jacking CADILLAC STS 2008 1.G Owners Manual

{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack, you
could be badly injured or killed. Never get under
a vehicle when it is supported only by a jack.
{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle or the
vehicle may fall and cause your or others injury.
If you ever use a jack to lift your vehicle, follow the
instructions that came with the jack, and be sure to use
the correct lifting points to avoid damaging your vehicle.Notice:Lifting your vehicle improperly can damage
your vehicle and result in costly repairs not
covered by your warranty. To lift your vehicle
properly, follow the advice in this part.
To help prevent vehicle damage:
Be sure the jack you are using meets the weight
standards for your vehicle and is in good
working order.
Be sure to place a block or pad between the
jack and the vehicle.
Make sure the jack you are using only contacts
the jacking location lift points and is not leaning
on any other vehicle components such as the
rocker panels, the oor pan, or the stone guard
moldings.
Lift only in the areas shown in the following
pictures.
5-84

Removing the Spare Tire and Tools
The equipment you will need is located in the trunk.
To gain access to the compact spare tire and jacking
equipment:
1. Open the trunk. SeeTrunk on page 2-16for more
information.
2. Remove the compact spare tire cover.
3. Turn the nut holding the jack package container
counterclockwise and remove it. Then remove the
jack and wheel wrench.4. Remove the compact spare tire. SeeCompact
Spare Tire on page 5-106for more information
about the compact spare tire.
The tools you will be using include the jack (A) and the
wheel wrench (B).
5-98

Removing the Flat Tire and
Installing the Spare Tire
1. Do a safety check before proceeding. SeeChanging
a Flat Tire on page 5-96for more information.
2. Loosen all of the wheel nuts, but do not remove
them yet, using the wheel wrench. Turn the
handle about 180 degrees, then ip the handle
back to the starting position. This avoids taking the
wrench off the lug nut for each turn.3. Find the vehicle’s jacking location using the
diagram above and corresponding V–shaped
notches located in the plastic molding on the
vehicle’s frame. The notches in the plastic molding
are marked with a triangle shape.
5-99
