CHEVROLET TRACKER 1999 2.G Owners Manual

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
2-63
CAUTION:
Your regular brake system may not be working
properly if the anti
-lock brake system warning
light is on. Driving with the anti
-lock brake
system warning light on can lead to an accident.
After you've pulled off the road and stopped
carefully, have the vehicle towed for service.
If the anti-lock brake system warning light stays on
longer than normal after you've started your engine, turn
the ignition off. Or, if the light comes on and stays on
when you're driving, stop as soon as possible and turn
the ignition off. Then start the engine again to reset the
system. If the light still stays on, or comes on again
while you're driving, your vehicle needs service. If the
light is on and the regular brake system warning light
isn't on, you still have brakes, but you don't have
anti
-lock brakes.
The anti
-lock brake system warning light should come
on briefly when you turn the ignition key to ON. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.
Engine Coolant Temperature Gage
X±02±0271±X
This gage shows the engine
coolant temperature. If the
gage pointer moves to the
H (red) side, your engine is
too hot.
It means that your engine coolant has overheated and
you should stop your vehicle and turn off the engine as
soon as possible.
The ªProblems on the Roadº section of this manual
shows what to do. See ªEngine Overheatingº in
the Index.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
2-64 Malfunction Indicator Lamp (Service
Engine Soon Light)
X±02±0046±T
Your vehicle is equipped
with a computer which
monitors operation of the
fuel, ignition and emission
control systems.
This system is called OBD II (On
-Board
Diagnostics
-Second Generation) and is intended to
assure that emissions are at acceptable levels for the life
of the vehicle, helping to produce a cleaner
environment. The SERVICE ENGINE SOON light
comes on to indicate that there is a problem and service
is required. Malfunctions often will be indicated by the
system before any problem is apparent. This may
prevent more serious damage to your vehicle. This
system is also designed to assist your service technician
in correctly diagnosing any malfunction.
NOTICE:
If you keep driving your vehicle with this light
on, after a while, your emission controls may not
work as well, your fuel economy may not be as
good and your engine may not run as smoothly.
This could lead to costly repairs that may not be
covered by your warranty.
NOTICE:
Modifications made to the engine, transmission,
exhaust or fuel system of your vehicle or the
replacement of the original tires with other than
those of the same Tire Performance Criteria
(TPC) can affect your vehicle's emission controls
and may cause the SERVICE ENGINE SOON
light to come on. Modifications to these systems
could lead to costly repairs not covered by your
warranty. This may also result in a failure to pass
a required Emission Inspection/Maintenance test.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
2-65
This light should come on, as a check to show you it is
working, when the ignition is on and the engine is not
running. If the light doesn't come on, have it repaired.
This light will also come on during a malfunction in one
of two ways:

Light Flashing
-- A misfire condition has been
detected. A misfire increases vehicle emissions and
may damage the emission control system on your
vehicle. Dealer or qualified service center diagnosis
and service may be required.

Light On Steady
-- An emission control system
malfunction has been detected on your vehicle.
Dealer or qualified service center diagnosis and
service may be required.
If the Light Is Flashing
The following may prevent more serious damage to
your vehicle:

Reducing vehicle speed.

Avoiding hard accelerations.

Avoiding steep uphill grades.

If you are towing a trailer, reduce the amount of
cargo being hauled as soon as it is possible.If the light stops flashing and remains on steady, see ªIf
the Light Is On Steadyº following.
If the light continues to flash, when it is safe to do so,
stop the vehicle. Find a safe place to park your vehicle.
Turn the key off, wait at least 10 seconds and restart the
engine. If the light remains on steady, see ªIf the Light
Is On Steadyº following. If the light is still flashing,
follow the previous steps, and drive the vehicle to your
dealer or qualified service center for service.
If the Light Is On Steady
You may be able to correct the emission system
malfunction by considering the following:
Did you recently put fuel into your vehicle?
If so, reinstall the fuel cap, making sure to fully install
the cap. See ªFilling Your Tankº in the Index. The
diagnostic system can determine if the fuel cap has been
left off or improperly installed. A loose or missing fuel
cap will allow fuel to evaporate into the atmosphere. A
few driving trips with the cap properly installed should
turn the light off.
Did you just drive through a deep puddle of water?
If so, your electrical system may be wet. The condition
will usually be corrected when the electrical system
dries out. A few driving trips should turn the light off.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
2-66
Are you low on fuel?
As your engine starts to run out of fuel, your engine may
not run as efficiently as designed since small amounts of
air are sucked into the fuel line causing a misfire. The
system can detect this. Adding fuel should correct this
condition. Make sure to install the fuel cap properly. See
ªFilling Your Tankº in the Index. It will take a few
driving trips to turn the light off.
Have you recently changed brands of fuel?
If so, be sure to fuel your vehicle with quality fuel (see
ªFuelº in the Index). Poor fuel quality will cause your
engine not to run as efficiently as designed. You may notice
this as stalling after start
-up, stalling when you put the
vehicle into gear, misfiring, hesitation on acceleration or
stumbling on acceleration. (These conditions may go away
once the engine is warmed up.) This will be detected by the
system and cause the light to turn on.
If you experience one or more of these conditions,
change the fuel brand you use. It will require at least one
full tank of the proper fuel to turn the light off.
If none of the above steps have made the light turn off,
have your dealer or qualified service center check the
vehicle. Your dealer has the proper test equipment and
diagnostic tools to fix any mechanical or electrical
problems that may have developed.
Oil Pressure Light
X±02±0034±T
If you have a problem with
your oil, this light may stay
on after you start your
engine, or come on when
you are driving.
This indicates that there is not enough pressure to keep
your engine properly lubricated and cool. The engine
could be low on oil, or have some other oil related
problem. Have it fixed right away.
The oil light could also come on in three
other situations.

