Page 201 of 392

3-31 AM-FM Stereo with Cassette Tape and
Compact Disc Player with Radio Data
System (RDS) and Automatic Tone
Control (Option)
Playing the Radio
PWR: Press this button to turn the system on and off.
VOL: Turn this knob clockwise to increase volume.
Turn it counterclockwise to decrease volume.DISP: Press this button to display the clock with the
ignition off. Press this button to display an RDS station
frequency or program type when the radio is on.
AUTO VOL: Your system has a feature called
Speed
-Compensated Volume (SCV). With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive. Set the volume at the
desired level. Press AUTO VOL to adjust the SCV.
AVOL will appear on the display. Each time you press
AUTO VOL, another volume setting (LOW, MEDIUM
or HIGH) will appear on the display. NONE will appear
on the display if the radio cannot find out the vehicle
speed. Then, as you drive, SCV automatically increases
the volume, as necessary, to overcome noise at any
particular speed. The volume level should always sound
the same to you as you drive. If you don't want to use
SCV, select OFF. Each volume setting allows for more
volume compensation at faster vehicle speeds.
Page 202 of 392

3-32
Finding a Station
AM FM: Press this button to switch between AM,
FM1 and FM2. The display shows your selection.
TUNE: Turn this knob to choose radio stations.
SEEK: Press the right arrow to tune to the next higher
station and the left arrow to tune to the next lower
station and stay there. The radio will seek to stations
with a strong signal only.
PUSHBUTTONS: The six numbered pushbuttons
let you return to your favorite stations. You can set up
to 18 stations (six AM, six FM1 and six FM2) by
performing the following steps:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press AUTO TONE to select the equalization that
best suits the type of station selected.5. Press and hold one of the six numbered buttons. The
radio will beep once to confirm. Whenever you press
that numbered button, the station you set will return
and the AUTO TONE equalization that you selected
will also be automatically selected for that button.
6. Repeat the steps for each pushbutton.
P SCAN: Press and hold one of the arrows for more
than two seconds. The radio will beep once to confirm.
Use P SCAN to listen to each of your favorite stations
stored on your pushbuttons for a few seconds. The radio
will scan through each of the stations stored on your
pushbuttons, except those stations with weak reception.
The AUTO TONE setting stored for that pushbutton will
be automatically chosen. Press P SCAN or one of the
pushbuttons again to stop scanning. SCAN will be
displayed whenever the tuner is in the P SCAN mode.
The channel number (P1 through P6) will appear with
the frequency. In FM mode, this function will scan
through the current band such as FM1 or FM2.
Page 203 of 392

3-33
Setting the Tone
BASS: Press and release the P
-TYPE LIST/AUDIO
knob until BASS appears on the display. Then turn the
knob clockwise to increase bass and counterclockwise
to decrease bass. The display will show the bass level.
When you use this control, the radio's AUTO TONE
setting will switch to manual. To set bass to the middle
position, select the control and press and hold the
P
-TYPE LIST/AUDIO knob. The radio will produce
one beep and set the display level to the middle position.
To set all tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST/AUDIO
knob when no tone or speaker control is active. The
radio will produce one beep and display ALL with the
level display in the middle position.
TREBLE: Press and release the P
-TYPE LIST/AUDIO
knob until TREB appears on the display. Turn the knob
clockwise to increase treble and counterclockwise to
decrease treble. The display will show the treble level.
When you use this control, the radio's AUTO TONE
setting will switch to manual. If a station is weak or
noisy, you may want to decrease the treble. To set treble to the middle position, select the control
and press and hold the P
-TYPE LIST/AUDIO knob.
The radio will produce one beep and set the display
level to the middle position. To set all tone and speaker
controls to the middle position, press and hold the
P
-TYPE LIST/AUDIO knob when no tone or
speaker control is active. The radio will produce
one beep and display ALL with the level display in
the middle position.
AUTO TONE: This feature allows you to choose
preset bass and treble equalization settings designed
for ROCK, NEWS, POP, JAZZ, CLASSICAL and
COUNTRY music stations. TONE and the preset
equalization setting will appear on the display when you
press AUTO TONE. Each time you press it, another
setting will appear on the display. The manual setting
allows tone control to return to the BASS and TREB
controls. Use PUSHBUTTONS and AUTO TONE
button to program AUTO TONE for station presets.
Page 204 of 392

