves out
of PARK (P), contact your GM Goodwrench
®dealer
for service.
Ignition Transmission Lock Check
While parked, and with the parking brake set, try to turn
the ignition to LOCK in each shift lever position.
The ignition should turn to LOCK only when the
shift lever is in PARK (P).
The key should come out only in LOCK.
Contact your GM Goodwrench
®dealer if service is
required.
6-12

Parking Brake and Automatic
Transmission Park (P) Mechanism Check
{CAUTION:
When you are doing this check, your vehicle
could begin to move. You or others could be
injured and property could be damaged. Make
sure there is room in front of your vehicle in
case it begins to roll. Be ready to apply the
regular brake at once should the vehicle begin
to move.Park on a fairly steep hill, with the vehicle facing
downhill. Keeping your foot on the regular brake, set the
parking brake.
To check the parking brake’s holding ability: With
the engine running and transmission in
NEUTRAL (N), slowly remove foot pressure from
the regular brake pedal. Do this until the vehicle is
held by the parking brake only.
To check the PARK (P) mechanism’s holding
ability: With the engine running, shift to PARK (P).
Then release the parking brake followed by the
regular brake.
Contact your GM Goodwrench
®dealer if service
is required.
Underbody Flushing Service
At least every spring, use plain water to ush any
corrosive materials from the underbody. Take care to
clean thoroughly any areas where mud and other debris
can collect.
6-13

Care of
Safety Belts..............................................5-100
Your Cassette Tape Player..........................3-103
Your CD and DVD Player...........................3-104
Your CDs and DVDs..................................3-104
Cargo Cover..................................................2-43
CD Changer...................................................3-98
Center Console Storage Area...........................2-41
Center Passenger Position, Safety Belts.............1-40
Chains, Tire...................................................5-76
Charging System Light....................................3-37
Check
Engine Light...............................................3-43
Checking Things Under the Hood......................5-10
Chemical Paint Spotting.................................5-104
Child Restraints
Child Restraint Systems...............................1-53
Infants and Young Children...........................1-49
Lower Anchorages and Top Tethers for
Children (LATCH System)..........................1-61
Older Children.............................................1-47
Securing a Child Restraint Designed for the
LATCH System........................................1-63
Securing a Child Restraint in a Center Rear
Seat Position...........................................1-65
Securing a Child Restraint in a Rear Outside
Seat Position...........................................1-63
Securing a Child Restraint in the Right Front
Seat Position...........................................1-67Child Restraints (cont.)
Top Strap...................................................1-57
Top Strap Anchor Location............................1-59
Where to Put the Restraint...........................1-56
Chime Level Adjustment.................................3-105
Cigarette Lighter.............................................3-21
Cleaning
Aluminum or Chrome-Plated Wheels.............5-102
Exterior Lamps/Lenses................................5-101
Fabric/Carpet..............................................5-98
Finish Care...............................................5-101
Glass Surfaces..........................................5-100
Instrument Panel........................................5-100
Interior Plastic Components.........................5-100
Leather......................................................5-99
Speaker Covers.........................................5-100
Tires........................................................5-103
Underbody Maintenance.............................5-103
Vinyl..........................................................5-99
Washing Your Vehicle.................................5-101
Weatherstrips............................................5-101
Windshield, Backglass, and Wiper Blades......5-102
Wood Panels............................................5-100
Climate Control System
Dual Automatic............................................3-22
Outlet Adjustment........................................3-28
Rear..........................................................3-29
Clock............................................................3-22
Comfort Guides, Rear Safety Belt.....................1-44
3

Driving (cont.)
Hill and Mountain Roads..............................4-36
In Rain and on Wet Roads...........................4-30
Recovery Hooks..........................................4-43
Rocking Your Vehicle to Get it Out.................4-42
Winter........................................................4-38
Dual Automatic Climate Control System.............3-22
DVD
Rear Seat Entertainment System...................3-84
E
Electrical System
Add-On Equipment.....................................5-106
Center Instrument Panel Fuse Block.............5-110
Fuses and Circuit Breakers.........................5-107
Instrument Panel Fuse Block.......................5-107
Power Windows and Other Power Options....5-107
Underhood Fuse Block...............................5-111
Windshield Wiper Fuses.............................5-106
Engine
Air Cleaner/Filter.........................................5-18
Battery.......................................................5-39
Check and Service Engine Soon Light............3-43
Coolant......................................................5-23
Coolant Heater............................................2-21
Coolant Temperature Gage...........................3-41
Engine Compartment Overview......................5-12Engine (cont.)
Exhaust.....................................................2-28
Fan Noise..................................................5-33
Oil .............................................................5-13
Oil Life System...........................................5-16
Overheated Protection Operating Mode...........5-28
Overheating................................................5-26
Starting......................................................2-19
Entry/Exit Lighting...........................................3-17
Event Data Recorders (EDR)............................. 7-9
Extender, Safety Belt.......................................1-46
Exterior Lamps...............................................3-14
F
Filter
Engine Air Cleaner......................................5-18
Finish Damage.............................................5-103
Flash-to-Pass................................................... 3-8
Flat Tire........................................................5-76
Flat Tire, Changing.........................................5-77
Flat Tire, Storing.............................................5-92
Fluid
Automatic Transmission................................5-21
Power Steering...........................................5-33
Windshield Washer......................................5-34
Fog Lamps....................................................3-16
Front Axle......................................................5-46
5

