The CHECK GAS CAP message in the Driver
Information Center (DIC) will come on if the fuel cap is
not properly reinstalled.
Notice:If you need a new fuel cap, be sure to get
the right type. Your dealer can get one for you.
If you get the wrong type, it may not ®t properly.
This may cause your malfunction indicator lamp to
light and may damage your fuel tank and emissions
system. See
Malfunction Indicator Lamp on
page 3-48.
Filling a Portable Fuel Container
{CAUTION:
Never ®ll a portable fuel container while it is in
your vehicle. Static electricity discharge from
the container can ignite the gasoline vapor.
You can be badly burned and your vehicle
damaged if this occurs. To help avoid injury to
you and others:
·Dispense gasoline only into approved
containers.
CAUTION: (Continued)
CAUTION: (Continued)
·
Do not ®ll a container while it is inside a
vehicle, in a vehicle's trunk, pickup bed or
on any surface other than the ground.
·Bring the ®ll nozzle in contact with the
inside of the ®ll opening before operating
the nozzle. Contact should be maintained
until the ®lling is complete.
·Do not smoke while pumping gasoline.
Checking Things Under
the Hood
{CAUTION:
An electric fan under the hood can start up
and injure you even when the engine is not
running. Keep hands, clothing and tools away
from any underhood electric fan.
5-10

Follow these steps to reinstall the cover to the engine
air cleaner/®lter housing:
1. Align the four tabs located on the back of the cover
with the three slots on the back of the housing.
2. Push the cover slightly down and towards the
engine to engage the tabs in the slots and align the
two wing screws.
3. Engage and tighten the two clasps on the top of the
engine air cleaner/®lter cover.
{CAUTION:
Operating the engine with the air cleaner/®lter
off can cause you or others to be burned. The
air cleaner not only cleans the air, it helps to
stop ¯ame if the engine back®res. If it is not
there and the engine back®res, you could
be burned. Do not drive with it off, and be
careful working on the engine with the air
cleaner/®lter off.
Notice:If the air cleaner/®lter is off, a back®re can
cause a damaging engine ®re. And, dirt can
easily get into your engine, which will damage it.
Always have the air cleaner/®lter in place when you
are driving.
Automatic Transmission Fluid
How to Check
It is not necessary to check the transmission ¯uid level.
A transmission ¯uid leak is the only reason for ¯uid
loss. If a leak occurs, take the vehicle to your dealer
service department and have it repaired as soon
as possible.
There is a special procedure for checking and changing
the transmission ¯uid. Because this procedure is
difficult, you should have this done at your dealer service
department. Contact your dealer for additional
information or the procedure can be found in the service
manual. To purchase a service manual, see
Service
Publications Ordering Information on page 7-11.
5-19

A low tire warning light also appears on the instrument
panel cluster when a low tire condition exists. The
DIC message, CHECK TIRE PRESSURE and the low
tire pressure warning light will be shown each time
the engine is started and stay on until the low tire
condition is corrected.
When the tire pressure
monitoring system warning
light is lit, one or more
of your tires is signi®cantly
under-in¯ated.
You should stop and check your tires as soon as
possible, and in¯ate them to the proper pressure as
indicated on the vehicle's tire information placard.
Driving on a signi®cantly under-in¯ated tire causes the
tire to overheat and can lead to tire failure.
Under-in¯ation also reduces fuel efficiency and tire tread
life, and may affect the vehicle's handling and stopping
ability. Each tire, including the spare, should be
checked monthly when cold and set to the
recommended in¯ation pressure as speci®ed in the
vehicle placard and owner's manual.The Tire and Loading Information Label (tire information
placard) is either on the rear edge of the driver's door
or the driver's door jamb near the latch. This label shows
the size of your vehicle's original tires and the correct
in¯ation pressure for your vehicle's tires when they
are cold. See
In¯ation - Tire Pressure on page 5-57.
Your vehicle's TPM system can alert you about a low or
high tire pressure condition but it does not replace
normal tire maintenance. See
Tire Inspection and
Rotation on page 5-60
Each TPM sensor has a unique identi®cation code that
is matched to one of the four tire positions on your
vehicle. The tire and wheel assembly positions are, left
front (LF); right front (RF); right rear (RR) and left
rear (LR). Any time you rotate your vehicle's tires or
replace one or more TPM sensors, the identi®cation
codes will need to be matched to the new tire and wheel
position. The TPM matching process is performed in
a speci®c sequence and time limit. A special tool is also
required. See your dealer for service.
The SVC TIRE MONITOR message is displayed when
the TPM system is malfunctioning. For example,
one or more TPM sensors may be inoperable or
missing. See your dealer for service.
5-59

