open gas tank CHEVROLET SUBURBAN 2018 Owner's Manual

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-11349385) - 2018 - crc - 11/3/17
Driving and Operating 267
higher. Do not use gasoline with a
posted octane rating of less than 87,
as this may cause engine knock and
will lower fuel economy.
Prohibited Fuels
Caution
Do not use fuels with any of the
following conditions; doing so
may damage the vehicle and void
its warranty:. For vehicles which are not
FlexFuel, fuel labeled
greater than 15% ethanol by
volume, such as mid-level
ethanol blends (16 –50%
ethanol), E85, or FlexFuel.
. Fuel with any amount of
methanol, methylal, and
aniline. These fuels can
corrode metal fuel system
parts or damage plastic and
rubber parts.
(Continued)
Caution (Continued)
.Fuel containing metals such
as methylcyclopentadienyl
manganese tricarbonyl
(MMT), which can damage
the emissions control
system and spark plugs.
. Fuel with a posted octane
rating of less than the
recommended fuel. Using
this fuel will lower fuel
economy and performance,
and may decrease the life of
the emissions catalyst.
California Fuel
Requirements
If the vehicle is certified to meet
California Emissions Standards, it is
designed to operate on fuels that
meet California specifications. See
the underhood emission control
label. If this fuel is not available in
states adopting California Emissions
Standards, the vehicle will operate
satisfactorily on fuels meeting federal specifications, but emission
control system performance may be
affected. The malfunction indicator
lamp could turn on and the vehicle
may not pass a smog-check test.
See
Malfunction Indicator Lamp
0 153. If this occurs, return to your
authorized dealer for diagnosis. If it
is determined that the condition is
caused by the type of fuel used,
repairs may not be covered by the
vehicle warranty.
Fuels in Foreign
Countries
To keep fuel systems clean, TOP
TIER detergent gasoline is
recommended. See Fuel0266.
If TOP TIER detergent gasoline is
not available, one bottle of GM Fuel
System Treatment Cleaner added to
the fuel tank at every engine oil
change, can help. GM Fuel System
Treatment Cleaner is the only
gasoline additive recommended by
General Motors. It is available at
your dealer.

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-11349385) - 2018 - crc - 11/3/17
270 Driving and Operating
{Warning
If a fire starts while you are
refueling, do not remove the
nozzle. Shut off the flow of fuel by
shutting off the pump or by
notifying the station attendant.
Leave the area immediately.
Filling the Tank with a Portable
Gas Can
If the vehicle runs out of fuel and
must be filled from a portable
gas can:
1. Locate the capless funnel adapter from inside the vehicle.
2. Insert and latch the funnel into the capless fuel system.
{Warning
Attempting to refuel without using
the funnel adapter may cause fuel
spillage and damage the capless
fuel system. This could cause a
fire and you or others could be
badly burned and the vehicle
could be damaged.
3. Remove and clean the funnel adapter and return to the
storage location.
Filling a Portable Fuel
Container
{Warning
Filling a portable fuel container
while it is in the vehicle can cause
fuel vapors that can ignite either
by static electricity or other
means. You or others could be
badly burned and the vehicle
could be damaged. Always:
(Continued)
Warning (Continued)
.Use approved fuel
containers.
. Remove the container from
the vehicle, trunk, or pickup
bed before filling.
. Place the container on the
ground.
. Place the nozzle inside the
fill opening of the container
before dispensing fuel, and
keep it in contact with the fill
opening until filling is
complete.
. Fill the container no more
than 95% full to allow for
expansion.
. Do not smoke, light
matches, or use lighters
while pumping fuel.
. Avoid using cell phones or
other electronic devices.