3-34
Adjusting the Speakers
BALANCE: Press and release the P
-TYPE
LIST/AUDIO knob until BAL appears on the display.
Turn the knob clockwise to move the sound to the right
speakers and counterclockwise to move the sound to the
left speakers. The middle position balances the sound
between the speakers. The display will show the speaker
balance. To set the balance to the middle position,
select the control and press and hold the P
-TYPE
LIST/AUDIO knob. The radio will produce one beep
and set the display level to the middle position. To set
all tone and speaker controls to the middle position,
press and hold the P
-TYPE LIST/AUDIO knob
when no tone or speaker control is active. The radio
will produce one beep and display ALL with the level
display in the middle position.
FADE: Press and release the P
-TYPE LIST/AUDIO
knob until FADE appears on the display. Turn the knob
clockwise to move the sound to the front speakers and
counterclockwise to move the sound to the rear speakers.
The middle position balances the sound between the
speakers. The display will show the speaker balance.
To set the fade to the middle position, select the control
and press and hold the P
-TYPE LIST/AUDIO knob. The radio will produce one beep and set the display
level to the middle position. To set all tone and speaker
controls to the middle position, press and hold the
P
-TYPE LIST/AUDIO knob when no tone or speaker
control is active. The radio will produce one beep and
display ALL with the level display in the middle position.
Using RDS
Your audio system is equipped with a Radio Data
System (RDS). RDS is a system that sends data along
with the audio of the FM station you are currently tuned
to. You can use RDS to display program information
and to control your radio. With RDS, the radio can:
Seek only to stations with the types of programs
you want to listen to,
seek to stations with traffic announcements,
receive announcements concerning local and
national emergencies, and
receive and display messages from radio stations.
RDS is always on. RDS features are only available for
use on FM stations which broadcast RDS information.
The RDS features of your radio rely upon receiving
specific RDS information from these stations. These
features will only work when the RDS information
is available.
Page 205 of 392

3-35
In rare cases, a radio station may broadcast incorrect
information that will cause the radio features to work
improperly. If this happens, please contact the
radio station.
When you are tuned to an RDS station, the station name
will appear on the display, instead of the frequency.
Most RDS stations provide their station name, the time
of day and a Program Type (PTY) for their current
programming. Some stations also provide the name
of the current program.
DISP: Press this knob to change what appears on the
display while using RDS. The display options are station
name, station frequency, PTY and the name of the
program (if available). Press and hold the display knob
to set the default display of the RDS station from the
displays available.
Accessing RDS Stations:
1. Push the SEEK TYPE button or turn the P
-TYPE
LIST/AUDIO knob to display the program type list.
2. Turn knob either clockwise or counterclockwise to
select a program type. List is alphabetical. If you
select ANY TYPE your radio will seek to the first
PTY available.
3. Push SEEK TYPE button to activate search.TRAF: Press this button to receive traffic
announcements. If the current tuned station does not
broadcast traffic announcements, the radio will seek to
a station that does. The TRAF icon will flash on the
display. When the radio finds a station that broadcasts
traffic announcements, it will stop. If no station is found,
NO TRAF will appear on the display.
Traffic Interrupt Feature: Your radio can be
programmed to interrupt the playback of a cassette tape,
CD or FM radio by enabling the traffic interrupt feature.
Press the TRAF button once to seek to an RDS station
that supports the traffic interrupt feature if the current
tuned station does not. The TRAF icon will flash on the
display when seeking for a station that supports traffic
interrupt. When the traffic interrupt feature is on, TRAF
will appear on the display.
When a traffic announcement comes on the tuned radio
station, you will hear it, even if the volume is muted or
a cassette tape or compact disc is playing. The TRAF
icon and TRAFFIC will appear on the display while
the traffic announcement plays. If the cassette tape or
compact disc player was being used, the tape or compact
disc will stay in the player and resume play at the point
where it stopped.
Page 206 of 392

