check engine CADILLAC XTS 2019 Owner's Guide

Cadillac XTS Owner Manual (GMNA-Localizing-U.S./Canada-12032610) -
2019 - crc - 8/22/18
322 SERVICE AND MAINTENANCE
Proper vehicle maintenance helps to
keep the vehicle in good working
condition, improves fuel economy, and
reduces vehicle emissions.
Because of the way people use
vehicles, maintenance needs vary.
There may need to be more frequent
checks and services. The Additional
Required Services - Normal are for
vehicles that:
.Carry passengers and cargo within
recommended limits on the Tire
and Loading Information label. See
Vehicle Load Limits 0179.
. Are driven on reasonable road
surfaces within legal driving limits.
. Use the recommended fuel.
See Recommended Fuel (LFX 3.6L
V6 Engine) 0226 orRecommended
Fuel (LF3 3.6L Twin Turbo
V6 Engine) 0226.
Refer to the information in the
Maintenance Schedule Additional
Required Services - Normal chart. The Additional Required Services -
Severe are for vehicles that are:
.
Mainly driven in heavy city traffic
in hot weather
. Mainly driven in hilly or
mountainous terrain
. Frequently towing a trailer
. Used for high speed or competitive
driving
. Used for taxi, police, or delivery
service
Refer to the information in the
Maintenance Schedule Additional
Required Services - Severe chart.
{Warning
Performing maintenance work can
be dangerous and can cause serious
injury. Perform maintenance work
only if the required information,
proper tools, and equipment are
available. If they are not, see your
dealer to have a trained technician
do the work. See Doing Your Own
Service Work 0238.
Maintenance Schedule
Owner Checks and Services
At Each Fuel Stop
.
Check the engine oil level. See
Engine Oil 0244.
Once a Month
. Check the tire inflation pressures.
See Tire Pressure 0279.
. Inspect the tires for wear. See Tire
Inspection 0285.
. Check the windshield washer fluid
level. See Washer Fluid 0256.
Engine Oil Change
When the CHANGE ENGINE OIL
SOON message displays, have the
engine oil and filter changed within
the next 1 000 km/600 mi. If driven
under the best conditions, the engine
oil life system may not indicate the
need for vehicle service for up to a
year. The engine oil and filter must be
changed at least once a year and the
oil life system must be reset. Your
trained dealer technician can perform
this work. If the engine oil life system

Cadillac XTS Owner Manual (GMNA-Localizing-U.S./Canada-12032610) -
2019 - crc - 8/22/18
SERVICE AND MAINTENANCE 323
is reset accidentally, service the
vehicle within 5 000 km/3,000 mi since
the last service. Reset the oil life
system when the oil is changed. See
Engine Oil Life System0246.
Air Conditioning Desiccant
(Replace Every Seven Years)
The air conditioning system requires
maintenance every seven years. This
service requires replacement of the
desiccant to help the longevity and
efficient operation of the air
conditioning system. This service can
be complex. See your dealer.
Tire Rotation and Required
Services Every 12 000 km/
7,500 mi
Rotate the tires, if recommended for
the vehicle, and perform the following
services. See Tire Rotation0285.
. Check engine oil level and oil
life percentage. If needed, change
engine oil and filter, and reset oil
life system.
See Engine Oil 0244 and Engine Oil
Life System 0246. .
Check engine coolant level. See
Cooling System 0250.
. Check windshield washer fluid
level. See Washer Fluid 0256.
. Check tire inflation pressures. See
Tire Pressure 0279.
. Inspect tire wear. See Tire
Inspection 0285.
. Visually check for fluid leaks.
. Inspect engine air cleaner filter.
See Engine Air Cleaner/Filter 0248.
. Inspect brake system. See Exterior
Care 0312.
. Visually inspect steering,
suspension, and chassis
components for damage, including
cracks or tears in the rubber boots,
loose or missing parts, or signs of
wear at least once a year. See
Exterior Care 0312.
. Inspect power steering for proper
attachment, connections, binding,
leaks, cracks, chafing, etc. .
Visually inspect halfshafts and
drive shafts for excessive wear,
lubricant leaks, and/or damage
including: tube dents or cracks,
constant velocity joint or universal
joint looseness, cracked or missing
boots, loose or missing boot
clamps, center bearing excessive
looseness, loose or missing
fasteners, and axle seal leaks.
. Check restraint system
components. See Safety System
Check 075.
. Visually inspect fuel system for
damage or leaks.
. Visually inspect exhaust system
and nearby heat shields for loose
or damaged parts.
. Lubricate body components. See
Exterior Care 0312.
. Check starter switch. See Starter
Switch Check 0259.

