lights CHEVROLET AVALANCHE 2002 1.G Owners Manual

Table of Contents
Windows
Keys and Door Locks
Keyless Entry System
Liftgate
Automatic Transmission Operation
Four-Wheel Drive
Parking Brake
Tilt Wheel
Turn Signal/Multifunction Lever
Windshield WipersCruise Control
Exterior and Interior Lamps
Mirrors
Storage Compartments
Convenience Net
Accessory Power Outlets
OnStar® System (If Equipped)
Sunroof (If Equipped)
HomeLink® Transmitter (If Equipped)
Instrument Panel, Warning Lights and Gages Seats and Seat Controls
Safety BeltsAir Bag Systems
Restraint Systems for Children
Section
1
Section
2
Seats and Restraint Systems
Features and Controls
ii

viii
Vehicle Damage Warnings
Also, in this book you will find these notices:
NOTICE:
These mean there is something that could damage
your vehicle.
In the notice area, we tell you about something that can
damage your vehicle. Many times, this damage would
not be covered by your warranty, and it could be costly.
But the notice will tell you what to do to help avoid
the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different
colors or in different words.
You'll also see warning labels on your vehicle.
They use the same words, CAUTION or NOTICE.
Vehicle Symbols
Your vehicle may be equipped with components and
labels that use symbols instead of text. Symbols, used on
your vehicle, are shown along with the text describing
the operation or information relating to a specific
component, control, message, gage or indicator.
If you need help figuring out a specific name of a
component, gage or indicator reference the following
topics in the index:

ªEngine Compartment Overviewº

ªInstrument Panelº

ªComfort Controlsº

ªAudio Systemsº
Also see ªWarning Lights and Gagesº in the Index.
Here are some examples of symbols you may find on
your vehicle:

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-10 Keyless Entry System
2
-13 Midgate
2
-23 Tailgate
2
-24 Theft
2
-25 Content Theft-Deterrent
2
-26 Passlock

2-27 New Vehicle ªBreak-Inº
2
-27 Ignition Positions
2
-29 Starting Your Engine
2
-30 Engine Coolant Heater (If Equipped)
2
-32 Automatic Transmission Operation
2
-35 Four-Wheel Drive (If Equipped)
2
-40 Parking Brake
2
-41 Shifting Into PARK (P)
2
-43 Shifting Out of PARK (P)
2
-44 Parking Over Things That Burn2
-44 Engine Exhaust
2
-45 Running Your Engine While You're Parked
2
-46 Locking Rear Axle
2
-46 Horn
2
-47 Tilt Wheel
2
-47 Turn Signal/Multifunction Lever
2
-53 Exterior Lamps
2
-58 Interior Lamps
2
-59 Mirrors
2
-64 Storage Compartments
2
-66 Tonneau Cover (If Equipped)
2
-73 Cargo Cover Panels (If Equipped)
2
-91 OnStar
System (If Equipped)
2
-98 The Instrument Panel - Your
Information System
2
-100 Instrument Panel Cluster
2
-101 Warning Lights, Gages and Indicators
2
-116 Message Center

2-11
Operation
UNLOCK: Pressing this button once will unlock the
driver's door. The parking lamps will flash and the
interior lights will come on. Pressing UNLOCK again
within three seconds will cause the remaining doors to
unlock. The parking lamps will flash and the interior
lights will come on.
LOCK: Pressing this button once will lock all of the
doors. Press LOCK again within three seconds and the
horn will chirp.
Operating the keyless entry transmitter may interact
with the theft
-deterrent system. See ªContent-Theft
Deterrentº in the Index.
Remote Panic Alarm
When the button with the horn symbol on the keyless
entry transmitter is pressed, the horn will sound and the
headlamps and taillamps will flash for up to 30 seconds.
This can be turned off by pressing the horn button again,
waiting for 30 seconds, or starting the vehicle.
Matching Transmitter(s) to Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to bring any
remaining transmitters with you when you go to your
dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock your
vehicle. Each vehicle can have a maximum of four
transmitters matched to it.

2-37
4HI: Use 4HI when you need extra traction, such as
on snowy or icy roads or in most off
-road situations.
This setting also engages your front axle to help drive
your vehicle. This is the best setting to use when
plowing snow.
4LO: This setting also engages your front axle and
delivers extra torque. You may never need 4LO. It sends
maximum power to all four wheels. You might choose
4LO if you are driving off
-road in deep sand, deep mud,
deep snow and climbing or descending steep hills.
CAUTION:
Shifting the transfer case to NEUTRAL can
cause your vehicle to roll even if the transmission
is in PARK (P). You or someone else could be
seriously injured. Be sure to set the parking
brake before placing the transfer case in
NEUTRAL. See ªParking Brakeº in the Index.
NEUTRAL: Shift the vehicle's transfer case to
NEUTRAL only when towing your vehicle.
See ªRecreational Vehicle Towingº or ªTowing
Your Vehicleº in the Index for more information.
Indicator lights in the switches show which setting your
transfer case is in. The indicator lights will come on
briefly when you turn on the ignition and one will stay
on. If the lights do not come on, you should take your
vehicle to your dealer for service. An indicator light will
flash while the transfer case is being shifted. It will
remain illuminated when the shift is complete. If for
some reason the transfer case cannot make a requested
shift, it will return to the last chosen setting.
If the SERVICE 4WD message stays on, you
should take your vehicle to your dealer for service.
See ªService 4WDº in the Index for further information.