Maintenance Footnotes
²The U.S. Environmental Protection Agency or the
California Air Resources Board has determined that the
failure to perform this maintenance item will not nullify
the emission warranty or limit recall liability prior to
the completion of the vehicle's useful life. We, however,
urge that all recommended maintenance services be
performed at the indicated intervals and the
maintenance be recorded.
(a)A ¯uid loss in any vehicle system could indicate a
problem. Have the system inspected and repaired
and the ¯uid level checked. Add ¯uid if needed.
(b)Visually inspect wiper blades for wear or cracking.
Replace blade inserts that appear worn or damaged
or that streak or miss areas of the windshield.
(c)Make sure the safety belt reminder light and all your
belts, buckles, latch plates, retractors and anchorages
are working properly. Look for any other loose or
damaged safety belt system parts. If you see anything
that might keep a safety belt system from doing its
job, have it repaired. Have any torn or frayed safety belts
replaced. Also look for any opened or broken air bag
coverings, and have them repaired or replaced. (The air
bag system does not need regular maintenance.)
(d)Lubricate the trunk key lock cylinder. Lubricate all
body door hinges. Lubricate all hinges and latches,
including those for the hood, trunk, console door and
any folding seat hardware. More frequent lubrication
may be required when exposed to a corrosive
environment. Applying silicone grease on weatherstrips
with a clean cloth will make them last longer, seal
better and not stick or squeak.
(e)If you drive regularly under dusty conditions, the
®lter may require replacement more often.
(f)Change automatic transmission ¯uid and ®lter if the
vehicle is mainly driven under one or more of these
conditions:
þIn heavy city traffic where the outside temperature
regularly reaches 90ÉF (32ÉC) or higher.
þIn hilly or mountainous terrain.
þUses such as high performance operation.
(g)Drain, ¯ush and re®ll cooling system. See Engine
Coolant on page 5-20for what to use. Inspect hoses.
Clean radiator, condenser, pressure cap and ®ller neck.
Pressure test the cooling system and pressure cap.
6-7

B
Battery..........................................................5-38
Battery Replacement......................................... 2-7
Battery Run-Down Protection............................3-26
Before Leaving on a Long Trip.........................4-25
Brake
Parking......................................................2-26
System Warning Light..................................3-45
Brake Fluid....................................................5-35
Brake Wear...................................................5-37
Brakes..........................................................5-35
Braking........................................................... 4-6
Braking in Emergencies..................................... 4-8
Break-In, New Vehicle.....................................2-19
Bulb Replacement...........................................5-49
Headlamp Aiming........................................5-46
Buying New Tires...........................................5-63
C
Cadillac Owner PrivilegesŸ............................... 7-6
California Fuel.................................................. 5-6
Canada ± Customer Assistance.......................... 7-4
Canadian Owners................................................ ii
Capacities and Speci®cations............................5-91Carbon Monoxide...................2-11, 2-31, 4-28, 4-37
Care of
Safety Belts................................................5-78
Your CD Player...........................................3-72
Your CDs ...................................................3-72
Cellular Phone Usage......................................3-72
Center Console Storage Area...........................2-41
Chains, Tires..................................................5-68
Check Engine Light.........................................3-48
Checking Coolant............................................5-22
Checking Engine Oil........................................5-13
Checking Things Under the Hood......................5-10
Chemical Paint Spotting...................................5-81
Child Restraints
Child Restraint Systems...............................1-23
Infants and Young Children...........................1-20
Lower Anchorages and Top Tethers for
Children (LATCH System)..........................1-27
Older Children.............................................1-18
Securing a Child Restraint Designed for
the LATCH System...................................1-29
Securing a Child Restraint in the
Passenger Seat Position...........................1-31
Top Strap...................................................1-27
Cigarette Lighter.............................................3-33
2

