CHEVROLET EXPRESS CARGO VAN 2001 1.G Owners Manual

3-17
If the player detects a tight or broken tape, ERR (error)
will appear on the display and the player will eject the
tape. The radio will go back to playing the last
station selected.
If you want to insert a tape when the ignition is off, first
press the eject button or the RCL knob.
PREV (1): Press this button or the left SEEK arrow to
go to the previous selection on the tape if the selection
has been playing for less than 3 seconds. If the PREV
button or the left SEEK arrow is pressed and the current
selection has been playing for more than 13 seconds, it
will go to the beginning of the current selection. If the
PREV button or the left SEEK arrow is pressed and the
current selection has been playing from 3 to 13 seconds,
it will go to the beginning of the previous selection or
the beginning of the current selection, depending on the
position on the tape. PRE will appear on the display
while the cassette player is in PREV mode. Your tape
must have at least three seconds of silence between
each selection for PREV to work. The sound will mute
while seeking.NEXT (2): Press this button or the right SEEK arrow to
go to the next selection on the tape. NXT will appear on
the display while the cassette player is in NEXT mode.
Your tape must have at least three seconds of silence
between each selection for NEXT to work. The sound
will mute while seeking.
REV (3): Press this button to reverse the tape rapidly.
REV will appear on the display. Press it again to return
to playing the tape. The radio will play the last selected
station while the tape reverses. You may select stations
during REV operation by using TUNE, SEEK, SCAN or
PRESET SCAN.
FWD (4): Press this button to advance quickly to
another part of the tape. FWD will appear on the display.
Press the button again to return to playing the tape.
The radio will play the last selected station while the
tape advances. You may select stations during FWD
operation by using TUNE, SEEK, SCAN or
PRESET SCAN.
SIDE (5): Press this button to play the other side
of the tape.

3-18
RPT (6): Press this button once to hear a selection over
again. RPT will appear on the display. The current
selection will continue to repeat. RPT will flash on the
display while the cassette player is searching for the
start of the selection. Your tape must have at least
three seconds of silence between each selection for RPT
to work. Press this button again to turn off repeated play.
OFF will appear on the display.
AM FM: Press this button to play the radio when
a tape is in the player. The tape will stop but remain in
the player.
TAPE: With a cassette tape in the player and the radio
playing, press this button to play a cassette tape. CAS
will appear on the display. Press AM FM to return to the
radio when a cassette tape is playing. The inactive tape
will remain safely inside the radio for future listening.
In order to use a portable CD player adapter or a cassette
tape head cleaner you must disable the TIGHT/LOOSE
TAPE sensor. Press and hold the TAPE button for two
seconds with the radio off and the vehicle on. CAS will
flash on the display showing the TIGHT/LOOSE TAPE
sensor has been disabled. The feature will remain
disabled until the tape is ejected.: Press this button to remove a tape. The radio will
play. Eject may be activated with the radio off. Cassette
tapes may be loaded with the radio and vehicle off if this
button is pressed first.
CLN: If this message appears on the display, the
cassette tape player needs to be cleaned. It will still play
tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index. After you clean
the player, press and hold the eject button for five
seconds to reset the CLN indicator. The radio display
will flash
--- to show the indicator was reset.
Radio Calibration
Your audio system has been calibrated for your vehicle
from the factory. If CAL appears on the display it means
that your radio has not been configured properly for
your vehicle and must be returned to the dealership
for service.
LOC: This message is displayed when the
THEFTLOCK

system has locked up. Your vehicle
must be returned to the dealership for service.

3-19 AM-FM Stereo with Compact Disc Player
(If Equipped)
Playing the Radio
PWR VOL: Press this knob to turn the system on and
off. To increase volume, turn the knob clockwise. Turn
it counterclockwise to decrease volume.
RCL: Press this knob to recall the station being played
or to display the clock. Pressing RCL while playing a
CD will also display the CD track number or elapsed
time of CD track.Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Turn this knob to choose radio stations.
SEEK: Press the right arrow to tune to the next higher
station and the left arrow to tune to the next lower
station and stay there. The radio will seek to stations
with a strong signal only.
SCAN: Press and hold one of the SEEK arrows for
two seconds until you hear a beep. Use SCAN to listen
to stations for a few seconds. The radio will go to a
station, stop for a few seconds and flash the station
frequency, then go on to the next station. Press one of
the SEEK arrows again to stop scanning. The radio will
scan to stations with a strong signal only.
PRESET SCAN: Press and hold one of the SEEK
arrows for more than four seconds until you will hear a
double beep. Use PRESET SCAN to listen to each of
your preset stations for a few seconds. The radio will go
to the first preset station stored on your pushbuttons,
except those stations with weak reception, stop for a few
seconds and flash the station frequency, then go on to
the next preset station. Press one of the SEEK arrows
again to stop scanning presets. The channel number
(P1
-P6) will appear momentarily just before the
frequency is displayed.

