CADILLAC XT5 2023 Service Manual

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16406251) - 2023 - CRC - 3/25/22
40 Keys, Doors, and Windows
PressVto scroll through the
adjustment options.
Press
tanduto adjust the
settings using the indicators
on the mirror. The indicators
will remain visible for
five seconds after the last
button activation, and the
settings will remain saved. The adjustment options are:
.Brightness
.Zoom
.Tilt

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16406251) - 2023 - CRC - 3/25/22
Keys, Doors, and Windows 41
{Warning
The Rear Camera Mirror
(RCM) has a limited view.
Portions of the road,
vehicles, and other objects
may not be seen. Do not
drive or park the vehicle
using only this camera.
Objects may appear closer
than they are. Check the
outside mirrors or glance
over your shoulder when
making lane changes or
merging. Failure to use
proper care may result in
injury, death, or vehicle
damage.Troubleshooting
See your dealer for service if a
blue screen and
3are
displayed in the mirror, and
the display shuts off. Also,
push the tab as indicated to
return to the automatic
dimming mode.
The Rear Camera Mirror may
not work properly or display a
clear image if:
.There is glare from the sun
or headlamps. This may
obstruct objects from view.
If needed, push the tab to
turn off the display.
.Dirt, snow, or other debris
blocks the camera lens.
Clean the lens with a soft
damp cloth, or if equipped,
with the Rear Camera
Washer. See Rear Window
Wiper/Washer 0116.
.The camera’s mounting on
the vehicle has been
damaged, and/or the
position or the mounting
angle of the camera has
changed.

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16406251) - 2023 - CRC - 3/25/22
42 Keys, Doors, and Windows
Windows{
Warning
Never leave a child, a
helpless adult, or a pet alone
in a vehicle, especially with
the windows closed in warm
or hot weather. They can be
overcome by the extreme
heat and suffer permanent
injuries or even death from
heat stroke.
The vehicle aerodynamics are
designed to improve fuel
economy performance. This may result in a pulsing sound
when one window is down and
the other three are up. To
reduce the sound, open
another window or the
sunroof, if equipped.
Power Windows
{Warning
Children could be seriously
injured or killed if caught in
the path of a closing
window. Never leave the
remote key in a vehicle with
children. When there are
children in the rear seat, use
the window lockout switch
to prevent operation of the
windows. See Keys
08.
The power windows work
when the ignition is on, in
accessory mode, or when
Retained Accessory Power
(RAP) is active. See Retained
Accessory Power (RAP) 0258.
Using the window switch,
press to open or pull to close
the window.
The windows may be
temporarily disabled if they
are used repeatedly within a
short time.

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16406251) - 2023 - CRC - 3/25/22
Keys, Doors, and Windows 43
Window Lockout
This feature stops the rear
passenger window switches
from working.
.Press2to engage the rear
window lockout feature. The
indicator light is on when
engaged.
.Press2again to disengage.
Window Express
Movement
All windows can be opened
without holding the window
switch. Press the switch down
fully and quickly release to
express open the window.
If equipped, pull the window
switch up fully and quickly
release to express close the
window.
Briefly press or pull the
window switch in the same
direction to stop that
window’s express movement.
Window Automatic
Reversal System
The express-close feature will
reverse window movement if it
comes in contact with an
object. Extreme cold or ice
could cause the window to
auto-reverse. The window will
operate normally after the
object or condition is removed.
Automatic Reversal
System Override
{Warning
If automatic reversal system
override is active, the
window will not reverse
automatically. You or others
could be injured and the
window could be damaged.
Before using automatic
reversal system override,
make sure that all people
and obstructions are clear
of the window path.
When the engine is on,
override the automatic
reversal system by pulling and
holding the window switch if
conditions prevent it from
closing.
Programming the Power
Windows
Programming may be
necessary if the vehicle
battery has been
disconnected or discharged.

