2-53 Cruise Control (Option)
With cruise control, you can
maintain a speed of about
25 mph (40 km/h) or more
without keeping your foot
on the accelerator.
This can really help on long trips. Cruise control does
not work at speeds below about 25 mph (40 km/h).
When you apply your brakes or push the clutch pedal
(manual transmission) the cruise control shuts off.CAUTION:

Cruise control can be dangerous where
you can't drive safely at a steady speed.
So, don't use your cruise control on
winding roads or in heavy traffic.

Cruise control can be dangerous on
slippery roads. On such roads, fast changes
in tire traction can cause needless wheel
spinning, and you could lose control.
Don't use cruise control on slippery roads.
If your vehicle is in cruise control when the optional
Acceleration Slip Regulation (ASR) System begins to
limit wheel spin, the cruise control will automatically
disengage. See ªASR Systemº in the Index. When road
conditions allow you to safely use it again, you may turn
the cruise control back on.

2-54
Setting Cruise Control
CAUTION:
If you leave your cruise control switch on when
you're not using cruise, you might hit a button
and go into cruise when you don't want to. You
could be startled and even lose control. Keep the
cruise control switch off until you want to use
cruise control.
1. Move the cruise control switch to ON.
2. Get up to the speed you want.
3. Push in the SET button at the end of the lever and
release it.
4. Take your foot off the accelerator pedal.Resuming a Set Speed
Suppose you set your cruise control at a desired speed and
then apply the brake or clutch pedal. This, of course, shuts
off the cruise control. But you don't need to reset it.
Once you're going about 25 mph (40 km/h) or more,
you can move the cruise control switch from ON to
R/A (Resume/Accelerate) briefly.
You'll go right back up to your chosen speed and
stay there.
Increasing Speed While Using Cruise Control
There are three ways to go to a higher speed:

Use the accelerator pedal to get to the higher speed.
Push the set button at the end of the lever, then
release the button and the accelerator pedal.
You'll now cruise at the higher speed.

To increase your speed in very small amounts,
briefly move the switch to R/A and then release it.
Each time you do this, your vehicle will go about
1 mph (1.6 km/h) faster.

Move the cruise switch from ON to R/A. Hold it
there until you get up to the speed you want, and
then release the switch.

2-55
Reducing Speed While Using Cruise Control
There are two ways to reduce your speed while using
cruise control:

Push in the set button at the end of the lever until
you reach the lower speed you want, then release it.

To slow down in very small amounts, briefly push
the button. Each time you do this, you'll go about
1 mph (1.6 km/h) slower.
Passing Another Vehicle While Using Cruise Control
Use the accelerator pedal to increase your speed. When
you take your foot off the pedal, your vehicle will slow
down to the cruise control speed you set earlier.Using Cruise Control on Hills
How well your cruise control will work on hills depends
upon your speed, load and the steepness of the hills.
When going up steep hills, you may have to step on the
accelerator pedal to maintain your speed. When going
downhill, you may have to brake or shift to a lower gear to
keep your speed down. Of course, applying the brake takes
you out of cruise control. Many drivers find this to be too
much trouble and don't use cruise control on steep hills.
Ending Out of Cruise Control
There are several ways to turn off the cruise control:

Step lightly on the brake pedal or push the clutch
pedal, if you have a manual transmission; or

move the cruise switch to OFF.
Erasing Speed Memory
When you turn off the cruise control or the ignition,
your cruise control set speed memory is erased.

2-56
Exterior Lamps
The main lamp control operates the following lamps:

Headlamps

Taillamps

Parking Lamps

License Lamps

Sidemarker Lamps

Instrument Panel Lights
Turn the knob to this position to turn on your
parking lamps and other operating lamps without
your headlamps.
Turn the knob to this position to turn on your
headlamps and other operating lamps.
Turn the knob to this position to turn off all
the lamps.
Headlamps on Reminder
If you turn the ignition to OFF and leave the lamps on,
you will hear a chime, lasting up to five seconds. If the
lamps are still on when you open the driver's door, the
chime will sound again.
Daytime Running Lamps / Automatic
Headlamp Control (If Equipped)
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset. Fully
functional daytime running lights are required on all
vehicles first sold in Canada.

