Vehicle Care 345
Brake Fluid
The brake master cylinder
reservoir is filled with GM
approved DOT 4 brake fluid as
indicated on the reservoir cap.
See Engine Compartment
Overview0331 for the
location of the reservoir.
Checking Brake Fluid
With the vehicle in P (Park) on
a level surface, the brake fluid
level should be between the
minimum and maximum marks
on the brake fluid reservoir.
There are only two reasons
why the brake fluid level in the
reservoir may go down:
.Normal brake lining wear.
When new linings are
installed, the fluid level goes
back up.
.A fluid leak in the brake
hydraulic system. Have the
brake hydraulic system fixed.
With a leak, the brakes will
not work well.
Always clean the brake fluid
reservoir cap and the area
around the cap before
removing it.
Do not top off the brake fluid.
Adding fluid does not correct a
leak. If fluid is added when the
linings are worn, there will be
too much fluid when new
brake linings are installed. Add
or remove fluid, as necessary,
only when work is done on the
brake hydraulic system.
{Warning
If too much brake fluid is
added, it can spill on the
engine and burn, if the
engine is hot enough. You or
others could be burned, and
the vehicle could be (Continued)
Warning (Continued)
damaged. Add brake fluid
only when work is done on
the brake hydraulic system.
When the brake fluid falls to a
low level, the brake warning
light comes on. See Brake
System Warning Light 0128.
Brake fluid absorbs water over
time which degrades the
effectiveness of the brake
fluid. Replace brake fluid at the
specified intervals to prevent
increased stopping distance.
See Maintenance Schedule
0 425.
What to Add
Use only GM approved DOT 4
brake fluid from a clean, sealed
container. See Recommended
Fluids and Lubricants 0429.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 349
5. Push the new bladeassembly securely on the
wiper arm until the release
lever clicks into place.
6. Start the engine and the rear wiper will return to its
normal position.
Windshield
Replacement
HUD System
If equipped, the windshield is
part of the HUD system. If the
windshield must be replaced,
get one that is designed for
HUD or the HUD image may
look out of focus.
Driver Assistance
Systems
When a windshield
replacement is needed and the
vehicle is equipped with a
front-looking camera sensor
for the Driver Assistance
Systems, the windshield must
be installed according to GM
specifications for these systems to work properly. If it
is not, there may be
unexpected behavior and/or
messages from these
systems.
Acoustic Windshield
The vehicle is equipped with
an acoustic windshield. If the
windshield needs to be
replaced, be sure to get an
acoustic windshield so you will
continue to have the benefits
an acoustic windshield can
provide.
Gas Strut(s)
Your vehicle may be equipped
with gas strut(s) to provide
assistance in lifting and
holding open the hood/trunk/
liftgate system in full open
position.
{Warning
If the gas struts that hold
open the hood, trunk, and/or
liftgate fail, you or others
(Continued)
Warning (Continued)
could be seriously injured.
Take the vehicle to your
dealer for service
immediately. Visually inspect
the gas struts for signs of
wear, cracks, or other
damage periodically. Check
to make sure the hood/
trunk/liftgate is held open
with enough force. If struts
are failing to hold the hood/
trunk/liftgate, do not
operate. Have the vehicle
serviced.
Caution
Do not apply tape or hang
any objects from gas struts.
Also do not push down or
pull on gas struts. This may
cause damage to the
vehicle.
See Maintenance Schedule
0 425.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 381
.There is cord or fabric
showing through the
tire's rubber.
.The tread or sidewall is
cracked, cut, or snagged
deep enough to show
cord or fabric.
.The tire has a bump,
bulge, or split.
.The tire has a puncture,
cut, or other damage that
cannot be repaired well
because of the size or
location of the damage.
Tire Rotation
Tires should be rotated
according to the interval
specified in the
Maintenance Schedule. See
Maintenance Schedule
0425. Tires are rotated to
achieve a more uniform
wear for all tires. The first
rotation is the most
important.
