The following functions are
available with the remote
keyless entry system:
LOCK:All doors will automatically lock when this
button is pressed. In addition, if all doors and the trunk
are closed, the headlamps will ¯ash once, the interior
lamps will turn off, and the vehicle content theft security
system will arm. See
Content Theft-Deterrent on
page 2-15.
UNLOCK:The driver's door will unlock when this button
is pressed. In addition, the headlamps will ¯ash twice, the
interior lamps will turn on for about 20 seconds or until the
ignition is turned on, and the content theft security system
will disarm. See
Content Theft-Deterrent on page 2-15.If
you press UNLOCK again within ®ve seconds, all
remaining doors will unlock.
V(Trunk Release):The trunk will unlock when this
button is pressed, as long as the trunk lockout is
not engaged. You can open the trunk with the
transmitter when the vehicle speed is less than 2 mph
(3 km/h). The headlamps will ¯ash twice.
L(Panic):The horn will sound and the headlamps
and interior lamps will ¯ash alternately when this button
is pressed. They can be turned off by pressing the
panic button again or by turning the ignition to ON. The
alarm will sound for two minutes unless cancelled by
the driver.
Your dealer can change the settings to disable the
headlamp ¯ash and horn chirp features. Your dealer can
also change the settings to allow the horn to chirp
twice on the ®rst press of the UNLOCK button. See your
dealer for more information.
Radio Personalization
Your vehicle can store different radio preset stations
depending on which keyless entry transmitter you use to
unlock the doors. The radio will recall all the stored
settings associated with that transmitter. Any radio
setting changes will be assigned to the transmitter last
used to unlock the doors.
This feature can be disabled by your dealer if you
desire. Contact your dealer for further information.
2-5

Matching Transmitter(s) to Your
Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can
be purchased through your dealer. Remember to bring
any remaining transmitters with you when you go to
your dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock
your vehicle. Each vehicle can have a maximum of four
transmitters matched to it.
Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about two years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have
to get close to your vehicle before the transmitter works,
it's probably time to change the battery.
Notice:When replacing the battery, use care not to
touch any of the circuitry. Static from your body
transferred to these surfaces may damage the
transmitter.To replace the battery in the transmitter:
1. Use a coin or similar object to separate the bottom
half from the top half of the transmitter.
2. Remove the battery and replace it with the new
one. Make sure the positive side of the battery
faces down. For battery replacement, use a
three-volt battery, type CR2032, or equivalent.
3. Read the instructions inside the case.
4. Put the two halves back together. Make sure the
cover is on tightly, so water won't get in.
5. Check the operation of the transmitter with your
vehicle. If the transmitter does not work, try
resynchronizing the transmitter with the receiver.
2-6

Resynchronization
Your remote keyless entry system is equipped with a
security system that prevents anyone from recording and
playing back your signal. The transmitter does not
send the same signal twice to the receiver. The receiver
will not respond to a signal that has been sent to it
more than once.
Normally, the transmitter and receiver resynchronize
automatically. However, under certain circumstances,
manual resynchronization may be required.
To resynchronize your transmitter and receiver, follow
these directions:
1. Stand close to your vehicle.
2. Press and hold the LOCK and UNLOCK buttons on
the transmitter at the same time.
3. Hold the buttons for at least 10 seconds. During this
time, the doors should lock and unlock once. This
con®rms the resynchronization. If the doors do
not lock and unlock, see your dealer for service.
Doors and Locks
Door Locks
{CAUTION:
Unlocked doors can be dangerous.
·Passengers Ð especially children Ð can
easily open the doors and fall out of a
moving vehicle. When a door is locked, the
handle won't open it. You increase the
chance of being thrown out of the vehicle
in a crash if the doors aren't locked. So,
wear safety belts properly and lock the
doors whenever you drive.
·Young children who get into unlocked
vehicles may be unable to get out. A child
can be overcome by extreme heat and can
suffer permanent injuries or even death
from heat stroke. Always lock your vehicle
whenever you leave it.
·Outsiders can easily enter through an
unlocked door when you slow down or
stop your vehicle. Locking your doors can
help prevent this from happening.
2-7

There are several ways to lock and unlock your vehicle.
Use your key to lock and unlock your vehicle from
the outside. If your vehicle is equipped with a remote
keyless entry system, you can also use it to lock
and unlock your vehicle. See
Remote Keyless Entry
System on page 2-3.
To lock the door from the
inside, push the locking
lever forward.
To unlock the door, pull the locking lever rearward.
Power Door Locks
If your vehicle has this
feature, you can lock or
unlock all doors on
your vehicle from the
driver's or front
passenger's door
lock switch.
Press the lower portion of the switch to lock the doors.
Press the upper portion of the switch to unlock the
doors.
The locking lever on each rear door works only
that door's lock. It won't lock (or unlock) all of the
doors ± that's a safety feature.
2-8

