roof CHEVROLET MONTE CARLO 2005 6.G Owners Manual

Seats and Restraint Systems........................... 1-1
Front Seats
............................................... 1-2
Rear Seats
............................................... 1-8
Safety Belts
.............................................. 1-9
Child Restraints
.......................................1-27
Airbag System
.........................................1-46
Restraint System Check
............................1-55
Features and Controls..................................... 2-1
Keys
........................................................ 2-2
Doors and Locks
....................................... 2-8
Windows
.................................................2-12
Theft-Deterrent Systems
............................2-13
Starting and Operating Your Vehicle
...........2-16
Mirrors
....................................................2-28
OnStar
®System
......................................2-30
HomeLink®Wireless Control System
...........2-32
Storage Areas
.........................................2-36
Sunroof
..................................................2-37
Vehicle Personalization
.............................2-38
Instrument Panel............................................. 3-1
Instrument Panel Overview
.......................... 3-4
Climate Controls
......................................3-22
Warning Lights, Gages, and Indicators
........3-27
Message Center
.......................................3-42Driver Information Center (DIC)
..................3-51
Trip Computer
.........................................3-53
Audio System(s)
.......................................3-54
Driving Your Vehicle....................................... 4-1
Your Driving, the Road, and Your Vehicle
..... 4-2
Towing
...................................................4-36
Service and Appearance Care.......................... 5-1
Service
..................................................... 5-3
Fuel
......................................................... 5-5
Checking Things Under the Hood
...............5-10
Headlamp Aiming
.....................................5-54
Bulb Replacement
....................................5-54
Windshield Wiper Blade Replacement
.........5-58
Tires
......................................................5-59
Appearance Care
.....................................5-88
Vehicle Identication
.................................5-96
Electrical System
......................................5-97
Capacities and Specications
...................5-103
Maintenance Schedule..................................... 6-1
Maintenance Schedule
................................ 6-2
Customer Assistance and Information.............. 7-1
Customer Assistance and Information
........... 7-2
Reporting Safety Defects
...........................7-10
Index................................................................ 1
2005 Chevrolet Monte Carlo Owner ManualM

Keys...............................................................2-2
Remote Keyless Entry System.........................2-3
Remote Keyless Entry System Operation...........2-4
Doors and Locks.............................................2-7
Door Locks....................................................2-7
Power Door Locks..........................................2-9
Programmable Automatic Door Locks................2-9
Lockout Protection........................................2-10
Trunk..........................................................2-10
Windows........................................................2-12
Power Windows............................................2-13
Sun Visors...................................................2-13
Theft-Deterrent Systems..................................2-13
Content Theft-Deterrent.................................2-14
Passlock
®....................................................2-15
Starting and Operating Your Vehicle................2-16
New Vehicle Break-In....................................2-16
Ignition Positions..........................................2-16
Retained Accessory Power (RAP)...................2-17
Starting the Engine.......................................2-17
Engine Coolant Heater..................................2-19
Automatic Transaxle Operation.......................2-20
Parking Brake..............................................2-23
Shifting Into Park (P).....................................2-24Shifting Out of Park (P).................................2-25
Parking Over Things That Burn.......................2-26
Engine Exhaust............................................2-26
Running the Engine While Parked...................2-27
Mirrors...........................................................2-28
Manual Rearview Mirror.................................2-28
Manual Rearview Mirror with OnStar
®..............2-28
Automatic Dimming Rearview Mirror................2-28
Automatic Dimming Rearview Mirror with
OnStar
®...................................................2-29
Outside Power Mirrors...................................2-29
Outside Convex Mirror...................................2-30
Outside Heated Mirrors..................................2-30
OnStar
®System.............................................2-30
HomeLink®Wireless Control System...............2-32
HomeLink®Wireless Control System Operation . . .2-33
Storage Areas................................................2-36
Glove Box...................................................2-36
Center Console Storage Area.........................2-36
Rear Storage Area........................................2-36
Convenience Net..........................................2-37
Sunroof.........................................................2-37
Vehicle Personalization...................................2-38
Section 2 Features and Controls
2-1