Doing Your Own Service Work........................... 5-4
Door
Locks.......................................................... 2-8
Power Door Locks.......................................2-10
Programmable Automatic Door Locks.............2-10
Driver
Position, Safety Belt.....................................1-10
Driver Information Center (DIC).........................3-55
DIC Controls and Displays............................3-55
DIC Vehicle Personalization..........................3-66
DIC Warnings and Messages........................3-57
Other Messages..........................................3-65
Driver Shift Control.........................................2-25
Driving
At Night.....................................................4-18
City...........................................................4-23
Defensive..................................................... 4-2
Drunken....................................................... 4-2
Freeway.....................................................4-24
Hill and Mountain Roads..............................4-26
In Rain and on Wet Roads...........................4-20
Winter........................................................4-28
Driving On Snow or Ice...................................4-29
Driving Through Deep Standing Water...............4-22
Driving Through Flowing Water.........................4-22
Dual Climate Control System............................3-33E
Eight-Way Power Seats..................................... 1-2
Electrical System
Add-On Equipment......................................5-84
Fuses and Circuit Breakers...........................5-85
Power Windows and Other Power Options......5-84
Windshield Wiper Fuses...............................5-84
Emergency Trunk Release Handle.....................2-14
Emissions Inspection and Maintenance
Programs...................................................3-51
Engine
Air Cleaner/Filter.........................................5-18
Battery.......................................................5-38
Check and Service Engine Soon Light............3-48
Coolant......................................................5-20
Coolant Heater............................................2-21
Coolant Temperature Gage...........................3-47
Drive Belt Routing.......................................6-13
Engine Compartment Overview......................5-12
Exhaust.....................................................2-31
Oil .............................................................5-13
Oil Pressure Gage.......................................3-52
Overheating................................................5-23
Starting......................................................2-20
Engine Oil Additives........................................5-16
4

Gasoline
Octane........................................................ 5-5
Speci®cations............................................... 5-5
Gate Operator and Canadian Programming........2-39
Glove Box.....................................................2-41
GM Mobility Program for Persons with
Disabilities.................................................... 7-5
H
Hazard Warning Flashers................................... 3-4
Headlamp
Aiming.......................................................5-46
Vertical Aiming............................................5-47
Headlamp High/Low-Beam Changer.................... 3-6
Headlamps
Bulb Replacement.......................................5-49
Headlamps on Reminder................................... 3-6
Head-Up Display (HUD)...................................3-27
Heated Seats................................................... 1-3
Highway Hypnosis...........................................4-26
Hill and Mountain Roads..................................4-26
HomeLink
žTransmitter....................................2-37
HomeLinkžTransmitter, Programming................2-37
Hood
Checking Things Under................................5-10
Release.....................................................5-11
Horn............................................................... 3-5How the System Works...................................3-31
How to Add Coolant to the Coolant
Surge Tank.................................................5-28
How to Check........................................5-19, 5-58
How to Check Lubricant...................................5-45
How to Check Power Steering Fluid..................5-33
How to Remove and Replace the Floor Mats......2-42
How to Use This Manual...................................... ii
How to Wear Safety Belts Properly..................... 1-9
Hydroplaning..................................................4-21
I
If No Steam Is Coming From Your Engine..........5-25
If Steam Is Coming From Your Engine...............5-24
If the Light Is Flashing.....................................3-49
If the Light Is On Steady.................................3-50
If You Are Caught in a Blizzard.........................4-30
If You Are Stuck in Sand, Mud, Ice or Snow.......4-31
Ignition Positions.............................................2-19
Infants and Young Children, Restraints...............1-20
In¯ation - Tire Pressure...................................5-57
Instrument Panel
Cluster.......................................................3-40
Overview..................................................... 3-2
Instrument Panel Brightness.............................3-25
Instrument Panel Fuse Block............................5-85
Interior Lamps................................................3-25
6

M
Magnetic Ride Control.....................................4-10
Magnetic Speed Variable Assist Steering............4-12
Maintenance Schedule
Additional Required Services........................... 6-6
At Each Fuel Fill........................................... 6-8
At Least Once a Month.................................. 6-8
At Least Once a Year.................................... 6-9
Introduction.................................................. 6-2
Maintenance Footnotes.................................. 6-7
Maintenance Record....................................6-14
Maintenance Requirements............................. 6-2
Normal Maintenance Replacement Parts.........6-13
Owner Checks and Services........................... 6-8
Recommended Fluids and Lubricants.............6-11
Scheduled Maintenance................................. 6-4
Using Your................................................... 6-2
Your Vehicle and the Environment................... 6-2
Malfunction Indicator Light................................3-48
Map Pocket...................................................2-42
Matching Transmitter(s) to Your Vehicle............... 2-5
Memory Mirrors..............................................2-53
Memory Seat.................................................2-53
Memory Steering Wheel Controls......................2-53
Message
DIC Warnings and Messages........................3-57Mexico, Central America and Caribbean Islands/
Countries (Except Puerto Rico and U.S. Virgin
Islands) ± Customer Assistance....................... 7-4
Mirror Operation.............................................2-33
Mirrors
Automatic Dimming Rearview with OnStar
ž.....2-33
Memory.....................................................2-53
Outside Automatic Dimming Mirror.................2-34
Outside Convex Mirror.................................2-34
Outside Curb View Assist Mirror....................2-34
Outside Power Heated Mirrors.......................2-33
MyGMLink.com................................................ 7-3
N
Navigation/Radio System..................................3-71
New Vehicle Break-In......................................2-19
Normal Maintenance Replacement Parts............6-13
O
Odometer......................................................3-41
Odometer, Trip...............................................3-41
Off-Road Recovery..........................................4-15
Oil
Engine.......................................................5-13
Engine Oil Pressure Gage............................3-52
Life Indicator...............................................3-70
8

