Driving and Operating 325
manufacturers recommend
replacing tires more than six
years old.
Overloading is another leading
cause of trailer tire blow-outs.
Never load your trailer with
more weight than the tires are
designed to support. The load
rating is located on the trailer
tire sidewall.
Always know the maximum
speed rating for the trailer
tires before driving. This may
be significantly lower than the
vehicle tire speed rating. The
speed rating may be on the
trailer tire sidewall. If the
speed rating is not shown, the
default trailer tire speed rating
is 105 km/h (65 mph).Conversions and
Add-Ons
Add-On Electrical
Equipment
{Warning
The Data Link Connector
(DLC) is used for vehicle
service and Emission
Inspection/Maintenance
testing. See Malfunction
Indicator Lamp (Check
Engine Light)0126. A device
connected to the DLC —
such as an aftermarket fleet
or driver-behavior tracking
device —may interfere with
vehicle systems. This could
affect vehicle operation and
cause a crash. Such devices
may also access information
stored in the vehicle’s
systems.
Caution
Some electrical equipment
can damage the vehicle or
cause components to not
work and would not be
covered by the vehicle
warranty. Always check with
your dealer before adding
electrical equipment.
Add-on equipment can drain
the vehicle's 12-volt battery,
even if the vehicle is not
operating.
The vehicle has an airbag
system. Before attempting to
add anything electrical to the
vehicle, see Servicing the
Airbag-Equipped Vehicle 076
and Adding Equipment to the
Airbag-Equipped Vehicle 077.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
326 Vehicle Care
Vehicle Care
General Information
General Information . . . . . . 327
California PerchlorateMaterials
Requirements . . . . . . . . . . . . . 327
Accessories and Modifications . . . . . . . . . . . . . . 327
Vehicle Checks
Doing Your OwnService Work . . . . . . . . . . . . . . 328
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . 329
Engine Compartment Overview . . . . . . . . . . . . . . . . . . . . 331
Engine Oil . . . . . . . . . . . . . . . . . . . . 332
Engine Oil Life System . . . 335
Automatic Transmission Fluid . . . . . . . . . . . . . . . . . . . . . . . . . 336
Engine Air Filter Life System . . . . . . . . . . . . . . . . . . . . . . 336
Engine Air Cleaner/ Filter . . . . . . . . . . . . . . . . . . . . . . . . . 337
Cooling System . . . . . . . . . . . . 338
Engine Overheating . . . . . . 342
Washer Fluid . . . . . . . . . . . . . . . . 343
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 344
Brake Fluid . . . . . . . . . . . . . . . . . . 345 Battery - North
America . . . . . . . . . . . . . . . . . . . . . 346
All-Wheel Drive . . . . . . . . . . . . . 347
Park Brake and P (Park) Mechanism Check . . . . . . . 347
Wiper Blade Replacement . . . . . . . . . . . . . . 347
Windshield Replacement . . . . . . . . . . . . . . 349
Gas Strut(s) . . . . . . . . . . . . . . . . . 349Headlamp Aiming
Front Headlamp Aiming . . . . . . . . . . . . . . . . . . . . . . . 350
Bulb Replacement
Bulb Replacement . . . . . . . . 350
LED Lighting . . . . . . . . . . . . . . . . 350
Front Turn SignalLamps . . . . . . . . . . . . . . . . . . . . . . . 350
Back-Up Lamps . . . . . . . . . . . . . 351
Electrical System
Electrical System Overload . . . . . . . . . . . . . . . . . . . . 352
Fuses and Circuit Breakers . . . . . . . . . . . . . . . . . . . . 353
Engine Compartment Fuse Block . . . . . . . . . . . . . . . . . 354
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 360
Wheels and Tires
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . 364
All-Season Tires . . . . . . . . . . . 365
Winter Tires . . . . . . . . . . . . . . . . 366
Summer Tires . . . . . . . . . . . . . . 366
Tire Sidewall Labeling . . . . 367
Tire Designations . . . . . . . . . . 369
Tire Terminology andDefinitions . . . . . . . . . . . . . . . . . 370
Tire Pressure . . . . . . . . . . . . . . . 372
Tire Pressure for High-Speed
Operation . . . . . . . . . . . . . . . . . . 374
Tire Pressure Monitor System . . . . . . . . . . . . . . . . . . . . . . 375
Tire Pressure Monitor Operation . . . . . . . . . . . . . . . . . . 376
Tire Inspection . . . . . . . . . . . . . 380
Tire Rotation . . . . . . . . . . . . . . . . 381
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . . 382
Buying New Tires . . . . . . . . . 383
Different Size Tires and Wheels . . . . . . . . . . . . . . . . . . . . . . 385
Uniform Tire Quality Grading . . . . . . . . . . . . . . . . . . . . . 385
Wheel Alignment and Tire Balance . . . . . . . . . . . . . . . . . . . . . 387
Wheel Replacement . . . . . . 387
Tire Chains . . . . . . . . . . . . . . . . . . 388

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
332 Vehicle Care
1. Engine Air Cleaner/Filter0337.
2. Engine Oil Fill Cap. See Engine Oil 0332.
3. Engine Oil Dipstick. See Engine Oil 0332.
4. Engine Cooling Fan (Out of View). See Cooling System
0338.
