CHEVROLET CAMARO 1999 4.G Owners Manual

yellowblue
2-85 Oil Pressure Gage
3800 V6 Engine 5.7L V8 Engine
This gage tells you if there could be a problem with your
engine oil pressure.The engine oil pressure gage shows the engine oil
pressure in psi (pounds per square inch) in the U.S., or
kPa (kilopascals) in Canada, when the engine is running.
On the 5.7L V8 engine, oil pressure should be 20 to
80 psi (140 to 550 kPa). On the 3800 V6 engine, the oil
pressure should be between 20 and 120 psi (140 to
827 kPa). It may vary with engine speed, outside
temperature and oil viscosity, but readings above the red
area show the normal operating range. Readings in the
red area tell you that the engine is low on oil, or that you
might have some other oil problem. See ªEngine Oilº in
the Index.
CAUTION:
Don't keep driving if the oil pressure is low. If
you do, your engine can become so hot that it
catches fire. You or others could be burned.
Check your oil as soon as possible and have your
vehicle serviced.

yellowblue
2-86
NOTICE:
Damage to your engine from neglected oil
problems can be costly and is not covered by
your warranty.
Low Oil Light
This warning light should
come on while you are
starting your engine. If the
light doesn't come on, have
it repaired.
If the light stays on after starting your engine, your
engine oil level may be too low. You may need to add
oil. See ªEngine Oilº in the Index.
NOTICE:
The oil level monitoring system only checks the
oil level when you are starting your engine. It
does not keep monitoring the level once the
engine is running. Also, the oil level check only
works when the engine has been turned off long
enough for the oil to drain back into the oil pan.

yellowblue
2-87 Oil Change Light
This OIL CHANGE light
should come on briefly as a
bulb check when you start
the engine. If the OIL
CHANGE light doesn't
come on, have it serviced.
If the OIL CHANGE light comes on and stays on for
60 seconds after you start the engine, have the
oil changed.
For additional information, see ªEngine Oil, When to
Changeº in the Index. After changing the engine oil, the
system must be reset. See ªHow to Reset the Oil Change
Lightº in the Index.
Service Vehicle Light
This warning light should
come on in your instrument
panel for a three
-second
bulb check when you first
start your vehicle. If the
light doesn't come on, have
it serviced.
This light will stay on steady if you have certain
non
-emission related vehicle problems. These problems
may not be obvious and may affect vehicle performance
or durability. Consult a qualified dealership for
necessary repairs to maintain top vehicle performance.

yellowblue
2-88 Check Gages Light
This warning light will
come on briefly when you
start the engine.
If the light comes on and stays on while you are driving,
check your gages to see if they are in the warning areas.
Hatch Ajar Light
This warning light should
come on in your instrument
panel for a three
-second
bulb check when you first
start your vehicle. If the
light doesn't come on, have
it serviced.
This light will stay on steady if your hatch is open or
ajar and the ignition key is in RUN.
Fuel Gage
Your fuel gage tells you
about how much fuel you
have left when the ignition
is on.
When the indicator nears E (empty), you still have a
little fuel left, but you should get more soon.

yellowblue
2-89
Here are four things that some owners ask about. All
these things are normal and do not indicate that anything
is wrong with the fuel gage.

At the gas station, the gas pump shuts off before the
gage reads F (full).

It takes more (or less) fuel to fill up than the gage
reads. For example, the gage reads half full, but it
took more (or less) than half of the tank's capacity to
fill it.

The gage pointer may move while cornering, braking
or speeding up.

The gage may not indicate E (empty) when the
ignition is turned off.
Low Fuel Light
If your fuel is low, your vehicle's CHECK GAGES light
on your instrument panel cluster will come on.
Reduced Engine Power Light
(V6 Engine Only)
The REDUCED ENG PWR
warning light should come
on in your instrument panel
for a three
-second bulb
check when you first start
your vehicle.
If the light doesn't come on, have it serviced.
If the REDUCED ENG PWR warning light comes on, a
noticeable reduction in the vehicle's performance may
occur. The vehicle may be driven at a reduced speed
while the REDUCED ENG PWR light is on, but
acceleration and speed may be reduced. Anytime this
warning light stays on, the vehicle should be taken to an
authorized Chevrolet dealer as soon as possible for
diagnosis and repair.

