CHEVROLET MONTE CARLO 2001 6.G Owners Manual

2-59
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder
before changing lanes.
Heated Outside Mirrors (Option)
The surface of both outside mirrors will heat when you
activate the rear window defogger. See ªRear Window
Defoggerº in the Index.
Storage Compartments
Glove Box
Use the door key to lock and unlock the glove box.
To open, lift the latch.
Center Console
The console has cupholders, a cassette tape storage area
and a coinholder. To open the console's storage area,
pull up on the latch located in the front of the console lid
and pull up.
Rear Seat Armrest and Cupholders
To access the rear cupholders, pull down on the
cloth strap located toward the top of your center
back seat cushion. You will then have access to the
dual cupholders.

2-60 Trunk Convenience Net (If Equipped)
Your vehicle may have a convenience net. You'll see it
on the back wall of the trunk.
Put small loads, like grocery bags, behind or inside the
net. It can help keep them from falling over during sharp
turns or quick starts and stops.
The net isn't for larger, heavier loads. Store those in the
trunk as far forward as you can.
You can unhook the net so that it will lie flat when
you're not using it.
Ashtrays and Lighter
The removable front ashtray is located on the console
and fits into the cupholder.
The ashtray is removable with a cupholder and liner
underneath. To remove the ashtray, lift up on the ashtray
and liner and pull the ashtray out. The ashtray assembly
can be stored until needed.
The rear ashtray is located behind a small door at the
rear of the console. Push on the right side of the door.
The ashtray will then turn to the right for usage. You can
only access the ashtray by pushing on the door's right
side. To remove the ashtray, push down on the snuffer
located in the middle of the ashtray and lift it out.
NOTICE:
Don't put papers and other things that burn into
your ashtrays. If you do, cigarettes or other
smoking materials could set them on fire,
causing damage.
To use the lighter, just push it in all the way and let go.
When it's ready, it will pop back out by itself.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.

2-61
Sun Visors
To block out glare, you can swing down the visors. You
can also move them from side to side. The visors also
have extenders that you can pull out for added coverage.
Visor Vanity Mirrors
Open the cover to expose the vanity mirror.
If your vehicle has the lighted vanity mirrors, the lamps
come on when you open the cover.
Accessory Power Outlet
Your vehicle has a 12-volt
accessory power outlet.
It is located at the rear of
the console.Lift the cover to access the outlet. This feature can be
used to add electrical equipment to your vehicle.
Certain accessory power plugs may not be compatible to
the accessory power outlet and could result in blow
vehicle or adapter fuses. If you experience a problem,
see your dealer for additional information on the
accessory power plugs.
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by your
warranty. Check with your dealer before adding
electrical equipment, and never use anything that
exceeds the fuse rating.

2-62
Auxiliary Power Connection
(Power Drop)
Your vehicle is equipped
with an auxiliary
power connection.
This feature provides power, ground and accessory
wires which can be accessed to add aftermarket
electrical equipment to your vehicle. It is located on the
passenger's side of the vehicle, under the glove box, and
is labeled with a wire function and fuse rating. For
information on accessing the connection and electrical
hookup, please refer to your service manual. To order a
service manual, see ªService Publications, Orderingº in
the Index.
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by your
warranty. Check with your dealer before adding
electrical equipment, and never use anything that
exceeds the fuse rating.
Cellular Phone Readiness
Package (Option)
Your vehicle may be equipped with a wiring harness that
will work with a dealer
-installed GM Hughes
portable
phone. The phone has integrated features with the radio
and car audio speakers. See your dealer for more details.

2-63
OnStar
System (If Equipped)
OnStar is a vehicle communications system that offers a
variety of services and provides a hands
-free
communication link between you and the OnStar Center.
A service subscription agreement and fee are required in
order to receive OnStar service. Services are available
24 hours a day, 7 days a week. For more information,
call 1
-888-ONSTAR-7 (1-888-667-8277).
OnStar Services Button: Press this button once to
contact an advisor who will be able to assist you with
these services. If you are not quickly connected, the
system will automatically reset and redial. This ensures
connection to the center; there is no additional action
required. Press the Call Answer/End button to cancel the
automatic redial.
Emergency Button: In an emergency situation,
press the emergency service button. Upon receiving the
call, an advisor at the center will locate your vehicle and
assess the situation. If necessary, the advisor will alert
the nearest emergency service provider.
Call ANSWER/END Button: Use this button to
answer a call. (If you are receiving a call, the audio
system will mute, and the ring will be heard). Press this
button at the end of a call to disconnect and return the
audio system to its previous settings. This button will
also cancel a call if one of the buttons is accidentally
pressed or if the automatic redial function is activated.
Volume Control: You can control the volume of the
OnStar System using either the volume control knob
on the radio or using the steering wheel volume control
(if equipped).
Telltale Light: This light will indicate the status of
the system. A solid green light will come on when you
start the vehicle to let you know that the system is on
and is ready to make or receive calls.
If the light blinks green it means that an incoming
or outgoing call is in progress. Press the Call
ANSWER/END button if you notice the light
blinking and you are not on a call.

