CHEVROLET MONTE CARLO 2000 6.G Owners Manual

2-45 Fog Lamps (If Equipped)
To turn the fog lamps on,
press the fog lamps switch
located next to the exterior
lamp control on the left side
of the steering column. Your
ignition must be in ON for
the fog lamps to illuminate.
A light will glow on the switch to let you know that they
are on. (Your parking lamps must be on or your fog
lamps won't come on.) Press the switch again to turn the
fog lamps off. The fog lamps will go off whenever you
change to high
-beam headlamps. When you return to
low beams, the fog lamps will come on again.
Interior Lamps
Instrument Panel Brightness Control
You can brighten or dim the instrument panel lights and
cluster by turning the exterior lamp knob. Turn the knob
clockwise to increase the brightness of the instrument
panel and cluster, and counterclockwise to decrease the
brightness. Your parking lamps must be on for this
feature to work.
Courtesy Lamps
When a door is opened, several lamps come on. These
lamps are courtesy lamps. They make it easy for you to
enter and leave your vehicle. You can also turn these
lamps on by turning the exterior lamps knob clockwise
all the way.
Some of the lamps have switches so you can turn them
on, even when the doors are closed. These lamps are
reading lamps.

2-46 Illuminated Entry (If Equipped)
Your courtesy lamps will come on and stay on for a set
time whenever you press UNLOCK on the remote
keyless entry transmitter (if equipped).
If you open a door, the lamps will stay on while it's open
and then turn off automatically about 25 seconds after
you close it. If you press UNLOCK and don't open a
door, the lamps will turn off after about 40 seconds.
Illuminated entry includes a feature called theater
dimming. With theater dimming, the lamps don't just
turn off at the end of the delay time. Instead, they slowly
dim after the delay time until they go out. The delay
time is canceled if you turn the ignition key to ON or
press the power door lock switch so the lamps will dim
right away.
When the ignition is on, illuminated entry is inactive,
which means the courtesy lamps won't come on unless a
door is opened.
Delayed Entry Lighting
Delayed entry lighting illuminates your vehicle's
interior for a period of time after all the doors have
been closed.
The ignition must be off for delayed entry lighting to
work. Just after all the doors have been closed, the delayed
entry lighting feature will continue to work until:

the ignition is in ON,

the doors are locked or

an illumination period of 25 seconds has elapsed.
If during the illumination period a door is opened, the
timed illumination period will be canceled and the
interior lamps will remain on since a door is open.

2-47 Delayed Exit Lighting
This feature illuminates your vehicle's interior for a
period of time after the ignition key is removed from
the ignition.
The vehicle's ignition must be off for delayed exit
lighting to work. When the ignition key is removed,
interior illumination will activate and remain on until:

the ignition is in ON,

the power door locks are activated or

an illumination period of 25 seconds has elapsed.
If during the illumination period a door is opened, the
timed illumination period will be canceled and the
interior lamps will remain on since a door is open.
Parade Mode
The instrument panel has an added feature called parade
mode to assist you in seeing the instrument panel cluster
and radio if your headlamps are on in the daylight.
Rearview Mirror Reading Lamps
Use the switch next to each lamp to turn them on
and off.
Reading Lamps (If Equipped)
The reading lamps are located on the assist handles in
the roof. These lamps and the interior courtesy lamps
come on when any door is opened. Press the lens to turn
them on. Press it again to turn them off.
Dome Lamp
The dome lamp will come on when you open the doors.
You can also turn this lamp on by turning the headlamp
knob clockwise as far as it will go.

2-48 Battery Rundown Protection
Your vehicle has a feature to help prevent you from
draining the battery in case you accidentally leave the
interior courtesy lamps, reading/map lamps, visor vanity
lamps, trunk lamp or glove box lamps on. If you leave
any of these lamps on, they will automatically turn off
after 10 minutes, if the ignition is in OFF. The lamps
won't come back on again until you:

turn the ignition on or

turn the lamp switch off, then on.
Note that if your vehicle has less than 15 miles (25 km)
on the odometer, the battery saver will turn off the lamps
after only three minutes.
Battery rundown protection will also work if the
headlamps are left on. After having been left on for
10 minutes, the headlamps and the parking lamps will
flash three times. They will remain on for one more
minute before being turned off automatically.
Mirrors
Adjust all the mirrors so you can see clearly when you
are sitting in a comfortable driving position.
Inside Day/Night Rearview Mirror
To reduce glare from lamps behind you, pull the lever at
the bottom of the mirror toward you (to the night
position). To return the mirror back to the day position,
push the lever away from you.
Electrochromic Automatic Dimming
Rearview Mirror (If Equipped)
Your vehicle may have an electrochromic day/night
rearview mirror. Push the button in the center of the
mirror to turn this feature on. The mirror will darken
gradually to reduce glare from headlamps behind you.
This may take a few moments. The mirror will also
lighten whenever you shift to REVERSE (R).

2-49
The mirror's two outer buttons operate the lights on the
bottom sides of the mirror.
One photocell on the front of the mirror senses when it
is becoming dark outside. Another photocell, facing
rearward, senses headlamps behind you. To turn the
electrochromic feature off, press the button in the center
of the mirror again.
To keep the photocells operating well, occasionally
clean them with a cotton swab and glass cleaner.
Power Outside Mirrors
The power mirror control
switch is located near the
driver's side window,
on the armrest.
To choose either the left or right outside mirror, press the
top switch. Press any of the four buttons located below the
top switch to move the mirrors in the desired direction.Adjust each mirror so you can see the side of your
vehicle and the area behind your vehicle.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from
the driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder
before changing lanes.
Storage Compartments
Glove Box
Use the door key to lock and unlock the glove box.
To open, lift the latch.

