wiper size CHEVROLET COLORADO 2020 Owner's Manual

Chevrolet Colorado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566640) - 2020 - CRC - 10/4/19
222 Vehicle Care
Vehicle Care
General Information
General Information . . . . . . . . . . 223
California Proposition65 Warning . . . . . . . . . . . . . . . . . 223
California Perchlorate Materials Requirements . . . . . 224
Accessories and Modifications . . . . . . . . . . . . . . . . 224
Vehicle Checks
Doing Your OwnService Work . . . . . . . . . . . . . . . 224
Hood . . . . . . . . . . . . . . . . . . . . . . . . . 225
Engine Compartment Overview . . . . . . . . . . . . . . . . . . . . 227
Engine Oil . . . . . . . . . . . . . . . . . . . . 230
Engine Oil Life System . . . . . . . 232
Automatic Transmission Fluid . . . . . . . . . . . . . . . . . . . . . . . . 234
Engine Air Cleaner/Filter . . . . . . 234
Cooling System . . . . . . . . . . . . . . 236
Engine Overheating . . . . . . . . . . 239
Engine Fan . . . . . . . . . . . . . . . . . . . 240
Washer Fluid . . . . . . . . . . . . . . . . . 241
Brakes . . . . . . . . . . . . . . . . . . . . . . . 242
Brake Fluid . . . . . . . . . . . . . . . . . . . 242
Battery - North America . . . . . . 243 Four-Wheel Drive . . . . . . . . . . . . . 244
Front Axle . . . . . . . . . . . . . . . . . . . . 245
Rear Axle . . . . . . . . . . . . . . . . . . . . 245
Starter Switch Check . . . . . . . . . 245
Automatic Transmission Shift
Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 246
Ignition Transmission Lock Check . . . . . . . . . . . . . . . . . . . . . . . 246
Park Brake and P (Park) Mechanism Check . . . . . . . . . . 246
Wiper Blade Replacement . . . . 247
Windshield Replacement . . . . . 247
Gas Strut(s) . . . . . . . . . . . . . . . . . . 248
Headlamp Aiming
Front Headlamp Aiming . . . . . . 249
Bulb Replacement
Bulb Replacement . . . . . . . . . . . . 249
Halogen Bulbs . . . . . . . . . . . . . . . . 249
Headlamps, Front Turn Signal, Sidemarker, and Parking
Lamps . . . . . . . . . . . . . . . . . . . . . . 250
Taillamps, Turn Signal, Stoplamps, and Back-Up
Lamps . . . . . . . . . . . . . . . . . . . . . . 250
Center High-Mounted Stoplamp (CHMSL) and
Cargo Lamp . . . . . . . . . . . . . . . . . 252
Electrical System
Electrical System Overload . . . 252
Fuses and Circuit Breakers . . . 253
Engine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 253
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 258
Wheels and Tires
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 261
All-Season Tires . . . . . . . . . . . . . . 262
Winter Tires . . . . . . . . . . . . . . . . . . 262
All-Terrain Tires . . . . . . . . . . . . . . . 263
Tire Sidewall Labeling . . . . . . . . 263
Tire Designations . . . . . . . . . . . . . 265
Tire Terminology andDefinitions . . . . . . . . . . . . . . . . . . 266
Tire Pressure . . . . . . . . . . . . . . . . . 268
Tire Pressure Monitor
System . . . . . . . . . . . . . . . . . . . . . . 269
Tire Pressure Monitor Operation . . . . . . . . . . . . . . . . . . . 270
Tire Inspection . . . . . . . . . . . . . . . . 275
Tire Rotation . . . . . . . . . . . . . . . . . 275
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 276
Buying New Tires . . . . . . . . . . . . . 277
Different Size Tires and Wheels . . . . . . . . . . . . . . . . . . . . . . 278

Chevrolet Colorado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566640) - 2020 - CRC - 10/4/19
Vehicle Care 253
Windshield Wipers
If the wiper motor overheats due to
heavy snow or ice, the windshield
wipers will stop until the motor cools
and will then restart.
Although the circuit is protected
from electrical overload, overload
due to heavy snow or ice may
cause wiper linkage damage.
Always clear ice and heavy snow
from the windshield before using the
windshield wipers.
If the overload is caused by an
electrical problem and not snow or
ice, be sure to get it fixed.
Fuses and Circuit
Breakers
The wiring circuits in the vehicle are
protected from short circuits by a
combination of fuses and circuit
breakers. This greatly reduces the
chance of damage caused by
electrical problems.
{Danger
Fuses and circuit breakers are
marked with their ampere rating.
Do not exceed the
specified amperage rating when
replacing fuses and circuit
breakers. Use of an oversized
fuse or circuit breaker can result
in a vehicle fire. You and others
could be seriously injured or
killed.
To check a fuse, look at the
silver-colored band inside the fuse.
If the band is broken or melted,
replace the fuse. Be sure to replace
a bad fuse with a new one of the
identical size and rating.
Fuses of the same amperage can
be temporarily borrowed from
another fuse location, if a fuse goes
out. Replace the fuse as soon as
possible.
Engine Compartment
Fuse Block
If the vehicle has a diesel engine,
see the Duramax diesel
supplement.
The engine compartment fuse block
is in the engine compartment, on
the driver side of the vehicle. See
Engine Compartment Overview
0 227
Lift the cover to access the fuse
block.

Chevrolet Colorado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566640) - 2020 - CRC - 9/30/19
366 Index
V
VehicleAlarm System . . . . . . . . . . . . . . . . . . 19
Canadian Owners . . . . . . . . . . . . . . . 2
Control . . . . . . . . . . . . . . . . . . . . . . . 143
Identification Number (VIN) . . . 329
Load Limits . . . . . . . . . . . . . . . . . . . 153
Messages . . . . . . . . . . . . . . . . . . . . .119
Personalization . . . . . . . . . . . . . . . 120
Remote Start . . . . . . . . . . . . . . . . . . . 15
Security . . . . . . . . . . . . . . . . . . . . . . . . 19
Speed Messages . . . . . . . . . . . . . 120
Towing . . . . . . . . . . . . . . . . . . . . . . . . 299
Vehicle Ahead Indicator . . . . . . . . 109
Vehicle Care
Tire Pressure . . . . . . . . . . . . . . . . . 268
Vehicle Data Recording and Privacy . . . . . . . . . . . . . . . . . . . . . . . . 345
Ventilation, Air . . . . . . . . . . . . . . . . . . 138
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
W
Warning Brake System Light . . . . . . . . . . . 108
Caution and Danger . . . . . . . . . . . . . 2
Lane Departure (LDW) . . . . . . . 197
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . . . . . . . 96 Warnings
Hazard Flashers . . . . . . . . . . . . . . 127
Washer Fluid . . . . . . . . . . . . . . . . . . . 241
Wheels Alignment and Tire Balance . . 280
Different Size . . . . . . . . . . . . . . . . . 278
Replacement . . . . . . . . . . . . . . . . . 281
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 276
Where to Put the Restraint . . . . . . 62
Windows . . . . . . . . . . . . . . . . . . . . . . . . 24 Power . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Windshield Replacement . . . . . . . . . . . . . . . . . 247
Wiper/Washer . . . . . . . . . . . . . . . . . . 92
Winter Driving . . . . . . . . . . . . . . . . . . . . . . . . 151
Winter Tires . . . . . . . . . . . . . . . . . . . . 262
Wiper Blade Replacement . . . . . . 247
Wireless Charging . . . . . . . . . . . . . . . 94