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16406251) - 2023 - CRC - 3/25/22
44 Keys, Doors, and Windows
If the window is unable to
express-up, program each
express-close window:1. Close all doors.
2. Turn the ignition on or to accessory mode.
3. Partially open the window to be programmed. Then
close it and continue to pull
the switch briefly after the
window has fully closed.
4. Open the window and continue to press the
switch briefly after the
window has fully opened.
Remote Window
Operation
If equipped, this feature allows
all windows to be opened
remotely. If enabled in vehicle
settings, press and hold
Kon
the remote key. To view
available settings for this
feature, touch the Settings
icon on the infotainment home
page. Select “Vehicle”to display the list of available
options and select
“Remote
Lock, Unlock, Start”.
Sun Visors
Pull the sun visor down to
block glare. Detach the sun
visor from the center mount to
pivot to the side window and,
if equipped, extend along
the rod.
Roof
Sunroof
If equipped, the ignition must
be on or in accessory mode,
or Retained Accessory Power
(RAP) must be active to operate the sunroof. See
Ignition Positions
0252 and
Retained Accessory Power
(RAP) 0258.
1. Sunroof Switch
2. Sunshade Switch
Sunroof Express Operation :
Press and release
e(1) to
vent. Press and release again
to move to the partially
opened comfort stop position.
Press and release again to
express-open to the fully
opened position. Press and
release
e(1) at any time to
stop movement. Press and

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16406251) - 2023 - CRC - 3/25/22
Keys, Doors, and Windows 45
releaseg(1) to
express-close. Press and
release
g(1) at any time to
stop movement.
Sunroof Comfort Stop
Position : This vehicle may be
equipped with a comfort stop
to prevent excessive wind
noise. The sunroof will stop
approximately halfway open
during and express open. To
fully open the sunroof, press
and release
g(1) again.
Sunroof Manual Operation :
The sunroof can change to
manual mode by holding
e(1)
while opening. The sunroof will
now open as long as
e(1) is
held. Press and release
e(1)
again to change back to
express operation.
Power Sunshade Express
Operation : Press and
release
C(2) to express-open
the sunshade. Press and
release
C(2) at any time to
stop movement. Press and release
Q(2) to
express-close the sunshade.
Press and release
Q(2) at
any time to stop movement.
Power Sunshade Manual
Operation : The sunshade can
change to manual mode by
holding
C(2) while opening.
The sunroof will now open as
long as
C(2) is held. Press and
release
C(2) again to change
back to express operation.
The sunroof cannot be opened
or closed if the vehicle has an
electrical failure.
Automatic Reversal
System
The sunroof and power
sunshade have an automatic
reversal system that is only
active when the sunroof and
power sunshade, if equipped,
are operated in
express-close mode. If an object is in the path while
express-closing, the reversal
system will detect an object,
stop, and open the sunroof or
power sunshade slightly.
If frost or other conditions
prevent closing, override the
feature by closing the sunroof
or power sunshade in manual
mode. To stop movement,
release the switch.
Dirt and debris may collect on
the sunroof seal or in the
track. This could cause an
issue with sunroof operation
or noise. It could also plug the
water drainage system.

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16406251) - 2023 - CRC - 3/25/22
46 Keys, Doors, and Windows
Periodically open the sunroof
and remove any obstacles or
loose debris. Wipe the sunroof
seal and roof sealing area
using a clean cloth, mild soap,
and water. Do not remove
grease from the sunroof.