5. Brake Fluid Reservoir. See Brake Fluid 0345.
6. Battery - North America 0346.
7. Engine Coolant Surge Tank and Pressure Cap. See
Cooling System 0338.
8. Positive (+) Battery Terminal (Under Cover).
See Jump Starting - North
America 0404.
9. Windshield Washer Fluid Reservoir. See Washer
Fluid 0343.
10. Engine Compartment Fuse Block 0354. 11. Remote Negative (-)
Battery Terminal. See
Jump Starting - North
America 0404.
Engine Oil
To ensure proper engine
performance and long life,
careful attention must be paid
to engine oil. Following these
simple, but important steps
will help protect your
investment:
.Use engine oil approved to
the proper specification and
of the proper viscosity
grade. See “Selecting the
Right Engine Oil” in this
section.
.Check the engine oil level
regularly and maintain the
proper oil level. See
“Checking Engine Oil” and
“When to Add Engine Oil” in
this section.
.Change the engine oil at the
appropriate time. See Engine
Oil Life System 0335.
.Always dispose of engine oil
properly. See “What to Do
with Used Oil” in this section.
Checking Engine Oil
Check the engine oil level
regularly, every 650 km
(400 mi), especially prior to a
long trip. The engine oil
dipstick handle is a loop. See
Engine Compartment
Overview0331 for the
location.
{Warning
The engine oil dipstick
handle may be hot; it could
burn you. Use a towel or
glove to touch the dipstick
handle.
If a low oil Driver Information
Center (DIC) message displays,
check the oil level.
Follow these guidelines:
.To get an accurate reading,
park the vehicle on level
ground. Check the engine oil
level after the engine has

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 333
been off for at least two
hours. Checking the engine
oil level on steep grades or
too soon after engine
shutoff can result in
incorrect readings. Accuracy
improves when checking a
cold engine prior to starting.
Remove the dipstick and
check the level.
.If unable to wait two hours,
the engine must be off for at
least 15 minutes if the
engine is warm, or at least
30 minutes if the engine is
not warm. Pull out the
dipstick, wipe it with a clean
paper towel or cloth, then
push it back in all the way.
Remove it again, keeping the
tip down, and check the
level.
When to Add Engine Oil
If the oil is below the
cross-hatched area at the tip
of the dipstick and the engine
has been off for at least
15 minutes, add 1 L (1 qt) of the
recommended oil and then
recheck the level. See
“Selecting the Right Engine
Oil”later in this section for an
explanation of what kind of oil
to use. For engine oil
crankcase capacity, see
Capacities and Specifications
0 433.
Caution
Do not add too much oil. Oil
levels above or below the
acceptable operating range
shown on the dipstick are
(Continued)
Caution (Continued)
harmful to the engine. If the
oil level is above the
operating range (i.e., the
engine has so much oil that
the oil level gets above the
cross-hatched area that
shows the proper operating
range), the engine could be
damaged. Drain the excess
oil or limit driving of the
vehicle, and seek a service
professional to remove the
excess oil.
See Engine Compartment
Overview 0331 for the
location of the engine oil
fill cap.
Add enough oil to put the level
somewhere in the proper
operating range. Push the
dipstick all the way back in
when through.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 335
bodies of water. Recycle it by
taking it to a place that
collects used oil.
Engine Oil Life
System
When to Change
Engine Oil
This vehicle has a computer
system that indicates when to
change the engine oil and
filter. This is based on a
combination of factors which
include engine revolutions,
engine temperature, and miles
driven. Based on driving
conditions, the mileage at
which an oil change is
indicated can vary
considerably. For the oil life
system to work properly, the
system must be reset every
time the oil is changed.
When the system has
calculated that oil life has been
diminished, it indicates that an
oil change is necessary.
A CHANGE ENGINE OILSOON message comes on.
Change the oil as soon as
possible within the next
1 000 km (600 mi). It is
possible that, if driving under
the best conditions, the oil life
system may indicate that an oil
change is not necessary for up
to a year. The engine oil and
filter must be changed at least
once a year and at this time
the system must be reset.
