CHEVROLET IMPALA 2002 8.G Owners Manual

2-55
The exterior lamps control has three positions:
OFF:Pushing the control all the way in turns off the
exterior lamps.
Parking Lamps:Pulling the control out halfway will
turn on the parking lamps together with the following:

Taillamps

LIcense Plate Lamps

Instrument Panel Lights
Headlamps: Pulling the control all the way out turns on
the headlamps together with the previously listed lamps
and lights. See ªInterior Lampsº later in this section for
information on the instrument panel brightness control
and on the dome lamps. A warning chime will sound if
you open the driver's door when the ignition switch is
off and the headlamps are on.
Daytime Running Lamps / Automatic
Headlamp Control
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset. Fully
functional daytime running lamps are required on all
vehicles first sold in Canada.A light sensor on top of the instrument panel makes the
DRL work, so be sure it isn't covered.
The DRL system's automatic headlamp control will
make your high
-beam headlamps come on at a reduced
brightness when the following conditions are met:

The ignition is on,

the exterior lamps control is off and

the gearshift is not in PARK (P).
When the DRL are on, only your high
-beam
headlamps, at a reduced level of brightness, will be on.
The headlamps, taillamps, sidemarker and other lamps
won't be on. Your instrument panel and cluster won't be
lit up either.
When it's dark enough outside, your high
-beam
headlamps will turn off and the headlamps and parking
lamps will turn on. The other lamps that come on with
your headlamps will also come on.
When it's bright enough outside, your headlamps will go
off and your DRL will come on.
As with any vehicle, you should turn on the regular
headlamp system when you need it.

2-56 Delayed Headlamp Illumination
Delayed headlamp illumination provides a period of
exterior lighting as you leave the area. The feature is
activated when the headlamps are on due to the
automatic headlamp control feature described previously
in this section, and when the ignition is turned off. Your
headlamps will then remain on until the exterior lamps
control is moved from OFF to the parking lamp position
or until either a 30 second or 60 second lighting period
has ended.
If you turn off the ignition with the headlamp switch in
the parking lamp or headlamp position, the delayed
headlamp illumination cycle will not occur.
To disable the delayed headlamp illumination feature or
change the time of delay, see ªVehicle Customization
Settingsº in the Index.
Fog Lamps (If Equipped)
The fog lamps button is
located on the instrument
panel next to the exterior
lamps control wheel to the
left of the steering column.
Your ignition must be in ON for the fog lamps
to illuminate.
To turn the fog lamps on, press the FOG button. A light
will glow in the button to let you know that the fog
lamps are on. Press the Fog button again to turn the fog
lamps off.
Your parking lamps must be on or your fog lamps won't
come on.
The fog lamps will go off whenever you change to
high
-beam headlamps. When you return to low beams,
the fog lamps will come on again.

2-57
Interior Lamps
Instrument Panel Brightness Control
This feature controls the instrument panel lights.
The control for this feature is located on the exterior
lamps control. Your parking lamps must be on for this
feature to work. Turn the control clockwise to brighten
the lights or counterclockwise to dim them.
Courtesy Lamps
When any door is opened, several lamps come on. These
lamps are courtesy lamps. They make it easy for you to
enter and leave your vehicle. You can also turn these
lamps on by turning the exterior lamps control all the
way clockwise.
Some of the lamps have switches so you can turn them
on, even when the doors are closed. These lamps are
reading lamps.
Illuminated Entry (If Equipped)
Your courtesy lamps will come on and stay on for a set
time whenever you press UNLOCK on the remote
keyless entry transmitter (if equipped).
If you open a door, the lamps will stay on while it's open
and then turn off automatically about 25 seconds after
you close it. If you press UNLOCK and don't open a
door, the lamps will turn off after about 40 seconds.
Illuminated entry includes a feature called theater
dimming. With theater dimming, the lamps don't just
turn off at the end of the delay time. Instead, they slowly
dim after the delay time until they go out. The delay
time is canceled if you turn the ignition key to ON or
press the power door lock switch. The lamps will dim
right away.
When the ignition is on, illuminated entry is inactive,
which means the courtesy lamps won't come on unless
a door is opened.

2-58 Delayed Entry Lighting
Delayed entry lighting illuminates the interior for a
period of time after all the doors have been closed.
The ignition must be off for delayed entry lighting to
work. Immediately after all the doors have been closed,
the delayed entry lighting feature will continue to work
until one of the following occurs:

The ignition is moved to ON,

the doors are locked, or

an illumination period of 25 seconds has elapsed.
If during the illumination period a door is opened, the
timed illumination period will be canceled and the
interior lamps will remain on because a door is open.
Delayed Exit Lighting
This feature illuminates the interior for a period of time
after the key is removed from the ignition.
The ignition must be off for delayed exit lighting
to work. When the key is removed, interior
illumination will activate and remain on until
one of the following occurs:

The ignition is moved to ON,

the power door locks are activated, or

an illumination period of 25 seconds has elapsed.
If during the illumination period a door is opened, the
timed illumination period will be canceled and the
interior lamps will remain on because a door is open.

