Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146119) - 2019 - crc - 7/27/18
VEHICLE CARE 329
dark spots etched into the paint
surface. See“Finish Care”previously in
this section.
Interior Care
To prevent dirt particle abrasions,
regularly clean the vehicle's interior.
Immediately remove any soils.
Newspapers or dark garments can
transfer color to the vehicle’s interior.
Use a soft bristle brush to remove
dust from knobs and crevices on the
instrument cluster. Using a mild soap
solution, immediately remove hand
lotions, sunscreen, and insect
repellent from all interior surfaces or
permanent damage may result.
Use cleaners specifically designed for
the surfaces being cleaned to prevent
permanent damage. Apply all cleaners
directly to the cleaning cloth. Do not
spray cleaners on any switches or
controls. Remove cleaners quickly.
Before using cleaners, read and follow
all safety instructions on the label.
While cleaning the interior, open the
doors and windows to get proper
ventilation. To prevent damage, do not clean the
interior using the following cleaners
or techniques:
.
Never use a razor or any other
sharp object to remove soil from
any interior surface.
. Never use a brush with stiff
bristles.
. Never rub any surface aggressively
or with too much pressure.
. Do not use laundry detergents or
dishwashing soaps with
degreasers. For liquid cleaners, use
approximately 20 drops per 3.8 L
(1 gal) of water. A concentrated
soap solution will create streaks
and attract dirt. Do not use
solutions that contain strong or
caustic soap.
. Do not heavily saturate the
upholstery when cleaning.
. Do not use solvents or cleaners
containing solvents.
Interior Glass
To clean, use a terry cloth fabric
dampened with water. Wipe droplets
left behind with a clean dry cloth.
If necessary, use a commercial glass
cleaner after cleaning with plain water.
Caution
To prevent scratching, never use
abrasive cleaners on automotive
glass. Abrasive cleaners or
aggressive cleaning may damage
the rear window defogger.
Cleaning the windshield with water
during the first three to six months of
ownership will reduce tendency to fog.
Speaker Covers
Vacuum around a speaker cover
gently, so that the speaker will not be
damaged. Clean spots with water and
mild soap.

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146119) - 2019 - crc - 7/27/18
330 VEHICLE CARE
Coated Moldings
Coated moldings should be cleaned.
.When lightly soiled, wipe with a
sponge or soft, lint-free cloth
dampened with water.
. When heavily soiled, use warm
soapy water.
Fabric/Carpet/Suede
Start by vacuuming the surface using
a soft brush attachment. If a rotating
vacuum brush attachment is being
used, only use it on the floor carpet.
Before cleaning, gently remove as
much of the soil as possible:
.Gently blot liquids with a paper
towel. Continue blotting until no
more soil can be removed.
. For solid soils, remove as much as
possible prior to vacuuming.
To clean: 1. Saturate a clean, lint-free colorfast cloth with water.
Microfiber cloth is recommended
to prevent lint transfer to the
fabric or carpet. 2. Remove excess moisture by
gently wringing until water does
not drip from the cleaning cloth.
3. Start on the outside edge of the soil and gently rub toward the
center. Fold the cleaning cloth to
a clean area frequently to
prevent forcing the soil in to the
fabric.
4. Continue gently rubbing the soiled area until there is no
longer any color transfer from
the soil to the cleaning cloth.
5. If the soil is not completely removed, use a mild soap
solution followed only by plain
water.
If the soil is not completely removed,
it may be necessary to use a
commercial upholstery cleaner or spot
lifter. Test a small hidden area for
colorfastness before using a
commercial upholstery cleaner or spot
lifter. If ring formation occurs, clean
the entire fabric or carpet.
After cleaning, use a paper towel to
blot excess moisture.
Cleaning High Gloss Surfaces
and Vehicle Information and
Radio Displays
Use a microfiber cloth on high gloss
surfaces or vehicle displays. First, use
a soft bristle brush to remove dirt that
can scratch the surface. Then gently
clean by rubbing with a microfiber
cloth. Never use window cleaners or
solvents. Periodically hand wash the
microfiber cloth separately, using mild
soap. Do not use bleach or fabric
softener. Rinse thoroughly and air dry
before next use.
Caution
Do not attach a device with a
suction cup to the display. This may
cause damage and would not be
covered by the vehicle warranty.

