CADILLAC STS 2007 1.G Owners Manual

Lockout Protection
Your vehicle can be programmed to sound the
horn three times and unlock the driver’s door when
all doors are closed and there is a keyless
access transmitter inside the interior of the vehicle.
When the driver’s door is reopened, the key in
reminder chime will sound continuously. The
vehicle will remain locked only when at least one
transmitter has been removed from the vehicle
and both doors are closed. SeeVehicle
Personalization on page 148.
Trunk
{CAUTION:
It can be dangerous to drive with the
trunk lid open because carbon monoxide
(CO) gas can come into your vehicle. You
cannot see or smell CO. It can cause
unconsciousness and even death. If you
must drive with the trunk lid open or if
electrical wiring or other cable
connections must pass through the seal
between the body and the trunk lid:
Make sure all other windows are shut.
Turn the fan on your heating or
cooling system to its highest speed
and select the control setting that will
force outside air into your vehicle. See
Climate Control System.
If you have air outlets on or under
the instrument panel, open them
all the way.
SeeEngine Exhaust on page 125.
101

Trunk Lid Release
There are several ways to release the trunk lid.
V(Trunk Lid Release):Press this
button located on the driver’s door. The vehicle
must be in PARK (P) or NEUTRAL (N) and
the valet mode turned off. To disable
valet mode, seeValet Lockout Switch on
page 110.
Press the trunk lid release button on the
keyless access transmitter. SeeKeyless
Access System Operation on page 88. The
vehicle must be in PARK (P) or NEUTRAL (N)
and the valet mode turned off.
Squeeze the trunk release button located on
the rear of the trunk lid above the license
plate, as long as you have your keyless
access transmitter with you. Entry occurs when
the button is being pressed and the vehicle
recognizes the transmitter. The vehicle
must be in PARK (P) and the valet mode
turned off.
If your vehicle has lost battery power, you can still
access the trunk by unlocking and lowering the
rear seat pass-through door and pulling the
emergency trunk release handle.
102

Rear Seat Pass-Through Door
This feature allows you to access the trunk without
opening the trunk lid. If the vehicle ever loses
power, the trunk can be accessed and opened
through this door.
To open the door, do the following:
1. Pull the rear seat armrest down.
2. If the door is locked, insert the key into the
lock and turn it counterclockwise.
3. Press the button above the lock.
4. Lower the door.
To open the trunk lid, pull the emergency trunk
release handle located in the trunk on the
other side of the door opening. See “Emergency
Trunk Release Handle” following.
Emergency Trunk Release Handle
Notice:Do not use the emergency trunk
release handle as a tie-down or anchor point
when securing items in the trunk as it
could damage the handle.
There is a glow-in-the-dark trunk release handle
located inside the trunk near the back of the
rear seats. This handle will glow following
exposure to light. Pull down the release handle to
open the trunk from the inside of the vehicle.
103

Windows
{CAUTION:
Leaving children, helpless adults, or pets
in a vehicle with the windows closed is
dangerous. They can be overcome by the
extreme heat and suffer permanent
injuries or even death from heat stroke.
Never leave a child, a helpless adult, or a
pet alone in a vehicle, especially with the
windows closed in warm or hot weather.
104

Power Windows
The power window switches are located on the
armrest near each window. Press the front of the
switch to the rst position to open the window
to the desired level. Lift up the front of the switch
to the rst position to close the window.
Your vehicle has Retained Accessory Power
(RAP) that allows you to use the power windows
once the engine has been turned off. For more
information, seeRetained Accessory Power (RAP)
on page 112.
Express-Down Window
This feature is on all windows. It allows you to
lower the window all the way without holding the
switch down.
Press the front of the switch to the second
position and release. If you want to stop the
window as it is lowering, briey pull up the switch.
Express-Up Window
This feature is on all windows. It allows you to
raise the window all the way without holding the
switch up. Lift the front of the switch briey to
activate the express-up feature. If you want to stop
the window as it is raising, briey press the
switch.
105

Programming the Power Windows
If the battery on your vehicle has been recharged,
disconnected, or is not working, you will need to
reprogram each window for the express-up feature
to work.
To program each window, follow these steps:
1. With the ignition on or in Acc., or while RAP is
active, close all doors.
2. Press and hold the power window switch until
the window has fully opened.
3. Continue holding the switch for approximately
two seconds.
4. Pull up the power window switch until the
window is fully closed.
The window is now programmed. Repeat the
process for all windows.
Express Window Anti-Pinch Feature
If any object is in the path of the window when the
express-up is active, the window will stop at the
obstruction and auto-reverse to a preset factory
position. Weather conditions such as severe icing
may also cause the window to auto-reverse.
The window will return to normal operation once the
obstruction or condition is removed.
Express Window Anti-Pinch Override
{CAUTION:
If express override is activated, the
window will not reverse automatically.
You or others could be injured and the
window could be damaged. Before you
use express override, make sure that all
people and obstructions are clear of the
window path.
In an emergency, the anti-pinch feature can be
overridden in a supervised mode. Hold the window
switch all the way up in the express position.
The window will rise for as long as the switch is
held. Once the switch is released, the express
mode is re-activated.
In this mode, the window can still close on an object
in its path. Use care when using the override mode.
106

