5. After entering all of the switch positions, again,
rmly press and release all three buttons at the
same time. The indicator lights will turn on.
6. Press and hold the button that will be used to
control the garage door until the garage door
moves. The indicator light above the selected button
should slowly blink. This button may need to be
held for up to 55 seconds.
7. Immediately release the button when the garage
door moves. The indicator light will blink rapidly
until programming is complete.
8. Press and release the same button again. The
garage door should move, conrming that
programming is successful and complete.
To program another Fixed Code device such as an
additional garage door opener, a security device,
or home automation device, repeat Steps 1-8, choosing
a different button in Step 6 than what was used for
the garage door opener.
Using Universal Home Remote
Press and hold the appropriate button for at least half of
a second. The indicator light will come on while the
signal is being transmitted.
Reprogramming Universal Home
Remote Buttons
Any of the three buttons can be reprogrammed by
repeating the instructions.
Erasing Universal Home Remote
Buttons
The programmed buttons should be erased when the
vehicle is sold or the lease ends.
To erase either Rolling Code or Fixed Code on the
Universal Home Remote device:
1. Press and hold the two outside buttons at the same
time for approximately 20 seconds, until the
indicator lights, located directly above the buttons,
begin to blink rapidly.
2. Once the indicator lights begin to blink, release both
buttons. The codes from all buttons will be erased.
For help or information on the Universal Home Remote
System, call the customer assistance phone number
underCustomer Assistance Offices on page 8-5.
2-65

Storage Areas
Glove Box
Lift up on the glove box lever to open it.
Cupholders
Cupholders are located in the center console for the
front passengers and on the back of the center console
for the rear passengers.
Press down and release the access door to use the
front cupholders. Push the door back down to close it.
Pull down on the door located on the back of the
console to use the rear cupholders.
Push down and then back to remove the front cupholder
to remove it for cleaning.
Instrument Panel Storage
For vehicles with a front closed storage area, located on
the instrument panel above the compact disc changer,
open it by pressing the bottom of the lid. Press down on
the lid to close the storage area.
Center Console Storage
The vehicle has a console compartment between the
bucket seats. The console has both an upper and lower
storage bin that can be opened by lifting up on the
latches located at the front of the console lids. An
accessory power outlet may be located inside the
console, seeAccessory Power Outlet(s) on page 3-20.
The rear of the console also has a cupholder that
swings down for the rear seat passengers to use.
Luggage Carrier
For vehicles with a luggage carrier, it can be used to
load things on top of the vehicle.
The luggage carrier has siderails attached to the roof. It
might also have crossrails which can be moved back
and forth to help secure cargo. Tie and secure the load
to the siderails or siderail supports.
Notice:Loading cargo on the luggage carrier that
weighs more than 200 lbs (91 kg) or hangs over
the rear or sides of the vehicle can damage
the vehicle. Load cargo so that it rests on the slats
as far forward as possible and against the side
rails, making sure to fasten it securely.
2-66

Do not exceed the maximum vehicle capacity when
loading the vehicle. For more information on vehicle
capacity and loading, seeLoading the Vehicle on
page 5-31.
Be sure the cargo is properly loaded.
If small heavy objects are placed on the roof, cut a
piece of 3/8 inch plywood to t inside the crossrails
and siderails to spread the load. Tie the plywood
to the siderail supports.
Tie the load and secure it to the crossrails or the
siderail supports. Use the crossrails only to keep
the load from sliding. To move a crossrail, turn
the release knobs, on both sides of the rail,
counterclockwise to loosen it. Slide the crossrail to
the desired position balancing the force side to
side. Turn the release knobs, on both sides of the
rail, clockwise to tighten it. Try to slide the crossrail
back and forth slightly to be sure it is tight.
To carry long items, move the crossrails as far
apart as possible. Tie the load to the crossrails and
the siderails or siderail supports. Also tie the
load to the bumpers, but do not tie the load so
tightly that the crossrails or siderails are damaged.
After moving a crossrail, make sure it is securely
locked into the siderail.
A Center High-Mounted Stoplamp (CHMSL) is located
above the rear glass. When loading items on the
roof, take care not to block or damage the CHMSL.
To prevent damage or loss of cargo while driving, check
periodically to make sure the luggage and cargo is
still securely fastened.
Rear Seat Armrest
For vehicle with an armrest/storage compartment
located by the second row seat, pull the loop at the top
of the armrest out to lower the armrest.
Push the button on the front of the armrest and pull the
top up to open the compartment.
2-67

