brake sensor CHEVROLET SPARK 2018 Owner's Manual

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-11348464) -
2018 - crc - 9/19/17
In Brief 7
1.Air Vents 0162.
2. Exterior Lamp Controls 0127.
Instrument Panel Illumination
Control 0131.
3. Turn and Lane-Change Signals
0130.
Driver Information Center (DIC)
Controls. See Driver
Information Center (DIC) 0114.
4. Instrument Cluster 0100.
Driver Information Center (DIC)
Display. See Driver Information
Center (DIC) 0114.
5. Windshield Wiper/Washer 095.
Rear Window Wiper/Washer
0 96.
6. Hazard Warning Flashers
0130.
7. Light Sensor. See Automatic
Headlamp System 0129.
8. Infotainment 0134.
9. Power Outlets 098.
10. Climate Control Systems
0160. 11.
Heated Front Seats 051 (If
Equipped).
12. Shift Lever. See Automatic
Transmission 0186 (If
Equipped) or Manual
Transmission 0188 (If
Equipped).
13. Parking Brake 0191.
14. Auxiliary Devices 0149 (If
Equipped).
15. Ignition Positions (Keyless
Access) 0176 orIgnition
Positions (Key Access) 0178.
16. Steering Wheel Controls 095
(If Equipped).
17. Horn 095.
18. Steering Wheel Adjustment
095.
19. Cruise Control 0195 (If
Equipped).
Forward Collision Alert (FCA)
System 0200 (If Equipped).
20. Traction Control/Electronic
Stability Control 0193. Lane Departure Warning
(LDW)
0202 (If Equipped).
21. Instrument Panel Fuse Block
0239.
22. Hood Release. See Hood
0 212.
23. Data Link Connector (DLC) (Out of View). See Malfunction
Indicator Lamp (Check Engine
Light) 0105.

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-11348464) -
2018 - crc - 9/19/17
94 Instruments and Controls
Instruments and
Controls
Controls
Steering Wheel Adjustment . . . . 95
Steering Wheel Controls . . . . . . . 95
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Windshield Wiper/Washer . . . . . . 95
Rear Window Wiper/Washer . . . 96
Compass . . . . . . . . . . . . . . . . . . . . . . 97
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Power Outlets . . . . . . . . . . . . . . . . . 98
Warning Lights, Gauges, and
Indicators
Warning Lights, Gauges, andIndicators . . . . . . . . . . . . . . . . . . . . 99
Instrument Cluster . . . . . . . . . . . . 100
Speedometer . . . . . . . . . . . . . . . . . 102
Odometer . . . . . . . . . . . . . . . . . . . . . 102
Trip Odometer . . . . . . . . . . . . . . . . 102
Tachometer . . . . . . . . . . . . . . . . . . . 102
Fuel Gauge . . . . . . . . . . . . . . . . . . . 102
Seat Belt Reminders . . . . . . . . . 103
Airbag Readiness Light . . . . . . . 103
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . 104
Charging System Light . . . . . . . 105 Malfunction Indicator Lamp
(Check Engine Light) . . . . . . . . 105
Service Vehicle Soon Light . . . 107
Owner Manual Indicator . . . . . . 107
Brake System Warning Light . . . . . . . . . . . . . . . . . . . . . . . . 107
Antilock Brake System (ABS) Warning Light . . . . . . . . . . . . . . . 108
Operate Pedal Light . . . . . . . . . . 108
Up-Shift Light . . . . . . . . . . . . . . . . . 109
Power Steering Warning Light . . . . . . . . . . . . . . . . . . . . . . . . 109
Lane Departure Warning (LDW) Light . . . . . . . . . . . . . . . . . 109
Vehicle Ahead Indicator . . . . . . 109
Ultrasonic Parking Sensor Light . . . . . . . . . . . . . . . . . . . . . . . . 109
Traction Off Light . . . . . . . . . . . . . 110
StabiliTrak OFF Light . . . . . . . . . 110
Traction Control System (TCS)/ StabiliTrak Light . . . . . . . . . . . . . 110
Engine Coolant Temperature Warning Light . . . . . . . . . . . . . . . 111
Tire Pressure Light . . . . . . . . . . . 111
Engine Oil Pressure Light . . . . . 112
Low Fuel Warning Light . . . . . . . 112
Immobilizer Light . . . . . . . . . . . . . 112
Reduced Engine Power Light . . . . . . . . . . . . . . . . . . . . . . . . 113
High-Beam On Light . . . . . . . . . . 113 Front Fog Lamp Light . . . . . . . . . 113
