Page 67 of 427
2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2-4 Keys
2-6 Door Locks
2-8 Keyless Entry System
2
-11 Midgate
2-22 Tailgate
2-23 Theft
2-24 Content Theft-Deterrent
2
-26 Passlock
2-26 New Vehicle ªBreak-Inº
2-27 Ignition Positions
2-28 Starting Your Engine
2-29 Engine Coolant Heater (If Equipped)
2-31 Automatic Transmission Operation
2-35 Parking Brake
2-36 Shifting Into PARK (P)
2-38 Shifting Out of PARK (P)
2-39 Parking Over Things That Burn
2-39 Engine Exhaust
2-40 Running Your Engine While You're Parked
2-41 Road Sensing Suspension
2-41 Locking Rear Axle2
-41 All-Wheel Drive
2-41 Horn
2-42 Tilt Wheel
2-42 Turn Signal/Multifunction Lever
2-49 Exterior Lamps
2-53 Interior Lamps
2-55 Mirrors
2-62 Storage Compartments
2-64 Cargo Cover Panels
2-81 Ashtray and Cigarette Lighter
2-82 Accessory Power Outlets
2-83 Analog Clock
2
-84 OnStar System (If Equipped)
2-87 Sunroof (If Equipped)
2
-88 Homelink Transmitter
2-92 The Instrument Panel - Your
Information System
2
-94 Instrument Panel Cluster
2-96 Warning Lights, Gages and Indicators
2-109 Message Center
2-117 Secondary Information Center (SIC)
2
-124 Ultrasonic Rear Parking Assist (URPA)
Page 92 of 427
2-26
Passlock
Your vehicle is equipped with the Passlock
theft
-deterrent system.
Passlock is a passive theft
-deterrent system. Passlock
enables fuel to the engine if the ignition lock cylinder
is turned with a valid key. If a correct key is not used
or the ignition lock cylinder is tampered with, fuel is
disabled.
If the engine stalls and the SECURITY message flashes,
wait until the light stops flashing before trying to restart
the engine. Remember to release the key from START
as soon as the engine starts.
If the engine is running and the SECURITY message
comes on, you will be able to restart the engine if you
turn the engine off. However, your Passlock system is
not working properly and must be serviced by your
dealer. Your vehicle is not protected by Passlock at this
time. You may also want to check the fuse (see ªFuses
and Circuit Breakersº in the Index). See your dealer
for service.
In an emergency, call the Cadillac Roadside Service
Center. See ªRoadside Serviceº in the Index.
New Vehicle ªBreak-Inº
NOTICE:
Your vehicle doesn't need an elaborate
ªbreak
-in.º But it will perform better in
the long run if you follow these guidelines:
Keep your speed at 55 mph (88 km/h) or
less for the first 500 miles (805 km).
Don't drive at any one speed
-- fast or
slow
-- for the first 500 miles (805 km).
Don't make full
-throttle starts.
Avoid making hard stops for the first
200 miles (322 km) or so. During this time
your new brake linings aren't yet broken
in. Hard stops with new linings can mean
premature wear and earlier replacement.
Follow this breaking
-in guideline every
time you get new brake linings.
Don't tow a trailer during break
-in.
See ªTowing a Trailerº in the Index for
more information.
Page 101 of 427
2-35
Parking Brake
To set the parking brake, hold the regular brake pedal
down with your right foot. Push down the parking brake
pedal with your left foot.
If the ignition is on, the brake system warning light will
flash. A chime will activate when the parking brake is
applied and the vehicle is moved at least 3 mph (5 km/h)
for at least three seconds.
To release the parking brake, hold the regular brake
pedal down. Pull the bottom edge of the lever, located
above the parking brake pedal, marked BRAKE
RELEASE, to release the parking brake.
If the ignition is on when the parking brake is released,
the brake system warning light will go off.
NOTICE:
Driving with the parking brake on can cause
your rear brakes to overheat. You may have to
replace them, and you could also damage other
parts of your vehicle.
If you are towing a trailer and are parking on any hill,
see ªTowing a Trailerº in the Index. That section shows
what to do first to keep the trailer from moving.
Page 114 of 427
2-48
Reducing Speed While Using Cruise Control
Press and hold the SET button at the end of the lever
until you reach the lower speed you want, then
release it.
To slow down in very small amounts, press the SET
button briefly. Each time you do this, you'll go about
1 mph (1.6 km/h) slower.
