Driving and Operating 295
When electrical grid power is
completely blocked, the
vehicle will not charge until the
utility interruption has expired.
The vehicle should be left
plugged in so that the vehicle
will automatically resume
charging.
Changing the charge mode to
Charge Now or performing a
delayed charging override will
not disable a utility
interruption.
A message will display on the
instrument cluster indicating
that a utility interruption has
occurred.
Electrical
Requirements for
Battery Charging
This vehicle is compatible with
most vehicle charging
equipment that complies with
one or more of the following
standards:
.SAE J1772
.SAE J2847-2
.IEC 61851-1
.IEC 61851-22
.IEC 61851-23
.IEC 61851-24
.IEC 62196-1
.IEC 62196-2
.IEC 62196-3
The portable charge cord
requires a circuit capacity as
follows:
Minimum : 120 volt system –
15 amps
Maximum : 240 volt system –
50 amps
Caution
Do not use portable or
stationary backup
generating equipment to
charge the vehicle. This may
cause damage to the
vehicle's charging system.
Only charge the vehicle from
utility supplied power.
Trailer Towing
General Towing
Information
Only use towing equipment
that has been designed for the
vehicle. Contact your dealer or
trailering dealer for assistance
with preparing the vehicle to
tow a trailer. Read the entire
section before towing a trailer.
To tow a disabled vehicle, see
Transporting a Disabled
Vehicle 0359. To tow the
vehicle behind another vehicle
such as a motor home, see
Recreational Vehicle Towing
0 362.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Vehicle Care 311
2. Release the handle, thenpull the handle again to fully
open the hood.
3. Go to the front of the vehicle and lift the
hood open. To close the hood:
1. Be sure all filler caps are on properly, and all tools are
removed.
2. Lower the hood down until the strut system is no
longer holding up the hood.
3. Allow the hood to fall. Check to make sure the hood is
latched completely. Repeat
this process with additional
force if necessary.
4. If the hood does not latch, a message will display on the
Driver Information Center
(DIC) indicating the vehicle
will not shift out of (P) Park.
To override this function,
press and hold the brake
pedal until override
completion message is
displayed on DIC.
{Warning
Do not drive the vehicle if
the hood is not latched
completely. The hood could
open fully, block your vision,
and cause a crash. You or
others could be injured.
Always close the hood
completely before driving.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
314 Vehicle Care
4. After the system hascompletely cooled, check
that the coolant level in the
reservoir.
5. If the coolant level is notvisible or needs to be
adjusted within the
reservoir, contact your
dealer.
Washer Fluid
What to Use
When windshield washer fluid
is needed, be sure to read the
manufacturer's instructions
before use. If operating the
vehicle in an area where the
temperature may fall below
freezing, use a fluid that has
sufficient protection against
freezing.
Adding Washer Fluid
If the vehicle is equipped with
a washer fluid level indicator,
and the washer fluid reservoir
is low, a message displays on
the Driver Information Center
(DIC). See Driver Information
Center (DIC) 0132 for more
information.
Open the cap with the washer
symbol on it. Add washer fluid
until the tank is full. See
Underhood Compartment
Overview 0312 for reservoir
location.
Caution
.Do not use washer fluid
that contains any type of
water repellent coating.
This can cause the wiper
blades to chatter or skip.
.Do not use engine coolant
(antifreeze) in the
windshield washer. It can
damage the windshield
washer system and paint.
.Do not mix water with
ready-to-use washer fluid.
Water can cause the
solution to freeze and
(Continued)

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
318 Vehicle Care
Warning (Continued)
whether an inspection is
needed. See Customer
Assistance Offices0386.
If the vehicle is in a crash, the
sensing system may shut
down the high voltage system.
When this occurs, the high
voltage battery is
disconnected and the vehicle
will not start. The SERVICE
VEHICLE SOON message in
the Driver Information Center
(DIC) will display. Before the
vehicle can operate again, it
must be serviced at your
dealer. If a crash occurs or an
airbag(s) inflates, see “If a
Crash Occurs” under Collision
Damage Repair 0392 and
What Will You See after an
Airbag Inflates? 065 for
additional information.