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146119) - 2019 - crc - 7/27/18
338 SERVICE AND MAINTENANCE
Footnotes—Maintenance Schedule
Additional Required Services -
Normal
(1) Or every two years, whichever
comes first. More frequent passenger
compartment air filter replacement
may be needed if driving in areas with
heavy traffic, poor air quality, high
dust levels, or environmental
allergens. Passenger compartment air
filter replacement may also be needed
if there is reduced airf low, window
fogging, or odors. Your GM dealer can
help determine when to replace the
filter.
(2) Visually check all fuel and vapor
lines and hoses for proper attachment,
connection, routing, and condition.
(3) Or every four years, whichever
comes first. If driving in dusty
conditions, inspect the filter at each
oil change or more often as needed.
(4) Or every five years, whichever
comes first. See Cooling System0262.
(5) Or every 10 years, whichever
comes first. Inspect for fraying,
excessive cracking, or damage; replace,
if needed. (6)
Replace brake fluid every five
years. See Brake Fluid 0268.
(7) Or every 12 months, whichever
comes first. See Wiper Blade
Replacement 0271.

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146119) - 2019 - crc - 7/27/18
SERVICE AND MAINTENANCE 339
Maintenance Schedule
Additional Required Services -
Severe12 000 km/7,500 mi
24 000 km/15,000 mi
36 000 km/22,500 mi
48 000 km/30,000 mi
60 000 km/37,500 mi
72 000 km/45,000 mi
84 000 km/52,500 mi
96 000 km/60,000 mi
108 000 km/67,500 mi
120 000 km/75,000 mi
132 000 km/82,500 mi
144 000 km/90,000 mi
156 000 km/97,500 mi
168 000 km/105,000 mi
180 000 km/112,500 mi
192 000 km/120,000 mi
204 000 km/127,500 mi
216 000 km/135,000 mi
228 000 km/142,500 mi
240 000 km/150,000 mi
Rotate tires and perform Required Services. Check
engine oil level and oil life percentage. Change
engine oil and filter, if needed.@ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @
Replace passenger compartment air filter. (1)@ @@@@@
Inspect evaporative control system. (2)@ @@
Replace engine air cleaner filter. (3)@@@
Change automatic transmission fluid.@@@
Replace spark plugs. Inspect spark plug wires.@
Drain and fill engine cooling system. (4)@
Visually inspect accessory drive belts. (5)@
Replace brake fluid. (6)
Replace windshield wiper blades. (7)
@ @ @ @ @ @ @ @ @ @
Replace hood and/or body lift support gas struts.@ @
Footnotes—Maintenance Schedule
Additional Required Services -
Severe
(1) Or every two years, whichever
comes first. More frequent passenger
compartment air filter replacement
may be needed if driving in areas with heavy traffic, poor air quality, high
dust levels, or environmental
allergens. Passenger compartment air
filter replacement may also be needed
if there is reduced airf low, window
fogging, or odors. Your GM dealer can
help determine when to replace the
filter.
(2)
Visually check all fuel and vapor
lines and hoses for proper attachment,
connection, routing, and condition.

