CHEVROLET MONTE CARLO 2001 6.G Owners Manual

2-69
2. Hold the end of the hand-held transmitter
approximately one to three inches (three to eight cm)
away from the HomeLink Transmitter making sure
that you can still see the display.
3. Decide which one of the three channels you want to
program. Using both hands, press the hand
-held
transmitter button and the desired button on the
HomeLink Transmitter. Continue to hold both
buttons through Step 4.
4. Hold down both buttons until you see the indicator
light on the HomeLink Transmitter flash, first slowly
then rapidly. The rapid flashing, which could take up
to 90 seconds, indicates that the HomeLink
Transmitter has been programmed. Release both
buttons once the light starts to flash rapidly.Canadian Programming: During programming, your
hand
-held transmitter may automatically stop
transmitting. Continue to press and hold the HomeLink
button while you press your hand
-held transmitter
button every two seconds until the HomeLink
Transmitter has been programmed. The indicator light
will flash slowly and then rapidly after several seconds
once it has been successfully programmed.
If you have trouble programming the HomeLink
Transmitter, make sure that you have followed the
directions exactly as described and that the battery in the
hand
-held transmitter is not dead. If you still cannot
program it, flip the hand
-held transmitter end over end
and try again. The HomeLink Transmitter may not work
with older garage door openers that do not meet current
Federal Consumer Safety Standards. If you cannot
program the transmitter after repeated attempts, consult
your dealer.
Be sure to keep the original hand
-held transmitter
in case you need to erase and reprogram the
HomeLink Transmitter.

2-70 Operating the Transmitter
Press and hold the appropriate button on the
HomeLink
Transmitter. The house symbol comes on
while the signal is being transmitted.
The effective transmission range of the HomeLink
Transmitter may differ from the hand
-held transmitter
and from one channel to another.
Training a Garage Opener with a ªRolling
Codeº Feature
If you programmed the HomeLink
Transmitter, but
the garage door will not open, and if your garage door
opener was manufactured after 1995, your garage door
may have a security feature that changes the ªcodeº
of your garage door opener every time it is opened
or closed.To determine if your garage door opener has this
ªrolling codeº feature, press the appropriate button
on the HomeLink Transmitter that was programmed.
If the indicator light flashes rapidly for one or
two seconds, then turns solid, your garage door opener
has this feature.
To program a garage door opener with the rolling code
feature, do the following:
1. Program your hand
-held transmitter to the
HomeLink Transmitter by following the steps
provided under ªProgramming the Transmitterº
earlier in this section.
Because of the steps involved, it may be helpful to
have another person available to assist you in
programming the transmitter.
2. Remove the cover panel from the garage door
opener receiver. It is located near the garage door
opener motor.

2-71
3. Locate the training button on the garage door opener
receiver. The exact location and color will vary
among brands.
4. Press the training button on the garage door opener
receiver. This will activate the training light.
5. Within thirty seconds of pressing the training button,
return to your vehicle and press the programmed
button on the HomeLink Transmitter until the
indicator light flashes rapidly (about two seconds).
6. Release the button, then press it again to confirm it
was programmed to the garage door opener receiver.
It may take more than one attempt to confirm that
the transmitter was programmed.
You may now use either the HomeLink Transmitter or
the hand
-held transmitter to open your garage door.
If you still have difficulty in programming and require
assistance, please call 1
-800-355-3515.
Erasing Channels
To erase all three programmed channels, hold down the
two outside buttons until the indicator light begins to
flash. Individual channels cannot be erased, but can be
reprogrammed using the procedure for programming the
transmitter explained earlier.
Accessories
Accessories for the HomeLink
Transmitter are
available from the manufacturer of the unit. If you
would like additional information, please call
1
-800-355-3515.

2-72
The Instrument Panel -- Your Information System

2-73
The main components of your instrument panel are listed here:
A. Instrument Panel Fuse Block
B. Turn Signal/Multifunction Lever
(behind steering wheel)
C. Audio Steering Wheel Controls (If Equipped)
D. Hazard Warning Flasher Switch
E. Audio System
F. Exterior Lamp ControlsG. Remote Trunk Release
H. Hood Release
I. Steering Wheel Cruise Control Switches
(If Equipped)
J. Ignition Switch
K. Automatic Transaxle Shift Lever
L. Climate Controls

2-74
Instrument Panel Cluster
3400 V6 Engine Cluster: United States Version Shown, Canadian Similar
Your instrument panel cluster is designed to let you know at a glance how your vehicle is running. You'll know how fast
you're going, about how much fuel is in your tank and many other things you need to drive safely and economically.