3-20
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2). Just:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press and hold one of the six numbered buttons until
you hear a beep. Whenever you press that numbered
button, the station you set will return.
5. Repeat the steps for each pushbutton.
Setting the Tone
BASS: Press and release AUDIO until BAS appears on
the display. Then press and hold the up arrow to increase
bass. ªBº and a positive number will appear on the
display. Press and hold the down arrow to decrease bass.
B and a negative number will appear on the display.
B and a zero will appear on the display when the bass
level is set to the middle position. Release the up or
down arrow when you find the bass level you want or
when the maximum or minimum level is reached.TREBLE: Press and release AUDIO until TRE appears
on the display. Then press and hold the up arrow to
increase treble. ªTº and a positive number will appear
on the display. Press and hold the down arrow to
decrease treble. T and a negative number will appear on
the display. T and a zero will appear on the display when
the treble level is set to the middle position. Release the
up or down arrow when you find the treble level you
want or when the maximum or minimum level is
reached. If a station is weak or noisy, you may want to
decrease the treble.
To set BASS or TREBLE to the middle position, first
select the desired tone control. Then press and hold
AUDIO for more than two seconds until you hear a
beep. B and a zero or T and a zero will appear on the
display. To set all of the tone controls and speaker
controls to the middle position, end out of audio mode.
Then press and hold AUDIO for more than two seconds
until you hear a beep. CEN will appear on the display.

3-21
Adjusting the Speakers
BALANCE: Press and release AUDIO until BAL
appears on the display. Then press and hold the up arrow
to move the sound to the right speakers or the down
arrow to move the sound to the left speakers. ªRº and a
number will appear on the display when the sound is
balanced toward the right speakers. ªLº and a number
will appear on the display when the sound is balanced
toward the left speakers. L and a zero will appear on the
display when the the sound is balanced between the
speakers. Release the up or down arrow when you find
the speaker balance you want or when the maximum or
minimum level is reached.
FADE: Press and release AUDIO until FAD appears on
the display. Then press and hold the up arrow to move
the sound to the front speakers or the down arrow to
move the sound to the rear speakers. ªFº and a number
will appear on the display when the sound is balanced
toward the front speakers. ªRº and a number will appear
on the display when the sound is balanced toward the
rear speakers. F and a zero will appear on the display
when the the sound is balanced between the speakers.
Release the up or down arrow when you find the speaker
balance you want or when the maximum or minimum
level is reached.To set BALANCE or FADE to the middle position, first
select the desired speaker control. Then press and hold
AUDIO for more than two seconds until you hear a
beep. L and a zero or F and a zero will appear on the
display. To set all of the tone controls and speaker
controls to the middle position, end out of audio mode.
Then press and hold AUDIO for more than two seconds
until you hear a beep. CEN will appear on the display.
Playing a Compact Disc
Insert a disc partway into the slot, label side up. The
player will pull it in. The disc should begin playing.
The display will show CD. If you want to insert a
compact disc with the ignition off, first press RCL or
the eject button.
If you're driving on a very rough road or if it's very hot,
the disc may not play and Err (error) may appear on the
display. When the road becomes smooth or the
temperature returns to normal, the disc should play.
If the disc comes out, it could be that:

The disc is upside down.

It is dirty, scratched or wet.

It is very humid. (If so, wait about an hour and
try again.)
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer.

3-22
PREV (1): Press this button or the left SEEK arrow to
go to the previous track if the current selection has been
playing for less than eight seconds. If the PREV button
or the left SEEK arrow is pressed and the current
selection has been playing for more than eight seconds,
it will go to the beginning of the current selection. The
track number will appear on the display. If you hold the
button or press it more than once, the player will
continue moving back through the disc. The sound will
mute while seeking.
NEXT (2): Press this button or the right SEEK arrow to
go to the next track. The track number will appear on
the display. If you hold the button or press it more than
once, the player will continue moving forward through
the disc. The sound will mute while seeking.
REV (3): Press and hold this button to reverse quickly
within a track. Release it to play the passage. The
display will show elapsed time while reversing.
FWD (4): Press and hold this button to advance quickly
within a track. Release it to play the passage. The
display will show elapsed time while forwarding.RDM (5): Press this button to hear the tracks in random,
rather than sequential, order. RND will show on the
display. Press RDM again to turn off random play.
OFF will appear on the display.
RPT (6): Press this button once to hear a selection over
again. RPT will appear on the display. The current track
will continue to repeat. Press RPT button again to turn
off repeated play. OFF will appear on the display.
RCL: Press this button to see the current track number
or how long the current track has been playing.
AM FM: Press this button to play the radio when
a disc is in the player. The disc will stop but remain in
the player.
CD: With a compact disc in the player and the
radio playing, press this button to play a compact disc.
CD will appear on the display. Press AM FM to
return to the radio when a compact disc is playing.
The inactive CD will remain safely inside the radio
for future listening.
: Press this button to remove the disc. The radio will
play. Eject may be activated with either the ignition or
radio off. CDs may be loaded with the radio and ignition
off if this button is pressed first.