When the ignition is on but the engine is not running,
the light will come on as a test to show you it is
working, but the light will go out when you turn the
engine to START. If it doesn't come on with the
ignition on, you may have a problem with the fuse or
bulb. Have it fixed right away.

Sometimes when the engine is idling at a stop, the
light may blink on and off. This is normal.

If you make a hard stop, the light may come on for a
moment. This is normal.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
2-67
CAUTION:
Don't keep driving if the oil pressure is low. If
you do, your engine can become so hot that it
catches fire. You or others could be burned.
Check your oil as soon as possible and have your
vehicle serviced.
NOTICE:
Damage to your engine from neglected oil
problems can be costly and is not covered by
your warranty.
Four Wheel Drive Light
X±02±0223±X
This light comes on when
the ignition switch is on and
the transfer case lever is in
one of the four wheel
drive positions.
See ªFour Wheel Driveº in the Index.
Power Indicator Light (If Equipped)
X±02±3507±T
This light comes on when the
power mode selector switch
is turned to P (power) with
the ignition switch in the
ON position.
This light comes on as a check for approximately
5 seconds when the ignition key is turned to ON
or START.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
2-68 Overdrive Off Light (If Equipped)
X±02±3506±T
This light comes on when
the automatic four
-speed
transmission has been
converted to the three
-speed
mode and the overdrive is
turned off.
This light also comes on as a check for approximately
5 seconds when the ignition key is turned to ON
or START.
Fuel Gage
X±02±0272±X
Your fuel gage shows about
how much fuel is in your
tank. When the gage first
indicates E (empty), you
still have about one or two
gallons (4 to 8 L) of fuel left
in your tank, but you need
to get more right away.Here are four concerns some owners have had about the
fuel gage. All these situations are normal and do not
indicate that anything is wrong with the fuel gage.

At the gas station, the fuel pump shuts off before the
gage reads F (full).

It takes more (or less) fuel to fill up than the gage
reads. For example, the gage reads half full, but it
took more (or less) than half of the tank's capacity to
fill it.

The gage moves a little when you turn, stop or
speed up.

When you turn the engine off, the gage doesn't go
back to E (empty).

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
2-69
-NOTES

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
2-70
-NOTES

3-
Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Climate Control System
3
-3 Air Conditioner Controls (Option)
3
-4 Heating
3
-4 Defogging and Defrosting
3
-4 Rear Window Defogger (If Equipped)
3
-5 Ventilation System
3
-6 Audio Systems
3
-6 Setting the Clock
3
-6AM-FM Stereo (If Equipped)3
-8AM-FM Stereo with Cassette Tape Player and
Automatic Tone Control (If Equipped)
3
-11 AM-FM Stereo with Compact Disc Player and
Automatic Tone Control (If Equipped)
3
-14 Understanding Radio Reception
3
-14 Tips About Your Audio System
3
-15 Care of Your Cassette Tape Player
3
-16 Care of Your Compact Discs
3
-16 Care of Your Compact Disc Player
3
-16 Antenna

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
3-2
Comfort Controls
With this system, you can control the heating and
ventilation in your vehicle. If you have the air
conditioning option, you can also control cooling.
Your vehicle also has the flow
-through ventilation
system described later in this section.
Climate Control System
JE±13±0001±X
Airflow Lever
VENT: This position directs the airflow through
the instrument panel vents.
BI-LEVEL: This position directs air through the
instrument panel vents and toward the floor.
FLOOR: This position directs air toward the floor.
DEFOG: This position directs air toward the floor,
the windshield and side windows. The air conditioning
compressor will run automatically in this setting.
DEFROST: This position directs air to the
windshield and side windows. The air conditioning
compressor will run automatically in this setting.
Fan Control Lever
Slide the lever away from OFF to turn the system on.
Move the lever toward the fan symbol to increase the
fan's speed.
Temperature Control Lever
Slide the lever to change the temperature of the air
flowing from the system. Move it to the right for
warmer air and to the left for cooler air. Without
optional air conditioning, the air temperature cannot be
less than the outside air temperature.
Air Intake Lever
RECIRCULATE: Choose this position to
recirculate the inside air through the comfort control system.
OUTSIDE AIR: Choose this position to circulate
outside air through the comfort control system.
