3-37
Using RDS Mode
Your audio system is equipped with a Radio Data
System (RDS). RDS mode gives you many useful new
features. With RDS, the radio can:

Seek only to stations with the types of programs you
want to listen to,

seek to stations with traffic announcements,

receive announcements concerning local and
national emergencies, and

receive and display messages from radio stations.
RDS features are only available for use on FM stations
which broadcast RDS information. The RDS features of
your radio rely upon receiving specific RDS information
from these stations. These features will only work when
the RDS information is available. In rare cases, a radio
station may broadcast incorrect information that will
cause the radio features to work improperly. If this
happens, please contact the radio station.
When you are tuned to an RDS station, the station
name will appear on the display, instead of the
frequency. Most RDS stations provide their station
name, the time of day and a Program Type (PTY) for
their current programming.TRAF: Press this button to receive traffic
announcements. The traffic announcement brackets will
appear on the display. TRAF will appear on the display
if the tuned station broadcasts traffic announcements. If
the current tuned station does not broadcast traffic
announcements, the radio will seek to a station that
does. When the radio finds a station that broadcasts
traffic announcements, it will stop. If no station is found,
NONE FOUND will appear on the display.
When a traffic announcement comes on the tuned radio
station or a related network station, you will hear it,
even if the volume is muted or a compact disc is
playing. If the compact disc player was being used, the
compact disc will stay in the player and resume play at
the point where it stopped.
INFO: If the current station has a message, INFO will
appear on the display. Press this button to see the
message. If the whole message does not appear on the
display, parts of the message will appear every three
seconds until the message is completed. To see the parts
of the message faster than every three seconds, press this
button again. A new group of words will appear on the
display. Once the complete message has been displayed,
INFO will disappear from the display until another new
message is received.

3-38
P-TYPE: This button is used to turn on and off
Program Type (PTY) select. PTY and the light next to
the button will turn on. The last selected PTY will
appear on the display for five seconds. Turn the P
-TYPE
knob to select the PTY you want to listen to. Press
SEEK or SCAN to find radio stations of the PTY you
want to listen to. The last PTY selected will be used for
seek or scan modes. If a station with the selected PTY is
not found, NONE FOUND will appear on the display.
If both P
-TYPE and TRAF are on, the radio will
search for stations with traffic announcements and the
selected PTY.
To use the P
-TYPE interrupt feature, press and hold the
P
-TYPE button until you hear a beep on the PTY you
want to interrupt on. When you are listening to a
compact disc, the last selected RDS FM station will
interrupt play if that selected PTY format is broadcast.
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite Program Types (PTYs).
These buttons have factory PTY presets. You can set up
to 12 PTYs (six FM1 and six FM2) by performing the
following steps:
1. Press P
-TYPE, if it is not already on.
2. Press AM FM to select FM1 or FM2.3. Turn the SELECT knob to select a PTY.
4. Press and hold one of the six numbered buttons until
you hear a beep. Whenever you press that numbered
button, the PTY you set will return.
5. Repeat the steps for each pushbutton.
ALERT!: This type of announcement warns of national
or local emergencies. You will not be able to turn off
alert announcements. ALERT! appears on the display
when an alert announcement plays. When an alert
announcement comes on the tuned radio station, you
will hear it, even if the volume is muted or a compact
disc is playing. If the compact disc player is playing,
play will stop for the announcement and resume when
the announcement is finished.
ALTERNATE FREQUENCY: This feature allows the
radio to switch to a stronger station with the same
program type. Press and hold AM FM for two seconds
to turn alternate frequency on. AF ON will appear on the
display. The radio may switch to stronger stations. Press
and hold AM FM again for two seconds to turn alternate
frequency off. AF OFF will appear on the display. The
radio will not switch to other stations. When you turn
the ignition off and then on again, the alternate
frequency feature will automatically be turned on.