2-59
Parade Mode
The instrument panel has an added feature called parade
mode. This feature prohibits the dimming of your
instrument panel displays during the daylight while
the headlamps are on so that you'll still be able to
see the displays.
Rearview Mirror Reading Lamps
Use the switch next to each lamp to turn them
on and off.
Reading Lamps (If Equipped)
The reading lamps are located on the assist handles in
the headliner. These lamps and the interior courtesy
lamps come on when any door is opened. Press the lens
to turn them on. Press it again to turn them off.
Dome Lamp (If Equipped)
The dome lamp will come on when you open a door.
You can also turn this lamp on by turning the exterior
lamps control clockwise as far as it will go. Vehicles that
have the optional sunroof do not have a dome lamp.
Battery Rundown Protection
Your vehicle has a feature to help prevent you from
draining the battery in case you accidentally leave on the
interior courtesy lamps, reading/map lamps, visor vanity
lamps, trunk lamp or glove box lamps.. If you leave any
of these lamps on, they will automatically turn off after
10 minutes, if the ignition is moved to OFF. The lamps
won't come back on again until you do the following:

Turn the ignition on, or

turn the exterior lamps control off, then on again.
If your vehicle has less than 15 miles (25 km) on the
odometer, the battery saver will turn off the lamps after
only three minutes.
Battery rundown protection will also work if the
headlamps are left on. After having been left on for
10 minutes, the headlamps and the parking lamps will
flash three times. They will remain on for one more
minute before being turned off automatically.
Mirrors
Adjust all the mirrors so you can see clearly when you
are sitting in a comfortable driving position.

2-60 Inside Day/Night Rearview Mirror with
Map Lamps
To reduce glare from headlamps behind you, pull the
lever at the bottom of the mirror toward you (to the
night position). To return the mirror back to the day
position, push the lever away from you.
There are two map lamps located on the bottom of the
mirror. Each lamp is turned on and off by pressing the
button next to the lamp.
Inside Day/Night Rearview Mirror with
OnStar
and Map Lamps (Option)
This mirror has a lever located at the bottom of the
mirror between the two map lamps. This lever is used to
change the mirror from day to night position. To reduce
glare from headlamps behind you while driving at night,
turn the lever 90 degrees. To return to the mirror back to
the day position, return the lever to its original position.
There are two map lamps located on the bottom of the
mirror. Each lamp is turned on and off by pressing the
button next to the lamp.
There are also three OnStar buttons located at the
bottom of the mirror face. See your dealer for more
information on the system and how to subscribe to
OnStar. See ªOnStar

Systemº in the Index for
more information about the services OnStar provides.

2-61
Electrochromic Automatic Dimming
Rearview Mirror (If Equipped)Your vehicle may have an electrochromic day/night
rearview mirror. Push the button in the center of the
mirror to turn this feature on. The mirror will darken
gradually to reduce glare from headlamps behind you.
This may take a few moments. The mirror will lighten
whenever you shift to REVERSE (R).
There are two map lamps located on the bottom of the
mirror. Each lamp is turned on and off by pressing the
button next to the lamp.
One photocell on the front of the mirror senses when it
is becoming dark outside. Another photocell, facing
rearward, senses headlamps behind you. To turn the
electrochromic feature off, press the button in the center
of the mirror again.
To keep the photocells operating well, occasionally
clean them with a cotton swab and glass cleaner.

2-62 Electrochromic Day/Night Rearview Mirror
with OnStar

and Map Lamps (Option)
Your vehicle may have an automatic electrochromic
day/night rearview mirror with the OnStar System.
The automatic dimming feature is turned on or off by
pressing the far left button, located on the lower part of
the mirror face, for up to three seconds. When turned on,
this mirror functions exactly like the electrochromic
mirror described previously. See ªMirrors,
Electrochromic Day/Night Rearviewº in the Index for
more information.There are two map lamps located on the bottom of the
mirror. Each lamp is turned on and off by pressing the
button next to the lamp.
There are also three OnStar buttons located at the
bottom of the mirror face. See your dealer for more
information on the system and how to subscribe to
OnStar. See ªOnStar

Systemº in the Index for
more information about the services OnStar provides.

2-63
Power Outside Rearview Mirrors
The power mirror
controls are located
near the driver's side
window, on the armrest.
Use the selector switch located above the four
-way
control panel to choose either the left or right outside
mirror. Then press any of the four arrows located on the
control pad to move each mirror in the desired direction.
Adjust each mirror so you can see the side of your
vehicle and the area beside and behind your vehicle.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
Heated Outside Mirrors (If Equipped)
The surface of both outside mirrors will heat when you
activate the rear window defogger. See ªRear Window
Defoggerº in the Index.

2-64
Storage Compartments
Glove Box
Use the key to lock and unlock the glove box. To open,
lift the latch.
Front Armrest (If Equipped)
If your vehicle has the split bench front seat, there is an
armrest located in the center of the seat. Dual cupholders
are located in front of the armrest.
Center Console (If Equipped)
The console has cupholders, a cassette tape and CD
storage area and a coinholder. To open the console's
storage area, pull up on the latch located in the front of
the console lid.
Rear Seat Armrest and Cupholder
(If Equipped)
If your vehicle has the split folding rear seat, there will
be two cupholders in the rear seat armrest. To access
them, pull down on the cloth strap located toward the
top of your center back seat cushion.
Trunk Convenience Net (If Equipped)
Your vehicle may have a convenience net. You'll see it
on the back wall of the trunk.
Put small loads, like grocery bags, behind or inside the
net. It can help keep them from falling over during sharp
turns or quick starts and stops.
The net isn't for larger, heavier loads. Store those in the
trunk as far forward as you can.
You can unhook the net so that it will lie flat when
you're not using it.