Cadillac XTS Owner Manual (GMNA-Localizing-U.S./Canada-12032610) -
2019 - crc - 8/22/18
SERVICE AND MAINTENANCE 325
Maintenance Schedule
Additional Required Services -
Normal12 000 km/7,500 mi
24 000 km/15,000 mi
36 000 km/22,500 mi
48 000 km/30,000 mi
60 000 km/37,500 mi
72 000 km/45,000 mi
84 000 km/52,500 mi
96 000 km/60,000 mi
108 000 km/67,500 mi
120 000 km/75,000 mi
132 000 km/82,500 mi
144 000 km/90,000 mi
156 000 km/97,500 mi
168 000 km/105,000 mi
180 000 km/112,500 mi
192 000 km/120,000 mi
204 000 km/127,500 mi
216 000 km/135,000 mi
228 000 km/142,500 mi
240 000 km/150,000 mi
Rotate tires and perform Required Services. Check
engine oil level and oil life percentage. Change
engine oil and filter, if needed.@ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @
Replace passenger compartment air filter. (1)@ @@@@@
Inspect evaporative control system. (2)@ @@
Replace engine air cleaner filter. (3)@@@
Replace spark plugs. Inspect ignition coils. (3.6L LFX
V6 engine)@
Replace spark plugs. Inspect ignition coils. (3.6L LF3
twin turbo V6 engine)@ @
Replace rear axle fluid, if equipped with limited-slip
differential.@@@
Replace rear axle fluid, except limited-slip
differential.@
Drain and fill engine cooling system. (4)@
Visually inspect accessory drive belts. (5)@
Replace brake fluid. (6)
Replace windshield wiper blades. (7)
@ @ @ @ @ @ @ @ @ @
Replace hood and/or body lift support gas struts.@ @

Cadillac XTS Owner Manual (GMNA-Localizing-U.S./Canada-12032610) -
2019 - crc - 8/22/18
SERVICE AND MAINTENANCE 327
Maintenance Schedule
Additional Required Services -
Severe12 000 km/7,500 mi
24 000 km/15,000 mi
36 000 km/22,500 mi
48 000 km/30,000 mi
60 000 km/37,500 mi
72 000 km/45,000 mi
84 000 km/52,500 mi
96 000 km/60,000 mi
108 000 km/67,500 mi
120 000 km/75,000 mi
132 000 km/82,500 mi
144 000 km/90,000 mi
156 000 km/97,500 mi
168 000 km/105,000 mi
180 000 km/112,500 mi
192 000 km/120,000 mi
204 000 km/127,500 mi
216 000 km/135,000 mi
228 000 km/142,500 mi
240 000 km/150,000 mi
Rotate tires and perform Required Services. Check
engine oil level and oil life percentage. Change
engine oil and filter, if needed.@ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @
Replace passenger compartment air filter. (1)@ @@@@@
Inspect evaporative control system. (2)@ @@
Replace engine air cleaner filter. (3)@@@
Change automatic transmission fluid.@@@
Replace spark plugs. Inspect ignition coils. (3.6L LFX
V6 engine)@
Replace spark plugs. Inspect ignition coils. (3.6L LF3
twin turbo V6 engine)@ @
Replace rear axle fluid, if equipped with limited-slip
differential.@@@
Replace rear axle fluid, except limited-slip
differential.@ @
Drain and fill engine cooling system. (4)@
Visually inspect accessory drive belts. (5)@
Replace brake fluid. (6)
Replace windshield wiper blades. (7)
@ @ @ @ @ @ @ @ @ @
Replace hood and/or body lift support gas struts.@@