Passing Another Vehicle While Using Cruise Control
Use the accelerator pedal to increase your speed. When
you take your foot off the pedal, your vehicle will slow
down to the cruise control speed you set earlier.Using Cruise Control on Hills
How well your cruise control will work on hills depends
upon your speed, load and the steepness of the hills.
When going up steep hills, you may want to step on the
accelerator pedal to maintain your speed. When going
downhill, you may have to brake or shift to a lower gear
to keep your speed down. Of course, applying the brake
takes you out of cruise control. Many drivers find this to
be too much trouble and don't use cruise control on
steep hills.
Ending Cruise Control
There are two ways to turn off the cruise control:
Step lightly on the brake pedal.
Move the cruise control switch to OFF.
Erasing Speed Memory
When you turn off the cruise control or the ignition,
your cruise control set speed memory is erased.
Page 116 of 427
2-50
Automatic Headlamp System
When it is dark enough outside, your automatic
headlamp system will turn on your headlamps at the
normal brightness along with other lamps such as the
taillamps, sidemarker, parking lamps and the instrument
panel lights. The radio lights will also be dim.
Your vehicle is equipped with a light sensor on the top
of the instrument panel under the radio speaker grill.
Be sure it is not covered or the system will be on
whenever the ignition is on.
The system may also turn on your headlamps when
driving through a parking garage, heavy overcast
weather or a tunnel. This is normal.
There is a delay in the transition between the daytime
and nighttime operation of the Daytime Running Lamps
(DRL) and the automatic headlamp systems so that
driving under bridges or bright overhead street lights
does not affect the system. The DRL and automatic
headlamp system will only be affected when the light
sensor sees a change in lighting lasting longer than
the delay.
To idle your vehicle with the automatic headlamp
system off, set the parking brake while the ignition is
off. Then start your vehicle. The automatic headlamp
system will stay off until you release the parking brake.As with any vehicle, you should turn on the regular
headlamp system when you need it.
You may be able to turn off your automatic headlamp
system. See ªDaytime Running Lamps (DRL)º later in
this section for more information.
Lamps On Reminder
A reminder chime will sound when your headlamps or
parking lamps are manually turned on, the driver's
door is opened and your ignition is in OFF, LOCK or
ACCESSORY. To turn the chime off, turn the
exterior lamps control all the way to the left or turn the
instrument panel thumbwheel down to the fully dimmed
position. In the automatic mode, the headlamps turn off
once the ignition key is in OFF.
Puddle Lamps
Your vehicle is equipped with puddle lamps to help you
see the area near the base of the front doors when it is
dark out. The puddle lamps will illuminate when a door
is opened or when you press the UNLOCK button on the
keyless entry transmitter. The lamps will time out or
turn off once the engine is started.
You can program the puddle lamps not to come on if
you choose. See ªSecondary Information Centerº in the
Index for more information.
Page 117 of 427
2-51
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset. Fully
functional daytime running lamps are required on all
vehicles first sold in Canada.
The DRL system will come on when the following
conditions are met:
the ignition is on,
the exterior lamps control is in OFF,
the automatic transmission is not in PARK (P),
the light sensor determines it is daytime and
the parking brake is released.
When the DRL are on, only your DRL lamps will be on.
The taillamps, sidemarker and other lamps won't be on.
The instrument panel won't be lit up either.
When it begins to get dark, the automatic headlamp
system will switch from DRL to the headlamps or the
last chosen headlamp setting that was used.When you turn the exterior lamps control off, the
headlamps will go off, and your DRL lamps will
illuminate, provided it is not dark outside.
To idle your vehicle with the DRL off, set the parking
brake. Shifting the transmission into PARK (P) will also
allow you to idle the vehicle with the DRL off. The DRL
will stay off until you release the parking brake or shift
the transmission out of PARK (P).
The following procedure applies only to vehicles first
sold in the United States.
When necessary, you may turn off the automatic
headlamp system and the DRL feature by following
these steps:
1. Turn the ignition to RUN.
2. Press the DOME OVERRIDE button four times
within six seconds. After the fourth press of the
button, a chime will sound informing you the system
is off. The system will revert back to the automatic
mode when the ignition is turned off and on again.
3. To return to the automatic mode, push the DOME
OVERRIDE button four times within six seconds
(the chime will sound), or turn the ignition off and
on again.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
Page 165 of 427
2-99
Brake System Warning Light
With the ignition on, the brake system warning light
will flash when you set the parking brake. The light will
flash if the parking brake doesn't release fully. If you
try to drive with the parking brake engaged, a chime
will sound when the vehicle speed is greater than
3 mph (5 km/h).