2-53
Exterior Lamps
The parking/headlamp knob is located on the driver's
side of the instrument panel.
(Parking Lamps): Turn the knob clockwise
to the parking lamps symbol to manually turn on
the following:

Parking Lamps

Sidemarker Lamps

Taillamps

License Plate Lamps

Instrument Panel Lights
(Headlamps): Turn the knob clockwise to the
master lamps symbol to turn on all the lamps listed as
well as the headlamps.
(Off): Turn the knob all the way counterclockwise to
turn off your lamps and put the system into automatic
headlamp mode.
You can switch your headlamps from high to low beam
by pulling on the turn signal/high
-beam lever.

2-54
Automatic Headlamp System
When it is dark enough outside, your automatic
headlamp system will turn on your headlamps at the
normal brightness along with other lamps such as the
taillamps, sidemarker, parking lamps and the instrument
panel lights. The radio lights will also be dim.
Your vehicle is equipped with a light sensor on the top
of the instrument panel under the radio speaker grill.
Be sure it is not covered or the system will be on
whenever the ignition is on.
The system may also turn on your headlamps when
driving through a parking garage, heavy overcast
weather or a tunnel. This is normal.
There is a delay in the transition between the daytime
and nighttime operation of the Daytime Running Lamps
(DRL) and the automatic headlamp systems so that
driving under bridges or bright overhead street lights
does not affect the system. The DRL and automatic
headlamp system will only be affected when the light
sensor sees a change in lighting lasting longer than
the delay.To idle your vehicle with the automatic headlamp
system off, set the parking brake while the ignition is
off. Then start your vehicle. The automatic headlamp
system will stay off until you release the parking brake.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
You may be able to turn off your automatic headlamp
system. See ªDaytime Running Lamps (DRL)º later
in this section for more information.
Lamps On Reminder
A reminder chime will sound when your headlamps or
parking lamps are manually turned on, the driver's
door is opened and your ignition is in OFF, LOCK or
ACCESSORY. To turn the chime off, turn the knob all
the way to the left or turn the instrument panel dimmer
down to the fully dimmed position. In the automatic
mode, the headlamps turn off once the ignition key is
in OFF.

2-58
Interior Lamps
Instrument Panel Intensity Control
The instrument panel intensity control is located to the
right of the headlamp knob.
Turn the thumbwheel up to adjust the instrument panel
lights. To turn on the dome lamps (with the vehicle
doors closed) turn the thumbwheel all the way up.
Exit Lighting
With exit lighting, the interior lamps will come on when
you remove the key from the ignition. The lights will
not come on if the DOME OVERRIDE button is
pressed in.
Illuminated Entry
Your vehicle is equipped with an illuminated entry feature.
When the doors are opened, the dome lamps will come
on if the DOME OVERRIDE button is in the out
position. If the DOME OVERRIDE button is pressed in,
the lamps will not come on.
Front Reading Lamps
Press the button located
next to each lamp to turn
the lamp on. The lamps can
be adjusted to point in the
direction you want.
Press the button again to turn the lamp off.

2-59
Dome Lamps
The dome lamps will come on when you open a door.
You can also turn the dome lamps on by turning the
thumbwheel, located next to the parking/headlamps
knob, all the way up. In this position, the dome lamps
will remain on whether the doors are opened or closed.
You can use the DOME OVERRIDE button, located
below the parking/headlamp knob, to set the dome
lamps to come on automatically when the doors are
opened, or to remain off. To turn the lamps off, press
the button into the in position. With the button in this
position, the dome lamps will remain off when the doors
are open. To return the lamps to automatic operation,
press the button again and return it to the out position.
With the button in this position, the dome lamps will
come on when you open a door.
Battery Run-Down Protection
This feature shuts off the dome, reading, glove box,
cargo and underhood lamps if they are left on for more
than 20 minutes when the ignition is off. This will keep
your battery from running down.
Mirrors
Electrochromic Inside Rearview Mirror
with Compass and Temperature Display
When on, an electrochromic mirror automatically dims
to the proper level to minimize glare from lights behind
you after dark.
The mirror also includes a display in the upper right
corner of the mirror face. The compass reading and the
outside temperature will both appear in the display at the
same time. The dual display can be turned on or off by
briefly pressing either the TEMP or the COMP button.

2-64
Storage Compartments
Your vehicle includes a number of storage
compartments for storage of often
-used items.
Some vehicles have storage areas in the instrument
panel. Use these spaces for items such as gloves or
small books. Some models have a storage pocket on
each of the front doors.
Glove Box
To open your glove box, pull the lever upward and
pull the door downward.
Center Overhead Console
Your vehicle has overhead console equipped with
reading lights and a small storage area.
Press the button next to the light to turn it on.
Press it again to turn it off.
Center Console Storage Area (If Equipped)
Your vehicle may have a console compartment between
the bucket seats.
To open it, insert the console key into the lock and unlock
the console. Press the button and swing the console lid
open. The console has a place to store tissues, pens and a
clip to hold business cards.
The rear of the console has a cupholder that swings down
for the rear seat passengers to use.
Your vehicle may have a compact disc holder in the console.