2-75
3800 V6 Engine Cluster: United States Version Shown, Canadian Similar

2-76 Speedometer and Odometer
Your speedometer lets you see your speed in both miles
per hour (mph) and kilometers per hour (km/h). Your
odometer shows how far your vehicle has been driven in
either miles (used in the United States) or in kilometers
(used in Canada).
Your vehicle has a tamper
-resistant odometer. If you see
ERROR, you'll know someone has probably tampered
with it and the numbers may not be accurate.
You may wonder what happens if your vehicle needs a
new odometer installed. If the new one can be set to the
mileage total of the old odometer, then that will be done.
But if it can't, then it will be set at zero and a label must
be put on the driver's door to show the old mileage
reading when the new odometer was installed.
Trip Odometer
Your trip odometer tells how far you have driven since
you last reset it.
Your trip/select reset switch will go back and forth
between the odometer and the trip odometer if the
button is pressed and released within 1.5 seconds. If the button is pressed and held for longer than
1.5 seconds while in the trip odometer mode, it will be
reset to zero. If the button is pressed and held for longer
than 1.5 seconds while in the odometer mode, it will
have no effect.
Your trip odometer will work no matter what position
your key is in, and even if the key isn't in.
Tachometer
The tachometer displays
the engine speed in
thousands of revolutions
per minute (rpm).
NOTICE:
Do not operate the engine with the tachometer in
the shaded area, or engine damage may occur.

2-77
Warning Lights, Gages
and Indicators
This part describes the warning lights and gages that
may be on your vehicle. The pictures will help you
locate them.
Warning lights and gages can signal that something is
wrong before it becomes serious enough to cause an
expensive repair or replacement. Paying attention to
your warning lights and gages could also save you or
others from injury.
Warning lights come on when there may be or is a
problem with one of your vehicle's functions. As you
will see in the details on the next few pages, some
warning lights come on briefly when you start the
engine just to let you know they're working. If you
are familiar with this section, you should not be alarmed
when this happens.
Gages can indicate when there may be or is a problem
with one of your vehicle's functions. Often gages and
warning lights work together to let you know when
there's a problem with your vehicle.When one of the warning lights comes on and stays on
when you are driving, or when one of the gages shows
there may be a problem, check the section that tells you
what to do about it. Please follow this manual's advice.
Waiting to do repairs can be costly
-- and even
dangerous. So please get to know your warning lights
and gages. They're a big help.
Your vehicle may also have a driver information center
that works along with the warning lights and gages.
See ªDriver Information Centerº in the Index.
Safety Belt Reminder Light
When the key is turned to ON, a chime will come on
for about eight seconds to remind people to fasten
their safety belts, unless the driver's safety belt is
already buckled.
The safety belt light will
also come on and stay on
for about 20 seconds,
then it will flash for
about 55 seconds.

2-78 Air Bag Readiness Light
There is an air bag readiness light on the instrument
panel, which shows the air bag symbol. The system
checks the air bag's electrical system for malfunctions.
The light tells you if there is an electrical problem.
The system check includes the air bag sensors, the air
bag modules, the wiring and the crash sensing and
diagnostic module. For more information on the air bag
system, see ªAir Bagº in the Index.
This light will come on
when you start your vehicle,
and it will flash for a few
seconds. Then the light
should go out. This means
the system is ready.
If the air bag readiness light stays on after you start the
vehicle or comes on when you are driving, your air bag
system may not work properly. Have your vehicle
serviced right away.
CAUTION:
If the air bag readiness light stays on after you
start your vehicle, it means the air bag system
may not be working properly. The air bags in
your vehicle may not inflate in a crash, or they
could even inflate without a crash. To help avoid
injury to yourself or others, have your vehicle
serviced right away if the air bag readiness light
stays on after you start your vehicle.
The air bag readiness light should flash for a few
seconds when you turn the ignition key to ON. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.
