{CAUTION:
If you spill fuel and then something ignites it,
you could be badly burned. Fuel can spray out
on you if you open the fuel cap too quickly.
This spray can happen if your tank is nearly
full, and is more likely in hot weather. Open
the fuel cap slowly and wait for any hiss noise
to stop. Then unscrew the cap all the way.
Be careful not to spill fuel. Do not top off or overll the
tank and wait a few seconds after you have nished
pumping before removing the nozzle. Clean fuel
from painted surfaces as soon as possible. See
Washing Your Vehicle on page 5-85.
When replacing the fuel cap, turn it clockwise until it
clicks. Make sure the cap is fully installed. The
diagnostic system can determine if the fuel cap has
been left off or improperly installed. This would allow fuel
to evaporate into the atmosphere. SeeMalfunction
Indicator Lamp on page 3-30.
The CHECK GAS CAP message will be displayed on
the Driver Information Center (DIC) if the fuel cap is not
properly installed. SeeDIC Warnings and Messages
on page 3-37for more information.
{CAUTION:
If a re starts while you are refueling, do not
remove the nozzle. Shut off the ow of fuel by
shutting off the pump or by notifying the
station attendant. Leave the area immediately.
Notice:If you need a new fuel cap, be sure to get
the right type. Your dealer can get one for you.
If you get the wrong type, it may not t properly.
This may cause your malfunction indicator lamp to
light and may damage your fuel tank and emissions
system. SeeMalfunction Indicator Lamp on
page 3-30.
5-9

{CAUTION:
You can be burned if you spill coolant on hot
engine parts. Coolant contains ethylene glycol,
and it will burn if the engine parts are hot
enough. Do not spill coolant on a hot engine.
1. You can remove the ll neck pressure cap when
the intercooler system, including the upper
intercooler hose, is no longer hot. Turn the pressure
cap slowly counterclockwise about one-quarter of
a turn. If you hear a hiss, wait for that to stop. This
will allow any remaining pressure to be vented.
2. Then keep turning the pressure cap slowly, and
remove it.3. Add the proper DEX-COOL
®coolant mixture to the
ll neck, until there is coolant visible in the horizontal
tube section of the ll neck.
4. With the ll neck pressure cap off, start the engine
and let it run for at least 30 seconds. Watch out for
the engine cooling fan. Turn the engine off. By
this time, the coolant level inside the ll neck may
be lower. If the level drops so that coolant is
no longer visible in the horizontal tube section of
the ll neck, add more of the DEX-COOL
®coolant
mixture to the ll neck until the level is again
visible in the horizontal tube section.
5. Replace the intercooler system pressure cap. Be
sure the pressure cap is hand-tight and fully
seated.
If the coolant is not at the proper level when the
system cools down again, see your dealer.
5-28

Notice:In cold weather, water can freeze and crack
the engine, radiator, heater core and other parts.
Use the recommended coolant and the proper
coolant mixture.
{CAUTION:
You can be burned if you spill coolant on hot
engine parts. Coolant contains ethylene glycol
and it will burn if the engine parts are hot
enough. Do not spill coolant on a hot engine.
1. You can remove the coolant surge tank pressure
cap when the cooling system, including the coolant
surge tank pressure cap and upper radiator
hose, is no longer hot. Turn the pressure cap slowly
counterclockwise about two or two and one-half
turns. If you hear a hiss, wait for that to stop. This
will allow any pressure still left to be vented out
the discharge hose.2. Then keep turning the
pressure cap slowly,
and remove it.
5-34

5. Pull the headlamp assembly up on an angle and
towards the radiator to remove.
6. Disconnect the bulb base from the wiring harness
by lifting the plastic locking tab.
7. To replace a headlamp bulb, do the following:
Disconnect the wiring harness from the bulb
socket.
Remove the black retainer by turning it
counterclockwise.
8. Turn the bulb socket for the headlamp, front turn
signal or parking lamp counterclockwise to remove.
For the sidemarker bulb, you will need to us a
tool to assist in turning the bulb socket.
9. Pull the old bulb out of the socket.
10. Install a new bulb.11. Reinstall the bulb assembly by reversing Steps 1
through 8.
When reinstalling the headlamp assembly, rst
ensure that the wiring harness is in its original
position. If not, the headlamp assembly will not t
correctly.
You will also need to line up the two tabs on the
bottom of the assembly that t into two slots in the
headlamp assembly bracket.
Center High-Mounted Stoplamp
(CHMSL)
To replace a CHMSL bulb, do the following:
1. Open the trunk. SeeTrunk on page 2-10for more
information.
2. Locate the CHMSL bulb assembly in the trunk lid.
3. Use a tool to depress the plastic tabs to release the
bulb assembly.
5-49

