The main components of your instrument panel are listed here:
A. Instrument Panel Fuse Block. See “Instrument Panel
Fuse Block” underFuses and Circuit Breakers on
page 5-104.
B. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 3-7.
C. Audio Steering Wheel Controls (If Equipped).
SeeAudio Steering Wheel Controls on page 3-92.
D. Instrument Panel Cluster. SeeInstrument Panel
Cluster on page 3-29.
E. Hazard Warning Flasher Button. SeeHazard
Warning Flashers on page 3-6.
F. Audio System. SeeAudio System(s) on page 3-55.
G. Air Outlet. See “Outlet Adjustment” underDual
Climate Control System on page 3-21.
H. Exterior Lamps Control. SeeExterior Lamps on
page 3-14.I. Remote Trunk Release. See “Remote Trunk
Release” underTrunk on page 2-10.
J. Tilt Steering Wheel Lever. SeeTilt Wheel on
page 3-7.
K. Hood Release. SeeHood Release on page 5-10.
L. Steering Wheel Cruise Contol (If Equipped).
SeeCruise Control on page 3-11.
M. Ignition Switch. See “Ignition Positions” under
New Vehicle Break-In on page 2-17.
N. Automatic Transaxle Shift Lever. SeeAutomatic
Transaxle Operation on page 2-21.
O. Climate Controls. SeeDual Climate Control System
on page 3-21.
P. Glove Box. SeeGlove Box on page 2-40.
3-5

Fuses Usage
TRK/ROOF BRP Trunk Lamps, Headliner Lamps
HVAC BLO HVAC Blower Relay
I/P BRPInstrument Panel Footwell
Lamps, Glovebox Lamps
HTD MIR Heated Mirrors
BRK SW Brake Switch
HAZ SW Hazard Switch
REAR PRK LP Rear Parking Lamps
AUX PWR Accessory Power Outlet (Battery)
C/LTR Cigarette Lighter
RADIORadio, Radio Amplier,
Remote Digital Radio Receiver
FRT PARK LPFront Parking Lamps,
Instrumentation LightingRelays Usage
PARK LP RELAY Parking Lamp Relay
BACKUP LP
RELAYBack-up Lamps Relay
BATT RUN
DOWN
PROTECTION
RELAYBattery Run Down
Protection Relay
REAR DEFOG
RELAYRear Defogger Relay,
Heated Mirror Relay
Breakers Usage
PWR SEATS
BRKRPower Seat Circuit Breaker
REAR DEFOG
BRKRRear Defogger Breaker
5-107

Flash-to-Pass Feature....................................... 3-9
Flat Tire........................................................5-81
Flat Tire, Changing.........................................5-82
Fluid
Automatic Transaxle.....................................5-28
Power Steering...........................................5-47
Windshield Washer......................................5-48
FM Stereo.....................................................3-93
FOB PROG (Remote Keyless Entry Transmitter
Programming).............................................2-50
FOB HORN
(Remote Audible Verication)..........................2-46
FOB LIGHT (Remote Visual Verication)..............2-45
Fog Lamps....................................................3-16
Folding Rear Seat............................................ 1-8
Following Distance..........................................4-42
Fuel............................................................... 5-4
Additives...................................................... 5-6
California Fuel.............................................. 5-5
Filling a Portable Fuel Container..................... 5-9
Filling Your Tank........................................... 5-7
Fuels in Foreign Countries.............................. 5-6
Gage.........................................................3-43
Gasoline Octane........................................... 5-4Fuel (cont.)
Gasoline Specications.................................. 5-5
Low Warning Message.................................3-50
Fuses
Fuses and Circuit Breakers.........................5-104
Windshield Wiper.......................................5-103
G
Gage
Engine Coolant Temperature.........................3-38
Fuel..........................................................3-43
Speedometer..............................................3-32
Tachometer.................................................3-33
Voltmeter Gage...........................................3-35
Garage Door Opener.......................................2-36
Gasoline
Octane........................................................ 5-4
Specications............................................... 5-5
Gate Operator and Canadian Programming........2-38
Glove Box.....................................................2-40
GM Mobility Program for Persons with
Disabilities.................................................... 7-6
