CHEVROLET TRACKER 1999 2.G Owners Manual

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
3-3 Air Conditioner Controls (Option)
JE±13±9999±X
The air conditioning
system uses the same
controls as described
previously. The
function of each lever
is explained under
ªClimate Control
Systemº in this part.
The incoming
air is cooled and
dehumidified instead
of being heated.
Push the A/C button to change your comfort control
system from heating to air conditioning. A light will
come on when the air conditioning is on. The A/C
button can also control the humidity in your vehicle.The air conditioner works best if you keep your
windows closed. On very hot days, open the windows
just long enough for the hot air to escape.
For normal cooling, push the A/C button and move the
air intake lever to OUTSIDE AIR. For faster cooling,
move the lever to RECIRCULATE. Then move the
airflow lever to VENT, the temperature control lever
toward the left and the fan control lever toward the
fan symbol.
On days when it is raining or the humidity is high,
follow these dehumidifying steps to help clean windows
that are cloudy with moisture. Move the air intake lever
to OUTSIDE AIR. Move the airflow lever to DEFROST
and the fan control lever toward the fan symbol. Adjust
the temperature control lever to a comfortable setting.
The air conditioning compressor will run automatically
when the air flow lever is in DEFOG or DEFROST.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
3-4 Heating
For the quickest results, move the air intake lever to
RECIRCULATE. Move the airflow lever to FLOOR, the
temperature control lever toward the right for warmer
air and the fan control lever toward the fan symbol. You
should switch to OUTSIDE AIR once in a while to
avoid stale air and cloudy windows.
Defogging and Defrosting
Slide the air intake lever to OUTSIDE AIR and the
airflow lever to DEFROST to direct air to the
windshield vents. Then slide the temperature control
lever toward the right and the fan lever toward the fan
symbol. When the windshield is clear, turn down the
fan speed.
Rear Window Defogger (If Equipped)
JE±13±0002±X
The rear window defogger
uses a warming grid to
remove fog from the
rear window.
Press the switch to turn on the defogger. An indicator
light on the switch will come on to remind you that the
defogger is on. The rear window defogger will turn
itself off after about 15 minutes. You can also turn it off
by pressing the switch again.
Do not attach anything like a temporary vehicle license
or a decal across the defogger grid on the rear window.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
3-5 Ventilation System
For mild outside temperatures, when little heating or
cooling is needed, you can still direct outside air through
your vehicle.
Move the air intake lever to OUTSIDE AIR and the
airflow lever to BI
-LEVEL. Adjust the temperature
control lever to a comfortable setting and move the fan
control lever toward the fan symbol.
Your vehicle's flow
-through ventilation system supplies
outside air into the vehicle when it is moving. Outside
air will also enter the vehicle when the fan is running
and the air intake lever is at OUTSIDE AIR.
JE±13±0003±X
Your vehicle has air
outlets that allow you
to adjust the direction
and amount of airflow
inside the vehicle.You can direct the airflow side
-to-side by rotating the
thumbwheel located in the center of the vent. The vent
can be tilted up and down also. To control the amount of
airflow though the outlets, rotate the thumbwheel below
the vent.
Ventilation Tips
Keep the hood and front air inlet free of ice, snow or any
other obstruction (such as leaves). The heater and
defroster will work far better, reducing the chance of
fogging the inside of your windows.
When you enter a vehicle in cold weather, move the fan
control lever toward the fan symbol for a few moments
before driving off. This helps clear the intake ducts of
snow and moisture, and reduces the chance of fogging
the inside of your windows.
Keep the air path under the front seats clear of objects.
This helps air to circulate throughout your vehicle.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
3-6
NOTICE:
Don't use a razor blade or something else sharp
on the inside of the rear window. If you do, you
could cut or damage the warming grid, and the
repairs wouldn't be covered by your warranty.
Audio Systems
Your Delco Electronics audio system has been designed
to operate easily and give years of listening pleasure.
You will get the most enjoyment out of it if you acquaint
yourself with it first. Find out what your Delco
Electronics system can do and how to operate all its
controls, to be sure you're getting the most out of the
advanced engineering that went into it.
Setting the Clock
Press and hold RECALL (TIME SET) to set the correct
hour. At the same time, press and hold the TUNE left
arrow (H) until the correct hour appears.
Press and hold RECALL (TIME SET) to set the correct
minute. At the same time, press and hold the TUNE
right arrow (M) until the correct minute appears.
AM-FM Stereo (If Equipped)
DE±13±0110±W
Playing the Radio
PWR
-VOLUME: This knob turns the system on and
off and controls the volume. To increase volume and
turn the radio on, turn the knob clockwise. Turn it
counterclockwise to decrease volume.
