To increase or decrease support, hold the control
forward or rearward. Keep in mind that as your
seating position changes, as it may during
long trips, so should the position of your lumbar
support. Adjust the seat as needed.
Heated Seats
Your vehicle may have
heated front seats. The
controls are located
on the driver’s and
passenger’s doors,
near the door handle.
I(Heated Seatback):Press this button to turn
on the heated seatback.The light on the button will come on to indicate
that the feature is working. Press the button
to cycle through the temperature settings of high,
medium, and low and to turn the heat to the
seatback off. Indicator lights next to the button
show the level of heat selected: three for high,
two for medium, and one for low.
J(Heated Seat and Seatback):Press this
button to turn on the heated seat and seatback.
The light on the button will come on to indicate that
the feature is working. Press the button to cycle
through the temperature settings of high, medium,
and low and to turn the heat to the seat off.
Indicator lights next to the button will show the
level of heat selected: three for high, two for
medium, and one for low.
The heated seats will be canceled ten seconds
after the ignition is turned off. If you want to
use the heated seat feature after you restart your
vehicle, you will need to press the appropriate
heated seat or seatback button again.
11

Memory Seat and Mirrors
If your vehicle has the memory feature, you can
program and recall memory settings for the driver’s
seating and outside rearview mirror driving
positions for up to two drivers. If your vehicle has
the adjustable throttle and brake pedal feature,
you can also program and recall memory settings
for the throttle and brake pedal driving positions.
The buttons for this feature are located on the
driver’s door armrest.
Use the following steps to program the buttons:
1. Adjust the driver’s seat including the seatback
recliner, both outside mirrors, and the throttle
and brake pedals. SeeOutside Power
Heated Mirrors on page 137andAdjustable
Throttle and Brake Pedal on page 120
for more information.2. Press and hold button 1 for at least
three seconds.
Two beeps will sound to conrm that the seat
and mirror positions have been saved.
3. Repeat the procedure for a second driver
using button 2.
The vehicle must be in PARK (P) to recall the
stored driving positions.
Press one of the numbered memory buttons to
recall the stored setting. Each time a memory
button is pressed, a single beep will sound.
A chime will sound and the setting will not be
recalled if you press button 1 or 2 when the vehicle
is not in PARK (P).
If you would like the stored driving positions to be
recalled when unlocking your vehicle with the
remote keyless entry transmitter or when you place
the key in the ignition, seeDIC Vehicle
Customization on page 231.
To stop recall movement of the memory feature at
any time, press one of the power seat or mirror
controls.
12

Two personalized exit positions can also be
programmed. Use the following steps to program
exit positions:
1. Press memory seat button 1 or the button with
the unlock symbol on the remote keyless
entry transmitter with the number 1 on
the back to recall the driving position.
2. Adjust the driver’s seat to the desired exit
position.
3. Press and hold the exit button located above
buttons 1 and 2 on the driver’s door armrest
for at least three seconds.
Two beeps will sound to conrm that the exit
position has been saved.
4. Repeat the procedure for a second driver
using memory seat button 2 or the remote
keyless entry transmitter with the number 2 on
the back.To recall the stored exit positions, press and
release the exit button. One beep will sound, and
the seat will move to the previously stored exit
position for the currently identied driver. If an exit
position has not been stored for this driver, the
seat will move all the way back. The position of the
outside mirrors is not stored or recalled for the
exit position.
The vehicle must be in PARK (P) to recall the exit
positions.
A chime will sound and the exit setting will not be
recalled if you press the exit button when the
vehicle is not in PARK (P).
If you would like your stored exit position to be
recalled when unlocking the vehicle with the
remote keyless entry transmitter or when the
ignition is turned off and the driver’s door is
opened, seeDIC Vehicle Customization on
page 231.
13

Reclining Seatbacks
Manual Reclining Seatbacks
{CAUTION:
You can lose control of the vehicle if you
try to adjust a manual driver’s seat while
the vehicle is moving. The sudden
movement could startle and confuse you,
or make you push a pedal when you do
not want to. Adjust the driver’s seat only
when the vehicle is not moving.
{CAUTION:
If the seatback is not locked, it could
move forward in a sudden stop or crash.
That could cause injury to the person
sitting there. Always push and pull on
the seatback to be sure it is locked.If your front passenger’s seat has a manual
reclining seatback, the lever used to operate it is
located on the outboard side of the seat.
To recline the seatback, do the following:
1. Lift the recline lever.
2. Move the seatback to the desired position,
then release the lever to lock the seatback
in place.
3. Push and pull on the seatback to make sure it
is locked.
14