5. Remove the taillamp from the quarter panel.
6. Remove the taillamp bulb socket from the assembly
by turning it counterclockwise.
7. Pull the old bulb out of the socket.
8. Install a new bulb.
9. Reverse Steps 1 through 6 to reinstall the taillamp
assembly.
Taillamps, Turn Signal, Stoplamps
and Back-up Lamps
To replace one of these bulbs, do the following:
1. Open the trunk. SeeTrunk on page 2-10for more
information.
2. Remove the fastener which holds down the
trunk trim.
3. Remove the outer two screws from the taillamp
assembly.
4. Disconnect the wiring harness by lifting up on the
tab to release and pull it straight out.
5. Remove the taillamp from the quarter panel.A. Sidemarker
B. Stoplamp/Turn Signal/Taillamp
C. Back-up
6. Locate the bulb you wish to change
7. Remove the taillamp bulb socket from the assembly
by turning it counterclockwise.
8. Pull the old bulb out of the socket.
9. Install a new bulb.
10. Reverse Steps 1 through 6 to reinstall the taillamp
assembly.
5-51

Back-Up Lamps (Coupe)
To replace a back-up lamp bulb, do the following:
1. Open the trunk. SeeTrunk on page 2-10for more
information.
2. Locate the back-up lamp bulb assembly in the
trunk lid.3. Remove the bulb socket by turning it
counterclockwise.
On vehicles that have a back-up lamp cover, rst
remove it by depressing the tab at the top.
4. Pull out the old bulb.
5. Install a new bulb.
6. Reinstall the bulb socket by aligning the tabs and
turning it clockwise to secure.
Reinstall the back-up lamp cover if your vehicle
has one.
5-52

3. Remove the nut that holds down the spare tire. See
Compact Spare Tire on page 5-80
4. Remove the spare tire by placing your hands at the
four and eight o’clock positions. Gently pull it up
and out of the trunk.
5. Remove the wing nut that holds the jack and
remove the jack and wheel wrench.Uplevel Models
1. Open the trunk. SeeTrunk on page 2-10for more
information.
2. Lift the trunk liner and place the plastic hook in the
lip of the trunk lid.
5-72

3. Remove the wing nut that retains the jack and the
spare tire.
4. Remove the spare tire by placing your hands at the
four and eight o’clock positions. Gently pull it up
and out of the trunk.
The tools you will be using include the jack (A) and
wheel wrench (B).
5-73

You will need to turn the plastic wheel nut
counterclockwise to loosen the wheel wrench from
the jack.Press the button and then pull on the end of the wheel
wrench to extend the handle.
5-74

5. Raise the jack head until it ts rmly in the vehicle’s
frame, where the notch is located, nearest the
at tire.
6. Put the compact spare tire near you.
{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack you
could be badly injured or killed. Never get
under a vehicle when it is supported only by
a jack.
{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to t the
jack lift head into the proper location before
raising the vehicle.7. Raise the vehicle by turning the jack handle
clockwise. Raise the vehicle far enough off the
ground so there is enough room for the compact
spare tire to t under the vehicle.
8. Remove all of the wheel nuts.
{CAUTION:
Rust or dirt on the wheel, or on the parts to
which it is fastened, can make the wheel nuts
become loose after a time. The wheel could
come off and cause an accident. When you
change a wheel, remove any rust or dirt from
the places where the wheel attaches to the
vehicle. In an emergency, you can use a cloth
or a paper towel to do this; but be sure to use
a scraper or wire brush later, if you need to, to
get all the rust or dirt off.
