CHEVROLET CAMARO 2013 5.G User Guide

Black plate (5,1)Chevrolet Camaro Owner Manual (Include Mex) - 2012
In Brief 1-5
3. Immediately after completingStep 2, press and hold
/until
the turn signal lamps flash, or for
about two seconds if the vehicle
is not in view.
When the engine starts, the parking
lamps will turn on and remain on as
long as the engine is running. The
doors will be locked and the climate
control system may come on.
The engine will continue to run for
10 minutes. Repeat the steps for a
10-minute time extension. Remote
start can be extended only once.
Canceling a Remote Start
To cancel a remote start, do one of
the following:
.Aim the RKE transmitter at the
vehicle and press and hold
/
until the parking lamps turn off.
.Turn on the hazard warning
flashers.
.Turn the vehicle on and then off. See
Remote Vehicle Start on
page 2‑5.
Door Locks
To lock or unlock a door:
.To lock the door from the inside,
use the door lock knob on the
top of the door.
.To unlock the door from inside,
pull the handle once. Pulling the
handle again unlatches the door.
.From the outside turn the key
clockwise or counterclockwise,
or press
QorKon the Remote
Keyless Entry (RKE) transmitter.
See Door Locks on page 2‑6 or
Remote Keyless Entry (RKE)
System Operation on page 2‑3.
Power Door Locks
There is a power door lock switch
on the instrument panel and on the
front door panels.
Q: Press to lock the doors.
K: Press to unlock the doors. See
Power Door Locks on page 2‑7.
Trunk Release
The trunk may be opened by
pressing the remote trunk release
button located on the lower portion
of the driver door or
Von the
Remote Keyless Entry (RKE)
transmitter. See Trunk on page 2‑8
for more information.
Seat Adjustment
Manual Seats
To adjust the seat:
1. Lift the handle under the seat to unlock it.

Black plate (6,1)Chevrolet Camaro Owner Manual (Include Mex) - 2012
1-6 In Brief
2. Slide the seat and release thehandle.
3. Try to move the seat back and forth to be sure it is locked in
place.
See Seat Adjustment on page 3‑3
for more information.
Power Seats
To adjust the seat, if equipped:
.Move the seat forward or
rearward by moving the
horizontal control forward or
rearward.
.Move the whole seat by moving
the horizontal control up
or down.
.Tilt the seat by pressing the
horizontal control forward or
rearward.
See Power Seat Adjustment on
page 3‑4.
To raise or recline the seatback, tilt
the vertical control forward or
rearward. See Reclining Seatbacks
on page 3‑4 for more information.
Heated Seats
If available, pressLorMto turn on
the heated seat. A light indicates
this feature is on.
To operate, the engine must be
running.
Press the button once for the
highest setting. With each press of
the button, the heated seat will
change to the next lower setting,
and then the off setting. Two lights
indicate the highest setting, and one
light indicates the lowest.
See Heated Front Seats on
page 3‑6 for more information.
Head Restraint
Adjustment
Do not drive until the head restraints
for all occupants are installed and
adjusted properly.
To achieve a comfortable seating
position, change the seatback
recline angle as little as necessary
while keeping the seat and the head
restraint height in the proper
position.

Black plate (7,1)Chevrolet Camaro Owner Manual (Include Mex) - 2012
In Brief 1-7
For more information seeHead
Restraints on page 3‑2 andSeat
Adjustment on page 3‑3.
Safety Belts
Refer to the following sections for
important information on how to use
safety belts properly:
.Safety Belts on page 3‑8.
.How to Wear Safety Belts
Properly on page 3‑9.
.Lap-Shoulder Belt on page 3‑10.
.Lower Anchors and Tethers for
Children (LATCH System) on
page 3‑39.
Passenger Sensing
System
United States
Canada and Mexico
The passenger sensing system will
turn off the right front passenger
frontal airbag under certain
conditions. The driver airbag and
roof‐rail airbags, if equipped, are not
affected by the passenger sensing
system.
The passenger airbag status
indicator will be visible on the
overhead console when the vehicle
is started. See Passenger Sensing
System on page 3‑23 for more
information.