Cadillac XTS Owner Manual (GMNA-Localizing-U.S./Canada-12032610) -
2019 - crc - 8/22/18
SERVICE AND MAINTENANCE 329
Additional Maintenance
and Care
Your vehicle is an important
investment and caring for it properly
may help to avoid future costly
repairs. To maintain vehicle
performance, additional maintenance
services may be required.
It is recommended that your dealer
perform these services—their trained
dealer technicians know your vehicle
best. Your dealer can also perform a
thorough assessment with a
multi-point inspection to recommend
when your vehicle may need
attention.
The following list is intended to
explain the services and conditions to
look for that may indicate services are
required.
Battery
The 12-volt battery supplies power to
start the engine and operate any
additional electrical accessories. .
To avoid break-down or failure to
start the vehicle, maintain a
battery with full cranking power.
. Trained dealer technicians have
the diagnostic equipment to test
the battery and ensure that the
connections and cables are
corrosion-free.
Belts
. Belts may need replacing if they
squeak or show signs of cracking
or splitting.
. Trained dealer technicians have
access to tools and equipment to
inspect the belts and recommend
adjustment or replacement when
necessary.
Brakes
Brakes stop the vehicle and are crucial
to safe driving.
. Signs of brake wear may include
chirping, grinding, or squealing
noises, or difficulty stopping. .
Trained dealer technicians have
access to tools and equipment to
inspect the brakes and recommend
quality parts engineered for the
vehicle.
Fluids
Proper fluid levels and approved fluids
protect the vehicle’s systems and
components. See Recommended Fluids
and Lubricants 0332 for GM approved
fluids.
. Engine oil and windshield washer
fluid levels should be checked at
every fuel fill.
. Instrument cluster lights may
come on to indicate that fluids
may be low and need to be filled.
Hoses
Hoses transport fluids and should be
regularly inspected to ensure that
there are no cracks or leaks. With a
multi-point inspection, your dealer
can inspect the hoses and advise if
replacement is needed.

Cadillac XTS Owner Manual (GMNA-Localizing-U.S./Canada-12032610) -
2019 - crc - 8/22/18
TECHNICAL DATA 337
Vehicle Data
Capacities and Specifications
ApplicationCapacities
Metric English
Air Conditioning Refrigerant For the air conditioning system refrigerant type and charge amount, see the refrigerant label under thehood. See your dealer for more information.
Engine Cooling System 3.6L (LF3) 9.8 L 10.4 qt
3.6L (LFX) 7.1 L 7.5 qt
Engine Oil with Filter 3.6L (LF3) 6.6 L 7.0 qt
3.6L (LFX) 5.7 L 6.0 qt
Fuel Tank Front-Wheel Drive 70.0 L 18.5 gal
All-Wheel Drive 74.0 L19.5 gal
Wheel Nut Torque 150Y 110 lb ft
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this manual.
Recheck fluid level after filling.

Cadillac XTS Owner Manual (GMNA-Localizing-U.S./Canada-12032610) -
2019 - crc - 8/22/18
348 CUSTOMER INFORMATION
Managing the Vehicle Damage
Repair Process
In the event that the vehicle requires
damage repairs, GM recommends that
you take an active role in its repair.
If you have a pre-determined repair
facility of choice, take the vehicle
there, or have it towed there. Specify
to the facility that any required
replacement collision parts be original
equipment parts, either new Genuine
GM parts or recycled original GM
parts. Remember, recycled parts will
not be covered by the GM vehicle
warranty.
Insurance pays the bill for the repair,
but you must live with the repair.
Depending on your policy limits, your
insurance company may initially value
the repair using aftermarket parts.
Discuss this with the repair
professional, and insist on Genuine
GM parts. Remember, if the vehicle is
leased, you may be obligated to have
the vehicle repaired with Genuine GM
parts, even if your insurance coverage
does not pay the full cost.If another party's insurance company
is paying for the repairs, you are not
obligated to accept a repair valuation
based on that insurance company's
collision policy repair limits, as you
have no contractual limits with that
company. In such cases, you can have
control of the repair and parts choices
as long as the cost stays within
reasonable limits.
Publication Ordering
Information
Service Manuals
Service manuals have the diagnosis
and repair information on the engine,
transmission, axle, suspension, brakes,
electrical system, steering system,
body, etc.
Customer Literature
Owner’s manuals are written
specifically for owners and are
intended to provide basic operational
information about the vehicle. The
owner’s manual includes the
Maintenance Schedule for all models.Customer literature publications
available for purchase include owner’s
manuals, warranty manuals,
infotainment manuals, and portfolios.
Portfolios include an owner’s manual,
warranty manual, infotainment
manual, if applicable, and zip lock bag
or pouch.
Current and Past Models
Service manuals and customer
literature are available for many
current and past model year GM
vehicles.
To order, call 1-800-551-4123
Monday–Friday, 8:00 a.m.–6:00 p.m.
eastern time
For credit card orders only (VISA,
MasterCard, or Discover), see Helm,
Inc. at: www.helminc.com.
To order by mail, write to:
Helm, Incorporated
Attention: Customer Service
47911 Halyard Drive
Plymouth, MI 48170
Make checks payable in U.S. funds.