Anytime unusual wear is
noticed, rotate the tires as
soon as possible, check for
proper tire inflation
pressure, and check for
damaged tires or wheels.
If the unusual wear
continues after the
rotation, check the wheel
alignment. See When It Is
Time for New Tires
0382
and Wheel Replacement
0 387.
Use this rotation pattern
when rotating the tires.
Do not include the compact
spare tire in the tire
rotation.
Adjust the front and rear
tires to the recommended
inflation pressure on the
Tire and Loading
Information label after the
tires have been rotated.
See Tire Pressure 0372
and Vehicle Load Limits
0 242.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Service and Maintenance 423
Service and
Maintenance
General Information
General Information . . . . . . 423
Maintenance Schedule
MaintenanceSchedule . . . . . . . . . . . . . . . . . . . 425
Multi-Point Vehicle
Inspection (MPVI)
Multi-Point VehicleInspection (MPVI) . . . . . . . . 427
Special Application
Services
Special ApplicationServices . . . . . . . . . . . . . . . . . . . . 428
Recommended Fluids,
Lubricants, and Parts
Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . 429
Maintenance Replacement Parts . . . . . 430
Maintenance Records
Maintenance Records . . . . 431
General
Information
Your vehicle is an important
investment. This section
describes the required
maintenance for the vehicle.
Follow this schedule to help
protect against major repair
expenses resulting from
neglect or inadequate
maintenance. It may also help
to maintain the value of the
vehicle if it is sold. It is the
responsibility of the owner to
have all required maintenance
performed.
Your dealer has trained
technicians who can perform
required maintenance using
genuine replacement parts.
They have up-to-date tools
and equipment for fast and
accurate diagnostics. Many
dealers have extended
evening and Saturday hours,
courtesy transportation, and
online scheduling to assist
with service needs. Your dealer recognizes the
importance of providing
competitively priced
maintenance and repair
services. With trained
technicians, the dealer is the
place for routine maintenance
such as oil changes and tire
rotations and additional
maintenance items like tires,
brakes, batteries, and wiper
blades.
Caution
Damage caused by improper
maintenance can lead to
costly repairs and may not
be covered by the vehicle
warranty. Maintenance
intervals, checks,
inspections, recommended
fluids, and lubricants are
important to keep the
vehicle in good working
condition.
Do not have chemical
flushes that are not
approved by GM performed
(Continued)

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
424 Service and Maintenance
Caution (Continued)
on the vehicle. The use of
flushes, solvents, cleaners,
or lubricants that are not
approved by GM could
damage the vehicle,
requiring expensive repairs
that are not covered by the
vehicle warranty.
The Tire Rotation and
Required Services are the
responsibility of the vehicle
owner. It is recommended to
have your dealer perform
these services every
12 000 km/7,500 mi. Proper
vehicle maintenance helps to
keep the vehicle in good
working condition, improves
fuel economy, and reduces
vehicle emissions.
Because of the way people
use vehicles, maintenance
needs vary. There may need to
be more frequent checks and
services. The Additional
Required Services - Normal
are for vehicles that:
.Carry passengers and cargo
within recommended limits
on the Tire and Loading
Information label. See
Vehicle Load Limits 0242.
.Are driven on reasonable
road surfaces within legal
driving limits.
.Use the recommended fuel.
See Recommended Fuel
0310.
Refer to the information in the
Maintenance Schedule
Additional Required Services -
Normal Service.
The Additional Required
Services - Severe are for
vehicles that are:
.Mainly driven in heavy city
traffic in hot weather.
.Mainly driven in hilly or
mountainous terrain.
.Frequently towing a trailer.
.Used for high speed or
competitive driving.
.Used for taxi, police,
or delivery service. Refer to the information in the
Maintenance Schedule
Additional Required Services -
Severe Service.
{Warning
Performing maintenance
work can be dangerous and
can cause serious injury.