To return the seatback to an upright position, do
the following:
1. Lift the lever fully without applying pressure to
the seatback and the seatback will return to
the upright position.
2. Push and pull on the seatback to make sure it
is locked.Power Reclining Seatbacks
If your seats have power reclining seatbacks, use
the vertical power seat control located on the
outboard side of each seat.
To recline the seatback, press the control
toward the rear of the vehicle.
To raise the seatback, press the control
toward the front of the vehicle.
15

{CAUTION:
Sitting in a reclined position when your
vehicle is in motion can be dangerous.
Even if you buckle up, your safety belts
cannot do their job when you are reclined
like this.
The shoulder belt cannot do its job. In a
crash, you could go into it, receiving neck
or other injuries.
The lap belt cannot do its job either. In a
crash the belt could go up over your
abdomen. The belt forces would be there,
not at your pelvic bones. This could cause
serious internal injuries.
For proper protection when the vehicle is
in motion, have the seatback upright.
Then sit well back in the seat and wear
your safety belt properly.
Do not have a seatback reclined if your vehicle is
moving.
16

Head Restraints
Adjust the head restraint so that the top of the
restraint is at the same height as the top of
the occupant’s head. This position reduces the
chance of a neck injury in a crash.The height of the front
seat head restraints can
be adjusted. Pull the
restraint up to raise it.
To lower it, press
the button, located on
the top of the seatback,
and push the head
restraint down.
The front seat head restraints can also tilt forward
and rearward. The second row seat head rests
do not tilt.
The height of the second row seat outboard head
rests and the third row seat head rests, if the
vehicle has them, can be adjusted. Pull these head
rests up or push them down for adjustment.
The second row seat may have a head rest in the
center position.
17

If the vehicle has third row seats, the head rests
adjust like the front seat head restraints.
The third row seat head rests can be removed
from the seatback. To do this, press the button,
located on the top of the seatback, and pull them
out from the seatback. Store the head rest,
front side facing up, in the compartment behind
the third row, by inserting the head rest posts into
the slots in the storage area.Rear Seats
Rear Seat Operation
Adjusting the Second Row Seat
The second row seat can be adjusted forward or
rearward. Pull up on the lever under the seat
cushion and slide the seat with your body. Release
the lever and try to move the seat forward and
rearward to be sure it is locked into place.
18

Entering or Exiting the Third Row Seat
{CAUTION:
Be sure to return the seat to the passenger
seating position when nished. Push and
pull on the seat to make sure it is locked
into place. Never use the third row seating
position while the second row is folded, or
folded and tumbled. This could cause
injury in a sudden stop or crash.
The passenger’s side of the second row seat has
an easy entry feature. This makes it easy to
get in and out of the third row seat, if your vehicle
has one.Notice:Folding a rear seat with the safety
belts still fastened may cause damage to the
seat or the safety belts. Always unbuckle
the safety belts and return them to their normal
stowed position before folding a rear seat.
To operate the seat, pull the release handle
located on the top of the seatback. Fold the
seatback forward, then pull the release handle on
the top of the seatback to release the seat to
tumble forward.
19

Stowable Seat
If your vehicle has a third row seat, it is a power
folding seat.
The head rests need to be removed before folding
the third row seat. SeeHead Restraints on
page 17for instructions for removing the third row
seat head rests. The seatback will not fold all
of the way down if the head rests are not removed.The buttons that are used to operate the power
folding third row seat are located inside of the
liftgate and behind the second row seat on the
passenger’s side of the vehicle.
Two buttons are located inside the liftgate.
One button is to tilt the seatback forward for added
storage space or when storing a at tire. The
other button is the power folding seat button. The
button behind the second row seat is also a
power folding seat button. Press and hold either
one of the two power folding seat buttons to
fold the seat.
Notice:Folding a rear seat with the safety
belts still fastened may cause damage to the
seat or the safety belts. Always unbuckle
the safety belts and return them to their normal
stowed position before folding a rear seat.
Inside Liftgate