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-11349385) - 2018 - crc - 11/3/17
OnStar 419
Press=to:
. Open the OnStar app on the
infotainment display. See the
infotainment manual for
information on how to use the
OnStar app.
Or
. Make a call, end a call,
or answer an incoming call.
. Give OnStar Hands-Free Calling
voice commands.
. Give OnStar Turn-by-Turn
Navigation voice commands.
. Obtain and customize the Wi-Fi
hotspot name or SSID and
password, if equipped.
Press
Qto connect to an
Advisor to:
. Verify account information or
update contact information.
. Get driving directions.
. Receive a Diagnostic check of
the vehicle's key operating
systems.
. Receive Roadside Assistance. .
Manage Wi-Fi Settings,
if equipped.
Press
>to get a priority connection
to an OnStar Advisor available
24/7 to:
. Get help for an emergency.
. Be a Good Samaritan or
respond to an AMBER Alert.
. Get assistance in severe
weather or other crisis situations
and find evacuation routes.
OnStar Services
Emergency
Emergency Services require an
active, OnStar service plan
(excludes Basic Plan). With
Automatic Crash Response, built-in
sensors can automatically alert a
specially trained OnStar Advisor
who is immediately connected in to
the vehicle to help.
Press
>for a priority connection to
an OnStar Advisor who can contact
emergency service providers, direct
them to your exact location, and
relay important information.
With OnStar Crisis Assist, specially
trained Advisors are available
24 hours a day, 7 days a week, to
provide a central point of contact,
assistance, and information during a
crisis.
With Roadside Assistance, Advisors
can locate a nearby service provider
to help with a flat tire, a battery
jump, or an empty gas tank.

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-11349385) - 2018 - crc - 11/3/17
434 Index
Fluid (cont'd)Four-Wheel Drive
Transfer Case . . . . . . . . . . . . . . . 234
Power Steering . . . . . . . . . . . . . . . .311
Washer . . . . . . . . . . . . . . . . . . . . . . . .311
Fog Lamps . . . . . . . . . . . . . . . . . . . . . 186 Bulb Replacement . . . . . . . . . . . . 322
Folding Mirrors . . . . . . . . . . . . . . . . . . 57
Forward Automatic Braking . . . . . 261
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . 258
Four-Wheel Drive . . . . . . . . . . 234, 314
Four-Wheel-Drive Light . . . . . . . . . 156
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 414
Front Axle . . . . . . . . . . . . . . . . . . . . . . 315
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Front Seats Adjustment . . . . . . . . . . . . . . . . . . . . . 66
Heated and Ventilated . . . . . . . . . . 72
Front Turn Signal Lamps . . . . . . . 322
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266 Additives . . . . . . . . . . . . . . . . . . . . . 268
Economy Driving . . . . . . . . . . . . . . . 29
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 270
Filling the Tank . . . . . . . . . . . . . . . 269 Fuel (cont'd)
Foreign Countries . . . . . . . . . . . . 267
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 147
Low Fuel Warning Light . . . . . . . 159
Management, Active . . . . . . . . . . 226
Requirements, California . . . . . 267
Full-Size Spare Tire . . . . . . . . . . . . 367
Fuses Engine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 325
Fuses and Circuit Breakers . . . 325
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . 330, 333
Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 335
G
Garage Door Opener . . . . . . . . . . . 178Programming . . . . . . . . . . . . . . . . . 178
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 319
Gauges Engine CoolantTemperature . . . . . . . . . . . . . . . . 149
Engine Oil Pressure . . . . . . . . . . 148
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Odometer . . . . . . . . . . . . . . . . . . . . . 147
Speedometer . . . . . . . . . . . . . . . . . 147
Tachometer . . . . . . . . . . . . . . . . . . . 147 Gauges (cont'd)
Trip Odometer . . . . . . . . . . . . . . . . 147
Voltmeter . . . . . . . . . . . . . . . . . . . . . 150
Warning Lights and
Indicators . . . . . . . . . . . . . . . . . . . 142
General Information Service and Maintenance . . . . . 387
Towing . . . . . . . . . . . . . . . . . . . . . . . . 271
Vehicle Care . . . . . . . . . . . . . . . . . . 290
Glass Replacement . . . . . . . . . . . . . 319
Glove Box . . . . . . . . . . . . . . . . . . . . . . 127
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 408
H
Halogen Bulbs . . . . . . . . . . . . . . . . . . 321
Hazard Warning Flashers . . . . . . . 185
Head Restraints . . . . . . . . . . . . . . . . . 65
Head-up Display . . . . . . . . . . . . . . . . 165
Headlamps . . . . . . . . . . . . . . . . . . . . . 321Aiming . . . . . . . . . . . . . . . . . . . . . . . . 320
Automatic . . . . . . . . . . . . . . . . . . . . . 184
Bulb Replacement . . . . . . . . . . . . 321
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . 184
Flash-to-Pass . . . . . . . . . . . . . . . . . 183
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . 321
