You need a new tire if any of the following statements
are true:
You can see the indicators at three or more places
around the tire.
You can see cord or fabric showing through the
tire’s rubber.
The tread or sidewall is cracked, cut or snagged
deep enough to show cord or fabric.
The tire has a bump, bulge or split.
The tire has a puncture, cut or other damage that
can’t be repaired well because of the size or
location of the damage.
Buying New Tires
To nd out what kind and size of tires you need, look at
the Certication/Tire label or the Tire and Loading
Information label. SeeLoading Your Vehicle on
page 4-55, for more information about these labels and
where they can be found on your vehicle.
The tires installed on your vehicle when it was new had a
Tire Performance Criteria Specications (TPC Spec)
number on each tire’s sidewall. When you get new tires,
GM recommends that you get tires with that same TPC
Spec number. That way your vehicle will continue to have
tires that are designed to give proper endurance,
handling, speed rating, load range, traction, ride, tire
pressure monitoring system performance and other
things during normal service on your vehicle. If your tires
have an all-season tread design, the TPC number will be
followed by an “MS” (for mud and snow).
5-83

Scheduled Maintenance
Service MaintenanceIMaintenanceII
Change engine oil and lter. Reset oil life system. SeeEngine Oil on
page 5-16.An Emission Control Service.••
Lubricate chassis components.See footnote #.••
Visually check for any leaks or damage.See footnote (j).••
Inspect engine air cleaner lter or change indicator (if equipped). If necessary,
replace lter. SeeEngine Air Cleaner/Filter on page 5-21.An Emission Control
Service. See footnote †.••
Rotate tires and check ination pressures and wear. SeeTires on page 5-68.••
Inspect brake system.See footnote (a).••
Check engine coolant and windshield washer uid levels and add uid as
needed.••
Perform any needed additional services. See “Additional Required Services” in
this section.••
Inspect suspension and steering components.See footnote (b).•
Inspect engine cooling system.See footnote (c).•
Inspect wiper blades.See footnote (d).•
Inspect restraint system components.See footnote (e).•
Lubricate body components.See footnote (f).•
Check transmission uid level and add uid as needed.•
6-5

Additional Required Services
The following services should be performed at the rst maintenance service (IorII) after the indicated miles
(kilometers) shown for each item.
Additional Required Services
Service and Miles (Kilometers)25,000
(41 500)50,000
(83 000)75,000
(125 000)100,000
(166 000)125,000
(207 500)150,000
(240 000)
Inspect fuel system for damage
or leaks.••••••
Inspect exhaust system for loose or
damaged components.••••••
Vehicles without a lter restriction
indicator: Replace engine air
cleaner lter. SeeEngine Air
Cleaner/Filter on page 5-21.
An Emission Control Service.••••••
Change automatic transmission
uid and lter (severe service).
See footnote (h).•••
Change automatic transmission
uid and lter (normal service).•
Change transfer case uid.
See footnote (g).•••
6-6

Locks (cont.)
Power Door.................................................. 2-9
Programmable Automatic Door Locks.............2-10
Rear Door Security Locks.............................2-13
Loss of Control...............................................4-19
LOW COOLANT LEVEL..................................3-66
Low Fuel Warning Light...................................3-52
Luggage Carrier..............................................2-66
Lumbar
Power Controls............................................. 1-3
M
Maintenance and Cleaning...............................2-79
Maintenance Schedule
Additional Required Services........................... 6-6
At Each Fuel Fill.........................................6-10
At Least Once a Month................................6-10
At Least Once a Year..................................6-11
Introduction.................................................. 6-2
Maintenance Footnotes.................................. 6-8
Maintenance Record....................................6-17Maintenance Schedule (cont.)
Maintenance Requirements............................. 6-2
Normal Maintenance Replacement Parts.........6-15
Owner Checks and Services.........................6-10
Recommended Fluids and Lubricants.............6-13
Scheduled Maintenance................................. 6-4
Using Your................................................... 6-3
Your Vehicle and the Environment................... 6-2
Maintenance When Trailer Towing.....................4-79
Making Turns.................................................4-76
Malfunction Indicator Light................................3-47
Manual Passenger Seat.................................... 1-2
Matching Transmitter(s) to Your Vehicle............... 2-6
Memory Seat.................................................2-90
Message
DIC Warnings and Messages........................3-65
Mexico, Central America and Caribbean Islands/
Countries (Except Puerto Rico and U.S. Virgin
Islands) – Customer Assistance........................ 7-5
Midgate.........................................................2-14
Midgate Drain Grate Removal and Cleaning.......2-81
10

W
Warning Lights, Gages and Indicators................3-33
Warnings
DIC Warnings and Messages........................3-65
Hazard Warning Flashers............................... 3-6
Other Warning Devices.................................. 3-7
Safety and Symbols......................................... iii
Vehicle Damage.............................................. iv
Washing Your Vehicle....................................5-114
Weight of the Trailer........................................4-71
Weight of the Trailer Tongue.............................4-73
What Kind of Engine Oil to Use........................5-17
What to Do with Used Oil................................5-20
Wheels
Alignment and Tire Balance..........................5-86
Replacement...............................................5-86
When to Add Engine Oil..................................5-16
When to Change Engine Oil
(GM Oil Life System)...................................5-19
When to Check Lubricant.................................5-55
When to Check Power Steering Fluid................5-41
When to Inspect.............................................5-21
When You Are Ready to Leave After Parking
on a Hill.....................................................4-79Where to Put the Restraint...............................1-38
Why Safety Belts Work....................................1-10
Windows.......................................................2-25
Power........................................................2-26
Windshield and Wiper Blades..........................5-116
Windshield Washer.........................................3-10
Fluid..........................................................5-42
Windshield Wiper
Blade Replacement......................................5-67
Fuses......................................................5-120
Windshield Wipers..........................................3-10
Winter Driving................................................4-44
X
XM™ Satellite Radio Antenna System..............3-117
XM™ Satellite Radio Service..........3-74, 3-86, 3-115
Y
Your Vehicle and the Environment....................... 6-2
18