Black plate (8,1)Chevrolet Camaro Owner Manual (Include Mex) - 2012
1-8 In Brief
Mirror Adjustment
Exterior
Coupe Shown, Convertible Similar
Vehicles with outside power mirrors
have controls located on the driver
door armrest.
To adjust each mirror:
1. Press the switch to select the driver or passenger side mirror.
2. Press one of the four sides on the
i(control pad) to adjust the
mirror. 3. Adjust each outside mirror so
that a little of the vehicle and the
area behind it can be seen.
See Power Mirrors on page 2‑12.
Interior
Adjust the inside rearview mirror
for a clear view of the area behind
your vehicle. To avoid glare of the
headlamps from behind, push the
tab forward for daytime and pull it
for nighttime use. See Manual
Rearview Mirror on page 2‑13.
On vehicles with an automatic
dimming inside rearview mirror,
the mirror reduces glare from the
headlamps of the vehicle behind
you. The dimming feature comes on
and the indicator light illuminates
each time the vehicle is started. See
Automatic Dimming Rearview Mirror
on page 2‑13.
Steering Wheel
Adjustment
To adjust the steering wheel:
1. Pull the lever (A) down.
2. Move the steering wheel up or down.
3. Pull or push the steering wheel closer or away from you.
4. Pull the lever (A) up to lock the steering wheel in place.
Do not adjust the steering wheel
while driving.

Black plate (9,1)Chevrolet Camaro Owner Manual (Include Mex) - 2012
In Brief 1-9
Interior Lighting
Dome Lamps
The dome lamp buttons are located
overhead near the rearview mirror.
To change the settings, press the
following:
(:Turns the lamp off, even
when a door is open.
H: Turns the lamp on
automatically when a door is
opened.
': Turns the lamp on.
For more information on interior
lighting, see Instrument Panel
Illumination Control on page 6‑5.
Exterior Lighting
The exterior lamps control is on the
instrument panel, on the outboard
side of the steering wheel.
The exterior lamps control has four
positions:
P: Briefly turn to this position to
turn the automatic light control off or
on again. When released, the
control returns to the AUTO
position.
AUTO: Use to automatically turn on
the headlamps, parking lamps,
taillamps, sidemarker lamps, license
plate lamps, and instrument panel
lights.
;: Use to turn on the parking
lamps together with the taillamps,
sidemarker lamps, license plate
lamps and instrument panel lights.
5: Use to turn on the headlamps
together with the parking lamps,
taillamps, sidemarker lamps, license
plate lamps, and instrument panel
lights.
#: Use to turn the fog lamps on
or off.
For more information, see:
.Exterior Lamp Controls on
page 6‑1.
.Daytime Running Lamps (DRL)
on page 6‑2.
.Front Fog Lamps on page 6‑5.

Black plate (10,1)Chevrolet Camaro Owner Manual (Include Mex) - 2012
1-10 In Brief
Windshield Wiper/Washer
The windshield wiper lever is on the
side of the steering column. With
the ignition in ACC/ACCESSORY or
ON/RUN, move the windshield
wiper lever to select the wiper
speed.
2:Use for fast wipes.
1: Use for slow wipes.
3:Move the lever up to3for
adjustable interval wipes, then turn
the band up for more frequent wipes
or down for less frequent wipes.
9: Use to turn the windshield
wipers off.
3: Use for a single wipe, briefly
move the wiper lever down. For
several wipes, hold the wiper
lever down.
3: Pull the windshield wiper lever
toward you to spray windshield
washer fluid and activate the wipers.
See Windshield Wiper/Washer on
page 5‑3.

Black plate (11,1)Chevrolet Camaro Owner Manual (Include Mex) - 2012
In Brief 1-11
Climate Controls
The heating, cooling, defrosting, and ventilation for the vehicle can be
controlled with this system.
A. Fan Control
B. Heated Seats
C. Temperature Control
D. Air Delivery Mode Controls
E. Air ConditioningF. Defrost
G. Rear Window Defogger
H. Recirculation
See
Climate Control Systems on
page 8‑1.
Transmission
Automatic Transmission
Tap Shift
Tap Shift allows the driver to
manually control the automatic
transmission. To use Tap Shift, the
shift lever must be in M (Manual
Mode). Vehicles with this feature
have indicators on the steering
wheel. The controls are on the
back of the steering wheel. Tap the
left control to downshift, and the
right control to upshift. A Driver
Information Center (DIC) message
indicates the gear the vehicle is in.
See Manual Mode on page 9‑29.