RECALL: Display the time with the ignition off by
pressing this button. When the radio is playing, press
this button to recall the station frequency.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
3-7
Finding a Station
AM´FM: Press this button to switch between AM and
FM. The display shows your selection.
TUNE: Press the right or left arrows to go to a higher or
lower station. Press and hold to continue tuning and
release when you find your station. The display will
show the frequency of each station tuned.
SEEK: Press the right or left arrow to go to the next
higher or lower station and stay there.
PUSHBUTTONS: The six numbered pushbuttons let
you return to your previously played stations. You can
set up to 12 stations (six AM and six FM). Just:
1. Turn the radio on.
2. Press AM´FM to select the band.
3. Tune in the desired station.
4. Press one of the six pushbuttons for at least two
seconds. The sound will mute and then return when
the station is stored. Whenever you press that
numbered button, the station you set will return.
5. Repeat the steps for each pushbutton.Setting the Tone
BASS: Press this knob lightly so it extends. Turn the
knob clockwise to increase bass and counterclockwise to
decrease bass.
TREB: Press this knob lightly so it extends. Turn the
knob clockwise to increase treble and counterclockwise
to decrease treble. If a station is weak or noisy, you may
want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.
Adjusting the Speakers
BAL: Press this knob lightly so it extends. Then pull
the knob all the way out. Turn the knob clockwise for
the right speakers and counterclockwise for the left
speakers. The middle position balances the sound
between the speakers.
FADE: Press this knob lightly so it extends. Then pull
the knob all the way out. Turn the knob clockwise to
adjust the sound to the rear speakers and
counterclockwise for the front speakers. The middle
position balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
3-8 AM-FM Stereo with Cassette Tape Player
and Automatic Tone Control (If Equipped)
DE±13±0115±W
Playing the Radio
PWR
-VOLUME: This knob turns the system on and
off and controls the volume. To increase volume and
turn the radio on, turn the knob clockwise. Turn it
counterclockwise to decrease volume.
RECALL: Display the time with the ignition off by
pressing this button. When the radio is playing, press
this button to recall the station frequency.Finding a Station
AM´FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Press the right or left arrows to go to a higher or
lower station. Press and hold to continue tuning and
release when you find your station. The display will
show the frequency of each station tuned.
SEEK: Press the right or left arrow to go to the next
higher or lower station and stay there.
PUSHBUTTONS: The six numbered pushbuttons let
you return to your previously played stations. You can
set up to 18 stations (six AM, six FM1 and six FM2).
Just:
1. Turn the radio on.
2. Press AM´FM to select the band.
3. Tune in the desired station.
4. Press one of the six pushbuttons for at least two
seconds. The sound will mute and then return when
the station is stored. Whenever you press that
numbered button, the station you set will return.
5. Repeat the steps for each pushbutton.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
3-9
Setting the Tone
BASS: Press this knob lightly so it extends. Turn the
knob clockwise to increase bass and counterclockwise to
decrease bass.
TREB: Press this knob lightly so it extends. Turn the
knob clockwise to increase treble and counterclockwise
to decrease treble. If a station is weak or noisy, you may
want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.
TONE: Press this button to choose preset bass and
treble equalization settings designed for ROCK, NEWS,
POP, JAZZ and CLASSIC. ROCK will appear when
you first press TONE. Each time you press it, another
setting will appear on the display. If you press it one
more time, after CLASSIC appears on the display, tone
control will be back to the BASS and TREB knobs.
Adjusting the Speakers
BAL: Press this knob lightly so it extends. Then pull the
knob all the way out. Turn the knob clockwise for the
right speakers and counterclockwise for the left
speakers. The middle position balances the sound
between the speakers.FADE: Press this knob lightly so it extends. Then pull
the knob all the way out. Turn the knob clockwise to
adjust the sound to the rear speakers and
counterclockwise for the front speakers. The middle
position balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.
Playing a Cassette Tape
With the ignition and radio on, insert a cassette tape.
The tape will begin playing as soon as it is inserted.
Press EJECT or RECALL to load a tape with the
ignition off. Then insert the cassette tape. A tape symbol
is shown in the center of the graphic display whenever a
tape is inserted. When a tape is active, the tape symbol
will be accompanied by a direction arrow.
Your tape player is built to work best with tapes that are
up to 30 to 45 minutes long on each side. Tapes longer
than that are so thin they may not work well in
this player.
The longer side with the tape visible should face to the
right. If you hear nothing or hear just a garbled sound, it
may not be in squarely. Press EJECT to remove the tape
and start over.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
3-10
While the tape is playing, use the VOLUME, FADE,
BAL, TREB, BASS and TONE controls just as you do
for the radio. The display will show an arrow to show
which side of the tape is playing. When the down
indicator arrow is lit, selections listed on the bottom side
of the cassette are playing. When the up arrow is lit,
selections listed on the top side of the cassette
are playing.