2-64
The light will be red in the event of an OnStar system
malfunction. If this occurs press the OnStar button to
attempt to contact an advisor. If the connection is made,
the advisor will assist you with steps to take to make
sure that the system is functioning properly. If you
cannot contact the advisor, take your vehicle to your
dealership as soon as possible for assistance.
Safety and Security Services

Automatic Notification of Air Bag
Deployment
-- If an air bag deploys, a priority
emergency signal is automatically sent to the center.
An advisor will locate your vehicle's position, try to
contact you and assist you in the situation. If the
center is unable to contact you, an emergency service
provider will be contacted.

Stolen Vehicle Tracking
-- Call the center at
1
-888-4-ONSTAR (1-888-466-7827) to report your
vehicle stolen. The system can then locate and track
your vehicle and the advisor will be able to notify
the proper authorities.

Roadside Assistance with Location
-- For vehicle
breakdowns, press the OnStar button. An advisor
will contact the appropriate help.
Remote Diagnostics
-- If an instrument panel light
comes on, the center can perform a check of the
engine on
-board computer. An advisor can then
recommend what action needs to be taken.

OnStar MED
-NET -- Med-Net can store your
personal medical history and provide it to emergency
personnel if necessary.

Accident Assist
-- An advisor can provide
step
-by-step guidance following an accident.

Remote Door Unlock
-- To contact the center, call
1
-888-4-ONSTAR. You will be required to provide
your security information. An advisor will send a
command to your vehicle to unlock itself. The
advisor can delay unlocking your vehicle. Remote
Door Unlock is disabled 48 hours after the vehicle is
parked to maintain the battery charge.

Vehicle Locator Service
-- To contact the center,
call 1
-888-4-ONSTAR. You will be required to
provide your security information. An advisor will
send a command to your vehicle to sound the horn
and/or flash the lamps.
In order to provide you with excellent service, calls with
the OnStar Center may be monitored or recorded.

2-65
Premium Services (Includes Safety and
Security Services)

Route Support -- An advisor can provide directions
or guidance to anywhere you want to go. In addition,
they can help you locate gas stations, rest areas,
ATMs, hospitals, hotels, stores, eateries and more.

Concierge Services
-- The concierge advisor can
obtain tickets, reservations, or help with vacation/trip
planning and other unique items and services.

Ride Assist
-- An advisor can locate transportation
in the event that you are unable to drive.
OnStar System Limitations
Complete limitations can be found on the Subscriber
Services Agreement.
OnStar Service is:

available in the United States and Canada;

available when the vehicle is within the operating
range of a cellular provider;

subject to limitations caused by atmospheric
conditions, such as severe weather or topographical
conditions, such as mountainous terrain;

subject to cellular carrier equipment limitations.
Global positioning capabilities used to deliver
OnStar Service will not be available if satellite
signals are obstructed.

2-66
OnStar will not function if the vehicle's battery is
discharged or disconnected. It may also be inoperative if
the vehicle is in an accident and the OnStar or vehicle
electrical system components are damaged.
Safety and security services are provided by existing
governmental emergency service providers. OnStar will
use reasonable efforts to contact the appropriate
emergency service provider and request assistance but
cannot promise that they will respond to the call in a
timely manner or at all.
Assist Handle
An assist handle above the passenger door can be used
when getting out of your vehicle.
Garment Hooks
For your convenience, garment hooks are attached to the
rear trim near the roof of the vehicle.
Power Sunroof (Option)
Your vehicle may have an express-open sunroof. It
includes a sliding and tilting glass panel and a sunshade.
The switch works only when the ignition is in ACC, ON
or when Retained Accessory Power (RAP) is active. The
switch is located on the overhead console if the vehicle
is equipped with a Driver Information Center (DIC). If
not, the sunroof switch is located in the headliner in the
roof panel.
To open the power sunroof,
press the switch to the rear
twice and the power sunroof
will fully open.
DIC Version Shown

2-67
To activate the express-open feature, press the switch
rearward. You can stop the power sunroof before it is
completely open by pressing the switch forward.
Your sunroof also has a vent feature. It can be activated
from the closed sunroof position by pressing the switch
once rearward. To close, push the sunroof switch
forward. When using this feature the sunshade should be
fully opened in the rearward position.
The sunshade can be opened manually by sliding it
rearward or automatically by opening the power
sunroof. You will need to close the sunshade manually
by sliding it forward.
To close the sunroof, press the switch forward and hold
until the sunroof motor stops, or release the switch when
the desired position has been reached.HomeLink
Transmitter (Option)
The HomeLink Transmitter allows you to consolidate
the functions of up to three individual hand
-held
transmitters. It will operate garage doors and gates, or
with the accessory package, other devices controlled by
radio frequency such as home/office lighting systems
and security systems.
The HomeLink Transmitter will learn and transmit the
frequencies of most current transmitters and is powered
by the battery and charging system.

2-68
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference, including
interference that may cause undesired operation of
the device.
Changes and modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.
Programming the HomeLink
Transmitter
Do not use the transmitter with any garage door opener
that does not have the ªstop and reverseº feature. This
includes any garage door opener model manufactured
before April 1, 1982.
Be sure that people and objects are clear of the garage
door you are programming!
The engine should be turned off while programming the
HomeLink Transmitter. Follow these steps to program
up to three channels:
1. If you have not previously programmed a universal
channel, proceed to Step 2. Otherwise, hold down
the two outside buttons on the HomeLink
Transmitter until the indicator light begins to flash
rapidly (approximately 20 seconds). Then release the
buttons. This procedure initializes the memory and
erases any previous settings for all three channels.