Lamps On Reminder . . . . . . . . . . 113
Cruise Control Light . . . . . . . . . . 113
Hood Ajar Light . . . . . . . . . . . . . . . 114
Door Ajar Light . . . . . . . . . . . . . . . 114
Information Displays
Driver Information
Center (DIC) . . . . . . . . . . . . . . . . 114
Vehicle Messages
Vehicle Messages (Base LevelCluster) . . . . . . . . . . . . . . . . . . . . . 119
Vehicle Messages (Uplevel Cluster) . . . . . . . . . . . . . . . . . . . . . 120
Engine Power Messages . . . . . 121
Vehicle Speed Messages . . . . . 121
Vehicle Personalization
Vehicle Personalization . . . . . . . 121

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-11348464) -
2018 - crc - 9/19/17
200 Driving and Operating
Turning the System On and Off
The RPA system can be turned on
and off using the infotainment
system controls. SeeVehicle
Personalization 0121.
When the System Does Not
Seem to Work Properly
This light may come on for the
following reasons:
.
The sensors are not clean. Keep
the vehicle's rear bumper free of
mud, dirt, snow, ice, and slush.
For cleaning instructions, see
Exterior Care 0274.
. The sensors are covered by
frost or ice. Frost or ice can form
around and behind the sensors
and may not always be seen;
this can occur after washing the vehicle in cold weather. The light
may not clear until the frost or
ice has melted.
. An object was hanging out of the
liftgate during the last drive
cycle. Once the object is
removed, RPA will return to
normal operation.
. The bumper is damaged. Take
the vehicle to your dealer to
repair the system.
. Other conditions, such as
vibrations from a jackhammer or
the compression of air brakes on
a very large truck, are affecting
system performance.
If the above conditions do not exist,
take the vehicle to your dealer to
repair the system.
Forward Collision Alert
(FCA) System
If equipped, the FCA system may
help to avoid or reduce the harm
caused by front-end crashes. When
approaching a vehicle ahead too
quickly, FCA provides a red flashing alert on the windshield and rapidly
beeps. FCA also lights an amber
visual alert if following another
vehicle much too closely.
FCA detects vehicles within a
distance of approximately 60 m
(197 ft) and operates at speeds
above 40 km/h (25 mph).
{Warning
FCA is a warning system and
does not apply the brakes. When
approaching a slower-moving or
stopped vehicle ahead too rapidly,
or when following a vehicle too
closely, FCA may not provide a
warning with enough time to help
avoid a crash. It also may not
provide any warning at all. FCA
does not warn of pedestrians,
animals, signs, guardrails,
bridges, construction barrels,
or other objects. Be ready to take
action and apply the brakes. See
Defensive Driving
0166.

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-11348464) -
2018 - crc - 9/19/17
Driving and Operating 201
FCA can be disabled with the FCA
steering wheel control.
Detecting the Vehicle Ahead
FCA warnings will not occur unless
the FCA system detects a vehicle
ahead. When a vehicle is detected,
the vehicle ahead indicator will
display green. Vehicles may not be
detected on curves, highway exit
ramps, or hills, due to poor visibility;
or if a vehicle ahead is partially
blocked by pedestrians or other
objects. FCA will not detect another
vehicle ahead until it is completely
in the driving lane.
{Warning
FCA does not provide a warning
to help avoid a crash, unless it
detects a vehicle. FCA may not
detect a vehicle ahead if the FCA
sensor is blocked by dirt, snow,
or ice, or if the windshield is
damaged. It may also not detect a
vehicle on winding or hilly roads,
or in conditions that can limit
visibility such as fog, rain,
or snow, or if the headlamps or
windshield are not cleaned or in
proper condition. Keep the
windshield, headlamps, and FCA
sensors clean and in good repair.