3-23
Radio Calibration
Your audio system has been calibrated for your vehicle
from the factory. If CAL appears on the display it means
that your radio has not been configured properly for
your vehicle and must be returned to the dealership
for service.
LOC: This message is displayed when the
THEFTLOCK

system has locked up. Your vehicle
must be returned to the dealership for service.
AM-FM Stereo with Cassette Tape and
Compact Disc Player with Radio Data
System (RDS) and Automatic Tone Control
(If Equipped)
Playing the Radio
PWR: Press this button to turn the system on and off.
VOL: Turn this knob clockwise to increase volume.
Turn it counterclockwise to decrease volume.
DISP: Press this button to display the clock with the
ignition off. Press this button to display an RDS station
frequency or program type when the radio is on.

3-24
AUTO VOL: Your system has a feature called
Speed
-Compensated Volume (SCV). With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive. Set the volume at the
desired level. Press AUTO VOL to adjust the SCV.
AVOL will appear on the display. Each time you press
AUTO VOL, another volume setting (LOW, MEDIUM
or HIGH) will appear on the display. NONE will appear
on the display if the radio cannot find out the vehicle
speed. Then, as you drive, SCV automatically increases
the volume, as necessary, to overcome noise at any
particular speed. The volume level should always sound
the same to you as you drive. If you don't want to use
SCV, select OFF. Each volume setting allows for more
volume compensation at faster vehicle speeds.
Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Turn this knob to choose radio stations.SEEK: Press the right arrow to tune to the next higher
station and the left arrow to tune to the next lower
station and stay there. The radio will seek to stations
with a strong signal only.
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2). Just:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press AUTO TONE to select the equalization that
best suits the type of station selected.
5. Press and hold one of the six numbered buttons. The
radio will beep once to confirm. Whenever you press
that numbered button, the station you set will return
and the AUTO TONE equalization that you selected
will also be automatically selected for that button.
6. Repeat the steps for each pushbutton.

3-25
P SCAN: Press and hold one of the arrows for more
than two seconds. The radio will beep once to confirm.
Use P SCAN to listen to each of your favorite stations
stored on your pushbuttons for a few seconds. The radio
will scan through each of the stations stored on your
pushbuttons, except those stations with weak reception.
The AUTO TONE setting stored for that pushbutton will
be automatically chosen. Press P SCAN or one of the
pushbuttons again to stop scanning. SCAN will be
displayed whenever the tuner is in the P SCAN mode.
The channel number (P1
-P6) will appear with the
frequency. In FM mode, this function will scan through
the current band such as FM1 or FM2.Setting the Tone
BASS: Press and release the P
-TYPE LIST/AUDIO
knob until BASS appears on the display. Then turn the
knob clockwise to increase bass and counterclockwise to
decrease bass. The display will show the bass level.
When you use this control, the radio's AUTO TONE
setting will switch to manual. To set bass to the middle
position, select the control and press and hold the
P
-TYPE LIST/AUDIO knob. The radio will produce
one beep and set the display level to the middle position.
To set all tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST/AUDIO
knob when no tone or speaker control is active. The
radio will produce one beep and display ALL with the
level display in the middle position.

3-26
TREBLE: Press and release the P-TYPE LIST/AUDIO
knob until TREB appears on the display. Turn the knob
clockwise to increase treble and counterclockwise to
decrease treble. The display will show the treble level.
When you use this control, the radio's AUTO TONE
setting will switch to manual. If a station is weak or
noisy, you may want to decrease the treble. To set treble
to the middle position, select the control and press and
hold the P
-TYPE LIST/AUDIO knob. The radio will
produce one beep and set the display level to the middle
position. To set all tone and speaker controls to the
middle position, press and hold the P
-TYPE
LIST/AUDIO knob when no tone or speaker control is
active. The radio will produce one beep and display
ALL with the level display in the middle position.
AUTO TONE: This feature allows you to choose preset
bass and treble equalization settings designed for
ROCK, NEWS, POP, JAZZ, CLASSICAL and
COUNTRY music. TONE and the preset equalization
setting will appear on the display when you press AUTO
TONE. Each time you press it, another setting will
appear on the display. The manual setting allows tone
control to return to the BASS and TREB controls. Use
PUSHBUTTONS and AUTO TONE button to program
AUTO TONE for station presets.Adjusting the Speakers
BALANCE: Press and release the P
-TYPE
LIST/AUDIO knob until BAL appears on the display.
Turn the knob clockwise to move the sound to the right
speakers and counterclockwise to move the sound to the
left speakers. The middle position balances the sound
between the speakers. The display will show the speaker
balance. To set the balance to the middle position,
select the control and press and hold the P
-TYPE
LIST/AUDIO button. The radio will produce one beep
and set the display level to the middle position. To set all
tone and speaker controls to the middle position, press
and hold the P
-TYPE LIST/AUDIO knob when no tone
or speaker control is active. The radio will produce one
beep and display ALL with the level display in the
middle position.