Cadillac XTS Owner Manual (GMNA-Localizing-U.S./Canada-12032610) -
2019 - crc - 8/22/18
364 INDEX
IndexA
Accessories and Modifications . . . . . 238
Accessory Power . . . . . . . . . . . . . . . . . . . . 188
Adaptive Cruise Control . . . . . . . . . . . . 202
Add-On Electrical Equipment . . . . . . 235
Additional InformationOnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 354
Additional Maintenance and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . 329
Adjustments
Lumbar, Front Seats . . . . . . . . . . . . . . . . 57
Thigh Support . . . . . . . . . . . . . . . . . . . . . . 59
Air Cleaner/Filter, Engine . . . . . . . . . . 248
Air Conditioning . . . . . . . . . . . . . . .163, 168
Air Filter, Passenger Compartment . . . . . . . . . . . . . . . . . . . . . 170
Air Vents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Airbag System Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
How Does an Airbag Restrain? . . . . . 81
Passenger Sensing System . . . . . . . . . 82
What Makes an Airbag Inflate? . . . . 80
What Will You See after anAirbag Inflates? . . . . . . . . . . . . . . . . . . . 81
When Should an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Where Are the Airbags? . . . . . . . . . . . . 78 Airbags
Adding Equipment to the
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Passenger Status Indicator . . . . . . . 130
Readiness Light . . . . . . . . . . . . . . . . . . . 129
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
System Check . . . . . . . . . . . . . . . . . . . . . . . 76
Alarm Vehicle Security . . . . . . . . . . . . . . . . . . . . . 41
Alert
Lane Change . . . . . . . . . . . . . . . . . . . . . . 221
Side Blind Zone (SBZA) . . . . . . . . . . 221
All-Season Tires . . . . . . . . . . . . . . . . . . . . . 273
All-Wheel Drive . . . . . . . . . . . . . . . .193, 259
Antilock Brake System (ABS) . . . . . . 194 Warning Light . . . . . . . . . . . . . . . . . . . . 134
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312
Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 316
Armrest
Rear Seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Armrest Storage . . . . . . . . . . . . . . . . . . . . . 109
Assistance Systems for Driving . . . . 217
Assistance Systems for Parking and Backing . . . . . . . . . . . . . . . . . . . . . . . 211
Automatic Dimming Mirrors . . . . . . . . . . . . . . . . . . . 45

Cadillac XTS Owner Manual (GMNA-Localizing-U.S./Canada-12032610) -
2019 - crc - 8/22/18
INDEX 365
Automatic (cont'd)Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Forward Braking . . . . . . . . . . . . . . . . . . 219
Headlamp System . . . . . . . . . . . . . . . . 157
Level Control . . . . . . . . . . . . . . . . . . . . . . 199
Transmission . . . . . . . . . . . . . . . . . . . . . . 191
Transmission Fluid . . . . . . . . . . . . . . . 247
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . . . . . 193
Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
B
BatteryExterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Power Protection . . . . . . . . . . . . . . . . . . 161
Battery - North America . . . . . .258, 306
Blade Replacement, Wiper . . . . . . . . . 260
Boost Gauge . . . . . . . . . . . . . . . . . . . . . . . . . 126
Brake Parking, Electric . . . . . . . . . . . . . . . . . . 194
System Warning Light . . . . . . . . . . . . 133
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256
Antilock . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
Braking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174 Braking (cont'd)
Automatic Forward . . . . . . . . . . . . . . . 219
Break-In, New Vehicle . . . . . . . . . . . . . . 183
Bulb Replacement Back-up Lamps . . . . . . . . . . . . . . . . . . . 263
Headlamp Aiming . . . . . . . . . . . . . . . . 262
Headlamps . . . . . . . . . . . . . . . . . . . . . . . . 263
License Plate Lamps . . . . . . . . . . . . . . 264
Buying New Tires . . . . . . . . . . . . . . . . . . . 287
C
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . 115
California Perchlorate Materials
Requirements . . . . . . . . . . . . . . . . . . . 238
California Proposition 65 Warning . . . . . . . . . . . . .237, 258, 306, Back Cover
Canadian Vehicle Owners . . . . . . . . . . . . . 2
Capacities and Specifications . . . . . . 337
Carbon Monoxide
Engine Exhaust . . . . . . . . . . . . . . . . . . . 190
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Winter Driving . . . . . . . . . . . . . . . . . . . . 178
Cargo Management System . . . . . . . . . . . . . 111
Tie-Downs . . . . . . . . . . . . . . . . . . . . . . . . . 110
Caution, Danger, and Warning . . . . . . . . 2 Center Console Storage . . . . . . . . . . . . . 109
Chains, Tire . . . . . . . . . . . . . . . . . . . . . . . . . 291
Charging
Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Charging System Light . . . . . . . . . . . . . 131
Check Engine Light (Malfunction
Indicator) . . . . . . . . . . . . . . . . . . . . . . . . 131
Child Restraints Infants and Young Children . . . . . . . . 90
Lower Anchors and Tethers forChildren . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Older Children . . . . . . . . . . . . . . . . . . . . . . 89
Securing . . . . . . . . . . . . . . . . . . . . . . 102, 104
Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Cigarette Lighter . . . . . . . . . . . . . . . . . . . . 119
Circuit Breakers . . . . . . . . . . . . . . . . . . . . . 265
Cleaning
Exterior Care . . . . . . . . . . . . . . . . . . . . . . 312
Interior Care . . . . . . . . . . . . . . . . . . . . . . 316
Climate Control Systems
Dual Automatic . . . . . . . . . . . . . . . . . . . 163
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Cluster, Instrument . . . . . . . . . . . . . . . . . 121
Collision Damage Repair . . . . . . . . . . . 346
Compact Spare Tire . . . . . . . . . . . . . . . . . 305

