3. Position the jack (A) under the vehicle as shown for
the front or rear locations.If the at tire is on the front of the vehicle, position
the jack to the rear of the front tire in the pocket
off of the frame. Front Position
Front Position
5-75

If the at tire is on the rear, position the jack under
the rear axle and get as close as possible to the
shock absorber.
4. Make sure the jack head is positioned so that the
rear axle is resting securely between the grooves
that are on the jack head.5. Turn the wheel wrench clockwise to raise the
vehicle. Raise the vehicle far enough off the ground
so there is enough room for the spare tire to t
under the wheel well.
6. Remove all the wheel
nuts and take off the
at tire.
Rear Position
5-76

{CAUTION:
Rust or dirt on the wheel, or on the parts to
which it is fastened, can make the wheel nuts
become loose after a time. The wheel could
come off and cause an accident. When you
change a wheel, remove any rust or dirt from
the places where the wheel attaches to the
vehicle. In an emergency, you can use a cloth
or a paper towel to do this; but be sure to use
a scraper or wire brush later, if you need to,
to get all the rust or dirt off.
7. Remove any rust or dirt
from the wheel bolts,
mounting surfaces
and spare wheel.8. Install the spare tire.{CAUTION:
Never use oil or grease on studs or nuts. If
you do, the nuts might come loose. Your wheel
could fall off, causing a serious accident.
9. Put the wheel nuts
back on with the
rounded end of the
nuts toward the wheel.
Tighten each wheel
nut by hand. Then use
the wheel wrench to
tighten the nuts
until the wheel is held
against the hub.
5-77

10. Turn the wheel wrench counterclockwise to lower
the vehicle. Lower the jack completely. Front Position
Rear Position
5-78

{CAUTION:
Incorrect wheel nuts or improperly tightened
wheel nuts can cause the wheel to come loose
and even come off. This could lead to an
accident. Be sure to use the correct wheel
nuts. If you have to replace them, be sure to
get new GM original equipment wheel nuts.
Stop somewhere as soon as you can and have
the nuts tightened with a torque wrench to the
proper torque specication. SeeCapacities
and Specifications on page 5-103for wheel nut
torque specication.
Notice:Improperly tightened wheel nuts can
lead to brake pulsation and rotor damage. To
avoid expensive brake repairs, evenly tighten the
wheel nuts in the proper sequence and to the
proper torque specication. SeeCapacities and
Specifications on page 5-103for the wheel nut
torque specication.11. Tighten the wheel nuts
rmly in a crisscross
sequence as shown by
turning the wheel
wrench clockwise.
When you reinstall the regular wheel and tire, you must
also reinstall the center cap. Place the cap on the
wheel and tap it into place until it seats ush with the
wheel. The cap only goes on one way. Be sure to line up
the tab on the center cap with the indentation on the
wheel.
For the Xtreme, tighten each nut cap by hand, then
tighten an additional one quarter of a turn with the
wheel wrench.
5-79

Secondary Latch System
Your vehicle has an underbody-mounted tire hoist
assembly equipped with a secondary latch system.
It is designed to stop the spare tire from suddenly falling
off your vehicle. For the secondary latch to work, the
spare must be installed with the valve stem pointing
down. SeeStoring a Flat or Spare Tire and Tools
on page 5-83.
{CAUTION:
Before beginning this procedure read all the
instructions. Failure to read and follow the
instructions could damage the hoist assembly
and you and others could get hurt. Read and
follow the instructions listed below.To release the spare tire from the secondary latch,
do the following:
1. Check under the
vehicle to see if the
cable end tting
is visible.
2. If the cable end tting is not visible, proceed to
Step 6.
If it is visible, rst try to tighten the cable by
turning the wheel wrench clockwise until you
hear two clicks or feel it skip twice. You cannot
overtighten the cable.
3. Loosen the cable by turning the wheel wrench
counterclockwise three or four turns.
5-80

4. Repeat this procedure at least two times. If the
spare tire lowers to the ground, continue with
Step 5 underRemoving the Spare Tire and Tools
on page 5-69.
5. Turn the wrench counterclockwise until
approximately 6 inches (15 cm) of cable is exposed.
6. Stand the wheel blocks on their shortest ends, with
the backs facing each other.
7. Place the bottom edge
of the jack (A) on the
wheel blocks (B),
separating them so that
the jack is balanced
securely.
8. Attach the jack handle, extension, and wheel
wrench to the jack and place it (with the wheel
blocks) under the vehicle towards the front of the
rear bumper. Position the center lift point of the
jack under the wheel.
9. Turn the wrench clockwise to raise the jack until it
lifts the tire.
10. Continue raising the jack until the tire stops moving
upward and is held rmly in place, the secondary
latch has released and the tire is balancing on
the jack.
5-81

11. Remove the jack handle and insert the hoist end of
the extension through the hole in the rear bumper.
Turn the wheel counterclockwise one turn or
until the wheel retainer assembly falls out.
12. Reinsert the jack handle into the jack. Lower the
jack by turning the wheel wrench counterclockwise.
Keep lowering the jack until the spare tire slides
off the jack or is hanging by the cable.
{CAUTION:
Someone standing too close during the
procedure could be injured by the jack. If the
spare tire does not slide off the jack completely,
make sure no one is behind you or on either
side of you as you pull the jack out from the
spare.
13. Disconnect the jack handle from the jack and
carefully remove the jack. Use one hand to
push against the spare while rmly pulling the
jack out from under the spare tire with the
other hand.
If the spare tire is hanging from the cable, insert
the hoist handle, extension and wheel wrench into
the hoist shaft hole in the bumper and turn the
wheel wrench counterclockwise to lower the spare
the rest of the way.
5-82

14. Tilt the tire retainer at the end of the cable and pull
it through the wheel opening. Pull the tire out from
under the vehicle.
15. If the cable is hanging under the vehicle, turn the
wheel wrench clockwise to raise the cable back up.
Have the hoist assembly inspected as soon as you
can. You will not be able to store a spare or at
tire using the hoist assembly until it has been
replaced.
To continue changing the at tire, seeRemoving the
Flat Tire and Installing the Spare Tire on page 5-73.
Storing a Flat or Spare Tire
and Tools
{CAUTION:
Storing a jack, a tire, or other equipment in
the passenger compartment of the vehicle
could cause injury. In a sudden stop or
collision, loose equipment could strike
someone. Store all these in the proper place.
Notice:Storing an aluminum wheel with a at tire
under your vehicle for an extended period of time
or with the valve stem pointing up may damage the
wheel. Always stow the wheel with the valve stem
pointing down and have the wheel/tire repaired
as soon as possible.
Store the tire under the rear of the vehicle in the spare tire
carrier. Use the following art and text to help you.
1. Put the tire on the ground at the rear of the vehicle
with the valve stem pointed down.
5-83

2. Tilt the retainer downward and through the wheel
opening. Make sure the retainer is fully seated
across the underside of the wheel.3. Attach the wheel wrench and extensions together.