3-36
VOL: Turn this knob clockwise to increase volume when
RDS interrupts regular play. Turn it counterclockwise to
decrease volume.
INFO: If the current station has a message, INFO will
appear on the display. These text messages are from the
RDS broadcaster to the listening public and may be
general information such as artist and song title, call in
phone numbers, etc. Press this button to see the
message. If the whole message does not appear on
the display, parts of the message will appear every
three seconds until the message is completed. To scroll
through the message at your own speed press the INFO
button again for less than one second. A new group
of words will appear on the display. Once the complete
message has been displayed, INFO will disappear from
the display until another new message is received. The
old message can be displayed by pressing the INFO
button until a new message is received or a different
station is tuned to.P-TYPE LIST: Turn this knob clockwise or
counterclockwise to select the Program Type (PTY) you
want to listen to. TYPE and a PTY will appear on the
display. Press the SEEK TYPE button and the radio
will seek to the first RDS broadcaster of the selected
P
-TYPE. If the radio cannot find the desired P-TYPE,
NONE will appear on the display and the radio will
return to the last station you were listening to.
SEEK TYPE: Press this button to go to a station with
the last selected PTY. TYPE and the last selected PTY
will appear on the display, if it is not already showing.
Press SEEK TYPE a second time to seek. If a station
with the selected PTY is not found, the radio will return
to the original station and display NONE.
ALERT!: This type of announcement warns of national
or local emergencies. You will not be able to turn off alert
announcements. ALERT! appears on the display when an
alert announcement plays. When an alert announcement
comes on the tuned radio station, you will hear it, even if
the volume is muted or a cassette tape or compact disc
is playing. If the cassette tape or compact disc player is
playing, play will stop for the announcement and resume
when the announcement is finished.
This function will only work during actual emergency
broadcasts, and will not work during tests of the
emergency broadcast system. This feature is not
supported by all RDS stations.
Page 207 of 392

3-37
ALTERNATE FREQUENCY: This RDS feature
allows the radio to automatically switch frequencies to
the best quality station with the same programming.
AF is off by default from the factory. Press and hold
AM FM for two seconds to turn alternate frequency on
or off. AF ON or AF OFF will appear on the display
and the radio will beep once. The radio will not
automatically switch to other stations when AF is off.
Playing a Cassette Tape
Your tape player is built to work best with tapes that are
up to 30 to 45 minutes long on each side. Tapes longer
than that are so thin they may not work well in this
player. The longer side with the tape visible should face
to the right. If the ignition is on, but the radio is off,
the tape can be inserted and will begin playing. A tape
symbol is shown on the display whenever a tape is
inserted. If you hear nothing but a garbled sound, the
tape may not be in squarely. Press EJT to remove the
tape and start over.
While the tape is playing, use the VOL, FADE, BAL,
TREB, BASS and SEEK controls just as you do
for the radio. The display will show TAPE and an
arrow showing which side of the tape is playing.If you want to insert a tape when the ignition is off,
first press EJT or DISP.
If CHK TAPE appears on the radio display, the tape
won't play because of an error.
CHK TAPE may be displayed when the tape is tight and
the player can't turn the tape hubs. Remove the tape.
Hold the tape with the open end down and try to turn
the right hub counterclockwise with a pencil. Turn the
tape over and repeat. If the hubs do not turn easily,
your tape may be damaged and should not be used in
the player. Try a new tape to make sure your player is
working properly.
CHK TAPE may be displayed when the tape is broken.
Try a new tape.
CHK TAPE may be displayed when the tape is wrapped
around the tape head. Attempt to get the cassette out.
Try a new tape.
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer.
Page 208 of 392

3-38
PREV (1): Press this button or the left SEEK arrow to
go to the previous selection on the tape if the selection
has been playing for less than three seconds. If the
PREV button or the left SEEK arrow is pressed and
the current selection has been playing for more than
13 seconds, it will go to the beginning of the current
selection. If the PREV button or the left SEEK arrow
is pressed and the current selection has been playing
from 3 to 13 seconds, it will go to the beginning of
the previous selection or the beginning of the current
selection, depending on the position on the tape. SEEK
and a ª
-1º will appear on the display while the cassette
player is in PREV mode. If PREV or the left SEEK
arrow is pressed additional times or held, the radio will
go to displayed number of previous selections up to ª9º.
SEEK and a negative number will appear on the display.
Your tape must have at least three seconds of silence
between each selection for PREV to work. The sound
will mute while seeking.
NEXT (2): Press this button to go to the next selection
on the tape. If you press the button more than once, the
player will continue moving forward through the tape.
SEEK and a positive number will appear on the display.
Your tape must have at least three seconds of silence
between each selection for NEXT to work. To forward
through each selection press the right SEEK arrow.
The sound will mute while seeking.REV (3): Press this button to reverse the tape rapidly.
Press it again to return to playing speed. The radio will
play the last selected station while the tape reverses. The
station frequency and REV will appear on the display.
You may select stations during REV operation by using
TUNE, SEEK and P SCAN controls.
FWD (4): Press this button to advance quickly to
another part of the tape. Press the button again to return
to playing speed. The radio will play the last selected
station while the tape advances. The station frequency
and FWD will appear on the display. You may select
stations during FWD operation by using TUNE, SEEK
and P SCAN controls.
SIDE (5): Press this button to play the other side of
the tape. TAPE and an up or down arrow will appear
on the display.
(6): Press this button to reduce background noise.
NR ON will appear on the display. Press it again to turn
Dolby off. NR OFF will appear on the display.
Dolby Noise Reduction is manufactured under a license
from Dolby Laboratories Licensing Corporation. Dolby
and the double
-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
Page 209 of 392