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16406251) - 2023 - CRC - 3/25/22
Seats and Restraints 47
Seats and
Restraints
Head Restraints
Head Restraints . . . . . . . . . . . . . 48
Front Seats
Seat Adjustment . . . . . . . . . . . . 49
Reclining Seatbacks . . . . . . . . 50
Lumbar Adjustment . . . . . . . . . 51
Memory Seats . . . . . . . . . . . . . . . . 51
Heated and VentilatedFront Seats . . . . . . . . . . . . . . . . . 54
Rear Seats
Rear Seats . . . . . . . . . . . . . . . . . . . . 56
Rear Seat Armrest . . . . . . . . . . 59
Heated Rear Seats . . . . . . . . . 59
Seat Belts
Seat Belts . . . . . . . . . . . . . . . . . . . . . 60
How to Wear Seat BeltsProperly . . . . . . . . . . . . . . . . . . . . . . . 61
Lap-Shoulder Belt . . . . . . . . . . 63
Seat Belt Use During Pregnancy . . . . . . . . . . . . . . . . . . . 67
Seat Belt Extender . . . . . . . . . 67
Safety System Check . . . . . . 67
Seat Belt Care . . . . . . . . . . . . . . . 68 Replacing Seat Belt
System Parts after a
Crash . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Airbag System
Airbag System . . . . . . . . . . . . . . . 69
Where Are the Airbags? . . . 71
When Should an AirbagInflate? . . . . . . . . . . . . . . . . . . . . . . . . 72
What Makes an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 73
How Does an Airbag Restrain? . . . . . . . . . . . . . . . . . . . . . 73
What Will You See after an Airbag Inflates? . . . . . . . . . . . . 74
Passenger Sensing System . . . . . . . . . . . . . . . . . . . . . . . . 75
Servicing the Airbag-Equipped
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . 79
Adding Equipment to the Airbag-Equipped
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . 80
Airbag System Check . . . . . . . 81
Replacing Airbag System Parts after a Crash . . . . . . . . 81
Child Restraints
Older Children . . . . . . . . . . . . . . . . 82
Infants and YoungChildren . . . . . . . . . . . . . . . . . . . . . . 83 Child Restraint
Systems . . . . . . . . . . . . . . . . . . . . . . 86
Where to Put the Restraint . . . . . . . . . . . . . . . . . . . . . 88
Lower Anchors and
Tethers for Children
(LATCH System) . . . . . . . . . . . 90
Replacing LATCH System Parts After a Crash . . . . . . . 97
Securing Child Restraints (With the Seat Belt in the
Rear Seat) . . . . . . . . . . . . . . . . . . . 97
Securing Child Restraints (With the Seat Belt in the
Front Seat) . . . . . . . . . . . . . . . . . . 99

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16406251) - 2023 - CRC - 3/25/22
48 Seats and Restraints
Head Restraints
The vehicle’s front seats have
adjustable head restraints in
the outboard seating
positions.
{Warning
With head restraints that
are not installed and
adjusted properly, there is a
greater chance that
occupants will suffer a neck/
spinal injury in a crash. Do
not drive until the head
restraints for all occupants
are installed and adjusted
properly.
If your vehicle has rear head
restraints that fold down,
always return them to the
full upright position
whenever an occupant is
seated in the seat.
Adjust the head restraint so
that the top of the restraint is
at the same height as the top
of the occupant's head. This
position reduces the chance of
a neck injury in a crash.
Front Seats
The vehicle's front seats have
adjustable head restraints in
the outboard seating
positions.
The height of the head
restraint can be adjusted.
To raise or lower the head
restraint, press the button
located on the side of the
head restraint and pull up or
push the head restraint down,
and release the button. Pull
and push on the head restraint
after the button is released to
make sure that it is locked in
place.
The front seat outboard head
restraints are not removable.

Cadillac XT5 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16406251) - 2023 - CRC - 3/25/22
Seats and Restraints 49
Rear Seats
Rear Head Restraint
Adjustment
The vehicle's rear seats have
adjustable head restraints in
the outboard seating
positions.
The height of the head
restraint can be adjusted. Pull
the head restraint up to raise
it. Try to move the head
restraint to make sure that it
is locked in place.
To lower the head restraint,
press the button, located on
the top of the seatback, andpush the head restraint down.
Try to move the head restraint
after the button is released to
make sure that it is locked in
place.
Always adjust the head
restraint so that the top of the
restraint is at the same height
as the top of the
occupant's head.
Rear outboard head restraints
are not removable.
Front Seats
Seat Adjustment
{Warning
You can lose control of the
vehicle if you try to adjust a
driver seat while the vehicle
is moving. Adjust the driver
seat only when the vehicle is
not moving.
{Warning
The power seats will work
with the ignition off. Children
could operate the power
seats and be injured. Never
leave children alone in the
vehicle.
To adjust a power seat:
.Move the seat forward or
rearward by sliding the
control forward or rearward.
.Raise or lower the front part
of the seat cushion by
moving the front of the
control up or down.