Collision Alert
When your vehicle approaches
another detected vehicle too rapidly,
the red FCA display will flash on the
windshield. Also, eight rapid
high-pitched beeps will sound from
the front. When this Collision Alert
occurs, the brake system may
prepare for driver braking to occur
more rapidly which can cause a
brief, mild deceleration. Continue to
apply the brake pedal as needed.
Cruise control may be disengaged
when the Collision Alert occurs.
Tailgating Alert
The vehicle ahead indicator will
display amber when you are
following a detected vehicle ahead
much too closely.

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-11348464) -
2018 - crc - 9/19/17
Vehicle Care 253
vehicle’s tires or replacing one or
more of the TPMS sensors. Also,
the TPMS sensor matching process
should be performed after replacing
a spare tire with a road tire
containing the TPMS sensor. The
malfunction light and the DIC
message, if equipped, should go off
at the next ignition cycle. The
sensors are matched to the tire/
wheel positions, using a TPMS
relearn tool, in the following order:
driver side front tire, passenger side
front tire, passenger side rear tire,
and driver side rear. See your
dealer for service or to purchase a
relearn tool. A TPMS relearn tool
can also be purchased. See Tire
Pressure Monitor Sensor Activation
Tool at
www.gmtoolsandequipment.com or
call 1-800-GM TOOLS
(1-800-468-6657).
There are two minutes to match the
first tire/wheel position, and
five minutes overall to match all four
tire/wheel positions. If it takes
longer, the matching process stops
and must be restarted.The TPMS sensor matching
process is:
1. Set the parking brake.
2. Turn the ignition on without starting the vehicle or place the
vehicle in Service Mode.
See Ignition Positions (Keyless
Access) 0176 orIgnition
Positions (Key Access) 0178.
3. Use MENU to select the Vehicle Information Menu
(Menu 2) in the Driver
Information Center (DIC).
4. Use the thumbwheel (or up and down arrows) to scroll to the
Tire Pressure Learn Menu Item
(Base DIC) or the Tire
Pressure Menu Item screen
(Uplevel DIC).
5. Press and hold SET/CLR to begin the sensor matching
process.
A message requesting
acceptance of the process may
display.
6. If requested, press SET/CLR again to confirm the selection. The horn sounds twice to
signal the receiver is in relearn
mode and the TIRE LEARN or
TIRE LEARNING ACTIVE
message displays on the DIC
screen.
7. Start with the driver side front tire.
8. Place the relearn tool against the tire sidewall, near the valve
stem. Then press the button to
activate the TPMS sensor.
A horn chirp confirms that the
sensor identification code has
been matched to this tire and
wheel position.
9. Proceed to the passenger side front tire, and repeat the
procedure in Step 8.
10. Proceed to the passenger side rear tire, and repeat the
procedure in Step 8.
11. Proceed to the driver side rear tire, and repeat the procedure
in Step 8. The horn sounds two
times to indicate the sensor
identification code has been
matched to the driver side rear

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-11348464) -
2018 - crc - 9/19/17
260 Vehicle Care
Wheel Replacement
Replace any wheel that is bent,
cracked, or badly rusted or
corroded. If wheel nuts keep coming
loose, the wheel, wheel bolts, and
wheel nuts should be replaced.
If the wheel leaks air, replace it.
Some aluminum wheels can be
repaired. See your dealer if any of
these conditions exist.
Your dealer will know the kind of
wheel that is needed.
Each new wheel should have the
same load-carrying capacity,
diameter, width, offset, and be
mounted the same way as the one it
replaces.
Replace wheels, wheel bolts, wheel
nuts, or Tire Pressure Monitor
System (TPMS) sensors with new
GM original equipment parts.{Warning
Using the wrong replacement
wheels, wheel bolts, or wheel
nuts can be dangerous. It could
affect the braking and handling of
the vehicle. Tires can lose air,
and cause loss of control, causing
a crash. Always use the correct
wheel, wheel bolts, and wheel
nuts for replacement.
