CHEVROLET CAMARO 2001 4.G Owners Manual

2-93
Readings in the red area tell you that the engine is low
on oil, or that you might have some other oil problem.
See ªEngine Oilº in the Index.
CAUTION:
Don't keep driving if the oil pressure is low. If
you do, your engine can become so hot that it
catches fire. You or others could be burned.
Check your oil as soon as possible and have your
vehicle serviced.
NOTICE:
Damage to your engine from neglected oil
problems can be costly and is not covered by
your warranty.
Low Oil Light
This warning light should
come on briefly while you
are starting your engine. If
the light doesn't come on,
have it repaired.
If the light stays on after starting your engine, your
engine oil level may be too low. You may need to add
oil. See ªEngine Oilº in the Index.
NOTICE:
The oil level monitoring system only checks the
oil level when you are starting your engine.
It does not keep monitoring the level once the
engine is running. Also, the oil level check only
works when the engine has been turned off long
enough for the oil to drain back into the oil pan.

2-94 Oil Change Light
This OIL CHANGE light
should come on briefly as a
bulb check when you start
the engine. If the OIL
CHANGE light doesn't
come on, have it serviced.
If the OIL CHANGE light comes on and stays on
for 60 seconds after you start the engine, have the
oil changed.
For additional information, see ªEngine Oil, When to
Changeº in the Index. After changing the engine oil, the
system must be reset. See ªHow to Reset the Oil Change
Lightº in the Index.
Service Vehicle Light
This warning light should
come on in your instrument
panel cluster for a
three
-second bulb check
when you first start your
vehicle. If the light doesn't
come on, have it serviced.
This light will stay on steady if you have certain
non
-emission related vehicle problems. These problems
may not be obvious and may affect vehicle performance
or durability. Consult a qualified dealer for necessary
repairs to maintain top vehicle performance.

2-95 Check Gages Light
This warning light will
come on briefly when you
start the engine.
If the light comes on and stays on while you are driving,
check your gages to see if they are in the warning areas.
Hatch Ajar Light
This warning light should
come on in your instrument
panel cluster for a
three
-second bulb check
when you first start your
vehicle. If the light doesn't
come on, have it serviced.
This light will stay on steady if your hatch is open or
ajar and the ignition key is in RUN.
Fuel Gage
Your fuel gage tells you
about how much fuel
you have left when the
ignition is on.
When the indicator nears E (empty), you still have a
little fuel left, but you should get more soon.

2-96
Here are four things that some owners ask about. All
these things are normal and do not indicate that anything
is wrong with the fuel gage.

At the gas station, the gas pump shuts off before the
gage reads F (full).

It takes more (or less) fuel to fill up than the
gage reads. For example, the gage reads half full, but
it took more (or less) than half of the tank's capacity
to fill it.

The gage pointer may move while cornering, braking
or speeding up.

The gage may not indicate E (empty) when the
ignition is turned off.
Low Fuel Light
If your fuel is low, your vehicle's CHECK GAGES light
on your instrument panel cluster will come on.
See ªCheck Gages Lightº in the Index.
Reduced Engine Power Light
(V6 Engine Only)
The REDUCED ENG PWR
warning light should come
on in your instrument panel
cluster for a three
-second
bulb check when you first
start your vehicle.
If the light doesn't come on, have it serviced.
If the REDUCED ENG PWR warning light comes on, a
noticeable reduction in the vehicle's performance may
occur. The vehicle may be driven at a reduced speed
while the REDUCED ENG PWR light is on, but
acceleration and speed may be reduced. Anytime this
warning light stays on, the vehicle should be taken to an
authorized Chevrolet dealer as soon as possible for
diagnosis and repair.

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-3 Cooling
3
-3 Heating
3
-4 Defogging and Defrosting
3
-4 Rear Window Defogger (Option)
3
-5 Ventilation System
3
-6 Audio Systems
3
-6 Setting the Clock for Systems without
Automatic Tone Control
3
-6 Setting the Clock for Systems with
Automatic Tone Control
3
-6AM-FM Stereo with Cassette Tape Player
3
-9 Monsoon
AM-FM Stereo with Cassette Tape
Player and Automatic Tone Control
(If Equipped)3
-15 Monsoon
AM-FM Stereo with Compact
Disc Player and Automatic Tone Control
(If Equipped)
3
-19 Trunk-Mounted CD Changer (If Equipped)
3
-23 Theft-Deterrent Feature (If Equipped)
3
-25 Audio Steering Wheel Controls (If Equipped)
3
-26 Understanding Radio Reception
3
-26 Tips About Your Audio System
3
-27 Care of Your Cassette Tape Player
3
-28 Care of Your Compact Discs
3
-28 Care of Your Compact Disc Player
3
-28 Fixed Mast Antenna

3-2
Comfort Controls
With this system you can control the heating, air
conditioning and ventilation in your vehicle.
Your vehicle also has the flow
-through ventilation
system described later in this section.
Fan Knob
: Turn this knob to select the force of air you want.Temperature Knob
Turn the knob to change the temperature of the air flowing
from the system. Turn it toward the red area (clockwise)
for warmer air and toward the blue area (counterclockwise)
for cooler air.
Air Knob
OFF: In this setting the system is off.
MAX: This setting provides maximum cooling for
quick cool
-down on very hot days. It recirculates most
of the air inside your vehicle. If it is used for long
periods of time, the air may become dry. This setting
directs air through the upper air vents.
A/C: Use A/C for normal cooling on hot days.
This setting cools outside air and directs it through the
upper air vents.
The air conditioner compressor operates in MAX, A/C,
BI
-LEVEL, BLEND and DEFROST when the outside
temperature is above freezing. When the air conditioner
is on, you may sometimes notice slight changes in your
vehicle's engine speed and power due to the operation of
the compressor.