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146119) - 2019 - crc - 7/27/18
INDEX 383
Power (cont'd)Protection, Battery . . . . . . . . . . . . . . . . 165
Retained Accessory (RAP) . . . . . . . . 192
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Pregnancy, Using Seat Belts . . . . . . . . . 74
Privacy Vehicle Data Recording . . . . . . . . . . 361
Program Courtesy Transportation . . . . . . . . . 356
Prohibited Fuels . . . . . . . . . . . . . . . . . . . . 237
Proposition 65 Warning,
California . . . . . . . . . . . . . . .254, 269, 319, Back Cover
Publication Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . 359
R
Radio Frequency Statement . . . . . . . . 359
Reading Lamps . . . . . . . . . . . . . . . . . . . . . 164
Rear Camera Mirror . . . . . . . . . . . . . . . . . 50
Rear Climate Control System . . . . . . 172
Rear Seat Armrest . . . . . . . . . . . . . . . . . . . 67
Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65Heated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Rear Storage . . . . . . . . . . . . . . . . . . . . . . . . 107
Rear Vision Camera (RVC) . . . . . . . . . 220
Rear Window Washer/Wiper . . . . . . . 116 Rearview Mirrors . . . . . . . . . . . . . . . . . . . . 50
Automatic Dimming . . . . . . . . . . . . . . . . 50
Reclining Seatbacks . . . . . . . . . . . . . . . . . 60
Recommended Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237
Recommended Fluids and Lubricants . . . . . . . . . . . . . . . . . . . . . . . . . 343
Records Maintenance . . . . . . . . . . . . . . . . . . . . . . 345
Recreational Vehicle Towing . . . . . . . 322
Reimbursement Program, GM Mobility . . . . . . . . . . . . . . . . . . . . . . . . . . . . 353
Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Remote Vehicle Start . . . . . . . . . . . . . . . . 33
Replacement Parts Airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Maintenance . . . . . . . . . . . . . . . . . . . . . . 344
Replacing Airbag System . . . . . . . . . . . . 88
Replacing LATCH System Parts after a Crash . . . . . . . . . . . . . . . . . . . . . . . 100
Replacing Seat Belt System Parts after a Crash . . . . . . . . . . . . . . . . . 76
Reporting Safety Defects Canadian Government . . . . . . . . . . . . 360
General Motors . . . . . . . . . . . . . . . . . . . 361
U.S. Government . . . . . . . . . . . . . . . . . . 360 Restraints
Where to Put . . . . . . . . . . . . . . . . . . . . . . . . 94
Retained Accessory Power (RAP) . . . . . . . . . . . . . . . . . . . . . . . 192
Reverse Tilt Mirrors . . . . . . . . . . . . . . . . . 49
Roads Driving, Wet . . . . . . . . . . . . . . . . . . . . . . . 180
Roadside Service . . . . . . . . . . . . . . . . . . . . 354
Roof Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Roof Rack System . . . . . . . . . . . . . . . . . . 111
Rotation, Tires . . . . . . . . . . . . . . . . . . . . . . 298
Routing, Engine Drive Belt . . . . . . . . . 349
Running the Vehicle While
Parked . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
S
Safety Defects ReportingCanadian Government . . . . . . . . . . . . 360
General Motors . . . . . . . . . . . . . . . . . . . 361
U.S. Government . . . . . . . . . . . . . . . . . . 360
Safety Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Safety System Check . . . . . . . . . . . . . . . . 75
Scheduling Appointments . . . . . . . . . . 356
Sealant Kit, Tire . . . . . . . . . . . . . . . . . . . . . 306
Seat Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68 Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146119) - 2019 - crc - 7/27/18
386 INDEX
Vehicle (cont'd)Speed Messages . . . . . . . . . . . . . . . . . . . 147
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 321
Vehicle Ahead Indicator . . . . . . . . . . . . 136
Vehicle Care
Storing the Tire Sealant andCompressor Kit . . . . . . . . . . . . . . . . . . 312
Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 291
Vehicle Data Recording and
Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 361
Ventilation, Air . . . . . . . . . . . . . . . . . . . . . 174
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Voltmeter Gauge . . . . . . . . . . . . . . . . . . . . 129
W
Warning Brake System Light . . . . . . . . . . . . . . . 134
Caution and Danger . . . . . . . . . . . . . . . . . 3
Lane Departure (LDW) . . . . . . . . . . . 235
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Warnings Hazard Flashers . . . . . . . . . . . . . . . . . . . 162
Washer Fluid . . . . . . . . . . . . . . . . . . . . . . . . 267
Wheels
Alignment and Tire Balance . . . . . 302
Different Size . . . . . . . . . . . . . . . . . . . . . . 301
Replacement . . . . . . . . . . . . . . . . . . . . . . 303 When It Is Time for New Tires . . . . 299
Where to Put the Restraint . . . . . . . . . 94
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Windshield Replacement . . . . . . . . . . . . . . . . . . . . . . 272
Wiper/Washer . . . . . . . . . . . . . . . . . . . . . 113
Winter Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
Winter Tires . . . . . . . . . . . . . . . . . . . . . . . . . 285
Wiper Blade Replacement . . . . . . . . . . 271
Wipers Rear Washer . . . . . . . . . . . . . . . . . . . . . . 116
Wireless Charging . . . . . . . . . . . . . . . . . . 118