Caution
The wrong wheel can also cause
problems with bearing life, brake
cooling, speedometer or
odometer calibration, headlamp
aim, bumper height, vehicle
ground clearance, and tire or tire
chain clearance to the body and
chassis.
Used Replacement Wheels
{Warning
Replacing a wheel with a used
one is dangerous. How it has
been used or how far it has been
driven may be unknown. It could
fail suddenly and cause a crash.
When replacing wheels, use a
new GM original equipment
wheel.
Tire Chains
{Warning
Do not use tire chains. There is
not enough clearance. Tire chains
used on a vehicle without the
proper amount of clearance can
cause damage to the brakes,
suspension, or other vehicle
parts. The area damaged by the
tire chains could cause loss of
control and a crash.(Continued)

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-11348464) -
2018 - crc - 9/19/17
Index 331
K
Keyless EntryRemote (RKE) System . . . . . 27, 29
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
L
Labeling, Tire Sidewall . . . . . . . . . . 243
Lamps Courtesy . . . . . . . . . . . . . . . . . . . . . . 131
Daytime Running (DRL) . . . . . . 128
Dome . . . . . . . . . . . . . . . . . . . . . . . . . 131
Exterior Controls . . . . . . . . . . . . . . 127
Exterior Lamps OffReminder . . . . . . . . . . . . . . . . . . . 128
Exterior Lighting Battery
Saver . . . . . . . . . . . . . . . . . . . . . . . 132
License Plate . . . . . . . . . . . . . . . . . 235
Malfunction Indicator (Check Engine) . . . . . . . . . . . . . 105
On Reminder . . . . . . . . . . . . . . . . . .113
Reading . . . . . . . . . . . . . . . . . . . . . . 132
Lane Departure Warning (LDW) . . . . . . . . . . . . . . . . 202
Lane Departure Warning
Light . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Lap-Shoulder Belt . . . . . . . . . . . . . . . 56 LATCH System
Replacing Parts after a
Crash . . . . . . . . . . . . . . . . . . . . . . . . . 85
LATCH, Lower Anchors and Tethers for Children . . . . . . . . . . . . 78
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Lighting Entry . . . . . . . . . . . . . . . . . . . . . . . . . 132
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Illumination Control . . . . . . . . . . . 131
Lights
Airbag Readiness . . . . . . . . . . . . . 103
Antilock Brake System(ABS) Warning . . . . . . . . . . . . . . 108
Brake System Warning . . . . . . . 107
Charging System . . . . . . . . . . . . . 105
Check Engine (Malfunction Indicator) . . . . . . . . . . . . . . . . . . . . 105
Cruise Control . . . . . . . . . . . . . . . . .113
Door Ajar . . . . . . . . . . . . . . . . . . . . . .114
Engine Coolant Temperature Warning . . . . . . . . 111
Engine Oil Pressure . . . . . . . . . . .112
Flash-to-Pass . . . . . . . . . . . . . . . . . 128
Front Fog Lamp . . . . . . . . . . . . . . .113
High-Beam On . . . . . . . . . . . . . . . . .113
High/Low Beam Changer . . . . . 128
Hood Ajar . . . . . . . . . . . . . . . . . . . . .114 Lights (cont'd)
Immobilizer . . . . . . . . . . . . . . . . . . . .112
Lane Departure Warning . . . . . . 109
Low Fuel Warning . . . . . . . . . . . . .112
Operate Pedal . . . . . . . . . . . . . . . . 108
Reduced Engine Power . . . . . . .113
Seat Belt Reminders . . . . . . . . . . 103
Service Vehicle Soon . . . . . . . . . 107
StabiliTrak OFF . . . . . . . . . . . . . . . .110
Tire Pressure . . . . . . . . . . . . . . . . . . 111
Traction Control System
(TCS)/StabiliTrak . . . . . . . . . . . . .110
Traction Off . . . . . . . . . . . . . . . . . . . .110
Ultrasonic Parking Sensor . . . . 109
Up-Shift . . . . . . . . . . . . . . . . . . . . . . 109
Warning, Power Steering . . . . . 109
Locks Automatic Door . . . . . . . . . . . . . . . . . 36