3-39
SEEK: SEEK and the right facing triangle is the same
as NEXT, and SEEK and the left facing triangle is the
same as PREV. If the button is held or pressed more
than once, the player will continue moving forward or
backward through the tape. SEEK and a positive or
negative number will appear on the display.
AM FM: Press this button to play the radio when a tape
is in the player. The tape will stop but remain in the player.
TAPE CD: With a tape in the player and the radio
playing, press this button to play a tape. Press AM FM
to return to the radio when a tape is playing. Press TAPE
CD to switch between the tape and compact disc if both
are loaded. The inactive tape or CD will remain safely
inside the radio for future listening.
EJT: Press this button located next to the cassette
slot to remove a tape. The radio will play. EJT may be
activated with the radio off. Cassette tapes may be
loaded with the radio off if this button is pressed first.
CLEAN: If this message appears on the display, the
cassette tape player needs to be cleaned. It will still play
tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index. After you clean
the player, press and hold the cassette eject button for five
seconds to reset the CLEAN indicator. The radio display
will display CLEANED to show the indicator was reset.Tight/Loose Tape Sensor Defeat
With the radio off and the ignition on, press and hold the
TAPE CD button to disable the tight/loose tape sensing
feature to enable play of some tape head cleaners and
portable CD adapters. The radio will display READY
and flash the cassette icon. The tight/loose tape sensing
feature will then be disabled until the next cassette eject.
Playing a Compact Disc
Insert a disc partway into the slot, label side up. The
player will pull it in. The disc should begin playing.
The display will show the CD symbol. If you want to
insert a compact disc with the ignition off, first press
DISP or EJT.
If you're driving on a very rough road or if it's very hot,
the disc may not play and CHECK CD may appear on
the display. When the road becomes smooth or the
temperature returns to normal, the disc should play.
If the disc comes out, it could be one of the following:
The disc is upside down.
It is dirty, scratched or wet.
It is very humid. (If so, wait about an hour and
try again.)
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer.
Page 210 of 392

3-40
PREV (1): Press this button or the left SEEK arrow to
go to the previous track if the current selection has been
playing for less than eight seconds. If the PREV button
or the left SEEK arrow is pressed and the current
selection has been playing for more than eight seconds,
it will go to the beginning of the current selection.
TRACK and the track number will appear on the
display. If you hold the button or press it more than
once, the player will continue moving back through
the disc. The sound will mute while seeking.
NEXT (2): Press this button or the right SEEK arrow
to go to the next track. TRACK and the track number
will appear on the display. If you hold the button or the
right SEEK arrow, or press it more than once, the player
will continue moving forward through the disc. The
sound will mute while seeking.
REV (3): Press and hold this button to reverse quickly
within a track. Press and hold this button for less than
two seconds to reverse at six times the normal playing
speed. Press and hold it for more than two seconds to
reverse at 17 times the normal playing speed. Release it
to play the passage. The display will show ET and the
elapsed time.FWD (4): Press and hold this button to advance quickly
within a track. Press and hold this button for less than
two seconds to advance at six times the normal playing
speed. Press and hold it for more than two seconds to
advance at 17 times the normal playing speed. Release it
to play the passage. The display will show ET and the
elapsed time.
RDM (6): Press this button to hear the tracks in random,
rather than sequential, order. RDM ON will show on the
display. RDM T and the track number will appear on
the display when each track starts to play. Press RDM
again to turn off random play. RDM OFF will appear
on the display.
SEEK: Press the left facing triangle, SEEK button to
go to the start of the current or previous track. Press the
right facing triangle, SEEK button to go to the start of
the next track. If either of the SEEK buttons is held or
pressed more then once, the player will continue moving
backward or forward through the CD.
DISP: Press this button to see how long the current
track has been playing. ET and the elapsed time will
appear on the display. To change what is normally
shown on the display (track or elapsed time), press the
button until you see the display you want, then hold
the button for two seconds until the display flashes.
The radio will produce one beep.
