Federal Communications Commission
(FCC) and Industry and Science
Canada
The Tire Pressure Monitor System (TPMS)
operates on a radio frequency and complies with
Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1. This device may not cause harmful
interference.
2. This device must accept any interference
received, including interference that may
cause undesired operation.
The Tire Pressure Monitor System (TPMS)
operates on a radio frequency and complies with
RSS-210 of Industry and Science Canada.
Operation is subject to the following two
conditions:
1. This device may not cause interference.
2. This device must accept any interference
received, including interference that may
cause undesired operation of the device.
Changes or modications to this system by other
than an authorized service facility could void
authorization to use this equipment.
Tire Inspection and Rotation
Tires should be rotated every 5,000 to 8,000 miles
(8 000 to 13 000 km).
Any time you notice unusual wear, rotate your
tires as soon as possible and check wheel
alignment. Also check for damaged tires or wheels.
SeeWhen It Is Time for New Tires on page 469
andWheel Replacement on page 474for
more information.
Make sure the spare tire is stored securely. Push,
pull, and then try to rotate or turn the tire. If it
moves, use the ratchet/wheel wrench to tighten the
cable. SeeChanging a Flat Tire on page 477.
The purpose of regular rotation is to achieve more
uniform wear for all tires on the vehicle. The
rst rotation is the most important. SeeScheduled
Maintenance on page 523.
467

When rotating your vehicle’s tires, always use the
correct rotation pattern shown here.
Do not include the spare tire in the tire rotation.
After the tires have been rotated, adjust the
front and rear ination pressures as shown on the
tire and loading information label. SeeLoading
Your Vehicle on page 372andInation - Tire
Pressure on page 460, for more information.
Vehicles that have the Tire Pressure Monitor
System (TPMS) will need to have the TPMS
sensors reset after a tire rotation. See “TPMS
Sensor Identication Codes” underTire Pressure
Monitor System on page 462.Make certain that all wheel nuts are properly
tightened. See “Wheel Nut Torque” under
Capacities and Specications on page 518.
{CAUTION:
Rust or dirt on a wheel, or on the parts to
which it is fastened, can make wheel nuts
become loose after a time. The wheel
could come off and cause an accident.
When you change a wheel, remove any
rust or dirt from places where the wheel
attaches to the vehicle. In an emergency,
you can use a cloth or a paper towel to do
this; but be sure to use a scraper or wire
brush later, if needed, to get all the rust or
dirt off. SeeChanging a Flat Tire on
page 477.
468

{CAUTION:
Rust or dirt on the wheel, or on the parts
to which it is fastened, can make the
wheel nuts become loose after a time. The
wheel could come off and cause an
accident. When you change a wheel,
remove any rust or dirt from the places
where the wheel attaches to the vehicle. In
an emergency, you can use a cloth or a
paper towel to do this; but be sure to use
a scraper or wire brush later, if needed, to
get all the rust or dirt off.
6. Remove any rust or
dirt from the wheel
bolts, mounting
surfaces, and spare
wheel.7. Install the spare tire.{CAUTION:
Never use oil or grease on studs or nuts.
If you do, the nuts might come loose.
Your wheel could fall off, causing a
serious accident.
8. Put the wheel nuts back on with the rounded
end of the nuts toward the wheel after
mounting the spare tire.
9. Tighten each wheel nut by hand. Then use
the wheel wrench to tighten the wheel nuts
until the wheel is held against the hub.
10. Turn the wheel wrench counterclockwise to
lower the vehicle. Lower the jack completely.
487