Your dealer has trained
service people who will
perform this work and reset
the system. It is also important
to check the oil regularly over
the course of an oil drain
interval and keep it at the
proper level.
If the system is ever reset
accidentally, the oil must be
changed at 5 000 km
(3,000 mi) since the last oil
change. Remember to reset
the oil life system whenever
the oil is changed.
How to Reset the Engine
Oil Life System
Reset the system whenever
the engine oil is changed so
that the system can calculate
the next engine oil change. To
reset the system:
1. Using the DIC controls on the right side of the
steering wheel, display
REMAINING OIL LIFE on
the DIC. See Driver
Information Center (DIC)
0136. When remaining oil
life is low, the CHANGE
ENGINE OIL SOON
message will appear on the
display.
2. Press
Von the DIC
controls and hold down for
a few seconds to clear the
CHANGE ENGINE OIL
SOON message and reset
the oil life at 100%.
Be careful not to reset the
oil life display accidentally
at any time other than
after the oil is changed.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
336 Vehicle Care
It cannot be reset
accurately until the next oil
change.
The system is reset when the
CHANGE ENGINE OIL SOON
message is off.
If the CHANGE ENGINE OIL
SOON message comes back
on when the vehicle is started,
the engine oil life system has
not been reset. Repeat the
procedure.
Automatic
Transmission Fluid
A transmission fluid leak is the
only reason for fluid loss. If a
leak occurs, take the vehicle to
your dealer and have it
repaired as soon as possible.
Caution
Use of the incorrect
automatic transmission fluid
may damage the vehicle, and
the damage may not be
covered by the vehicle (Continued)
Caution (Continued)
warranty. Always use the
correct automatic
transmission fluid. See
Recommended Fluids and
Lubricants0429.
See your dealer to have the
fluid and filter changed at the
intervals listed in the
Maintenance Schedule 0425.
Engine Air Filter Life
System
If equipped, this feature
provides the engine air filter's
remaining life and best timing
for a change. The timing to
change an engine air filter
depends on driving and
environmental conditions.
When to Change Engine
Air Filter
When the Driver Information
Center (DIC) displays a
message to replace the engine
air filter at the next oil change,
follow this timing.
When the DIC displays a
message to replace the engine
air filter soon, replace the
engine air filter at the earliest
convenience. The system must
be reset after the engine air
filter is changed.
If the DIC displays a message
to check the engine air filter
system, see your dealer.
How to Reset Engine Air
Filter Life System
To reset:
1. Place the vehicle in P (Park).
2. Display the Air Filter Life on the DIC. See Driver
Information Center (DIC)
0136.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 339
{Warning
Do not touch heater or
radiator hoses, or other
engine parts. They can be
very hot and can burn you.
Do not run the engine if
there is a leak; all coolant
could leak out. That could
cause an engine fire and can
burn you. Fix any leak before
driving the vehicle.
Engine Coolant
The engine cooling system in
the vehicle is filled with
DEX-COOL engine coolant
mixture. This coolant needs to
be checked and changed at
appropriate levels. See
Recommended Fluids and
Lubricants0429 and
Maintenance Schedule 0425.
The following explains the
cooling system and how to
check and add coolant when it
is low. If there is a problem
with engine overheating, see
Engine Overheating 0342.
What to Use
{Warning
Do not touch heater or
radiator hoses, or other
engine parts. They can be
very hot and can burn you.
Do not run the engine if
there is a leak; all coolant
could leak out. That could
cause an engine fire and can
burn you. Fix any leak before
driving the vehicle.
Use a 50/50 mixture of clean,
drinkable water and
DEX-COOL coolant. This
mixture:
.Gives freezing protection
down to −37 °C (−34 °F),
outside temperature.
.Gives boiling protection up
to 129 °C (265 °F), engine
temperature.
.Protects against rust and
corrosion.
.Will not damage aluminum
parts.
.Helps keep the proper
engine temperature.
Caution
Do not use anything other
than a mix of DEX-COOL
coolant that meets GM
Standard GMW3420 and
clean, drinkable water.
Anything else can cause
damage to the engine
cooling system and the
vehicle, which would not be
covered by the vehicle
warranty.
Never dispose of engine
coolant by putting it in the
trash, pouring it on the
ground, or pouring into
sewers, streams, or bodies of
water. Have the coolant
changed by an authorized
service center, familiar with
legal requirements regarding
used coolant disposal. This will
help protect the environment
and your health.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
340 Vehicle Care
Checking Coolant
The vehicle must be on a level
surface when checking the
coolant level.