3-39
Adjusting the Speakers
BAL
-FADE: The AUDIO knob adjusts balance and
fade. To adjust balance, press the AUDIO knob until
BAL appears on the display. Turn the knob to adjust the
sound to the left or right speakers. The middle position
balances the sound between the speakers. To adjust fade,
press and hold the AUDIO knob until FAD appears on
the display. Turn the knob to adjust the sound to the
front or rear speakers. The middle position balances the
sound between the speakers.
To set the balance and fade to the middle position, select
balance or fade and press and hold the AUDIO knob.
The radio will beep once and will set the display level to
the middle position. To set all tone and speaker controls
to the middle position, press and hold the AUDIO knob
when tone or speaker controls are not active. The radio
will produce one beep and CENTERED will appear on
the display.Playing a Compact Disc
LOAD: This compact disc player will accommodate up
to six discs.
To insert one disc do the following:
1. Turn the ignition on.
2. Press and release the LOAD button.
3. Wait for the light, located to the right of the slot, to
turn green.
4. Load a disc. Insert a disc partway into the slot, label
side up. The player will pull the disc in.
When the disc is inserted, the CD symbol will be
displayed. If you select an EQ setting for your disc,
it will be activated each time you play a disc.
5. If the radio is on or off, the disc will begin to
play automatically.

3-40
To insert multiple discs do the following:
1. Turn the ignition on.
2. Press and hold the LOAD button for two seconds.
You will then hear a beep and the light, located to the
right of the slot, will begin to flash.
3. Once the light stops flashing and turns green, load a
disc. Insert a disc partway into the slot, label side up.
The player will pull the disc in.
Once the disc is loaded, the light will begin flashing
again. Once the light stops flashing and turns green
you can then load another disc. The disc player takes
up to six discs. Do not try to load more than six.
When a disc is inserted, the CD symbol will be
displayed. If more than one disc has been loaded, a
CD symbol for each disc will be displayed. If you
select an EQ setting for your disc, it will be activated
each time you play a disc.
4. If the radio is on or off, the last disc loaded will
begin to play automatically.
5. To load more than one disc but less than six,
complete steps 1, 2 and 3. When you have finished
loading discs, with the radio on or off, press LOAD
to cancel the loading function. The radio will begin
to play the last CD loaded.As each new track starts to play, the track number will
appear on the display.
If CHECK CD appears on the radio display, it could
be that:

The road is too rough. The disc should play when the
road is smoother.

The disc is dirty, scratched, wet or upside down.

The air is very humid. If so, wait about an hour and
try again.
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer. If your radio
displays an error message, write it down and provide it
to your dealer when reporting the problem.
Playing a Specific Loaded CD: For every CD loaded, a
number will appear on the radio display. To play a
specific CD, first press the CD AUX button to start
playing a CD. Then press the numbered button that
corresponds to the CD you want to play. A small bar
will appear under the CD number that is playing, and the
track number will appear.

3-41
: This button will eject a disc or discs. Do the
following to eject:

Press and release the eject button to eject the disc
that is currently playing, or

to remove all of the discs, press this button for two
seconds, you will hear a beep, and the light will flash
to let you know when a disc is being ejected.
When the eject button is pressed, the receiver will eject
the disc and REMOVE CD will be displayed. You can
either remove the disc or if the disc is not removed, after
25 seconds, the disc will be automatically pulled back
into the receiver. If you try to push the disc back into the
receiver manually, before the 25 second time period is
complete, the receiver will sense an error and will try to
eject the disc several times before stopping. You will be
able to remove the disc at this time. Pressing the
receiver's VOLUME
-PWR knob, off and then on,
will allow the receiver to clear its disc sensing feature.
You may now be able to use the LOAD and eject
features normally. Do not, at any time, press the eject
button more than once, the receiver's 25 second eject
timer will reset at each press of eject, which will cause
the receiver to not eject a disc, until the 25 second time
period has elapsed.REV: Press and hold this button to reverse quickly
within a track. Release it to play the passage. You will
hear sound at a reduced volume. The display will show
elapsed time.
FWD: Press and hold this button to advance quickly
within a track. Release it to play the passage. You will
hear sound at a reduced volume. The display will show
elapsed time.
RPT: With repeat, you can repeat one track or an entire
disc. To use repeat, do the following:

To repeat the track you are listening to, press and
release the RPT button. RPT will appear on the
display. Press RPT again to turn it off.

