1-55
6. To tighten the belt, feed the shoulder belt back
into the retractor while you push down on the child
restraint. You may find it helpful to use your knee
to push down on the child restraint as you tighten
the belt.
7. Push and pull the child restraint in different
directions to be sure it is secure.
To remove the child restraint, just unbuckle the vehicle's
safety belt and let it go back all the way. The safety belt
will move freely again and be ready to work for an adult
or larger child passenger.

1-56
Older Children
Older children who have outgrown booster seats should
wear the vehicle's safety belts.
If you have the choice, a child should sit next to a
window so the child can wear a lap
-shoulder belt and
get the additional restraint a shoulder belt can provide.
Q:What is the proper way to wear safety belts?
A:If possible, an older child should wear a
lap
-shoulder belt and get the additional restraint a
shoulder belt can provide. The shoulder belt should
not cross the face or neck. The lap belt should fit
snugly below the hips, just touching the top of the
thighs. It should never be worn over the abdomen,
which could cause severe or even fatal internal
injuries in a crash.
Accident statistics show that children are safer if they
are restrained in the rear seat.
In a crash, children who are not buckled up can strike
other people who are buckled up, or can be thrown
out of the vehicle. Older children need to use safety
belts properly.

1-57
CAUTION:
Never do this.
Here two children are wearing the same belt.
The belt can't properly spread the impact forces.
In a crash, the two children can be crushed
together and seriously injured. A belt must be
used by only one person at a time.
Q:What if a child is wearing a lap-shoulder belt,
but the child is so small that the shoulder belt is
very close to the child's face or neck?
A:Move the child toward the center of the vehicle, but
be sure that the shoulder belt still is on the child's
shoulder, so that in a crash the child's upper body
would have the restraint that belts provide. If the
child is sitting in a rear seat outside position, see
ªRear Safety Belt Comfort Guidesº in the Index.
If the child is so small that the shoulder belt is still
very close to the child's face or neck, you might
want to place the child in a seat that has a lap belt,
if your vehicle has one.

1-58
CAUTION:
Never do this.
Here a child is sitting in a seat that has a
lap
-shoulder belt, but the shoulder part is behind
the child. If the child wears the belt in this way,
in a crash the child might slide under the belt.
The belt's force would then be applied right on
the child's abdomen. That could cause serious or
fatal injuries.
Wherever the child sits, the lap portion of the belt
should be worn low and snug on the hips, just touching
the child's thighs. This applies belt force to the child's
pelvic bones in a crash.

1-59
Safety Belt Extender
If the vehicle's safety belt will fasten around you,
you should use it.
But if a safety belt isn't long enough to fasten,
your dealer will order you an extender. It's free.
When you go in to order it, take the heaviest coat
you will wear, so the extender will be long enough for
you. The extender will be just for you, and just for the
seat in your vehicle that you choose. Don't let someone
else use it, and use it only for the seat it is made to fit.
To wear it, just attach it to the regular safety belt.
Checking Your Restraint Systems
Now and then, make sure the safety belt reminder light
and all your belts, buckles, latch plates, retractors and
anchorages are working properly. Look for any other
loose or damaged safety belt system parts. If you see
anything that might keep a safety belt system from
doing its job, have it repaired.
Torn or frayed safety belts may not protect you in
a crash. They can rip apart under impact forces.
If a belt is torn or frayed, get a new one right away.
Also look for any opened or broken air bag covers,
and have them repaired or replaced. (The air bag
system does not need regular maintenance.)

1-60
Replacing Restraint System Parts
After a Crash
CAUTION:
A crash can damage the restraint systems in your
vehicle. A damaged restraint system may not
properly protect the person using it, resulting in
serious injury or even death in a crash. To help
make sure your restraint systems are working
properly after a crash, have them inspected
and any necessary replacements made as soon
as possible.
If you've had a crash, do you need new belts?
After a very minor collision, nothing may be necessary.
But if the belts were stretched, as they would be if worn
during a more severe crash, then you need new parts.
If belts are cut or damaged, replace them. Collision
damage also may mean you will need to have safety belt
or seat parts repaired or replaced. New parts and repairs
may be necessary even if the belt wasn't being used at
the time of the collision.
If an air bag inflates, you'll need to replace air bag
system parts. See the part on the air bag system
earlier in this section.

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2-4 Keys
2-6 Door Locks
2-8 Keyless Entry System
2
-11 Midgate
2-22 Tailgate
2-23 Theft
2-24 Content Theft-Deterrent
2
-26 Passlock

2-26 New Vehicle ªBreak-Inº
2-27 Ignition Positions
2-28 Starting Your Engine
2-29 Engine Coolant Heater (If Equipped)
2-31 Automatic Transmission Operation
2-35 Parking Brake
2-36 Shifting Into PARK (P)
2-38 Shifting Out of PARK (P)
2-39 Parking Over Things That Burn
2-39 Engine Exhaust
2-40 Running Your Engine While You're Parked
2-41 Road Sensing Suspension
2-41 Locking Rear Axle2
-41 All-Wheel Drive
2-41 Horn
2-42 Tilt Wheel
2-42 Turn Signal/Multifunction Lever
2-49 Exterior Lamps
2-53 Interior Lamps
2-55 Mirrors
2-62 Storage Compartments
2-64 Cargo Cover Panels
2-81 Ashtray and Cigarette Lighter
2-82 Accessory Power Outlets
2-83 Analog Clock
2
-84 OnStar
System (If Equipped)
2-87 Sunroof (If Equipped)
2
-88 Homelink
Transmitter
2-92 The Instrument Panel - Your
Information System
2
-94 Instrument Panel Cluster
2-96 Warning Lights, Gages and Indicators
2-109 Message Center
2-117 Secondary Information Center (SIC)
2
-124 Ultrasonic Rear Parking Assist (URPA)

2-2
Windows
CAUTION:
Leaving children in a vehicle with the windows
closed is dangerous. A child can be overcome by
the extreme heat and can suffer permanent
injuries or even death from heat stroke. Never
leave a child alone in a vehicle, especially with the
windows closed in warm or hot weather.

2-3
Power Windows
The switches to operate all of the power windows are
located on the driver's door armrest. The front
passenger's door and the rear side doors also each have
an individual power window switch.
Your power windows will work when the ignition has
been turned to ACCESSORY or RUN or when Retained
Accessory Power (RAP) is active. See ªRetained
Accessory Powerº in the Index.
Press the rear or front of the switch with the power
window symbol on it to lower or raise the window.Driver's Express
-Down Window
The driver's window has an express down feature that
allows the window to be lowered without holding the
switch. Press and hold the rear of the power window
switch marked AUTO for one second to activate the
express down mode. The express down mode can be
canceled at any time by pressing the opposite side of
the switch. To open the window partway, lightly tap
the power window switch until the window is at the
desired position.
Window Lockout Switch
The driver's door power window switch has a lockout
feature. This feature prevents the passenger's windows
from operating except from the driver's position when
the driver's door button labeled WINDOW LOCK
is engaged.

2-4
Keys
CAUTION:
Leaving children in a vehicle with the ignition
key is dangerous for many reasons. A child or
others could be badly injured or even killed.
They could operate the power windows or
other controls or even make the vehicle move.
Don't leave the keys in a vehicle with children.
