lock CADILLAC XT4 2023 Owners Manual

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
412 Vehicle Care
Appearance Care
Exterior Care
Locks
Locks are lubricated at the
factory. Use a de-icing agent
only when absolutely
necessary, and have the locks
greased after using. See
Recommended Fluids and
Lubricants0429.
Washing the Vehicle
To preserve the vehicle's
finish, wash it often and out of
direct sunlight.
Caution
Do not use
petroleum-based, acidic,
or abrasive cleaning agents
as they can damage the
vehicle's paint, metal,
or plastic parts. If damage
occurs, it would not be
covered by the vehicle
warranty. Approved cleaning
(Continued)
Caution (Continued)
products can be obtained
from your dealer. Follow all
manufacturer directions
regarding correct product
usage, necessary safety
precautions, and
appropriate disposal of any
vehicle care product.
Caution
Avoid using high-pressure
washes closer than 30 cm
(12 in) to the surface of the
vehicle. Use of power
washers exceeding
8 274 kPa (1,200 psi) can
result in damage or removal
of paint and decals.
If using an automatic car wash,
follow the car wash
instructions. The windshield
wiper and rear window wiper,
if equipped, must be off. Remove any accessories that
may be damaged or interfere
with the car wash equipment.
Rinse the vehicle well, before
washing and after, to remove
all cleaning agents completely.
If they are allowed to dry on
the surface, they could stain.
Dry the finish with a soft, clean
chamois or an all-cotton towel
to avoid surface scratches
and water spotting.
Cleaning Underhood
Components
Caution
Do not power wash any
component under the hood
that has this
esymbol.
This could cause damage
that would not be covered
by the vehicle warranty.
Solvents or aggressive
cleaners may harm underhood
components. The usages of
these chemicals should be
avoided.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
416 Vehicle Care
Caution
To avoid surface damage on
wheels and wheel trim, do
not use strong soaps,
chemicals, abrasive polishes,
cleaners, or brushes. Use
only GM approved cleaners.
Do not drive the vehicle
through an automatic car
wash that uses silicon
carbide tire/wheel cleaning
brushes. Damage could
occur and the repairs would
not be covered by the
vehicle warranty.
Brake System
Visually inspect brake lines
and hoses for proper hook-up,
binding, leaks, cracks, chafing,
etc. Inspect disc brake pads
for wear and rotors for
surface condition. Inspect
drum brake linings/shoes for
wear or cracks. Inspect all
other brake parts.
Steering, Suspension, and
Chassis Components
Visually inspect steering,
suspension, and chassis
components for damaged,
loose, or missing parts or signs
of wear at least once a year.
Inspect power steering for
proper attachment,
connections, binding, leaks,
cracks, chafing, etc.
Visually check constant
velocity joint boots and axle
seals for leaks.
Body Component
Lubrication
Lubricate all key lock cylinders,
hood hinges, liftgate hinges,
and the steel fuel door hinges,
unless the components are
plastic. Applying silicone
grease on weatherstrips with
a clean cloth will make them
last longer, seal better, and
not stick or squeak.
Underbody Maintenance
At least twice a year, spring
and fall, use plain water to
flush any corrosive materials
from the underbody. Take care
to thoroughly clean any areas
where mud and other debris
can collect.
Do not directly power wash
the transfer case and/or
front/rear axle output seals.
High pressure water can
overcome the seals and
contaminate the fluid.
Contaminated fluid will
decrease the life of the
transfer case and/or axles and
should be replaced.
Sheet Metal Damage
If the vehicle is damaged and
requires sheet metal repair or
replacement, make sure the
body repair shop applies
anti-corrosion material to
parts repaired or replaced to
restore corrosion protection.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 421
{Warning
Do not bleach or dye seat
belt webbing. It may severely
weaken the webbing. In a
crash, they might not be
able to provide adequate
protection. Clean and rinse
seat belt webbing only with
mild soap and lukewarm
water. Allow the webbing
to dry.
Floor Mats
{Warning
If a floor mat is the wrong
size or is not properly
installed, it can interfere
with the pedals. Interference
with the pedals can cause
unintended acceleration
and/or increased stopping
distance which can cause a
crash and injury. Make sure
the floor mat does not
interfere with the pedals.Use the following guidelines
for proper floor mat use.