Check to see if coolant is
visible in the coolant surge
tank. If the coolant inside the
coolant surge tank is boiling,
do not do anything else until it
cools down. If coolant is visible
but the coolant level mark is
not at or above the indicated
mark, add a 50/50 mixture of
clean, drinkable water and
DEX-COOL coolant. Be surethe cooling system is cool
before this is done. See
Engine Overheating
0342.
The coolant surge tank is in
the engine compartment on
the driver side of the vehicle.
See Engine Compartment
Overview 0331.
How to Add Coolant to the
Surge Tank
{Warning
Spilling coolant on hot
engine parts can burn you.
Coolant contains ethylene
glycol and it will burn if the
engine parts are hot enough.
{Warning
Steam and scalding liquids
from a hot cooling system
are under pressure. Turning
the pressure cap, even a
little, can cause them to
come out at high speed and
(Continued)
Warning (Continued)
you could be burned. Never
turn the cap when the
cooling system, including the
pressure cap, is hot. Wait for
the cooling system and
pressure cap to cool.
Caution
Failure to follow the specific
coolant fill procedure could
cause the engine to
overheat and could cause
system damage. If coolant is
not visible in the surge tank,
contact your dealer.
The coolant surge tank
pressure cap can be removed
when the cooling system,
including the surge tank
pressure cap and upper
radiator hose, is no longer hot.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 341
1. Turn the pressure capslowly counterclockwise.
If a hiss is heard, wait for
that to stop. A hiss means
there is still some
pressure left.
2. Keep turning the pressure cap slowly and remove it.
3. If topping off the level inthe coolant surge tank, add
the proper mixture until
the level reaches the mark
on the front of the tank
and replace the cap.
Operate the vehicle.
Repeat steps 1–3, as
necessary.
If filling the system (such
as after servicing), follow
the Automatic Coolant
Service Fill Instructions.
Caution
If the pressure cap is not
tightly installed, coolant loss
and engine damage may
occur. Be sure the cap is
properly and tightly secured.
Automatic Coolant
Service Fill Instructions
This feature assists in filling
and removing air from the
cooling system after service of
components or when coolant
is added after being too low. To activate the fill and air
removal process:
1. With a cold system, add coolant to the indicated
mark on the surge tank.
2. Replace the cap on the surge tank.
3. Connect the vehicle to a battery charger.
4. Turn the ignition to Service Mode. See Ignition
Positions 0247.
5. Turn off the air conditioning.
6. Set the parking brake.
7. At the same time, press the accelerator and the
brake for automatic
transmission vehicles for
two seconds, then release.
At the end of the cycle, check
the coolant level in the surge
tank and add coolant if it is
low. Turn off the vehicle, allow
the Electronic Control Module
(ECM) to go to sleep, about
2 minutes, and repeat
Steps 3-7.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
342 Vehicle Care
Listen for pump activation and
movement of the control
valves while watching the level
of the coolant in the surge
tank. If the tank empties, turn
the ignition off, carefully
remove the surge tank cap,
refill to the indicated mark, and
repeat Steps 3-6. The fill and
air removal process will run for
approximately 10 minutes.
Engine Overheating
The vehicle has several
indicators to warn of the
engine overheating.
There is an engine coolant
temperature gauge on the
instrument cluster. See Engine
Coolant Temperature Gauge
0123. The vehicle may also
display a message on the
Driver Information
Center (DIC).
If the decision is made not to
lift the hood when this
warning appears, get service
help right away. See Roadside
Assistance Program 0439. If the decision is made to lift
the hood, make sure the
vehicle is parked on a level
surface. Then check to see if
the engine cooling fan is
running. If the engine is
overheating, the fan should be
running. If it is not, do not
continue to run the engine.
Have the vehicle serviced.
Caution
Do not run the engine if
there is a leak in the engine
cooling system. This can
cause a loss of all coolant
and can damage the system
and vehicle. Have any leaks
fixed right away.
If Steam Is Coming from
the Engine Compartment
{Warning
Steam and scalding liquids
from a hot cooling system
are under pressure. Turning
the pressure cap, even a
(Continued)
Warning (Continued)
little, can cause them to
come out at high speed and
you could be burned. Never
turn the cap when the
cooling system, including the
pressure cap, is hot. Wait for
the cooling system and
pressure cap to cool.
If No Steam Is Coming
from the Engine
Compartment
If an engine overheat warning
is displayed but no steam can
be seen or heard, the problem
may not be too serious.
Sometimes the engine can get
a little too hot when the
vehicle:
.Climbs a long hill on a
hot day.
.Stops after high-speed
driving.
.Idles for long periods in
traffic.