Cadillac XTS Owner Manual (GMNA-Localizing-U.S./Canada-12032610) -
2019 - crc - 8/22/18
INDEX 367
E
Electric Parking Brake . . . . . . . . . . . . . . 194
Electric Parking Brake Light . . . . . . . 133
Electrical Equipment, Add-On . . . . . 235
Electrical SystemEngine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
Fuses and Circuit Breakers . . . . . . . 265
Instrument Panel Fuse Block . . . . 268
Overload . . . . . . . . . . . . . . . . . . . . . . . . . . . 264
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270
Emergency OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 353
Engine Air Cleaner/Filter . . . . . . . . . . . . . . . . . 248
Check Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . . . . . 131
Compartment Overview . . . . . . . . . . 240
Coolant Temperature Gauge . . . . . 128
Coolant Temperature
Warning Light . . . . . . . . . . . . . . . . . . . 136
Cooling System . . . . . . . . . . . . . . . . . . . 250
Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243
Drive Belt Routing . . . . . . . . . . . . . . . . 338
Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186
Oil Life System . . . . . . . . . . . . . . . . . . . . 246 Engine (cont'd)
Oil Pressure Light . . . . . . . . . . . . . . . . . 137
Overheated Protection
Operating Mode . . . . . . . . . . . . . . . . . 254
Overheating . . . . . . . . . . . . . . . . . . . . . . . 253
Power Messages . . . . . . . . . . . . . . . . . . 146
Running While Parked . . . . . . . . . . . 191
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
Engine Oil
Temperature Gauge . . . . . . . . . . . . . . . 127
Entry Lighting . . . . . . . . . . . . . . . . . . . . . . 160
Equipment, Towing . . . . . . . . . . . . . . . . . 234
Event Data Recorders . . . . . . . . . . . . . . 350
Exit Lighting . . . . . . . . . . . . . . . . . . . . . . . . 161
Extended Parking . . . . . . . . . . . . . . . . . . . 189
Extender, Seat Belt . . . . . . . . . . . . . . . . . . 74
Exterior Lamp Controls . . . . . . . . . . . . 155
Exterior Lamps Off Reminder . . . . . . 156
Exterior Lighting Battery Saver . . . . 161
F
Features Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Filter,
Engine Air Cleaner . . . . . . . . . . . . . . . . 248
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . . . 157
Flashers, Hazard Warning . . . . . . . . . . 158
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291 Flat Tire (cont'd)
Changing . . . . . . . . . . . . . . . . . . . . . . . . . . 300
Floor Mats . . . . . . . . . . . . . . . . . . . . . . . . . . . 319
Fluid Automatic Transmission . . . . . . . . . 247
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
Power Steering . . . . . . . . . . . . . . . . . . . . 255
Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256
Folding Mirrors . . . . . . . . . . . . . . . . . . . . . . 44
Forward Automatic Braking . . . . . . . . 219
Forward Collision Alert (FCA)
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 349
Front Seats Heated and Ventilated . . . . . . . . . . . . . 63
Fuel Additives . . . . . . . . . . . . . . . . . . . . . . . . . . 227
Economy Driving . . . . . . . . . . . . . . . . . . . 25
Filling a Portable Fuel
Container . . . . . . . . . . . . . . . . . . . . . . . . 229
Filling the Tank . . . . . . . . . . . . . . . . . . . 227
Foreign Countries . . . . . . . . . . . . . . . . . 227
Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Low Fuel Warning Light . . . . . . . . . 138
Prohibited Fuels . . . . . . . . . . . . . . . . . . 227
Recommended . . . . . . . . . . . . . . . . . . . . 226
Top Tier . . . . . . . . . . . . . . . . . . . . . . . . . . . 226