.The original equipment floor
mats were designed for your
vehicle. If the floor mats
need to be replaced, it is
recommended that
GM-certified floor mats be
purchased. Non-GM floor
mats may not fit properly
and may interfere with the
pedals. Always check that
the floor mats do not
interfere with the pedals.
.Do not use a floor mat if the
vehicle is not equipped with
a floor mat retainer on the
driver side floor.
.Use the floor mat with the
correct side up. Do not turn
it over.
.Do not place anything on top
of the driver side floor mat.
.Use only a single floor mat
on the driver side.
.Do not place one floor mat
on top of another.
Removing and Replacing
the Floor Mats
The driver and passenger side
floor mats are held in place by
two button-type retainers.
1. Pull up on the rear of the
floor mat to unlock each
retainer and remove.
2. Reinstall by lining up the floor mat retainer openings
over the carpet retainers
and pushing down to snap
into position.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
428 Service and Maintenance
Exterior Lights
.Visual inspection
Windshield and Wipers
.Visual inspection
Battery
.Battery visual inspection
.Battery test results
.Battery cables and
connections
Systems, Fluids, and
Visible Leak Inspection
.Engine oil
.Transmission
.Drive axle
.Transfer case
.Engine cooling system
.Power steering, if equipped
.Fuel system
.Windshield washer fluid
Tire Inspection
.Tire pressure, tread depth,
and wear
.Rotation, if applicable
.Alignment check, optional
.Reset tire pressure monitor
.Check tire sealant expiration
date, if equipped
.Check spare tire, if equipped
Brakes
.Check brake system
Visible and Functional
Inspections
.Seat belt components
.Exhaust system
.Accelerator pedal
.Passenger compartment air
filter, if equipped
.Engine air filter
.Hoses
.Belts
.Shocks and struts
.Steering components
.Axle boots or driveshaft and
u-joints
.Compartment lift struts,
if equipped
.Floor mats secured, no
interference with pedals
.Horn
.Ignition lock, if equipped
.Starter switch
.Evaporative control system
Lubricate
.Chassis components
Special Application
Services
.Severe Commercial Use
Vehicles Only: Lubricate
chassis components every
oil change.
.Have underbody flushing
service performed. See
"Underbody Maintenance" in
Exterior Care 0412.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Service and Maintenance 429
Recommended Fluids, Lubricants, and Parts
Recommended Fluids and Lubricants
Fluids and lubricants identified below by name or specification, including fluids or lubricants not
listed here, can be obtained from your dealer.Usage Fluid/Lubricant
Automatic Transmission DEXRON-VI Automatic Transmission Fluid. Engine Coolant 50/50 mixture of clean, drinkable water and use only DEX-COOL Coolant. See Cooling System 0338.
Engine Oil Engine oil meeting the dexos1 specification of the proper SAE viscosity grade. ACDelco dexos1 full synthetic is recommended.
See Engine Oil0332.
Hood Latch Assembly,
Secondary Latch, Pivots, Spring Anchor, and Release Pawl Lubriplate Lubricant Aerosol or lubricant meeting requirements
of NLGI #2, Category LB or GC-LB.
Hydraulic Brake System DOT 4 Hydraulic Brake Fluid.
Key Lock Cylinders, Hood and Door Hinges Multi-Purpose Lubricant, Superlube. See your dealer.
Front Axle/Rear Axle See your dealer.
Transfer Case (All-Wheel Drive) Transfer Case Fluid. See your dealer. Windshield Washer Automotive windshield washer fluid that meets regional freeze protection requirements.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
440 Customer Information
In the U.S., anyone driving the
vehicle is covered. In Canada,
a person driving the vehicle
without permission from the
owner is not covered.
Roadside Assistance is not a
part of the New Vehicle
Limited Warranty. General
Motors North America and
Cadillac reserve the right to
make any changes or
discontinue the Roadside
Assistance program at any
time without notification.
General Motors North America
and Cadillac reserve the right
to limit services or payment to
an owner or driver if they
decide the claims are made
too often, or the same type of
claim is made many times.
Cadillac Owner
Privileges™
.Emergency Fuel Delivery:
Delivery of enough fuel for
the vehicle to get to the
nearest service station.