R
Radios..........................................................3-70
Care of Your CD Player...............................3-72
Care of Your CDs........................................3-72
Navigation/Radio System..............................3-71
Theft-Deterrent............................................3-71
Understanding Reception..............................3-72
RainsenseŸ Wipers.......................................... 3-8
Raising the Retractable Hardtop........................2-45
Reaching Roadside Service............................... 7-6
Reading Lamps..............................................3-26
Rear Axle......................................................5-45
Limited-Slip.................................................4-10
Rear Storage Area..........................................2-43
Rear Window Defogger....................................3-37
Rearview Mirror, Automatic Dimming
with OnStar
ž..............................................2-33
Recommended Fluids and Lubricants.................6-11
Recreational Vehicle Towing.............................4-32
Replacing Brake System Parts..........................5-37
Reporting Safety Defects
Canadian Government..................................7-10
General Motors...........................................7-11
United States Government............................7-10
Reprogramming a Single HomeLink
žButton.......2-40
Resetting Defaults...........................................2-40
Restraint System Check
Checking Your Restraint Systems...................1-48Restraint System Check (cont.)
Replacing Restraint System Parts
After a Crash..........................................1-49
Restraint Systems
Checking....................................................1-48
Replacing Parts...........................................1-49
Retained Accessory Power (RAP)......................2-20
Retractable Hardtop........................................2-44
Lowering....................................................2-44
Raising......................................................2-45
Roadside
Service........................................................ 7-5
Roadside Service Availability.............................. 7-6
Roadside Service for the Hearing or Speech
Impaired...................................................... 7-6
Rocking Your Vehicle To Get It Out...................4-32
Routing, Engine Drive Belt...............................6-13
Run-Flat Tires................................................5-56
Running Your Engine While You Are Parked.......2-32
S
Safety Belt
Pretensioners..............................................1-17
Reminder Light............................................3-41
Safety Belts
Care of......................................................5-78
Driver Position............................................1-10
How to Wear Safety Belts Properly.................. 1-9
10

U
Ultrasonic Rear Parking Assist (URPA)...............3-30
Underhood Fuse Block....................................5-88
Understanding Radio Reception........................3-72
Uniform Tire Quality Grading............................5-64
United States ± Customer Assistance.................. 7-4
Using Cleaner on Fabric..................................5-76
Using HomeLink
ž...........................................2-40
V
Valet Lockout Switch.......................................2-18
Vehicle
Control........................................................ 4-5
Damage Warnings........................................... iv
Loading......................................................4-32
Symbols......................................................... iv
Vehicle Data Collection and Event Data
Recorders.................................................... 7-8
Vehicle Identi®cation
Number (VIN).............................................5-83
Service Parts Identi®cation Label...................5-83
Vehicle Personalization
DIC ...........................................................3-66
Memory Seat, Mirrors and Steering Wheel......2-53Vehicle Storage..............................................5-38
Ventilation Adjustment......................................3-38
Visors...........................................................2-16
Voltmeter Gage..............................................3-44
W
Warning Lights, Gages and Indicators................3-39
Warnings
DIC Warnings and Messages........................3-57
Hazard Warning Flashers............................... 3-4
Other Warning Devices.................................. 3-4
Safety and Symbols......................................... iii
Vehicle Damage.............................................. iv
Washing Your Vehicle......................................5-78
What Kind of Engine Oil to Use........................5-14
What to Do with Used Oil................................5-17
What to Use..................................5-21, 5-33, 5-45
Wheels
Alignment and Tire Balance..........................5-65
Replacement...............................................5-66
When to Add Engine Oil..................................5-14
When to Change Engine Oil (GM Oil Life
System).....................................................5-16
When to Check..............................................5-58
13