Scheduled Maintenance
When the CHANGE ENGINE OIL SOON message
comes on, it means that service is required for your
vehicle. Have your vehicle serviced as soon as
possible within the next 600 miles (1 000 km). It is
possible that, if you are driving under the best
conditions, the engine oil life system may not
indicate that vehicle service is necessary for over a
year. However, your engine oil and lter must be
changed at least once a year and at this time the
system must be reset. Your GM Goodwrench
®
dealer has GM-trained service technicians who will
perform this work using genuine GM parts and reset
the system.
If the engine oil life system is ever reset
accidentally, you must service your vehicle within
3,000 miles (5 000 km) since your last service.
Remember to reset the oil life system whenever
the oil is changed. SeeEngine Oil Life System on
page 410for information on the Engine Oil Life
System and resetting the system.When the CHANGE ENGINE OIL SOON message
appears, certain services, checks, and inspections
are required. Required services are described
in the following for “MaintenanceI” and
“MaintenanceII.” Generally, it is recommended
that your rst service be MaintenanceI, your
second service be MaintenanceII, and that you
alternate MaintenanceIand MaintenanceII
thereafter. However, in some cases,
MaintenanceIImay be required more often.
MaintenanceI— Use MaintenanceIif the
CHANGE ENGINE OIL SOON message comes on
within 10 months since the vehicle was purchased
or MaintenanceIIwas performed.
MaintenanceII— Use MaintenanceIIif the
previous service performed was MaintenanceI.
Always use MaintenanceIIwhenever the message
comes on 10 months or more since the last
service or if the message has not come on at all
for one year.
523

Flat Tire Change (Covers change only):
Installation of your spare tire, in good
condition, will be covered at no charge.
The customer is responsible for the repair or
replacement of the tire if not covered by a
warrantable failure.
Trip Interruption:If your trip is interrupted
due to a warranty failure, incidental
expenses may be reimbursed during the
48 months/50,000 miles (80 000 km) warranty
period. Items covered are hotel, meals,
and rental car.
Additional Services for Canadian
Customers
Trip Routing Service:Upon request, Cadillac
Roadside Service will send you detailed,
computer-personalized maps, highlighting your
choice of either the most direct route or the
most scenic route to your destination,
anywhere in North America, along with any
helpful travel information we may have
pertaining to your trip. To request this service,
please call us toll-free at 1-800-268-6800.
We will make every attempt to send your
personalized trip routing as quickly as possible,
but it is best to allow three weeks before your
planned departure date. Trip routing requests
will be limited to six per calendar year.
Alternative Service:There may be times
when Roadside Service cannot provide timely
assistance. Your advisor may authorize you to
secure local emergency road service, and you
will be reimbursed up to $100 upon submission
of the original receipt to Cadillac Roadside
Service
®.
550

Roadside Service Availability
Wherever you drive in the United States or
Canada, an advisor is available to assist you over
the phone. A dealer technician, if available, can
travel to your location within a 30 mile (50 km)
radius of a participating Cadillac dealership.
If beyond this radius, we will arrange to have your
car towed to the nearest Cadillac dealership.
For prompt and efficient assistance when calling,
please provide the following to the Roadside
Service Representative:
A description of the problem
Name, home address, home telephone
number
Location of your Cadillac and number you are
calling from
The model year, Vehicle Identication Number
(VIN), odometer reading, and date of deliveryWhile we hope you never have the occasion to
use our service, it is added security while traveling
for you and your family. Remember, we are
only a phone call away. In the United States or
Canada, customers call Roadside Service:
1-800-882-1112. Any customer who has access to
a (TTY) or a conventional teletypewriter can
communicate with Cadillac by dialing from the
United States or Canada1-888-889-2438— daily,
24 hours.
Cadillac and General Motors of Canada Limited
reserve the right to limit services or reimbursement
to an owner or driver when, in their sole discretion,
the claims become excessive in frequency or type
of occurrence.
Roadside Service is not part of or included in the
coverage provided by the New Vehicle Limited
Warranty. Cadillac and General Motors of Canada
Limited reserve the right to make any changes
or discontinue the Roadside Service program
at any time without notication.
551

Courtesy Rental Vehicle
Your dealer may arrange to provide you with a
courtesy rental vehicle or reimburse you for
a rental vehicle that you obtain if your vehicle is
kept for a warranty repair. Taxi reimbursement
may also be available if you meet the eligibility for
a courtesy rental and a rental vehicle is not
practical for your requirements. Rental and taxi
reimbursement will be limited (contact your dealer)
and must be supported by original receipts. This
requires that you sign and complete a rental
agreement and meet state/provincial, local and
rental vehicle provider requirements. Requirements
vary and may include minimum age requirements,
insurance coverage, credit card, etc. You are
responsible for fuel usage charges and may also
be responsible for taxes, levies, usage fees,
excessive mileage or rental usage beyond the
completion of the repair.
Generally it is not possible to provide a like-vehicle
as a courtesy rental.
Additional Program Information
All program options, such as shuttle service, may
not be available at every dealer. Please contact
your dealer for specic information about
availability. All Courtesy Transportation
arrangements will be administered by appropriate
dealer personnel.
Cadillac and General Motors of Canada reserve
the right to unilaterally modify, change or
discontinue Courtesy Transportation at any time
and to resolve all questions of claim eligibility
pursuant to the terms and conditions described
herein at their sole discretion.
554