.Lock-Out Service:Service
to unlock the vehicle if you
are locked out. A remote
unlock may be available if
you have OnStar. For
security reasons, the driver
must present identification
before this service is given.
.Emergency Tow from a
Public Road or Highway:
Tow to the nearest Cadillac
dealer for warranty service,
or if the vehicle was in a
crash and cannot be driven.
Assistance is not given when
the vehicle is stuck in the
sand, mud, or snow.
.Flat Tire Change: Service to
change a flat tire with a
spare tire. The spare tire,
if equipped, must be in good
condition and properly
inflated. It is your
responsibility for the repair
or replacement of the tire if
it is not covered by the
warranty.
.Battery Jump Start: Service
to jump start a dead battery.
.Trip Interruption Benefits
and Service: If your trip is
interrupted due to a
warranty failure, incidental
expenses may be
reimbursed during the
Powertrain warranty period.
Items considered are hotel,
meals, and rental car or a
vehicle being delivered back
to the customer, up to
500 miles.
Cadillac Technician
Roadside Assistance
(U.S. Only)
Cadillac's exceptional
Roadside Assistance is more
than an auto club or towing
service. It provides every
Cadillac owner in the United
States with the advantage of
contacting a Cadillac advisor
and, where available, a Cadillac
trained dealer technician who
can provide on-site service.
A dealer technician will travel
to your location within a
30-mile radius of a
participating Cadillac

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Customer Information 441
dealership. If beyond this
radius, we will arrange to have
your car towed to the nearest
Cadillac dealership. Each
technician travels with a
specially equipped service
vehicle complete with the
necessary Cadillac parts and
tools required to handle most
roadside repairs.
Services Not Included in
Roadside Assistance
.Impound towing caused by
violation of any laws
.Legal fines
.Mounting, dismounting,
or changing of snow tires,
chains, or other traction
devices
Service is not provided if a
vehicle is in an area that is not
accessible to the service
vehicle or is not a regularly
traveled or maintained public
road, which includes ice and
winter roads. Off-road use is
not covered.
Services Specific to
Canadian-Purchased
Vehicles
.Fuel delivery:
Reimbursement is up to 7
liters. Diesel fuel delivery
may be restricted. Propane
and other fuels are not
provided through this
service.
.Lock-Out Service: Vehicle
registration is required.
.Trip Interruption Benefits
and Assistance:
Pre-authorization, original
detailed receipts, and a copy
of the repair orders are
required. Once authorization
has been received, the
Roadside Assistance advisor
will help you make
arrangements and explain
how to receive payment.
Items considered are hotel,
meals, and rental car or a
vehicle being delivered back
to the customer, up to
800 km.
.Alternative Service: If
assistance cannot be
provided right away, the
Roadside Assistance advisor
may give you permission to
get local emergency road
service. You will receive
payment, up to $100, after
sending the original receipt
to Roadside Assistance.
Mechanical failures may be
covered, however any cost
for parts and labor for
repairs not covered by the
warranty are the owner
responsibility.
Scheduling Service
Appointments
When the vehicle requires
warranty service, contact your
dealer and request an
appointment. By scheduling a
service appointment and
advising the service
consultant of your
transportation needs, your
dealer can help minimize your
inconvenience.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
446 Customer Information
suspension, brakes, electrical
system, steering system,
body, etc.
Customer Literature
Owner’s manuals are written
specifically for owners and are
intended to provide basic
operational information about
the vehicle. The owner’s
manual includes the
Maintenance Schedule for all
models.
Customer literature
publications available for
purchase include owner’s
manuals, warranty manuals,
and portfolios. Portfolios
include an owner’s manual,
warranty manual, if applicable,
and zip lock bag or pouch.
Current and Past Models
Service manuals and customer
literature are available for
many current and past model
year GM vehicles.To order, call 1-800-551-4123
Monday–Friday, 8:00 a.m.–
6:00 p.m. Eastern Time
For credit card orders only
(VISA, MasterCard,
or Discover), see Helm, Inc. at:
www.helminc.com.
To order by mail, write to:
Helm, Incorporated
Attention: Customer Service
47911 Halyard Drive
Plymouth, MI 48170
Make checks payable in U.S.
funds.