Window Lockout
o
(Window Lockout):The rear window lockout
button is located on the driver’s door armrest
near the window switches. Press this button to
disable the rear window controls. The light on the
button will illuminate, indicating that the feature
is in use. The rear windows can be raised or
lowered using the driver’s window switches when
the lockout feature is on. To restore power to
the rear windows, press the button again. The light
on the button will go out.
The front passenger window can be programmed
to be disabled using the window lockout button.
SeeVehicle Personalization on page 148.
Secure Car Feature
The windows can be closed by pressing the lock
button on the keyless access transmitter. See
Keyless Access System Operation on page 88for
more information. The window, if down, will
express-up. If any window was unable to
completely close, it will reverse and the horn will
chirp. See “Anti-Pinch Feature” previously.
The engine must be off to operate this feature.
Sun Visors
Swing down the visor or detach it from the center
mount and move to the side to block out glare.
The visors also have side-to-side slide capability
for greater coverage.
Lighted Visor Vanity Mirrors
Pull the visor down and lift the cover. Move the
slide switch up or down to brighten or dim
the lamp.
Theft-Deterrent Systems
Vehicle theft is big business, especially in some
cities. Although your vehicle has a number of
theft-deterrent features, we know that nothing
we put on it can make it impossible to steal.
107

Theft-Deterrent System
Your vehicle has a theft-deterrent alarm system.
The security light is
located on the
instrument panel cluster.
If the ignition is off and a door is open, the
security light will ash, reminding you to arm
the theft-deterrent system.
To arm the system, do one of the following:
Press the lock button on the keyless access
transmitter. If the door is closed when the
lock button is pressed, the security light
will stay illuminated for 30 seconds. After the
security light goes off, the theft-deterrent
system is armed. Pressing the lock button
twice will arm the system immediately.
If the vehicle is locked using the keyless
access transmitter and the trunk lid, hood
or a door is open or not closed completely,the security light will ash for 60 seconds and
then turn off. At this time, the theft-deterrent
system is armed but the alarm will not sound if
the trunk lid, hood or door that was not
closed completely is tampered with or opened.
The alarm will sound for the trunk lid, hood
or a door that was completely closed at
the time the vehicle was locked using the
keyless access transmitter.
Open the door. Lock the door with the power
door lock switch or lock button on the keyless
access transmitter. The security light should
ash. Close the door. The security light
will stop ashing and stay on. After 30 seconds
the light should turn off, the theft-deterrent
system is armed.
Passive Arming, if activated through the
vehicle personalization feature, will arm
the system automatically after you close the
door and take at least one keyless access
transmitter with you. The security light will turn
on. After 60 seconds the light should turn
off. The theft-deterrent system is armed. See
Vehicle Personalization on page 148.
108

If a door, hood, or the trunk is opened without
the keyless access transmitter, the horn will
sound for 30 seconds and the lamps will ash
for two minutes. The vehicle cannot be started
without a keyless access transmitter.
The Theft-Deterrent system will not arm if:
The key is used to turn the key cylinder to
the lock position.
The driver’s door is locked using the power
door lock switch after the doors are closed.
If the vehicle is locked using the keyless access
transmitter and the trunk lid, hood or a door
is open or not closed completely, the security
light will ash for 60 seconds and then turn off.
At this time, the theft-deterrent system is armed
but the alarm will not sound if the trunk lid, hood or
door that was not closed completely is tampered
with or opened. The alarm will sound for the
trunk lid, hood or a door that was completely
closed at the time the vehicle was locked using
the keyless access transmitter.
The vehicle can be programmed to automatically
unlock the doors and disarm the theft-deterrent
system when you approach the vehicle and
the keyless access transmitter is with you. See
Vehicle Personalization on page 148.Pressing the unlock button on the keyless access
transmitter or using the key to unlock the
driver’s door disarms the theft-deterrent system.
Unlocking a door any other way while the
system is armed will activate the alarm.
Testing the Alarm
1. From inside the vehicle, roll down the window,
then get out of the vehicle, keeping the
door open.
2. From outside of the vehicle, with the door
open, lock the vehicle using the power door
lock switch or the keyless access transmitter
and close the door. Wait about 30 seconds
until the security light goes off.
3. Reach in and open the door using the inside
door handle. The horn will sound and the
exterior lamps will ash.
You can turn off the alarm by pressing the unlock
button on the keyless access transmitter or by
starting the car.
If the alarm does not sound when it should, check to
see if the horn works. The horn fuse may be blown.
109

To replace the fuse, seeFuses and Circuit
Breakers on page 487. If the fuse does not need to
be replaced, you may need to have your vehicle
serviced.
To reduce the possibility of theft, always arm the
Theft-Deterrent system when leaving your vehicle.
Valet Lockout Switch
The valet lockout switch
is located inside the
glove box.
9(Off):Press the left side of the valet lockout
switch to turn the lockout feature off. When the
lockout feature is off, you can open the trunk using
either the keyless access transmitter or the trunk
release button located on the driver’s door.
R(On):Press the right side of the valet lockout
switch to turn the lockout feature on. When
the lockout feature is turned on, the trunk cannot
be unlocked with the keyless access transmitter
or the trunk release button located on the driver’s
door. If the valet lockout feature is on it will
also disable the remote start feature and the
Universal Home Remote transmitter, if equipped.
Locking the glove box with your key will also
help to secure your vehicle.
SeeKeyless Access System Operation on
page 88andTrunk on page 101for additional
information.
110