3-3
BI-LEVEL: This setting directs air through the
upper air vents and the heater ducts.
VENT: This setting directs air through the upper
air vents.
HEATER: This setting directs most of the air
through the heater ducts and some of the air through the
windshield defroster vents.
BLEND: This setting directs air through the
windshield defroster vents and the heater ducts.
DEFROST: This setting directs most of the air
through the windshield defroster vents and some of the
air through the heater ducts.
Cooling
The air conditioner works best if you keep your
windows closed. On very hot days, open the windows
just long enough for the hot air to escape.
1. Turn the air knob to A/C for normal cooling. For
faster cooling turn the knob to MAX.
2. Turn the temperature knob to a
comfortable setting.
3. Turn the fan knob to the desired speed.
Heating
The heater works best if you keep your windows closed
while using it.
1. Turn the air knob to HEATER.
2. Turn the fan knob to the desired speed.
3. Turn the temperature knob to a
comfortable setting.
If your vehicle is equipped with an engine coolant heater,
you can use it in cold weather (around 20
F/
-8
C or
lower) to improve heater performance on initial start up.
See ªEngine Coolant Heaterº in the Index.
Bi
-Level
You may want to use BI
-LEVEL on cool, but sunny
days. This setting directs cool air toward your body and
warmer air toward your feet.
1. Turn the air knob to BI
-LEVEL.
2. Turn the temperature knob to a
comfortable setting.
3. Turn the fan knob to the desired speed.

3-4 Defogging and Defrosting
1. Turn the air knob to DEFROST.
2. Turn the temperature knob to the
desired setting.
3. Turn the fan knob to the desired speed.
The side window defogging works equally as well in the
heater, blend and defrost modes.
Rear Window Defogger (Option)
The rear window defogger
uses a warming grid to
remove fog from the
rear window.Press the button to turn on the defogger. An indicator
light will come on to remind you that the defogger is
on. The defogger will turn off automatically after about
10 minutes of use. If you turn it on again, the defogger
will operate for about five minutes only. You can also
turn the defogger off by pressing the button again. The
indicator light will go off when the system is turned off.
Do not attach anything like a temporary vehicle license
or a decal across the defogger grid on the rear window.NOTICE:
Don't use a razor blade or something else sharp
on the inside of the rear window. If you do, you
could cut or damage the warming grid, and the
repairs wouldn't be covered by your warranty.

3-5 Ventilation System
Adjust the direction of airflow by moving the vents.
Your vehicle's flow
-through ventilation system
supplies outside air into the vehicle when it is moving.
Outside air will also enter the vehicle when the blower
fan is running.For mild outside temperatures when little heating or
cooling is needed, you can still direct outside air through
your vehicle.
1. Turn the air knob to VENT.
2. Turn the temperature knob to a
comfortable setting.
3. Turn the fan knob to the desired speed.
Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction (such as leaves). The heater
and defroster will work far better, reducing the
chance of fogging the inside of your windows.

When you enter a vehicle in cold weather, turn the
fan knob clockwise for a few moments before
driving off. This helps clear the intake ducts of snow
and moisture, and reduces the chance of fogging the
inside of your windows.

Keep the air path under the front seats clear of
objects. This helps air to circulate throughout
your vehicle.

3-6
Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all its controls, to be sure you're getting the
most out of the advanced engineering that went into it.
If you have power door locks, your vehicle has a feature
called Retained Accessory Power (RAP). With RAP,
you can play your audio system even after the ignition is
off. See ªRetained Accessory Powerº in the Index.
Setting the Clock for Systems without
Automatic Tone Control
Press SET. SET will appear on the display for
five seconds. Within five seconds, press and hold the
right arrow on the SEEK button until the correct minute
appears. Press and hold the left arrow on the
SEEK button until the correct hour appears.
Setting the Clock for Systems with
Automatic Tone Control
Press and hold HR until the correct hour appears.
Press and hold MN until the correct minute appears.
AM-FM Stereo with Cassette Tape Player
Playing the Radio
VOLUME: This knob turns the system on and off and
controls the volume. To increase volume and turn the radio
on, turn the knob clockwise. Turn it counterclockwise to
decrease volume and turn the radio off.
RECALL: Display the time with the ignition off by
pressing the RECALL knob. When the radio is playing,
press this button to recall the station frequency.