Black plate (12,1)Chevrolet Camaro Owner Manual (Include Mex) - 2012
1-12 In Brief
Manual Transmission
One to Four Shift Message
(V8 Only)
Driver Information Center
When this message comes on, you
can only shift from 1 (First) to
4 (Fourth) instead of 1 (First) to
2 (Second). The message will be
displayed in the Driver Information
Center. See Manual Transmission
on page 9‑30.
Vehicle Features
Radio(s)
VOL/O: Press to turn the system
on and off. Turn to increase or
decrease the volume.
RADIO/BAND: Press to choose
between FM, AM, or XM™,
if equipped.
MENU/SELECT: Turn to select
radio stations.
7SEEK: Press to seek the
previous radio station or track.
6SEEK: Press to seek the next
radio station or track.
Buttons 1‐6: Press to save and
select favorite stations.
INFO: Press to show available
information about the current station
or track.
For more information about these
and other radio features, see
Overview on page 7‑3.
Storing a Favorite Station
Stations from all bands can be
stored in the favorite lists in any
order. Up to six stations can be
stored in each favorite page and the
number of available favorite pages
can be set.
To store the station to a position in
the list, press the corresponding
numeric button 1‐6 until the station
can be heard again.
For more information, see “Storing
and Retrieving Favorites” inAM-FM
Radio on page 7‑8.
Setting the Clock
Adjusting the Time
The clock menu can be only be
used with the radio on while in
ON/RUN or ACC/ACCESSORY.
1. Press the CONFIG button.
2. Select Time and Date Settings.
3. Select Set Time.
4. Turn the MENU/SELECT knob to adjust the highlighted value.

Black plate (13,1)Chevrolet Camaro Owner Manual (Include Mex) - 2012
In Brief 1-13
5. Press the MENU/SELECT knobto select the next value.
6. To save the time or date and return to the Time and Date
Settings menu, press the
/
BACK button at any time or
press the MENU/SELECT knob
after adjusting the minutes.
Setting the 12/24 Hour Format
1. Press the CONFIG button.
2. Select Time and Date Settings.
3. Highlight 12/24 Hour Format.
4. Press the MENU/SELECT knob to select the 12 hour or 24 hour
display format.
For detailed instructions on setting
the clock, see Clock on page 5‑4.
Satellite Radio
Vehicles with an XM™ satellite radio
tuner and a valid XM satellite radio
subscription can receive XM
programming.
XM Satellite Radio Service
XM is a satellite radio service based
in the 48 contiguous United States
and 10 Canadian provinces. XM
satellite radio has a wide variety of
programming and commercial-free
music, coast to coast, and in
digital-quality sound. A fee is
required to receive the XM service.
For more information refer to:
.www.xmradio.com or call
1-800-929-2100 (U.S.).
.www.xmradio.ca or call
1-877-438-9677 (Canada).
For more information, see Satellite
Radio on page 7‑9.
Portable Audio Devices
Some vehicles have a 3.5 mm
(1/8 in) auxiliary input and a USB
port located in the center console.
External devices such as iPods
®,
laptop computers, MP3 players, CD
changers, and USB storage devices
may be connected, depending on
the audio system. For more information, see
Auxiliary
Devices on page 7‑16.
Bluetooth®
The Bluetooth system allows users
with a Bluetooth-enabled cell phone
to make and receive hands-free
calls using the vehicle audio system
and controls.
The Bluetooth-enabled cell phone
must be paired with the in-vehicle
Bluetooth system before it can be
used in the vehicle. Not all phones
will support all functions.
See Bluetooth (Overview) on
page 7‑21 orBluetooth
(Infotainment Controls) on
page 7‑23 orBluetooth (Voice
Recognition) on page 7‑26.

Black plate (14,1)Chevrolet Camaro Owner Manual (Include Mex) - 2012
1-14 In Brief
Steering Wheel Controls
Some audio steering wheel controls
can be adjusted at the steering
wheel.
b/g:Press to interact with the
available Bluetooth or OnStar
systems.
$/i: Press to silence the
vehicle speakers only. Press again
to turn the sound on. For vehicles
with OnStar or Bluetooth systems,
press to reject an incoming call,
or end a current call.
_SRC^: Press to select an audio
source.
Turn up or down to select the next
or previous favorite radio station,
CD, or MP3 track.
+
x− : Press + to increase the
volume; press −to decrease the
volume.
For more information, see Steering
Wheel Controls on page 5‑2.
Cruise Control
The cruise control buttons are
located on the outboard side of the
steering wheel.
5: Press to turn the cruise control
system on and off. An indicator light
comes on in the instrument panel
cluster.
\: Press to disengage cruise
control without erasing the set
speed from memory.
RES/+ : Move the thumbwheel up
to make the vehicle resume to a
previously set speed or to
accelerate to a higher speed.
SET/− :Move the thumbwheel
down to set a speed or to make the
vehicle decelerate.
See Cruise Control on page 9‑38.