Perform maintenance work
only if the required
information, proper tools,
and equipment are available.
If they are not, see your
dealer to have a trained
technician do the work. See
Doing Your Own Service
Work
0328.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Service and Maintenance 425
Maintenance
Schedule
Tire Rotation and
Required Services Every
12 000 km (7,500 mi)
Tires are rotated to achieve a
more uniform wear for all tires.
The first rotation is the most
important.
Anytime unusual wear is
noticed, rotate the tires as
soon as possible, check for
proper tire inflation pressure,
and check for damaged tires
or wheels. If the unusual wear
continues after the rotation,
check the wheel alignment.
See When It Is Time for New
Tires0382 and
Wheel Replacement 0387.
.Perform Multi-Point Vehicle
Inspection. See Multi-Point
Vehicle Inspection (MPVI)
0427.
.Lubricate body components.
See Exterior Care 0412.
Additional Required
Services —Normal
Service
Every 12 000 km (7,500 mi)
.Check engine oil level and oil
life percentage. If needed,
change engine oil and filter,
and reset oil life system. Or
when the CHANGE ENGINE
OIL SOON message displays,
have the engine oil and filter
changed within the next
1 000 km (600 mi). If driven
under the best conditions,
the engine oil life system
may not indicate the need
for vehicle service for up to
a year. The engine oil and
filter must be changed at
least once a year and the oil
life system must be reset.
Your trained dealer
technician can perform this
work. If the engine oil life
system is reset accidentally,
service the vehicle within
5 000 km (3,000 mi) since
the last service. Reset the oil life system when the oil is
changed. See Engine Oil Life
System
0335.
.When the REPLACE AT
NEXT OIL CHANGE
message displays, the engine
air filter should be replaced
at the next engine oil
change. When the REPLACE
ENGINE AIR FILTER SOON
message displays, the engine
air filter should be replaced
at the earliest convenience.
Reset the engine air filter life
system after the engine air
filter is replaced. See Engine
Air Filter Life System 0336.
Every 36 000 km (22,500 mi)
.Passenger compartment air
filter replacement (or every
24 months, whichever
occurs first). More frequent
replacement may be needed
if the vehicle is driven in
areas with heavy traffic,
poor air quality, areas with
high dust levels or are
sensitive to environmental
allergens. Filter replacement

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Service and Maintenance 431
Maintenance Records
After the scheduled services are performed, record the date, odometer reading, who performed
the service, and the type of services performed in the boxes provided. Retain all maintenance
receipts.Date Odometer
Reading Serviced By Maintenance
Stamp Services Performed

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
438 Customer Information
United States and
Puerto Rico
Cadillac Customer Assistance
Center
Cadillac Motor Car Division
P.O. Box 33169
Detroit, MI 48232-5169
1-800-458-8006
1-800-833-2622 (For Text
Telephone devices (TTYs))
Roadside Assistance:
1-800-224-1400
From U.S. Virgin Islands:
1-800-496-9994
Canada
Cadillac Customer Care
Centre
General Motors of Canada
Company
500 Wentworth Street W
Oshawa, ON L1J 0C5
1-888-446-2000 (English/
French)
Cadillac Roadside Assistance:
1-800-882-1112
Overseas
Contact the local General
Motors Business Unit.
Customer Assistance
for Text Telephone
(TTY) Users
To assist customers who are
deaf, hard of hearing,
or speech-impaired and who
use Text Telephones (TTYs),
Cadillac has TTY equipment
available at its Customer
Assistance Center. Any TTY
user can communicate with
Cadillac by dialing:
1-800-833-2622. TTY users in
Canada can dial
1-800-263-3830.
Online Account
Create a Cadillac Account
(U.S.) at cadillac.com
Learn more about your vehicle
features, shop for and manage
your connected services andOnStar plans, and access
diagnostic information specific
to your vehicle.
Membership Benefits
E:
Download owner’s
manuals and view
vehicle-specific how-to videos.