To repeat the disc you are listening to, press and hold
the RPT button for two seconds. Press RPT again to
turn if off.

3-42
RDM: With random, you can listen to the tracks in
random, rather than sequential order, on all of the discs
or on one disc. To use random, do the following:

Press and release the RDM button to play the tracks
on all of the discs that are loaded, in random order.
RDM will appear in the display. Press RDM to turn
it off.

To play the tracks on the disc you are listening to in
random order, press and hold RDM for more than
two seconds. You will hear a beep and RDM will
appear on the display. Press RDM again to turn
if off.
AUTO EQ: Press AUTO EQ to select the desired preset
equalization setting while playing a compact disc. The
equalization will be automatically set whenever you
play a compact disc.
SEEK: Press the left arrow while playing a CD to go to
the start of the current track, if more than ten seconds
have played. Press the right arrow to go to the next
track. If you press the button more than once, the
player will continue moving backward or forward
through the disc.SCAN: Press and hold the SEEK button for more than
two seconds until SCAN appears on the display and you
hear a beep. Use SCAN to listen to each track for a few
seconds. The sound will mute while scanning. SCAN
will appear on the display. Press this button, again, to
stop scanning.
DISC SCAN: Press and hold the SEEK button for more
than four seconds until DISC SCAN appears on the
display and you hear a beep. Use DISC SCAN to listen
to the first track, for ten seconds of each disc loaded.
The sound will mute while scanning to the next track.
DISC SCAN will appear on the display. Press the
SEEK button, again, to stop scanning.
RCL: Press this button to see how long the current track
has been playing. To change what is normally shown on
the display (track or elapsed time), press the button until
you see the display you want, then hold the button until
the display flashes.
AM FM: Press this button to play the radio when a disc
is in the player.

3-43
Using Song List Mode
The integrated 6
-disc CD changer has a feature
called song list. This feature is capable of saving
20 track selections.
To save tracks into SONG LIST:
1. The disc player must be on with at least one disc
loaded. See ªLOAD/EJECTº previously for
more information.
2. The disc changer must not be in song list mode.
S
-LIST should not appear on the display. If S-LIST
is present, press SONG LIST to turn it off.
3. Select the desired disc by pressing the numbered
pushbutton and then use the SEEK right arrow
button to locate the track that you want to save.
The track will begin to play.
4. Press and hold SONG LIST for two or more seconds
to save the track into memory. When SONG LIST is
pressed a beep will be heard immediately. After
two seconds of pressing SONG LIST continuously,
two beeps will sound, to confirm that the track has
been saved.
5. Repeat Steps 3 and 4 for saving other selections.To play the SONG LIST:
Press SONG LIST. One beep will be heard and
S
-LIST will appear on the display.
The recorded tracks will begin to play in the order
that they were saved.
You may seek through the song list by using the
SEEK arrows. Seeking past the last saved track will
return you to the first saved track.
To delete tracks from SONG LIST:
1. The disc player must be turned on.
2. Press SONG LIST to turn song list on. S
-LIST will
appear on the display.
3. SEEK to the desired track to be deleted.
4. Press and hold the SONG LIST buttons for
two seconds. When pressing SONG LIST one beep
will be heard immediately. After two seconds of
pressing the SONG LIST button continuously,
two beeps will be heard, to confirm that the track
has been deleted.
After a track has been deleted, the remaining tracks are
moved up the list. When another track is added to the
song list, the tracks will be added to the end of the list.

