CHEVROLET TRACKER 2001 2.G Owners Manual

6-69
Capacities and Specifications
The following approximate capacities are given in
English and metric conversions.
Air ConditioningSee the refrigerant . . . . . . . . . . . . .
information label under the hood.
Cooling System
1.6L Engine 5.8 quarts (5.5 L). . . . . . . . . . . . . . . . .
2.0L Engine 6.9 quarts (6.5 L). . . . . . . . . . . . . . . . .
2.5L Engine 8.5 quarts (8.0 L). . . . . . . . . . . . . . . . .
Crankcase with Filter
1.6L Engine 4.4 quarts (4.2 L)**. . . . . . . . . . . . . . .
2.0L Engine 5.5 quarts (5.2 L)**. . . . . . . . . . . . . . .
2.5L Engine 5.8 quarts (5.5 L)**. . . . . . . . . . . . . . .
Fuel Tank
Tw o
-Door Convertible 14.8 U.S. gallons (56 L). . .
Four
-Door Hardtop 17.4 U.S. gallons (66 L). . . . . . Automatic Transmission
Drain and Refill 2.6 quarts (2.5 L)*. . . . . . . . . . . . .
Manual Transmission
Four
-Wheel Drive 1.6 quarts (1.5 L)*. . . . . . . . . . .
Tw o
-Wheel Drive 2.0 quarts (1.9 L)*. . . . . . . . . . .
Differential
Front 1.1 quarts (1.0 L)*. . . . . . . . . . . . . . . . . . . . .
Rear 2.3 quarts (2.2 L)*. . . . . . . . . . . . . . . . . . . . . .
Transfer Case1.8 quarts (1.7 L) . . . . . . . . . . . . . . . .
*Recheck fluid level after filling. See ªAutomatic
Transmission Fluidº or ªManual Transmission Fluidº in
the Index.
**When changing the oil filter, additional oil may be
needed. Recheck the oil level after filling. See ªEngine
Oilº in the Index.

6-70 1.6L Engine Specifications
VIN Engine Code 6. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type L4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 97. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-3-4-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 190
F (88
C) . . . . . . . . . . .
2.0L Engine Specifications
VIN Engine Code C. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type L4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 127. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-3-4-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 179
F (82
C) . . . . . . . . . . .
2.5L Engine Specifications
VIN Engine Code 4. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 155. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 179
F (82
C) . . . . . . . . . . .
Wheel and Tires
Wheel Nut Torque 69 lb-ft (95 N´m) . . . . . . . . . . . . .
Tire Pressure See the Tire
-Loading . . . . . . . . . . . . . .
Information label. See ªLoading
Your Vehicleº in the Index.

6-71
Normal Maintenance
Replacement Parts
Engine Air Cleaner/Filter GM Part No. 91174457. . . .
or equivalent
Engine Oil Filter
1.6L Engine GM Part No. 25011520. . . . . . . . . . . . .
or equivalent (PF±53)
2.0L Engine GM Part No. 91173772. . . . . . . . . . . . .
or equivalent
2.5L Engine GM Part No. 91176162. . . . . . . . . . . . .
or equivalent
Passenger Compartment
Air Filter GM Part No. 91175057. . . . . . . . . . . . . . .
or equivalentPCV Valve
1.6L Engine GM Part No. 96068664. . . . . . . . . . . . .
or equivalent
2.0L Engine GM Part No. 91174516. . . . . . . . . . . . .
or equivalent
2.5L Engine GM Part No. 91176183. . . . . . . . . . . . .
or equivalent
Spark Plugs
1.6L Engine GM Part No. 91173854. . . . . . . . . . . . .
DENSO SK20PR
-A11 or NGK IFRGE11
Gap: 0.043 inch (1.1 mm)
2.0L Engine GM Part No. 91175704. . . . . . . . . . . . .
DENSO: SK16PR11, PK16PR11 or
NGK: IFR5J11, PFR5G
-11
Gap: 0.043 inch (1.1 mm)
2.5L Engine GM Part No. 91173854. . . . . . . . . . . . .
DENSO: SK16PR11, PK16PR11 or
NGK: IFR5J11, PFR5G
-11
Gap: 0.043 inch (1.1 mm)