Convenience Net
The vehicle may have a convenience net located on the
back wall of the trunk.
Put small loads, like grocery bags, behind the net. It can
help keep them from falling over.
The net is not for larger, heavier loads. Store those in
the trunk as far forward as possible.
Unhook the net so that it will lie at when not in use.
Sunroof
The vehicle may have a sunroof and a sunshade.
The switch is located on
the overhead console if
the vehicle is equipped
with a Driver Information
Center (DIC).
If the vehicle is not equipped with a DIC, the sunroof
switch is located on the headliner.The sunroof can only be operated when the ignition is in
ACC, ON, or when Retained Accessory Power (RAP)
is active. SeeRetained Accessory Power (RAP)
on page 2-17.
Vent:The sunroof has a vent position. To vent the
sunroof when it is closed, press the sunroof switch once
rearward. To close, push and hold the sunroof switch
forward. When using the vent, the sunshade should be
fully opened.
The sunshade can be opened or closed manually by
sliding it rearward or forward.
Open/Express:To activate the express-open feature,
press rearward twice on the sunroof switch. Press
the switch forward to stop movement of the sunroof. The
sunshade will automatically open when using
express-open.
Close:To close the sunroof, push and hold the switch
forward until the sunroof motor stops, or release the
switch when the desired position has been reached.
DIC Version Shown
2-37

Driver Information Center (DIC)
If your vehicle is equipped with the DIC, it will show
information about the vehicle and the surroundings. It is
located in the headliner between the sun visors.
RESET:You can reset the AVG ECON, FUEL USED
or AVG SPEED trip computer modes by pressing
and holding this button for three seconds while you are
in the mode you wish to reset. A chime will sound to
conrm that your requested change has been made and
all the segments of the display will briey light up.To change the display to a metric or English reading,
press the RESET and MODE buttons at the same time.
Hold them down for three seconds and the display
will change. A chime will be heard to conrm the new
selection.
The reset button can also be used to manually calibrate
the compass. See “Manual Compass Calibration”
later in this section.
The reset button can be used to set the compass zone
variation. See “Compass Variance” later in this section.
MODE:Press this button to cycle through three modes
of operation: Off, Compass/Temperature and Trip
Computer mode.
Off:No driver information is displayed in this mode
of operation.
Compass/Temperature Mode:One of eight
compass readings and the outside temperature are
displayed. If the temperature is below 38°F (3°C), the
word ICE is displayed for two minutes.
Trip Computer:Pressing the MODE button cycles
through the ve displays. Press the MODE button
after the last Trip Computer display to return the DIC
to the OFF mode. Optional Sunroof Version Shown
3-51

XM™ Satellite Radio Antenna
System
The XM™ Satellite Radio antenna is located on the roof
of your vehicle. Keep this antenna clear of snow and
ice build up for clear radio reception.
The performance of the XM system may be affected if
the sunroof is open.
Vehicle Customization Settings
The audio system can be used to control vehicle
customization settings using the DISPL knob when the
radio is off. SeeVehicle Personalization on page 2-38
for more information.
Chime Level Adjustment
The radio is the vehicle chime producer. To change the
volume level, press and hold pushbutton 6 with the
ignition on and the radio power off. The chime volume
level will change from the normal level to loud, and
LOUD will appear on the radio display. To change back
to the default or normal setting, press and hold
pushbutton 6 again. The chime level will change from
the loud level to normal, and NORMAL will appear
on the radio display. Each time the chime volume is
changed, three chimes will sound as an example of the
new volume selected. Removing the radio and not
replacing it with a factory radio or chime module will
disable vehicle chimes.
3-93