Keep the vehicle plugged in,
even when fully charged, to
keep the high voltage battery
temperature ready for the next drive. This is important
when outside temperatures
are extremely hot or cold.
Propulsion power may be
reduced in extremely cold
temperatures, or if the high
voltage battery is too cold.
The message BATTERY TOO
COLD, PLUG IN TO WARM will
display. If the message
displays, a level 2 charger is
required to heat the battery to
a minimum temperature to
enable propulsion or charging.
A vehicle cover, which can
reduce sun loading on the
vehicle and improve high
voltage battery life, is available
from your dealer.
See Radio Frequency
Statement
0395.
Federal Communications
Commission (FCC) Radiation
Exposure Statement
This equipment has been
evaluated to be installed and
operated at a minimum
distance of 5.7 cm (2.2 in) between the device and your
body. The vehicle design
ensures this distance is
maintained during normal use.
Changes or modifications to
any of these systems by other
than an authorized service
facility could void
authorization to use this
equipment.
Innovation, Science, and
Economic Development
(ISED) Radiation Exposure
Statement
This equipment complies with
RSS-102 radiation exposure
limits set forth for an
uncontrolled environment. This
equipment should be installed
and operated with a minimum
distance of 5.7 cm (2.2 in)
between the radiator and any
part of your body. The vehicle
design ensures this distance is
maintained during normal use.
Changes or modifications to
any of these systems by other
than an authorized service

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Vehicle Care 321
To replace the windshield
wiper blade:1. Pull the windshield wiper assembly away from the
windshield.
2. Press the button in themiddle of the wiper arm
connector, and pull the
wiper blade away from the
arm connector.
3. Remove the wiper blade.
4. Reverse Steps 1–3 for wiper blade replacement.
Windshield
Replacement
Driver Assistance
Systems
If the windshield needs to be
replaced and the vehicle is
equipped with a front camera
sensor for the Driver
Assistance Systems, a GM
replacement windshield is
recommended. The
replacement windshield must
be installed according to GM
specifications for proper
alignment. If it is not, error
messages may display,
or these systems may not
work properly or at all. See
your dealer for proper
windshield replacement.
Acoustic and Heated
Wiper Park (HWP)
Windshield
The vehicle is equipped with
an acoustic and HWP
windshield. If the windshield
needs replacement, make sure to use a GM compatible
acoustic and HWP windshield
to retain its features
Gas Strut(s)
Your vehicle may be equipped
with gas strut(s) to provide
assistance in lifting and
holding open the hood/trunk/
liftgate system in full open
position.
{Warning
If the gas struts that hold
open the hood, trunk, and/or
liftgate fail, you or others
could be seriously injured.