Rear Door Security Locks
If your vehicle is a
four-door model, it is
equipped with rear door
security locks that
help prevent passengers
from opening the rear
doors on your vehicle from
the inside.
Using the Rear Door Security Lock
1. Use a key to move the lock all the way up.
2. Close the door.
3. Do the same thing to the other rear door lock.
The rear doors on your vehicle cannot be opened from
the inside when this feature is in use.
Opening a Rear Door When the
Security Lock is On
1. Unlock the door from the inside.
2. Then open the door from the outside.
If you don't cancel the security lock feature, adults or
older children who ride in the rear won't be able to open
the rear door from the inside. You should let adults
and older children know how to cancel the locks.
Canceling the Rear Door Security Lock
1. Unlock the door from the inside and open the
door from the outside.
2. Use a key to move the lock all the way down.
3. Do the same for the other rear door.
The rear door lock will now work normally.
2-9

Lockout Protection
If your vehicle is equipped with remote keyless entry,
you have lockout protection. This feature stops the
power door locks from locking when the keys are in the
ignition and the door is open.
If the power door lock switch is pressed when a door is
open and the key is in the ignition, all the doors will
lock and the driver's door will unlock.
Leaving Your Vehicle
If you are leaving the vehicle, open your door and set
the locks from the inside. Then get out and close
the door.
Trunk
To unlock the trunk from the outside, insert the key and
turn the trunk lock cylinder or use the remote keyless
entry transmitter if your vehicle has one.
When closing the trunk, close from the center to ensure
it fully latches. Although you may use one hand to
unlock the trunk, it is recommended that two hands on
the upper surface be used to close the trunk.
{CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even
death. If you must drive with the trunk lid open
or if electrical wiring or other cable
connections must pass through the seal
between the body and the trunk lid:
·Make sure all other windows are shut.
·Turn the fan on your heating or cooling
system to its highest speed and select the
control setting that will force outside air
into your vehicle. See ªClimate Control
Systemº in the Index.
·If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.
2-10

Remote Trunk Release
Press the remote trunk release button, located on the
lower left side of the instrument panel, to release
the trunk lid.
If your vehicle is equipped with the remote keyless entry
system, the daytime running lamps will ¯ash twice.
Make sure the remote trunk release lockout feature is
not activated. Also, the remote trunk release will
only work when either the ignition is in OFF or
ACCESSORY, the parking brake is engaged or the
vehicle speed is less than 2 mph (3 km/h).
Remote Trunk Release Lockout
Your remote trunk release is equipped with a lockout
feature. The switch is located on the inside of the trunk
lid, mounted to the trunk lid latch.
To turn the lockout on, slide the switch all the way to
the left to ON. To turn the lockout off, slide the switch all
the way to the right to OFF.
When the lockout is on, the remote trunk release button
will not release the trunk lid. However, the trunk lid
can still be opened with the key, but not with the keyless
entry transmitter if your vehicle has one.
2-11

Emergency Trunk Release Handle
Notice:The emergency trunk release handle is not
designed to be used to tie down the trunk lid or
as an anchor point when securing items in the trunk.
Improper use of the emergency trunk release
handle could damage it.There is a glow-in-the-dark emergency trunk release
handle located on the inside of the trunk lid of your
vehicle. This handle will glow following exposure to light.
Pull the release handle up to open the trunk from the
inside.
Trap-Resistant Trunk Kit
To help prevent a child from becoming trapped in your
trunk, you can order a trap-resistant trunk kit from
your dealer. This kit includes:
·a modi®ed trunk latch,
·a lighted release handle, and
·seatback tethers (for vehicles with folding rear
seatbacks).
See your dealer for additional information.
2-12

Windows
{CAUTION:
Leaving children in a vehicle with the windows
closed is dangerous. A child can be overcome
by the extreme heat and can suffer permanent
injuries or even death from heat stroke. Never
leave a child alone in a vehicle, especially with
the windows closed in warm or hot weather.
2-13

Manual Windows
On a vehicle with manual windows, use the window
crank to open and close each window.
Power Windows
If your vehicle has this feature, the switches on the
center console control each of the power windows when
the ignition is on. In addition, on four-door models,
each rear passenger door has a control switch for its
own window.To lower a window, press and hold the rear of the
switch. To raise the window, press and hold the switch
forward.
Express-Down Window
The driver's window switch has an express-down
feature. The driver's window can be opened to the
desired position by pressing the rear of the switch to the
®rst detent. To use the express-down feature, press
the rear of the switch all the way down. The window will
continue going down until fully opened.
To stop the window while it is lowering, brie¯y press the
switch forward, then release it.
Window Lock-Out
Four-door models also have a lock-out switch. Press the
lock-out switch to disable the rear passenger's power
window switches. This will prevent rear passengers from
opening and closing the windows. The driver can still
control all windows with the switch in the lock position.
Press the lock-out switch again to enable the
passenger's window switches.
Sun Visors
To block out glare, you can swing down the visors. You
can also swing them to the side.
2-14
