Seats and Restraints 3-3Push down on the head restraint
after the button is released to make
sure that it is locked in place.
The head restraints are not
designed to be removed.
The vehicle's 2nd-row seats have
head restraints in the outboard
seating positions that cannot be
adjusted.
The vehicle's 3rd-row seat,
if equipped, has headrests that
can be adjusted up and down. Front Seats Power Seat Adjustment
To adjust a power seat: .
Move the seat forward or
rearward by sliding the control
forward or rearward. .
Raise or lower the front or rear
part of the seat cushion by
moving the front or rear of the
control up or down. .
Raise or lower the entire seat by
moving the entire control up
or down.
To adjust the seatback, see
Reclining Seatbacks on page 3 ‑ 6 .

Black plate (15,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
Seats and Restraints 3-15
3. Lift the release lever “ 1, ” on the
bottom rear of the seatback on
the outboard side of the seat,
and the seatback folds forward. Returning the Seatback to the
Upright Position To return the seatback to the upright
position:
1. Open the liftgate to access the
controls for the seat.
2. Raise the seatback to the
upright position.
{ WARNINGIf either seatback is not locked, it
could move forward in a sudden
stop or crash. That could cause
injury to the person sitting there.
Always push and pull on the
seatbacks to be sure they are
locked.
3. Push and pull on the seatback to
make sure it is locked. Tumbling the Third Row Seat To tumble the seat:
1. Open the liftgate to access the
controls for the seat.
2. Make sure the headrests are
completely lowered and there is
nothing under, in front of, or on
the seat.
3. Fold the seatbacks forward
using lever “ 1 ” and the
instructions listed previously
under “ Folding the Seatback. ”
The seat cannot be unlatched
from the floor unless the
seatback is folded.

Black plate (65,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
Seats and Restraints 3-65Notice: Do not let the LATCH
attachments rub against the
vehicle ’ s safety belts. This may
damage these parts. If necessary,
move buckled safety belts to
avoid rubbing the LATCH
attachments.
Do not fold the empty rear seat
with a safety belt buckled. This
could damage the safety belt or
the seat. Unbuckle and return the
safety belt to its stowed position,
before folding the seat.
1. Attach and tighten the
lower attachments to the
lower anchors. If the child
restraint does not have lower
attachments or the desired
seating position does not have
lower anchors, secure the child
restraint with the top tether and
the safety belts. Refer to your child restraint manufacturer
instructions and the instructions
in this manual.
1.1. Find the lower anchors for
the desired seating
position.
1.2. Put the child restraint on
the seat.
1.3. Attach and tighten the lower
attachments on the child
restraint to the lower
anchors.
2. If the child restraint manufacturer
recommends that the top tether
be attached, attach and tighten
the top tether to the top tether
anchor, if the vehicle has one. Refer to the child restraint
instructions and the following
steps:
2.1. Find the top tether anchor.
2.2. Route, attach, and tighten
the top tether according
to your child restraint
instructions and the
following instructions:
.
If the position you are using
does not have a headrest
or head restraint and you
are using a single tether,
route the tether over the
seatback.

Black plate (66,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
3-66 Seats and Restraints .
If the position you are using
does not have a headrest
or head restraint and you
are using a dual tether,
route the tether over the
seatback. .
If the position you are using
has an adjustable headrest
or head restraint and you
are using a single tether,
raise the headrest or head
restraint and route the
tether under the headrest
or head restraint and in
between the headrest or
head restraint posts. .
If the position you are using
has a fixed headrest or
head restraint and you are
using a single tether, route
the tether around the
inboard or outboard side
of the headrest or head
restraint.

Black plate (67,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
Seats and Restraints 3-67.
If the position you are using
has a fixed or an adjustable
headrest or head restraint
and you are using a dual
tether, route the tether
around the headrest or
head restraint. 3. Before placing a child in the
child restraint, make sure it is
securely held in place. To check,
grasp the child restraint at the
LATCH path and attempt
to move it side ‐ to ‐ side and
back ‐ and ‐ forth. There should
be no more than 2.5 cm (1 in) of
movement, for proper
installation.
Replacing LATCH System
Parts After a Crash
{ WARNING
A crash can damage the LATCH
system in the vehicle. A damaged
LATCH system may not properly
secure the child restraint,
(Continued) WARNING (Continued) resulting in serious injury or
even death in a crash. To help
make sure the LATCH system is
working properly after a crash,
see your dealer to have the
system inspected and any
necessary replacements made
as soon as possible.
If the vehicle has the LATCH system
and it was being used during a
crash, new LATCH system parts
may be needed.
New parts and repairs may be
necessary even if the LATCH
system was not being used at the
time of the crash.