Message
DIC Warnings and Messages........................3-53
Mirrors
Automatic Dimming Rearview with OnStar
®,
Compass and Temperature Display.............2-30
Outside Automatic Dimming Mirror with
Curb View Assist......................................2-34
Outside Convex Mirror.................................2-33
Outside Heated Mirrors................................2-34
Outside Power Mirrors..................................2-32
MyGMLink.com................................................ 7-3
N
Navigation/Radio System, see
Navigation Manual.......................................3-84
New Vehicle Break-In......................................2-18
Normal Maintenance Replacement Parts............6-16
O
Odometer......................................................3-33
Off-Road Recovery..........................................4-13
Oil
Engine.......................................................5-13
Pressure Gage............................................3-46
Oil, Engine Oil Life System..............................5-16
Older Children, Restraints................................1-47Online Owner Center........................................ 7-3
OnStar
®System, see OnStar®Manual...............2-35
Operating Your All-Wheel-Drive Vehicle Off
Paved Roads..............................................4-16
Other Warning Devices...................................... 3-6
Outlet Adjustment............................................3-28
Outside
Automatic Dimming Mirror with Curb
View Assist.............................................2-34
Convex Mirror.............................................2-33
Heated Mirrors............................................2-34
Power Mirrors.............................................2-32
Overheated Engine Protection
Operating Mode..........................................5-28
Owner Checks and Services.............................6-10
Owners, Canadian............................................... ii
P
Park Aid........................................................3-18
Park (P)
Shifting Into................................................2-26
Shifting Out of............................................2-27
Parking
Assist........................................................3-18
Brake........................................................2-25
Over Things That Burn.................................2-28
Passenger Airbag Status Indicator.....................3-35
Passenger Sensing System..............................1-80
9

Replacement Bulbs.........................................5-58
Reporting Safety Defects
Canadian Government..................................7-11
General Motors...........................................7-11
United States Government............................7-10
Restraint System Check
Checking the Restraint Systems....................1-85
Replacing Restraint System Parts
After a Crash..........................................1-86
Retained Accessory Power (RAP)......................2-19
Right Front Passenger Position, Safety Belts......1-40
Road Sensing Suspension................................. 4-8
Roadside
Service........................................................ 7-5
Rocking Your Vehicle to Get it Out....................4-42
Running the Engine While Parked.....................2-29
S
Safety Belt
Reminder Light............................................3-33
Safety Belts
Care of....................................................5-100
Center Passenger Position............................1-40
Driver Position............................................1-32
How to Wear Safety Belts Properly................1-32
Questions and Answers About Safety Belts.....1-31
Rear Safety Belt Comfort Guides for
Children and Small Adults.........................1-44Safety Belts (cont.)
Rear Seat Passengers.................................1-41
Right Front Passenger Position......................1-40
Safety Belt Extender....................................1-46
Safety Belt Use During Pregnancy.................1-39
Safety Belts Are for Everyone.......................1-26
Safety Warnings and Symbols.............................. iii
Scheduled Maintenance..................................... 6-5
Seats
50/50 Split Bench Seat.................................1-13
60/40 Split Bench Seat.................................1-10
Bench Seat................................................1-18
Bucket Seats, Rear......................................1-23
Head Restraints............................................ 1-7
Heated and Cooled Seats......................1-5, 1-10
Heated Seats............................................... 1-4
Heated Seats, Rear....................................... 1-9
Memory.....................................................2-45
Power Lumbar.............................................. 1-4
Power Seats................................................. 1-3
Rear Seat Operation...................................... 1-8
Reclining Seatbacks...................................... 1-6
Secondary Latch System.................................5-89
Securing a Child Restraint
Center Rear Seat Position............................1-65
Designed for the LATCH System...................1-63
Rear Outside Seat Position...........................1-63
Right Front Seat Position..............................1-67
Security Light.................................................3-47
11