REV (TUNE): Press the left arrows to reverse the tape
rapidly. Press REV (TUNE) or TAPE to return to
playing speed.
FWD (TUNE): Press the right arrows to advance
rapidly to another part of the tape. Press FWD (TUNE)
or TAPE to return to playing speed.
PREV (SEEK): Press the left arrow to go to the start
of the current selection if more than eight seconds have
played. If you hold the button or press it more than once,
the player will continue moving back through the tape.
Press the left arrow or TAPE to return to playing speed.
NEXT (SEEK): Press the right arrow to go to the start
of the next selection if more than eight seconds have
played. If you hold the button or press it more than once,
the player will continue moving forward through the
tape. Press the right arrow or TAPE to return to
playing speed.
(2): Press this button to reduce background noise
from tapes encoded with Dolby NR.
Dolby Noise Reduction is manufactured under a license
from Dolby Laboratories Licensing Corporation. Dolby
and the double
-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
MTL: Your bias is set automatically. MTL will appear
on your display when a metal or chrome tape is inserted.
AM´FM: Press this button to play the radio when a tape
is playing.
TAPE: With a tape loaded in the player and the radio playing,
press this button once to play the tape. To switch from the
tape to the radio when the tape is playing, press the AM´FM
button. Press this button to switch from one side of the tape to
the other. Your cassette tape player can play continuously
because the player has an auto
-reverse feature.
EJECT: Press this button to remove the tape. The radio
will play.
CLEAN: If this message appears on the display, the
cassette tape player needs to be cleaned. It will still play
tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index. After you clean
the player, press and hold EJECT for five seconds to
reset the CLEAN indicator. The radio will display
--- to
show the indicator was reset.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
3-11 AM-FM Stereo with Compact Disc Player
and Automatic Tone Control (If Equipped)
DE±13±0120±W
Playing the Radio
PWR
-VOLUME: This knob turns the system on and
off and controls the volume. To increase volume and
turn the radio on, turn the knob clockwise. Turn it
counterclockwise to decrease volume.
RECALL: Display the time with the ignition off by
pressing this button. When the radio is playing, press
this button to recall the station frequency.Finding a Station
AM´FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Press the right or left arrows to go to a higher or
lower station. Press and hold to continue tuning and
release when you find your station. The display will
show the frequency of each station tuned.
SEEK: Press the right or left arrow to go to the next
higher or lower station and stay there.
PUSHBUTTONS: The six numbered pushbuttons let
you return to your previously played stations. You can
set up to 18 stations (six AM, six FM1 and six FM2).
Just:
1. Turn the radio on.
2. Press AM´FM to select the band.
3. Tune in the desired station.
4. Press one of the six pushbuttons for at least two
seconds. The sound will mute and then return when
the station is stored. Whenever you press that
numbered button, the station you set will return.
5. Repeat the steps for each pushbutton.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
3-12
Setting the Tone
BASS: Press this knob lightly so it extends. Turn the
knob clockwise to increase bass and counterclockwise to
decrease bass.
TREB: Press this knob lightly so it extends. Turn the
knob clockwise to increase treble and counterclockwise
to decrease treble. If a station is weak or noisy, you may
want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.
TONE: Press this button to choose preset bass and
treble equalization settings designed for ROCK, NEWS,
POP, JAZZ and CLASSIC. ROCK will appear when
you first press TONE. Each time you press it, another
setting will appear on the display. If you press it one
more time, after CLASSIC appears on the display, tone
control will be back to the BASS and TREB knobs.
Adjusting the Speakers
BAL: Press this knob lightly so it extends. Then pull
the knob all the way out. Turn the knob clockwise for
the right speakers and counterclockwise for the left
speakers. The middle position balances the sound
between the speakers.FADE: Press this knob lightly so it extends. Then pull
the knob all the way out. Turn the knob clockwise to
adjust the sound to the rear speakers and
counterclockwise for the front speakers. The middle
position balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.
Playing a Compact Disc
With the radio on, insert a disc into the CD slot, label
side up. The player will pull it in. The disc should begin
playing. A CD symbol is shown in the center of the
graphic display whenever a disc is inserted.
Don't use the smaller discs (three
-inch singles). They
won't eject. Use full
-size compact discs.
If you're driving on a very rough road or if it's very hot,
the disc may not play and Err (error) may appear on the
display. Press RECALL to take Err off the display.
When things get back to normal, the disc should play.
If the disc comes out, it could be that:

The disc is upside down. The player will not pull the
disc in.

It is dirty, scratched or wet.

It is very humid. (If so, wait about an hour and
try again.)