Owner Information
Owner publications are written specically for
owners and intended to provide basic operational
information about the vehicle. The owner
manual will include the Maintenance Schedule for
all models.
In-Portfolio: Includes a Portfolio, Owner Manual,
and Warranty Booklet.
RETAIL SELL PRICE: $35.00 US +
Processing Fee
Without Portfolio: Owner Manual only.
RETAIL SELL PRICE: $25.00 US +
Processing Fee
Current and Past Model Order Forms
Technical Service Bulletins and Manuals are
available for current and past model GM vehicles.
To request an order form, please specify year
and model name of the vehicle.
ORDER TOLL FREE: 1-800-551-4123
Monday-Friday 8:00 AM - 6:00 PM
Eastern Time
For Credit Card Orders Only
(VISA-MasterCard-Discover), visit Helm, Inc. on
the World Wide Web at: www.helminc.com
Or you can write to:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
Prices are subject to change without notice and
without incurring obligation. Allow ample time
for delivery.
Note to Canadian Customers: All listed prices are
quoted in U.S. funds. Canadian residents are
to make checks payable in U.S. funds.
563

H
Hazard Warning Flashers............................ 194
Head Restraints............................................ 15
Headlamp
Aiming..................................................... 447
Headlamps
Automatic Headlamp System.................... 210
Bulb Replacement.................................... 450
Daytime Running Lamps.......................... 209
Flash-to-Pass........................................... 198
High Intensity Discharge (HID) Lighting.... 450
High/Low Beam Changer......................... 197
On Reminder........................................... 209
Heated Seats......................................... 10, 11
Heated Steering Wheel............................... 195
Heater......................................................... 219
Highbeam On Light..................................... 241
High-Speed Operation, Tires........................ 462
Highway Hypnosis....................................... 363
Hill and Mountain Roads............................. 364
Hood
Checking Things Under............................ 404
Release................................................... 405Horn............................................................ 194
How to Use This Manual ................................ 4
How to Wear Safety Belts Properly............... 23
I
Ignition Positions......................................... 124
Infants and Young Children, Restraints .......... 42
Ination - Tire Pressure............................... 460
Instrument Panel
Overview.................................................. 192
Storage Area............................................ 166
Instrument Panel (I/P)
Brightness................................................ 211
Cluster..................................................... 226
J
Jump Starting.............................................. 438
K
Keyless Entry System................................... 92
Keys............................................................. 91
571

Security Light.............................................. 240
Service........................................................ 396
Accessories and Modications.................. 397
Adding Equipment to the Outside of
Your Vehicle......................................... 399
California Proposition 65 Warning............. 397
Doing Your Own Work............................. 398
Engine Soon Light................................... 236
Publications Ordering Information............. 562
Servicing Your Airbag-Equipped Vehicle......... 84
Setting the Time.......................................... 269
Sheet Metal Damage................................... 505
Shifting Into Park (P)................................... 138
Shifting Out of Park (P)............................... 140
Shoulder Belt Height Adjuster........................ 30
Signals, Turn and Lane-Change.................. 196
Spare Tire................................................... 495
Installing.................................................. 482
Removing................................................ 478
Storing..................................................... 492Specications, Capacities............................ 518
Speedometer............................................... 227
StabiliTrak
®System..................................... 330
StabiliTrak®Indicator Light........................... 235
Starting Your Engine................................... 126
Steering...................................................... 333
Steering Wheel Controls, Audio................... 316
Steering Wheel, Heated .............................. 195
Steering Wheel, Tilt Wheel.......................... 195
Storage Areas
All-Weather Cargo Area........................... 181
Center Console Storage Area................... 166
Cupholder(s)............................................ 166
Glove Box................................................ 165
Instrument Panel Storage Area................. 166
Luggage Carrier....................................... 166
Rear Seat Armrest................................... 168
Top-Box Storage...................................... 186
Stuck in Sand, Mud, Ice, or Snow............... 370
Sun Visors.................................................. 117
Sunroof....................................................... 187
577