Take the vehicle to your
dealer for service
immediately. Visually inspect
the gas struts for signs of
wear, cracks, or other
damage periodically. Check
to make sure the hood/
trunk/liftgate is held open
with enough force. If struts
are failing to hold the hood/
(Continued)

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
332 Vehicle Care
Fuses UsageF1 –
F2 APO/CIGAR LTR –
Auxiliary Power
Outlet Instrument
Panel/Cigar
Lighter
F3 –
F4 USB PORT/APO AC 150W –
Universal Serial
Bus Port/Auxiliary
Power Outlet
Alternating
Current 150W
F5 STRG COL LOCK –RUN/CRANK
Steering
Column Lock
F6 ELM 1– Exterior
Lighting Module 1
F7 AMP-BASE –
Amplifier-Base
F8 RT DR LATCH –
Right Door Latch Fuses Usage
F9 LT DR LATCH –
Left Door Latch
F10 STRG COL POS MDL–Steering
Column Position
Module
F11 ACP 4 –ADAS
Compute
Platform 4
F12 –
F13 EUROPE-TRLR CON & ECP_E/
ECP_S/VICM –
RUN/CRANK
Europe –Trailer
Control and Elec-
trification Control
Processor
(Traction Power
Inverter 1 and 2)/
Vehicle Integration
Control Module
F14 HEADLAMPS –
RUN/CRANK
Headlamps Fuses Usage
F15 HDLP RT –
Headlamp Right
F16 STRG COL/ CLOCK SPRING –
Steering Column
Lock/Clock Spring
F17 SEAT FAN PASS & SEAT FAN
DRVR–RUN/
CRANK Seat Fan
Passenger and
Seat Fan Driver
F18 VCD & SRR –
Virtual Cockpit
Display and Short
Range Radar

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Vehicle Care 333
Fuses UsageF19 MISC 2 & MISC 1 –
RUN/CRANK
Miscellaneous 2
Switch Bank/
Electronic Toll
Collection/Interior
Particulate Matter
Sensor/Reflective
Light Auxiliary
Display and
Miscellaneous 1
Electronic Brake
Control Module/
Exterior Lighting
Module/Sensing
and Diagnostic
Module/Inside
Rear View Mirror
F20 BCM 1 & VICM –
Body Control
Module 1 and
Vehicle Integration
Control Module Fuses Usage
F21 LRR-RR & EPBS/ ESM–Long
Range Radar –
Rear and Electric
Park Brake
Switch/Electronic
Transmission
Range Select
Shifter Module
F22 VKM/VKBM/AUX JACK & ACP3 –
Virtual Key
Module/Virtual
Key Backup
Module/
Auxiliary Jack
F23 T/LAMP RT & T/ LAMP LT –Tail
Lamp Right and
Tail Lamp Left Fuses Usage
F24 UPA/APA/SBZA & SDM/AOS –
Universal Park
Assist/Automatic
Park Assist/Side
Blind Zone Alert
and Sensing
Diagnostic
Module/Automatic
Occupant Sensing
Module
F25 ACP 2/EOCM_LC/ FCM/MFC & DMS/
CGM/DLC/VDM –
ADAS Compute
Platform 2/
External Object
Calculating
Module/Front
Camera Module/
Multi Function
Control and Driver
Monitoring
System/Central
Gateway Module/
Diagnostic Link
Connector/Vehicle
Data Monitor

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
334 Vehicle Care
Fuses UsageF26 ECP_E_BATT 2/ ACEC & HUD/
HVAC DISPLAY –
Electrification
Control Processor
Battery 2/Air
Condition Electric
Compressor and
Heads-Up Display/
Heating,
Ventilation and Air
Conditioning
Display
F27 BCM 3 –Body
Control Module 3
F28 BCM 2 –Body
Control Module 2
F29 AMP-UPLEVEL –
Amplifier-Uplevel
F30 BCM 4 –Body
Control Module 4 Fuses Usage
F31 VPM/SD CARD/ ILSS/OHC –Video
Processing
Module/SD Card/
Indicator Light and
Solar Sensor/Over
Head Console
F32 HSWM –Heated
Steering Wheel
Module
F33 LRR FR/LIDAR –
Long Range Radar
Front/Light
Detection and
Ranging
F34 ELM 2 –Exterior
Lighting Module 2
F35 HDLP LT –
Headlamp Left
F36 VCU BATT 1 –
Virtual Cockpit
Unit Battery 1
F37 TCP (OnStar) –
Telematics
Communication
Platform Fuses Usage
F38 WCM –Wireless
Charger Module
F39 HI VOLTAGE SYS LCKOUT –High
Voltage System
Lockout
F40 VCU Batt 2 –
Virtual Cockpit
Unit Battery 2
F41 ELM 6 –Exterior
Lighting Module 6
F42 –
Wheels and Tires
Tires
Every new GM vehicle has
high-quality tires made by a
leading tire manufacturer.
See the warranty manual
for information regarding
the tire warranty and
where to get service. For
additional information refer
to the tire manufacturer.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
344 Vehicle Care
maintain correct tire pressure,
even if under-inflation has not
reached the level to trigger
illumination of the TPMS low
tire pressure telltale.
