A. Underhood Fuse Block. SeeUnderhood Fuse
Block on page 455.
B. Windshield Washer Fluid Reservoir. See
“Adding Washer Fluid” underWindshield
Washer Fluid on page 380.
C. Battery. SeeBattery on page 385.
D. Passenger Compartment Air Filter. See
Passenger Compartment Air Filter on page 195.
E. Power Steering Fluid Reservoir. SeePower
Steering Fluid on page 379.
F. Engine Oil Fill Cap. See “When to Add Engine
Oil” underEngine Oil on page 360.G. Engine Oil Dipstick (Out of View). See
“Checking Engine Oil” underEngine Oil on
page 360.
H. Brake Master Cylinder Reservoir. See “Brake
Fluid” underBrakes on page 381.
I. Engine Coolant Surge Tank and Pressure Cap.
SeeCoolant Surge Tank Pressure Cap on
page 371andCooling System on page 374.
J. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 365.
357

A. Underhood Fuse Block. SeeUnderhood Fuse
Block on page 455.
B. Battery. SeeBattery on page 385.
C. Passenger Compartment Air Filter. See
Passenger Compartment Air Filter on page 195.
D. Windshield Washer Fluid Reservoir. See
“Adding Washer Fluid” underWindshield
Washer Fluid on page 380.
E. Power Steering Fluid Reservoir. SeePower
Steering Fluid on page 379.
F. Engine Oil Fill Cap. See “When to Add Engine
Oil” underEngine Oil on page 360.G. Engine Oil Dipstick (Out of View). See
“Checking Engine Oil” underEngine Oil on
page 360.
H. Brake Master Cylinder Reservoir. See “Brake
Fluid” underBrakes on page 381.
I. Engine Coolant Surge Tank and Pressure Cap.
SeeCoolant Surge Tank Pressure Cap on
page 371andCooling System on page 374.
J. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 365.
359

Engine Oil
Your vehicle may have
an oil pressure light on
the instrument cluster.
There is also an OIL PRESSURE LOW STOP
ENGINE message on the Driver Information
Center (DIC). If the light and/or message appears,
check the engine oil level right away. For more
information, see “OIL PRESSURE LOW STOP
ENGINE” underDIC Warnings and Messages on
page 220andOil Pressure Light on page 211.
You should check the engine oil level regularly;
this is an added reminder.
Checking Engine Oil
It is a good idea to check the engine oil every time
you get fuel. In order to get an accurate reading,
the oil must be warm and the vehicle must be
on level ground.
The engine oil dipstick handle is a yellow loop.
SeeEngine Compartment Overview on page 356
for the location of the engine oil dipstick.
1. Turn off the engine and give the oil
several minutes to drain back into the oil pan.
If you do not do this, the oil dipstick might
not show the actual level.
2. Pull out the dipstick and clean it with a paper
towel or cloth, then push it back in all the
way. Remove it again, keeping the tip down,
and check the level.
360

When to Add Engine Oil
If the oil is below the cross-hatched area at the tip
of the dipstick, you need to add at least one
quart/liter of oil. But you must use the right kind.
This section explains what kind of oil to use.
For engine oil crankcase capacity, seeCapacities
and Specications on page 464.Notice:Do not add too much oil. If the engine
has so much oil that the oil level gets above
the cross-hatched area that shows the
proper operating range, the engine could be
damaged.
SeeEngine
Compartment Overview
on page 356for the
location of the engine
oil ll cap.
Be sure to add enough oil to put the level
somewhere in the proper operating range. Push the
dipstick all the way back in when you are through.
3.6L V6 Engine
4.6L V8 Engine
361
