7-26
Fluid Leaks Check
Check for fuel, coolant, oil or other fluid leaks by
looking at the surface beneath the vehicle after it has
been parked for awhile.
Underbody Inspection
Corrosive materials used for ice, snow removal and dust
control can collect on the underbody. If these materials
are not removed, accelerated corrosion (rust) can occur
on underbody parts such as fuel lines, frame, floor pan
and exhaust system. At least every spring, flush these
materials from the underbody with plain water. Take
care to clean well any areas where mud and other debris
can collect. Sediment packed in closed areas of the
frame should be loosened before being flushed.
Engine Cover Check
Check that the cab's engine cover and seal (if equipped)
are not torn or damaged. Be sure that the cover is
clamped down firmly to the floor.At Least Once a Year
Key Lock Cylinders Service
Lubricate the key lock cylinders with the lubricant
specified in Part C.
Underbody Flushing Service
At least every spring, use plain water to flush any
corrosive materials from the underbody. Take care to
clean thoroughly any areas where mud and other debris
can collect.
Tractor Protection (Breakaway) Valve Check
On air brake models, remove, disassemble, clean and
inspect the tractor protection (breakaway) valve.
7-27
Part C: Recommended Fluids and
Lubricants
Fluids and lubricants identified below by name,
part number or specification may be obtained from
your dealer.
USAGE
FLUID/LUBRICANT
Engine Oil
(Gasoline
Engine)Engine oil with the American
Petroleum Institute Certified for
Gasoline Engines starburst symbol
of the proper viscosity. To
determine the preferred viscosity
for your vehicle's engine, see
ªEngine Oilº in the Index.
Engine Oil
(Caterpillar
Diesel Engine)See the Caterpillar Operation &
Maintenance Manual for engine
oil recommendations.
USAGEFLUID/LUBRICANT
Engine Coolant
(Gasoline
Engine &
DURAMAX
Diesel)50/50 mixture of clean, drinkable
water and use only DEX
-COOL
Coolant. See ªEngine Coolantº in
the Index.
Engine Coolant
(Caterpillar
Diesel Engine)See the Caterpillar Operation &
Maintenance Manual for engine
coolant recommendations.
Hydraulic Brake
SystemDelco Supreme 11 Brake Fluid
or equivalent DOT
-3 brake fluid.
Windshield
Washer SolventGM Optikleen Washer Solvent
or equivalent.
Clutch Bearing
LubricantClutch Bearing Lubricant
(GM Part No. 12378484 or
equivalent NLGI #3 consistency).