2-50 Center Console
The console has cupholders, a cassette tape storage area
and a coinholder. To open the console's storage area,
pull up on the latch located in the front of the console lid
and pull up.
Rear Seat Cupholder (If Equipped)
To access the rear cupholders, pull down on the cloth
strap located toward the top of your center back seat
cushion. You will then have access to the dual
oversized cupholders.
Trunk Convenience Net (If Equipped)
Your vehicle may have a convenience net. You'll see it
on the back wall of the trunk.
Put small loads, like grocery bags, behind the net. It can
help keep them from falling over during sharp turns or
quick starts and stops.
The net isn't for larger, heavier loads. Store those in the
trunk as far forward as you can.
You can unhook the net so that it will lie flat when
you're not using it.
Ashtrays and Lighter
The removable front ashtray is located on the console
and fits into the cupholder.
The ashtray is removable with a cupholder and liner
underneath. To remove the ashtray, lift up on the ashtray
and liner and pull the ashtray out. The ashtray assembly
can be stored until needed.
The rear ashtray is located within a small door at the
rear of the console. Push on the right side of the door.
The ashtray will then turn to the right for usage. You can
only access the ashtray by pushing on the door's right
side. To remove the ashtray, push down on the snuffer
located in the middle of the ashtray and lift it out.
NOTICE:
Don't put papers and other things that burn
into your ashtrays. If you do, cigarettes or
other smoking materials could set them on fire,
causing damage.
To use the lighter, just push it in all the way and let go.
When it's ready, it will pop back by itself.

2-51
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.
Sun Visors
To block out glare, you can swing down the visors. You
can also move them from side to side. The visors also
have extenders that you can pull out for added coverage.
Visor Vanity Mirrors
Open the cover to expose the vanity mirror.
If your vehicle has the optional lighted vanity mirrors,
the lamps come on when you open the cover.
Accessory Power Outlet
Your vehicle has a 12-volt
outlet. It is located at the
rear of the console.
Lift the cover to use the outlet. This feature can be used
to add electrical equipment to your vehicle.
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by your
warranty. Check with your dealer before adding
electrical equipment, and never use anything that
exceeds the fuse rating.

2-52
Auxiliary Power Connection
(Power Drop)
Your vehicle is equipped
with an auxiliary
power connection.
This feature provides power, ground and accessory
wires which can be accessed to add aftermarket
electrical equipment to your vehicle. It is located on
the passenger's side of the vehicle, under the glove box,
and is labeled with a wire function and fuse rating.
For information on accessing the connection and
electrical hookup, please refer to your service manual.
To order a service manual, see ªService Publications,
Orderingº in the Index.
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by your
warranty. Check with your dealer before adding
electrical equipment, and never use anything that
exceeds the fuse rating.
Cellular Phone Readiness Package
(If Equipped)
Your vehicle may be equipped with a wiring harness that
will work with a dealer
-installed GM Hughes
portable
phone. The phone has integrated features with the radio
and car audio speakers. See your dealer for more details.

2-53
OnStar
System (If Equipped)
OnStar is a vehicle communications service. The
following services are available through a subscription
with OnStar and are available 24 hours a day:
Emergency Services

Automatic Notification of Air Bag Deployment

Theft Notification and Stolen
-Vehicle Tracking

Roadside Assistance with Location

Remote Diagnostics

OnStar MED
-NET

Accident Assist
Convenience Services

Remote Door Unlock

Route Support

Concierge Services

Ride Assist
A complete user's guide is provided with the OnStar
System. For more information contact OnStar
at 1
-888-ONSTAR7.
Assist Handle (If Equipped)
An assist handle above the passenger door can be used
when getting out of your vehicle.
Garment Hooks
For your convenience, garment hooks are attached to the
rear headliner.
Power Sunroof (Option)
Your vehicle may have an express-open sunroof. It
includes a sliding and tilting glass panel and a sunshade.
The switch works only when the ignition is in ACC, ON
or with the retained accessory power. The switch is
located on the overhead console if the vehicle is
equipped with a Driver Information Center (DIC). If
not, the sunroof switch is located in the headliner of the
roof panel.

2-54
To open the power sunroof,
press the switch to the rear
twice and the power sunroof
will fully open.
DIC Version Shown
This is the express
-open operation. During this
operation, press the switch forward to stop the power
sunroof at a desired position.
Your sunroof also has a vent feature. It can be activated
from the closed sunroof position by pressing the switch
once rearward. To close, push the sunroof switch
forward. When using this feature the sunshade should
be fully opened in the rearward position.
The sunshade can be opened manually by sliding it
rearward or automatically by opening the power
sunroof. You will need to close the sunshade manually
by sliding it forward.To close the sunroof, press the switch forward and hold
until the sunroof motor stops, or release the switch when
a desired position has been reached.
HomeLink
Transmitter
(If Equipped)
The HomeLink
Transmitter allows you to consolidate
the functions of up to three individual hand
-held
transmitters. It will operate garage doors and gates, or
with the accessory package, other devices controlled by
radio frequency such as home/office lighting systems
and security systems.
The HomeLink

Transmitter will learn and transmit the
frequencies of most current transmitters and is powered
by your vehicle's battery and charging system.