Delayed Locking . . . . . . . . . . . . . . . . 36
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Lockout Protection . . . . . . . . . . . . . . 36
Power Door . . . . . . . . . . . . . . . . . . . . . 35
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Loss of Control . . . . . . . . . . . . . . . . . 168
Low Fuel Warning Light . . . . . . . . . 112
Lower Anchors and Tethers for Children (LATCH
System) . . . . . . . . . . . . . . . . . . . . . . . . 78

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-11348464) -
2018 - crc - 9/19/17
332 Index
M
MaintenanceAir Conditioning RegularOperation . . . . . . . . . . . . . . . . . . . 164
Records . . . . . . . . . . . . . . . . . . . . . . 296
Maintenance and Care Additional . . . . . . . . . . . . . . . . . . . . . 291
Maintenance Schedule . . . . . . . . . 286 Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . . . 294
Malfunction Indicator Lamp . . . . . 105
Manual Mirrors . . . . . . . . . . . . . . . . . . 42
Manual Transmission . . . . . . . . . . . 188 Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Manual Windows . . . . . . . . . . . . . . . . 44
Media Avoiding Untrusted Devices . . 143
Messages Engine Power . . . . . . . . . . . . . . . . 121
Vehicle . . . . . . . . . . . . . . . . . . 119, 120
Vehicle Speed . . . . . . . . . . . . . . . . 121
Mirrors Convex . . . . . . . . . . . . . . . . . . . . . . . . . 42
Folding . . . . . . . . . . . . . . . . . . . . . . . . . 43
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 43
Manual . . . . . . . . . . . . . . . . . . . . . . . . . 42
Manual Rearview . . . . . . . . . . . . . . . 43
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Mirrors, Interior Rearview . . . . . . . . 43
Monitor System, Tire
Pressure . . . . . . . . . . . . . . . . . . . . . . 250
Multi-band Antenna . . . . . . . . . . . . . 142
N
Navigation OnStar . . . . . . . . . . . . . . . . . . . . . . . 316
New Vehicle Break-In . . . . . . . . . . . 176
O
Odometer . . . . . . . . . . . . . . . . . . . . . . . 102 Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . 168
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . 215
Engine Oil Life System . . . . . . . 217
Pressure Light . . . . . . . . . . . . . . . . .112
Older Children, Restraints . . . . . . . 72
Online Owner Center . . . . . . . . . . . 303
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . 313
OnStar Additional Information . . . . . . . . . . . . . . . . . . . . 320
OnStar Connections . . . . . . . . . . . . 317
OnStar Diagnostics . . . . . . . . . . . . . 319
OnStar Emergency . . . . . . . . . . . . . 315
OnStar Navigation . . . . . . . . . . . . . . 316
OnStar Overview . . . . . . . . . . . . . . . 314 OnStar Security . . . . . . . . . . . . . . . . 316
Operate Pedal Light . . . . . . . . . . . . 108
Operation
Fog Lamps . . . . . . . . . . . . . . . . . . . 130
Infotainment System . . . . . . . . . . 137
Ordering Service Publications . . . . . . . . . . 309
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Overheating, Engine . . . . . . . . . . . . 224
Overview . . . . . . . . . . . . . . . . . . . . . . . 136
Owner Manual Indicator . . . . . . . . 107
P
Park Shifting Into . . . . . . . . . . . . . . . . . . . 183
Shifting Out of . . . . . . . . . . . . . . . . 184
Parking . . . . . . . . . . . . . . . . . . . . . . . . . 184 Brake . . . . . . . . . . . . . . . . . . . . . . . . . 191
Brake and P (Park)Mechanism Check . . . . . . . . . . 229
Extended . . . . . . . . . . . . . . . . . . . . . 185
Over Things That Burn . . . . . . . 185
Ultrasonic Sensor Light . . . . . . . 109
Parking Assist . . . . . . . . . . . . . . . . . . 199
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . 104