Your vehicle's hydraulic brake system is divided into
two parts. If one part isn't working, the other part can
still work and stop you. For good braking, though,
you need both parts working well.
If the warning light comes on, there could be a brake
problem. Have your brake system inspected right away.
United States CanadaThis light should come on briefly when you turn the
ignition key to RUN. If it doesn't come on then,
have it fixed so it will be ready to warn you if there's
a problem.
If the light comes on while you are driving, pull off the
road and stop carefully. You may notice that the pedal is
harder to push. Or, the pedal may go closer to the floor.
It may take longer to stop. If the light is still on, have the
vehicle towed for service. See ªTowing Your Vehicleº in
the Index.
CAUTION:
Your brake system may not be working properly
if the brake system warning light is on. Driving
with the brake system warning light on can lead
to an accident. If the light is still on after you've
pulled off the road and stopped carefully, have
the vehicle towed for service.
Page 166 of 427
2-100
Anti-Lock Brake System Warning Light
With the anti-lock brake
system, this light will
come on when you start
your engine and may stay
on for several seconds.
That's normal.
If the light stays on, or comes on when you're driving,
your vehicle needs service. If the regular brake system
warning light isn't on, you still have brakes, but you
don't have anti
-lock brakes. If the regular brake system
warning light is also on, you don't have anti
-lock brakes
and there's a problem with your regular brakes. See
ªBrake System Warning Lightº earlier in this section.
The anti
-lock brake system warning light should come
on briefly when you turn the ignition key to RUN. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.
Engine Coolant Temperature Gage
United States Canada
This gage shows the engine coolant temperature.
It also provides an indicator of how hard your vehicle is
working. During a majority of the operation, the gage
will read 210F (100C) or less. If you are pulling a
load or going up hills, it is normal for the temperature to
fluctuate and approach the 250F (122C) mark. If the
gage reaches the 260F (125C) mark, it indicates that
the cooling system is working beyond its capacity.
See ªEngine Overheatingº in the Index.
Page 183 of 427
2-117
STABILITY SYSTEM DISABLED Message
The STABILITY SYSTEM
DISABLED message
indicates that the stability
enhancement system has
been temporarily disabled.
There are three conditions that can cause this message to
appear. One condition is overheating, which could
occur if the stability enhancement system activates
continuously for an extended period of time.
The STABILITY SYSTEM DISABLED message will
also be displayed if the brake system warning light is on.
See ªBrake System Warning Lightº in the Index.
Finally, the message could be displayed if the stability
system takes longer than usual to complete its diagnostic
checks due to driving conditions. The STABILITY
SYSTEM DISABLED message will turn off as soon as
the conditions that caused the message to be displayed
are no longer present. See ªStabilitrak Systemº in
the Index.
Secondary Information Center (SIC)
This section explains the features of your SIC.
The SIC provides instant information about fuel,
mileage and vehicle history in addition to allowing you
to personalize certain features of your vehicle. If you
would like to skip to the section on personalizing your
vehicle, see the section under MENU.
Page 192 of 427
2-126
If the URPA Display Flashes Red
If the URPA system is not functioning properly, the
display will flash red, indicating that there is a problem.
The light will also flash red while driving if any of the
following conditions exist:
A trailer or trailer
-hitch ball mount is attached to
your vehicle.
A bicycle or object is on the back of, or hanging out
the cargo area.
If the tailgate is lowered.
If your vehicle is moving in REVERSE (R) at a
speed greater than 3 mph (5 km/h).
The light will continue to flash until the trailer or the
object is removed or the tailgate raised and your vehicle
is driven forward at least 15 mph (25 km/h).It may also flash red if the ultrasonic sensors are not
kept clean.
So be sure to keep your rear bumper free of mud, dirt,
snow, ice and slush or materials such as paint or the
system may not work properly. If after cleaning the rear
bumper and driving forward at least 15 mph (25 km/h),
the display continues to flash red, see your dealer. For
cleaning instructions, see ªCleaning Your Vehicleº in
the Index.
Other conditions that may affect system performance
include things like the vibrations from a jackhammer or
the compression of air brakes on a very large truck.
As always, drivers should use care when backing up a
vehicle. Always look behind you, being sure to check
for other vehicles, obstructions and blind spots.