6-72 Vehicle Dimensions
Length
Tw o
-Door Convertible
Tw o
-Wheel Drive
Base Model 151.6 inches (385.1 cm). . . . . . . . . . .
Four
-Wheel
Drive Models 151.8 inches (385.6 cm). . . . . . . . . .
Four
-Door Hardtop
Tw o
-Wheel Drive
Base Model 162.6 inches (413.0 cm). . . . . . . . . . .
Four
-Wheel Drive
Base Model 162.8 inches (413.5 cm). . . . . . . . . . .
ZR2 Models 163.4 inches (415.0 cm). . . . . . . . . . . .
LT Models 163.0 inches (414.0 cm). . . . . . . . . . . . .
Width
Base Model 67.3 inches (171.0 cm). . . . . . . . . . . . . .
ZR2 Model 69.3 inches (176.0 cm). . . . . . . . . . . . . . .
LT Model 71.3 inches (181.1 cm). . . . . . . . . . . . . . . . Height
Tw o
-Door Convertible 66.5 inches (168.9 cm). . . . . .
Four
-Door Hardtop
Tw o
-Wheel Drive
Base Model 65.6 inches (166.6 cm). . . . . . . . . . . .
Four
-Wheel Drive
Base Model 66.3 inches (168.4 cm). . . . . . . . . . . .
ZR2 Model 66.5 inches (169.0 cm). . . . . . . . . . . . .
ZR2 Model with
Luggage Carrier 70.7 inches (178.0 cm). . . . . . . .
Tw o
-Wheel Drive
LT Model 67.2 inches (171.0 cm). . . . . . . . . . . . .
Four
-Wheel Drive
LT Model 70.0 inches (178.0 cm). . . . . . . . . . . . .
Wheelbase
Tw o
-Door Convertible 86.6 inches (220.0 cm). . . .
Four
-Door Hardtop 97.6 inches (248.0 cm). . . . . .
Tread
Front
Base and LT Model 57.5 inches (146.1 cm). . . . . . .
ZR2 Model 58.3 inches (148.1 cm). . . . . . . . . . . . .
Rear
Base and LT Model 57.5 inches (146.1 cm). . . . . . .
ZR2 Model 58.3 inches (148.1 cm). . . . . . . . . . . . .

7-
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-4 Part A: Scheduled Maintenance Services
7
-9 Short Trip/City Scheduled Maintenance
7
-30 Long Trip/Highway Scheduled Maintenance7
-44 Part B: Owner Checks and Services
7
-48 Part C: Periodic Maintenance Inspections
7
-50 Part D: Recommended Fluids and Lubricants
7
-53 Part E: Maintenance Record

7-2
Have you purchased the GM Protection Plan? The Plan
supplements your new vehicle warranties. See your
Warranty and Owner Assistance booklet or your dealer
for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.
Maintenance Requirements
Maintenance intervals, checks, inspections and
recommended fluids and lubricants as prescribed in this
manual are necessary to keep your vehicle in good
working condition. Any damage caused by failure to
follow recommended maintenance may not be covered
by warranty.

7-3 How This Section is Organized
This maintenance schedule is divided into five parts:
ªPart A: Scheduled Maintenance Servicesº shows
what to have done and how often. Some of these
services can be complex, so unless you are technically
qualified and have the necessary equipment, you should
let your dealer's service department or another qualified
service center do these jobs.
CAUTION:
Performing maintenance work on a vehicle can
be dangerous. In trying to do some jobs, you can
be seriously injured. Do your own maintenance
work only if you have the required know
-how
and the proper tools and equipment for the job.
If you have any doubt, have a qualified
technician do the work.
If you want to get the service information, see ªService
and Owner Publicationsº in the Index.ªPart B: Owner Checks and Servicesº tells you
what should be checked and when. It also explains
what you can easily do to help keep your vehicle in
good condition.
ªPart C: Periodic Maintenance Inspectionsº explains
important inspections that your dealer's service
department or another qualified service center
should perform.
ªPart D: Recommended Fluids and Lubricantsº lists
some recommended products necessary to help keep
your vehicle properly maintained. These products, or
their equivalents, should be used whether you do the
work yourself or have it done.
ªPart E: Maintenance Recordº is a place for
you to record and keep track of the maintenance
performed on your vehicle. Keep your maintenance
receipts. They may be needed to qualify your vehicle
for warranty repairs.