2-57
A light sensor on top of the instrument panel automatically
turns the headlamps on, so be sure it isn't covered.
The DRL will not activate if the parking brake is
engaged prior to turning the ignition on.
The DRL system will make your front turn signal lamps
come on when:

The ignition is on,

the headlamp switch is off,

the parking brake is released, and

it is bright enough outside.
When the DRL are on, only your front turn signal lamps
will be on. The taillamps, sidemarker and other lamps
won't be on. Your instrument panel won't be lit up
either. When you use your turn signals, the front turn
signal and the taillamp on the desired side will flash.
When it's dark enough outside, your front turn signal
lamps will go out and your headlamps will come on.
The other lamps will also come on.
When it's bright enough outside, the regular lamps will
go off, and your front turn signal lamps will come on.
As with any vehicle, you should turn on the regular
headlamp system when you need it.Fog Lamps (Option)
Use your fog lamps for better vision in foggy or misty
conditions. Your parking lamps must be on or your fog
lamps won't work.
Your fog lamp button is
located on your console,
above the audio system.
To turn the fog lamps on, push the right side of the fog
lamp switch and a light on the switch will come on
indicating that the fog lamps are on. Push the left side
of the switch to turn the fog lamps off.
The fog lamps will go off whenever your high
-beam
headlamps come on. When the high
-beam headlamps
go off, the fog lamps will come on again.

2-58
If your vehicle has the content theft-deterrent/alarm system
and your fog lamp switch is on, the fog lamps may flash
along with the parking lamps to indicate operation of the
content theft
-deterrent/alarm system. See ªContent
Theft
-Deterrent/Alarm Systemº in the Index.
Interior Lamps
Instrument Panel Brightness Control
The thumbwheel controls the brightness of your
instrument panel lights. Move the thumbwheel up or down
to brighten or dim the lights. If you move the thumbwheel
all the way up, your courtesy lamps will come on.
Courtesy Lamps
When either door is opened, several interior lamps go
on. These lamps are courtesy lamps. They make it easier
for you to enter and leave your vehicle.
Courtesy lamps include two map lamps on the inside
rearview mirror and other lamps throughout the interior
of your vehicle.
To prevent battery rundown, your interior lamps will be
disabled about 10 minutes after the ignition is turned to
OFF. The 10
-minute timer will be restarted if you do
any of the following:

Turn the ignition on.

Open either door.

Press any button on your remote keyless entry
transmitter (option).

Turn the interior lamp switch from off to on.

Open the hatch.

2-59 Delayed Illumination
With delayed illumination, the courtesy lamps will come
on and stay on for 25 seconds after you enter the vehicle
and close the door. They will also stay on for five
seconds after you exit the vehicle and close the doors.
Delayed illumination will be shortened if the ignition is
turned to RUN or if the power locks are activated. To
turn this feature on or off, see ªFeature Customizationº
in the Index.
Exit Lighting
With exit lighting, the interior lamps will come on when
you remove the key from the ignition to help you see
while exiting the vehicle. To turn this feature on or off,
see ªFeature Customizationº in the Index.
Front Map Lamps
Your inside rearview mirror includes two map lamps.
Each lamp has its own switch. Use the switch closest to
the lamp to turn it on. The lamps will also come on
when a door is opened.
Mirrors
Inside Day/Night Rearview Mirror
An inside rearview mirror is attached to your
windshield. The mirror pivots so that you can adjust it.
You can adjust the mirror for day or night driving. Pull
the tab for night driving to reduce glare. Push the tab for
daytime driving.
Outside Manual Adjustable Mirror
Adjust the passenger's outside mirror by hand so that
you can see a little of the side of your vehicle when you
are sitting in a comfortable driving position.
Manual Remote Control Mirror
Adjust the driver's outside mirror with the lever located
on the door. Adjust the mirror so that you can see a little
of the side of your vehicle when you are sitting in a
comfortable driving position.

2-60 Power Remote Control Mirrors (If Equipped)
The power mirror control is located on the driver's door.
To adjust either mirror, turn the selector switch to L (left)
or R (right). Then push the control in the direction you
want the mirror to go.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.

2-61
Storage Compartments
Glove Box
To open the glove box, lift up on the lever. Use your
door key to lock or unlock it.
Front Console
To use the storage area, push in the button located on the
driver's side of the console and pull up on the console cover.
Cassette and Compact Disc Storage
You have a storage area for cassette tapes and compact
discs in your console.
Cargo Cover
Using the Cargo Cover
The cargo cover can be closed for hidden storage in the
rear area of your vehicle. It can also help reduce noise in
the vehicle when placed in the upright position, closing
out the rear area.
When carrying large or heavy items, it is a good idea
to open the cover and place the items in the rear area of
the vehicle.

2-62
Removing the Cargo Cover
1. Close the cover. If the cargo cover is not closed and
resting on the trim panel, it cannot be removed.
2. Pull the cover toward you to unsnap it. Then slide
the cargo cover along the groove in the trim panel.
Reverse the steps to install the cover.
CAUTION:
An improperly stored cargo cover could be
thrown about the vehicle during a collision or
sudden maneuver. You or others could be
injured. If you remove the cover, always store it
outside your vehicle. When you put it back,
always be sure that it is securely reattached.