3-44
To delete the entire SONG LIST:
1. The disc player must be on.
2. Press SONG LIST to turn song list on. S
-LIST will
appear on the display.
3. Press and hold SONG LIST for more than four
seconds. A beep will be heard, followed by two
beeps after two seconds and a final beep will be
heard after four seconds. S
-LIST EMPTY will
appear on the display indicating that the song list
has been deleted.
If a disc is ejected, and the song list contains saved
tracks from that disc, those tracks are automatically
deleted from the song list.
To end SONG LIST mode, press the SONG LIST
button. One beep will be heard and S
-LIST will be
removed from the display.
Theft-Deterrent Feature RDS Radios
(If Equipped)
THEFTLOCK
is designed to discourage theft of your
radio. The feature works automatically by learning a
portion of the Vehicle Identification Number (VIN).
If the radio is moved to a different vehicle, it will not
operate and LOCKED will be displayed.
When the radio and vehicle are turned off, the blinking
red light indicates that THEFTLOCK is armed.
With THEFTLOCK activated, your radio will not
operate if stolen.
Theft-Deterrent Feature Non-RDS
Radios (If Equipped)
THEFTLOCK
is designed to discourage theft of your
radio. The feature works automatically by learning a
portion of the Vehicle Identification Number (VIN).
If the radio is moved to a different vehicle, it will not
operate and LOC will be displayed.
With THEFTLOCK activated, your radio will not
operate if stolen.

3-45 Understanding Radio Reception
AM
The range for most AM stations is greater than for
FM, especially at night. The longer range, however, can
cause stations to interfere with each other. AM can pick
up noise from things like storms and power lines. Try
reducing the treble to reduce this noise if you ever get it.
FM Stereo
FM stereo will give you the best sound, but FM signals
will reach only about 10 to 40 miles (16 to 65 km). Tall
buildings or hills can interfere with FM signals, causing
the sound to come and go.
Tips About Your Audio System
Hearing damage from loud noise is almost undetectable
until it is too late. Your hearing can adapt to higher
volumes of sound. Sound that seems normal can be loud
and harmful to your hearing. Take precautions by
adjusting the volume control on your radio to a safe
sound level before your hearing adapts to it.To help avoid hearing loss or damage:

Adjust the volume control to the lowest setting.

Increase volume slowly until you hear comfortably
and clearly.
NOTICE:
Before you add any sound equipment to your
vehicle
-- like a tape player, CB radio, mobile
telephone or two
-way radio -- be sure you can
add what you want. If you can, it's very
important to do it properly. Added sound
equipment may interfere with the operation of
your vehicle's engine, Delphi Delco Electronics
radio or other systems, and even damage them.
Your vehicle's systems may interfere with the
operation of sound equipment that has been
added improperly.
So, before adding sound equipment, check with
your dealer and be sure to check Federal rules
covering mobile radio and telephone units.

3-46 Care of Your Cassette Tape Player
A tape player that is not cleaned regularly can cause
reduced sound quality, ruined cassettes or a damaged
mechanism. Cassette tapes should be stored in their
cases away from contaminants, direct sunlight and
extreme heat. If they aren't, they may not operate
properly or may cause failure of the tape player.
Your tape player should be cleaned regularly after every
50 hours of use. Your radio may display CLN to indicate
that you have used your tape player for 50 hours without
resetting the tape clean timer. If this message appears on
the display, your cassette tape player needs to be
cleaned. It will still play tapes, but you should clean it as
soon as possible to prevent damage to your tapes and
player. If you notice a reduction in sound quality, try a
known good cassette to see if it is the tape or the tape
player at fault. If this other cassette has no improvement
in sound quality, clean the tape player.The recommended cleaning method for your cassette
tape player is the use of a scrubbing action,
non-abrasive cleaning cassette with pads which scrub
the tape head as the hubs of the cleaner cassette turn.
The recommended cleaning cassette is available through
your dealer (GM Part No. 12344789).
When using a scrubbing action, non
-abrasive cleaning
cassette, it is normal for the cassette to eject because
your unit is equipped with a cut tape detection feature
and a cleaning cassette may appear as a broken tape. To
prevent the cleaning cassette from being ejected, use the
following steps.
1. Turn the ignition to RUN or ACCESSORY.
2. Turn the radio off.
3. Press and hold the TAPE AUX button for five
seconds. The tape symbol on the display will flash
for two seconds.
4. Insert the scrubbing action cleaning cassette.
5. Eject the cleaning cassette after the manufacturer's
recommended cleaning time.