7-4
Part A: Scheduled
Maintenance Services
Using Your Maintenance Schedule
We at General Motors want to help you keep your
vehicle in good working condition. But we don't know
exactly how you'll drive it. You may drive very short
distances only a few times a week. Or you may drive
long distances all the time in very hot, dusty weather.
You may use your vehicle in making deliveries.
Or you may drive it to work, to do errands or in many
other ways.
Because of all the different ways people use their
vehicles, maintenance needs vary. You may need more
frequent checks and replacements. So please read the
following and note how you drive. If you have any
questions on how to keep your vehicle in good
condition, see your dealer.
This part tells you the maintenance services you should
have done and when you should schedule them. If you
go to your dealer for your service needs, you'll know
that GM
-trained and supported service people will
perform the work using genuine GM parts.The proper fluids and lubricants to use are listed in
Part D. Make sure whoever services your vehicle
uses these. All parts should be replaced and all
necessary repairs done before you or anyone else
drives the vehicle.
These schedules are for vehicles that:

carry passengers and cargo within recommended
limits. You will find these limits on your vehicle's
Tire
-Loading Information label. See ªLoading Your
Vehicleº in the Index.

are driven on reasonable road surfaces within legal
driving limits.

are driven off
-road in the recommended manner. See
ªOff
-Road Driving With Your Four-Wheel-Drive
Vehicleº in the Index.

use the recommended fuel. See ªFuelº in the Index.
Selecting the Right Schedule
First you'll need to decide which of the two schedules is
right for your vehicle. Here's how to decide which
schedule to follow:

Scheduled Maintenance
7-5
Short Trip/City Definition
Follow the Short Trip/City Scheduled Maintenance if
any one of these conditions is true for your vehicle:

Most trips are less than 5 to 10 miles (8 to 16 km).
This is particularly important when outside
temperatures are below freezing.

Most trips include extensive idling (such as frequent
driving in stop
-and-go traffic).

You frequently tow a trailer or use a carrier on top of
your vehicle.

If the vehicle is used for delivery service, police, taxi
or other commercial application.
One of the reasons you should follow this schedule if
you operate your vehicle under any of these conditions
is that these conditions cause engine oil to break
down sooner.
Short Trip/City Intervals
Every 3,000 Miles (5 000 km): Engine Oil and Filter
Change (or 3 months, whichever occurs first).
Every 6,000 Miles (10 000 km): Passenger
Compartment Air Filter Inspection. Tire Rotation.
Every 15,000 Miles (25 000 km): Engine Air Cleaner
Filter Inspection, if driving in dusty conditions. Front
Wheel Bearing Repack (2WD only) (or at each brake
relining, whichever occurs first). Automatic
Transmission Service (severe conditions only).
Manual Transmission Fluid Change. Transfer Case
Fluid Change. Differential Fluid Change. Valve Lash
(Clearance) Adjustment (1.6L Code 6 engine only).
Propeller Shafts and U
-Joints Inspection (or every
15 months, whichever occurs first).
(Continued)

Scheduled Maintenance
7-6
Short Trip/City Intervals
Every 30,000 Miles (50 000 km): Engine Air Cleaner
Filter Replacement. Passenger Compartment Air
Filter Replacement. Ignition Coil Plug Cap Inspection
(or every 30 months, whichever occurs first). Engine
Accessory Drive Belt Inspection (or every 30 months,
whichever occurs first). Cooling System Service (or
every 30 months, whichever occurs first). Fuel Tank,
Cap and Lines Inspection. Fuel Filter Replacement
(or every 30 months, whichever occurs first).
Every 45,000 Miles (75 000 km): Automatic
Transmission Fluid Hose Replacement (or every
45 months, whichever occurs first).
Every 60,000 Miles (100 000 km): Fuel Tank Cap
Gasket Replacement. Emission System Hoses
Inspection. Camshaft Timing Belt Replacement
(1.6L Code 6 engine only). Brake Fluid Service.
Spark Plug Replacement. Spark Plug Wire
Replacement (or every 60 months, whichever
occurs first).
Short Trip/City Intervals
At 90,000 Miles (150 000 km): Camshaft Timing Belt
Inspection (1.6L Code 6 engine only).
Every 100,000 Miles (166 000 km): Automatic
Transmission Service (normal conditions).
Every 120,000 Miles (200 000 km): Evaporative
Emissions Canister and Air Suction Filter
Replacement (or every 120 months, whichever occurs
first). Engine Accessory Drive Belt Replacement
(or every 120 months, whichever occurs first).
These intervals only summarize maintenance services.
Be sure to follow the complete scheduled maintenance
on the following pages.