Fuses Usage
ABS/PCMAnti-Lock Brake System, Powertrain
Control Module, Brake Switch,
Crank Relay, Canister Vent Solenoid
(Run, Crank)
STOPBrake Lamps, Body Control Module
(Run, Crank)
TRN/SIG Turn Signal Flashers
CRUISECruise Control Steering Column
Controls
AC/CRUISEHVAC Temp Door Motors & Module,
Cruise Control Module
A/C FAN HVAC Blower
STR COL Steering Wheel Lighting
DR/LKBody Control Module, Door Lock
Controls
PWR MIR Power Mirrors
CLSTR/BCMCluster, Body Control Module, Data
Link Connector (Battery)
LH HTD/
ST/BCMDriver’s Heated Seat, Body Control
Module, Battery controlled LoadsRelays Usage
RAP Retained Accessory Power Relay
HEADLAMP Headlamp Relay
Circuit
BreakersUsage
RETAINED
ACCSRY
PWR BRKRPower Windows, Sunroof Breaker
Passenger’s Side Fuse Block
Some fuses are in a fuse
block at the end of the
instrument panel on
the passenger’s side of the
vehicle. Pull off the
cover labeled FUSES to
expose the fuses.
5-99

Fuses Usage
RH HTD ST Passenger Heated Seat
PWR DROP Accommodated Device
B/U LP Back-Up Lamps
DIC/RKEDriver Information Center, Remote
Keyless Entry, HVAC
TRK/ROOF
BRPTrunk Lamps, Headliner Lamps
HVAC BLO HVAC Blower Relay
Fuses Usage
I/P BRPInstrument Panel Footwell Lamps,
Glovebox Lamps
HTD MIR Heated Mirrors
BRK SW Brake Switch
HAZ SW Hazard Switch
REAR PRK LP Rear Parking Lamps
AUX PWR Accessory Power Outlet (Battery)
C/LTR Cigarette Lighter
RADIORadio, Radio Amplier, Remote
Digital Radio Receiver
FRT PARK LPFront Parking Lamps,
Instrumentation Lighting
Relays Usage
PARK LP
RELAYParking Lamp Relay
BACK UP LP
RELAYBack-up Lamps Relay
BATT RUN
DOWN
PROTECTION
RELAYBattery Run Down Protection Relay
REAR DEFOG
RELAYRear Defogger Relay, Heated Mirror
Relay
5-100

Storage Areas
Center Console Storage Area........................2-36
Convenience Net.........................................2-37
Glove Box..................................................2-36
Rear Storage Area.......................................2-36
Stuck in Sand, Mud, Ice or Snow......................4-30
Sun Visors.....................................................2-13
Sunroof.........................................................2-37
T
Tachometer....................................................3-31
Taillamps
Turn Signal, Stoplamps and Sidemarker
Lamps....................................................5-56
TCS Warning Light..........................................3-35
Theft-Deterrent, Radio.....................................3-88
Theft-Deterrent Systems...................................2-13
Content Theft-Deterrent................................2-14
Passlock
®...................................................2-15
Tilt Wheel........................................................ 3-6
Tire
Low Message.............................................3-46
Tires.............................................................5-59
Aluminum Wheels, Cleaning..........................5-93
Buying New Tires........................................5-70Tires (cont.)
Chains.......................................................5-74
Changing a Flat Tire....................................5-76
Cleaning....................................................5-94
Compact Spare Tire.....................................5-87
If a Tire Goes Flat.......................................5-75
Ination -- Tire Pressure...............................5-65
Inspection and Rotation................................5-68
Installing the Spare Tire................................5-79
Pressure Monitor System..............................5-66
Removing the Flat Tire.................................5-79
Removing the Spare Tire and Tools...............5-77
Storing a Flat or Spare Tire and Tools............5-85
Tire Sidewall Labelling..................................5-60
Tire Terminology and Denitions....................5-62
Uniform Tire Quality Grading.........................5-71
Wheel Alignment and Tire Balance.................5-72
Wheel Replacement.....................................5-72
When It Is Time for New Tires......................5-69
Top Strap......................................................1-37
Top Strap Anchor Location...............................1-38
Towing
Recreational Vehicle.....................................4-36
Towing a Trailer..........................................4-38
Your Vehicle...............................................4-36
12