Cargo Cover Panels
The vehicle has a three-piece cargo cover system with
cargo panels that can be removed and stored in the
cargo area of the vehicle.
{CAUTION:
Improperly stored cargo cover panels could be
thrown about the vehicle during a collision or
sudden maneuver. Someone could be injured. If a
panel is removed, always store it in the proper
storage location. When putting it back, always
make sure that it is securely reattached.
Notice:Exceeding the weight limit of 250 lbs
(113 kg) can damage the cargo covers, and the
repairs would not be covered by the vehicle
warranty. Do not put anything on top of the cargo
covers over the weight limit.
To remove a cargo panel(s):
1. Lower the tailgate. SeeTailgate on page 2-21for
more information on the tailgate.The panels are embossed on the upper center
portion with the numbers 1, 2 and 3. There are also
numbered labels on the bottom of the panels.
The numbers on the top and bottom of the panels
will be used as reference when removing, storing
and reinstalling the panels.
2-68

2. Unlock the cargo panel 3 by pulling forward on the
driver side and passenger side cargo panel latches,
located on the bottom of each cargo panel.
3. Remove cargo panel 2 in the same way and set it
aside. Remove as many cargo panels as needed.
4. To remove cargo panel 1, unlock the two rear
latches, lift the cover slightly and pull rearward.
After each cargo panel is removed, store them within
the cargo storage area using the cargo panel storage
system.
Cargo Panel Storage System
The three cargo panels can be stored in the cargo area
using the storage strap system. Always use the
storage strap system to store the cargo panels while
driving.
2-69

To store the panels:
1. Secure the storage
strap system in the
cargo storage area by
attaching the six clips
on the cargo strap
system to the tie down
locations on either side
of the storage area.
Before storing the cargo panels, make sure that
their latches are in the locked position. The latches
are in the locked position when they are parallel
to the front and back edge of the panel.Use the following instructions for the proper storage
sequence and location for each panel:
A. Secure clip A on the secondary strap.
B. Secure clip B on the secondary strap.
C. Place the remaining primary straps on top of the
lid and tray at the top of the cargo area.
2-70

2. Starting with cargo panel 1, load the cargo panel
with the latches facing up toward the side of the
cargo box.
Do the same for cargo panel 2 then 3. Make sure to
store panel 2 with the latches facing down and
panel 3 with latches facing up toward the side of the
cargo box.3. Place the primary straps over the three cargo
covers (A). Fasten the four strap clips (B).
2-71

4. Tighten all straps by pulling on the free end of
each strap.5. Close both cross locks at the center of the strap
system to secure tightly.
2-72

Reinstalling the Cargo Cover Panels
The strap system can remain attached to the side of the
cargo area while it is not in use, or it can be stored
inside the top box storage compartment. SeeTop-Box
Storage on page 2-81for more information.
To reinstall a cargo panel:
1. Starting with cargo panel 1, place the latches in the
unlocked position. Place cargo panel 1 on the cargo
area rails while holding the back of the cargo
panel up. Panels 3, 2, 1 Loaded
2-73

Place the cover on the cargo box within 4 inches of
the Midgate®and lower the rear of the panel
within 2 to 3 inches from the top of the cargo box.
Push the cover forward making sure that the
guide block engages the retainer bracket opening.
Continue to push forward until the panel is fully
seated against the Midgate. Then lower the rear of
the cover to engage the striker pegs (A) to align
with the striker assembly (B).2. The driver side cargo cover panel latch must lock in
place before the passenger side latch can be
locked. If this procedure is not followed exactly, the
cargo cover panels might not correctly lock in
place. Push the driver side latch toward the front of
the vehicle to lock the cover in position. A click
sounds when each latch locks. Lock the remaining
passenger side latch on panel 1. Driver Side Shown, Passenger Side Similar
2-74