Radio Frequency
Statement
This vehicle uses
license-exempt transmitters /
receivers / systems that
operate on a radio frequency
that complies with Part 15/
Part 18 of the Federal
Communications Commission
(FCC) rules and with
Innovation, Science andEconomic Development (ISED)
Canada's license-exempt
RSS(s) / RSP-100 / ICES-GEN.
Operation is subject to the
following two conditions:
1. The device may not cause harmful interference.
2. The device must accept any interference received,
including interference that
may cause undesired
operation of the device.
Changes or modifications to
any of these systems by other
than an authorized service
facility could void
authorization to use this
equipment.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
448 Customer Information
Cadillac Customer Assistance
Center
Cadillac Motor Car Division
P.O. Box 33169
Detroit, MI 48232-5169
In Canada, call
1-888-446-2000, or write:
Canadian Cadillac Customer
Care Centre
General Motors of Canada
Company
500 Wentworth Street W
Oshawa, ON L1J 0C5
In Mexico, call 800-466-0805
or 800-212-234-5522.
In other Central America and
Caribbean Countries, call
52-555-901-2369.
Vehicle Data
Recording and
Privacy
The vehicle has a number of
computers that record
information about the vehicle’s
performance and how it is
driven or used. For example,the vehicle uses computer
modules to monitor and
control engine and
transmission performance, to
monitor the conditions for
airbag deployment and deploy
them in a crash, and,
if equipped, to provide antilock
braking to help the driver
control the vehicle. These
modules may store data to
help the dealer technician
service the vehicle or to help
GM improve safety or
features. Some modules may
also store data about how the
vehicle is operated, such as
rate of fuel consumption or
average speed. These
modules may retain personal
preferences, such as radio
presets, seat positions, and
temperature settings.
Cybersecurity
GM collects information about
the use of your vehicle
including operational and
safety related information. We
collect this information to
provide, evaluate, improve, and
troubleshoot our products and
services and to develop new
products and services. The
protection of vehicle
electronics systems and
customer data from
unauthorized outside
electronic access or control is
important to GM. GM
maintains appropriate security
standards, practices,
guidelines and controls aimed
at defending the vehicle and
the vehicle service ecosystem
against unauthorized
electronic access, detecting
possible malicious activity in
related networks, and
responding to suspected
cybersecurity incidents in a
timely, coordinated and
effective manner. Security
incidents could impact your
safety or compromise your
private data. To minimize
security risks, please do not
connect your vehicle
electronic systems to
unauthorized devices or

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
OnStar 453
With Roadside Assistance,
Advisors can locate a nearby
service provider to help with a
flat tire, a battery jump, or an
empty gas tank.
Security
If equipped, OnStar provides
these services:
.With Stolen Vehicle
Assistance, OnStar Advisors
can use GPS to pinpoint the
vehicle and help authorities
quickly recover it.
.With Remote Ignition Block,
if equipped, OnStar can
block the vehicle from being
restarted.
.With Stolen Vehicle
Slowdown, if equipped,
OnStar can work with law
enforcement to gradually
slow the vehicle down.
Theft Alarm Notification
If equipped, if the doors are
locked and the vehicle alarm
sounds, a notification by text,
email, or phone call is sent.If the vehicle is stolen, an
OnStar Advisor can work with
authorities to recover the
vehicle.
OnStar Additional
Information
In-Vehicle Audio
Messages
Audio messages may play
important information at the
following times:
.Prior to vehicle purchase.
Press
Qto set up an
account.
.After change in ownership
and at 90 days.
Transferring Service
PressQto request account
transfer eligibility information.
The Advisor can cancel or
change account information.
Selling/Transferring the
Vehicle
Call 1-888-4ONSTAR
(1-888-466-7827) immediately
to terminate your OnStar or
connected services if the
vehicle is disposed of, sold,
transferred, or if the
lease ends.
Reactivation for
Subsequent Owners
PressQand follow the
prompts to speak to an
Advisor as soon as possible.
The Advisor will update vehicle
records and explain OnStar or
connected service options.
How OnStar Service
Works
Automatic Crash Response,
Emergency Services, Crisis
Assist, Stolen Vehicle
Assistance, Remote Services,
and Roadside Assistance are
available on most vehicles. Not
all OnStar services are
available everywhere or on all