G: View maintenance
schedules, alerts, and Vehicle
Diagnostic Information.
Schedule service
appointments.
I: View service records from
your dealership and add
your own.
D: Select a dealer and view
locations, maps, phone
numbers, and hours.
r: Track your vehicle’s
warranty information.
J: View active recalls or
search by Vehicle
Identification Number (VIN).
See Vehicle Identification
Number (VIN) 0432.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
446 Customer Information
suspension, brakes, electrical
system, steering system,
body, etc.
Customer Literature
Owner’s manuals are written
specifically for owners and are
intended to provide basic
operational information about
the vehicle. The owner’s
manual includes the
Maintenance Schedule for all
models.
Customer literature
publications available for
purchase include owner’s
manuals, warranty manuals,
and portfolios. Portfolios
include an owner’s manual,
warranty manual, if applicable,
and zip lock bag or pouch.
Current and Past Models
Service manuals and customer
literature are available for
many current and past model
year GM vehicles.To order, call 1-800-551-4123
Monday–Friday, 8:00 a.m.–
6:00 p.m. Eastern Time
For credit card orders only
(VISA, MasterCard,
or Discover), see Helm, Inc. at:
www.helminc.com.
To order by mail, write to:
Helm, Incorporated
Attention: Customer Service
47911 Halyard Drive
Plymouth, MI 48170
Make checks payable in U.S.
funds.
Radio Frequency
Statement
This vehicle uses
license-exempt transmitters /
receivers / systems that
operate on a radio frequency
that complies with Part 15/
Part 18 of the Federal
Communications Commission
(FCC) rules and with
Innovation, Science andEconomic Development (ISED)
Canada's license-exempt
RSS(s) / RSP-100 / ICES-GEN.
Operation is subject to the
following two conditions:
1. The device may not cause harmful interference.
2. The device must accept any interference received,
including interference that
may cause undesired
operation of the device.
Changes or modifications to
any of these systems by other
than an authorized service
facility could void
authorization to use this
equipment.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
460 Connected Services
vehicles, Wi-Fi can also be
managed from the Wi-Fi
Hotspot menu.
MyCadillac Mobile App (If
Available)
Download the myCadillac
mobile app to compatible
Apple and Android
smartphones. Cadillac users
can access the following
services from a smartphone:
.Remotely start/stop the
vehicle, if factory-equipped.
.Lock/unlock doors,
if equipped with automatic
locks.
.Activate the horn and lamps.
.Check the vehicle fuel level,
oil life, or tire pressure,
if factory-equipped with the
Tire Pressure Monitor
System.
.Send destinations to the
vehicle.
.Locate the vehicle on a map
(U.S. market only).
.Turn the vehicle's Wi-Fi
hotspot on/off, manage
settings, and monitor data
consumption, if equipped.
.Locate a dealer and
schedule service.
.Request Roadside
Assistance.
.Set a parking reminder with
pin drop, take a photo, make
a note, and set a timer.
.Connect with Cadillac on
social media.
Features are subject to
change. For myCadillac mobile
app information and
compatibility, see
my.cadillac.com.
An active OnStar or
connected service plan may be
required. A compatible device,
factory-installed remote start,
and power locks are required.
Data rates apply. See
www.onstar.com for details
and system limitations.
Remote Services
Contact an OnStar Advisor to
unlock the doors or sound the
horn and flash the lamps.
Marketplace
OnStar Advisors can provide
offers from restaurants and
retailers on your route, help
locate hotels, or book a room.
These services vary by
market.
Diagnostics
By monitoring and reporting
on the vehicle’s key systems,
OnStar Advanced Diagnostics,
if equipped, provides a way
to keep up on maintenance.
Capabilities vary by model. See
www.onstar.com for details
and system limitations.
Features are subject to
change. For updates on
feature capabilities, see
my.cadillac.com. Message and
data rates may apply.