yellowblue
2-90
-NOTES

3-
yellowblue
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle. Be
sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-3 Heating
3
-4 Defogging and Defrosting
3
-4 Rear Window Defogger
3
-5 Ventilation System
3
-6 Audio Systems
3
-6 Setting the Clock for Systems without
Automatic Tone Control
3
-6 Setting the Clock for Systems with Automatic
Tone Control
3
-6AM-FM Stereo with Cassette Tape Player
3
-9 Monsoon
AM-FM Stereo with Cassette
Tape Player and Automatic Tone Control
(If Equipped)3
-14 Monsoon AM-FM Stereo with Compact
Disc Player and Automatic Tone Control
(If Equipped)
3
-18 Trunk-Mounted CD Changer (If Equipped)
3
-22 Theft-Deterrent Feature (If Equipped)
3
-24 Understanding Radio Reception
3
-24 Tips About Your Audio System
3
-25 Care of Your Cassette Tape Player
3
-27 Care of Your Compact Discs
3
-27 Care of Your Compact Disc Player
3
-27 Fixed Mast Antenna

yellowblue
3-2
Comfort Controls
With this system you can control the heating, air
conditioning and ventilation in your vehicle.
Your vehicle also has the flow
-through ventilation
system described later in this section.
Fan Control Knob
: Turn this knob to select the force of air
you want.
Temperature Control Knob
Turn the knob to change the temperature of the air
flowing from the system. Turn it toward the red area
(clockwise) for warmer air and toward the blue area
(counterclockwise) for cooler air.
Air Control Knob
OFF: The system is off.
MAX: Provides maximum cooling for quick cool
-down
on very hot days. This setting recirculates most of the air
inside your vehicle. If it is used for long periods of time,
the air may become dry. This setting directs air through
the upper air vents.
A/C: Use for normal cooling on hot days. This setting
cools outside air and directs it through the upper
air vents.
The air conditioner compressor operates in MAX, A/C,
Bi
-Level, Blend and Defrost when the outside
temperature is above freezing. When the air conditioner
is on, you may sometimes notice slight changes in your
vehicle's engine speed and power due to the operation of
the compressor.

yellowblue
3-3
BI-LEVEL: Air is directed through the upper air
vents and the heater ducts.
VENT: Air flows through the upper air vents.
HEATER: This setting directs most of the air
through the heater ducts and some of the air through the
windshield defroster vents.
BLEND: Air is directed through the windshield
defroster vents and the heater ducts.
DEFROST: This setting directs most of the air
through the windshield defroster vents and some of the
air through the heater ducts.
Cooling
The air conditioner works best if you keep your
windows closed. On very hot days, open the windows
just long enough for the hot air to escape.
1. Turn the air control knob to A/C for normal cooling.
For faster cooling turn the knob to MAX.
2. Turn the temperature control knob to a
comfortable setting.
3. Turn the fan control knob to the desired speed.
Heating
The heater works best if you keep your windows closed
while using it.
1. Turn the air control knob to heater.
2. Turn the fan control knob to the desired speed.
3. Turn the temperature control knob to a
comfortable setting.
If your vehicle is equipped with an engine coolant
heater, you can use it in cold weather (around
20
F/
-8
C or lower) to improve heater performance
on initial start up. See ªEngine Coolant Heaterº in
the Index.
Bi-Level Heating
You may want to use Bi-Level heating on cool, but
sunny days. This setting directs cool air toward your
body and warmer air toward your feet.
1. Turn the air control knob to Bi
-Level.
2. Turn the temperature control knob to a
comfortable setting.
3. Turn the fan control knob to the desired speed.

yellowblue
3-4 Defogging and Defrosting
1. Turn the air control knob to defrost.
2. Turn the temperature control knob to the
desired setting.
3. Turn the fan control knob to the desired speed.
The side window defogging works equally as well in the
heater, blend and defrost modes.
Rear Window Defogger
The rear window defogger
uses a warming grid to
remove fog from the
rear window.Press the button to turn on the defogger. An indicator
light will come on to remind you that the defogger is on.
The defogger will turn off automatically after about
10 minutes of use. If you turn it on again, the defogger
will operate for about five minutes only. You can also
turn the defogger off by pressing the button again. The
indicator light will go off when the system is turned off.
Do not attach anything like a temporary vehicle license
or a decal across the defogger grid on the rear window.NOTICE:
Don't use a razor blade or something else sharp
on the inside of the rear window. If you do, you
could cut or damage the warming grid, and the
repairs wouldn't be covered by your warranty.