Your vehicle has also been
equipped with a TPMS
malfunction indicator to
indicate when the system is
not operating properly. The
TPMS malfunction indicator is
combined with the low tire
pressure telltale. When the
system detects a malfunction,
the telltale will flash for
approximately one minute and
then remain continuously
illuminated. This sequence will
continue upon subsequent
vehicle start-ups as long as
the malfunction exists.
When the malfunction
indicator is illuminated, the
system may not be able to
detect or signal low tire
pressure as intended. TPMS
malfunctions may occur for a
variety of reasons, including
the installation of replacementor alternate tires or wheels on
the vehicle that prevent the
TPMS from functioning
properly. Always check the
TPMS malfunction telltale
after replacing one or more
tires or wheels on your vehicle
to ensure that the
replacement or alternate tires
and wheels allow the TPMS to
continue to function properly.
See Tire Pressure Monitor
Operation
0344.
See Radio Frequency
Statement 0395.
Tire Pressure Monitor
Operation
This vehicle may have a Tire
Pressure Monitor System
(TPMS). The TPMS is designed
to warn the driver when a low
tire pressure condition exists.
TPMS sensors are mounted
onto each tire and wheel
assembly, excluding the spare
tire and wheel assembly. The
TPMS sensors monitor the air
pressure in the tires and transmit the tire pressure
readings to a receiver located
in the vehicle.
When a low tire pressure
condition is detected, the
TPMS illuminates the low tire
pressure warning light located
on the instrument cluster.
If the warning light comes on,
stop as soon as possible and
inflate the tires to the
recommended pressure
shown on the Tire and
Loading Information label. See
Vehicle Load Limits
0202.
A message to check the
pressure in a specific tire
displays in the Driver
Information Center (DIC). The
low tire pressure warning light
and the DIC warning message
come on each time the vehicle
is turned on until the tires are

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Vehicle Care 345
inflated to the correct inflation
pressure. If the vehicle has
DIC buttons, tire pressure
levels can be viewed. For
additional information and
details about the DIC
operation and displays, see
Driver Information Center
(DIC)0132.
The low tire pressure warning
light may come on in cool
weather when the vehicle is
first started, and then turn off
as the vehicle is driven. This
could be an early indicator
that the air pressure is getting
low and needs to be inflated to
the proper pressure.
A Tire and Loading
Information label shows the
size of the original equipment
tires and the correct inflation
pressure for the tires when
they are cold. See Vehicle
Load Limits 0202, for an
example of the Tire and
Loading Information label and
its location. Also see Tire
Pressure 0342. The TPMS can warn about a
low tire pressure condition but
it does not replace normal tire
maintenance. See Tire
Inspection
0347, Tire Rotation
0 348, and Tires 0334.
Caution
Tire sealant materials are
not all the same.
A non-approved tire sealant
could damage the TPMS
sensors. TPMS sensor
damage caused by using an
incorrect tire sealant is not
covered by the vehicle
warranty. Always use only
the GM approved tire
sealant available through
your dealer or included in
the vehicle.
TPMS Malfunction Light
and Message
The TPMS will not function
properly if one or more of the
TPMS sensors are missing or
inoperable. When the system
detects a malfunction, the low tire pressure warning light
flashes for about one minute
and then stays on for the
remainder of the time the
vehicle is on. A DIC warning
message also displays. The
malfunction light and DIC
warning message will come on
each time the vehicle is turned
on until the problem is
corrected. Some of the
conditions that can cause
these to come on are:
.One of the road tires has
been replaced with the
spare tire. The spare tire
does not have a TPMS
sensor. The malfunction light
and the DIC message should
go off after the road tire is
replaced and the sensor
matching process is
performed successfully. See
"TPMS Sensor Matching
Process" later in this section.
.The TPMS sensor matching
process was not done or not
completed successfully after
rotating the tires. The
malfunction light and the DIC
