2-15
Ignition Positions
With the key in the ignition
switch, you can turn the
switch to four positions.
LOCK (A): This is the only position from which you
can remove the key. This locks your steering wheel,
ignition and automatic transmission.
If you have an automatic transmission, the ignition
switch can't be turned to LOCK unless the shift lever
is in PARK (P).CAUTION:
On manual transmission vehicles, turning the key
to LOCK will lock the steering column and result
in a loss of ability to steer the vehicle. This could
cause a collision. If you need to turn the engine
off while the vehicle is moving, turn the key only
to ACC. Don't push the key in while the vehicle
is moving.
NOTICE:
If your key seems stuck in LOCK and you can't
turn it, be sure you are using the correct key;
if so, is it all the way in? If it is, then turn the
steering wheel left and right while you turn the
key hard. But turn the key only with your hand.
Using a tool to force it could break the key or the
ignition switch. If none of this works, then your
vehicle needs service.

2-16
ACC (ACCESSORY) (B): This is the position in
which you can operate your electrical power accessories.
It also unlocks the steering wheel and ignition. Use this
position if your vehicle must be pushed or towed.
ON (C): This is the position that the switch returns
to after you start your engine and release the switch.
The switch stays in ON when the engine is running.
But even when the engine is not running, you can use
ON to operate your electrical power accessories and to
display some instrument panel cluster warning and
indicator lights.
START (D): This is the position that starts the engine.
When the engine starts, release the key. The ignition
switch will return to ON for normal driving.
When the engine is not running, ACC and ON allow you
to operate your electrical accessories, such as the radio.
A warning tone will sound if you open the driver's door
when the ignition is in ACC or LOCK and the key is in
the ignition.Starting Your Engine
Automatic Transmission
Move your shift lever to PARK (P) or NEUTRAL (N).
Your engine won't start in any other position
-- that's a
safety feature. To restart when you're already moving,
use NEUTRAL (N) only.
NOTICE:
Don't try to shift to PARK (P) if your vehicle
is moving. If you do, you could damage the
transmission. Shift to PARK (P) only when
your vehicle is stopped.
Manual Transmission
The gear selector should be in NEUTRAL and the
parking brake engaged. Hold the clutch pedal to the
floor and start the engine. Your vehicle won't start if
the clutch pedal is not all the way down
-- that's a
safety feature.

2-17 Starting Your Engine
1. With your foot off the accelerator pedal, turn your
ignition key to START. When the engine starts,
let go of the key.
NOTICE:
Holding your key in START for longer than
15 seconds at a time will cause your battery
to be drained much sooner. And the excessive
heat can damage your starter motor. Wait
about 15 seconds between each try to help avoid
draining your battery or damaging your starter.
2. If it doesn't start, push the accelerator pedal
one
-third of the way down. Hold it there, for not
more than 15 seconds at a time, while you turn your
key to START. When the engine starts, let go of the
key and release the pedal. Wait about 15 seconds
between each try.3. If your engine still won't start (or starts but then
stops), it could be flooded with too much gasoline.
Try pushing your accelerator pedal all the way to the
floor and holding it there as you hold the key in
START for about three seconds. If the vehicle starts
briefly but then stops again, do the same thing, but
this time keep the pedal down for five or six seconds.
This clears the extra gasoline from the engine.
NOTICE:
Your engine is designed to work with the
electronics in your vehicle. If you add electrical
parts or accessories, you could change the way
the engine operates. Before adding electrical
equipment, check with your dealer. If you don't,
your engine might not perform properly.

2-18
Engine Coolant Heater (If Equipped)
In very cold weather, 0
F (-18
C) or colder, the engine
coolant heater can help. You'll get easier starting and
better fuel economy during engine warm
-up. Usually,
the coolant heater should be plugged in a minimum of
four hours prior to starting your vehicle.
To Use the Engine Coolant Heater
1. Turn off the engine.
2. Open the hood and unwrap the electrical cord. It is
located at the front of the engine compartment on the
driver's side.3. Plug it into a normal, grounded 110
-volt AC outlet.
CAUTION:
Plugging the cord into an ungrounded outlet
could cause an electrical shock. Also, the wrong
kind of extension cord could overheat and cause
a fire. You could be seriously injured. Plug the
cord into a properly grounded three
-prong
11 0
-volt AC outlet. If the cord won't reach,
use a heavy
-duty three-prong extension cord
rated for at least 15 amps.
4. Before starting the engine, be sure to unplug and store
the cord as it was before to keep it away from moving
engine parts. If you don't, it could be damaged.
How long should you keep the coolant heater plugged
in? The answer depends on the outside temperature, the
kind of oil you have, and some other things. Instead of
trying to list everything here, we ask that you contact
your dealer in the area where you'll be parking your
vehicle. The dealer can give you the best advice for
that particular area.

2-19
Automatic Transmission Operation
There are several different positions for your shift lever.
PARK (P): This position locks your rear wheels. It's the
best position to use when you start your engine because
your vehicle can't move easily.
CAUTION:
It is dangerous to get out of your vehicle if the
shift lever is not fully in PARK (P) with the
parking brake firmly set. Your vehicle can roll.
Don't leave your vehicle when the engine is
running unless you have to. If you have left the
engine running, the vehicle can move suddenly.
You or others could be injured. To be sure your
vehicle won't move, even when you're on fairly
level ground, always set your parking brake and
move the shift lever to PARK (P).
If you have four-wheel drive, your vehicle
will be free to roll
-- even if your shift lever
is in PARK (P)
-- if your transfer case is in
NEUTRAL. So, be sure the transfer case is in a
drive gear, two
-wheel high (2H) or four-wheel
high (4H) or four
-wheel low (4L) -- not in
NEUTRAL. See ªShifting Into PARK (P)º in the
Index. If you're pulling a trailer, see ªTowing a
Trailerº in the Index.

2-20
Ensure the shift lever is fully in PARK (P) before
starting the engine. Your vehicle has an automatic
transmission shift lock control system. You have to
fully apply your regular brakes before you can shift
from PARK (P) when the ignition key is in ON. If you
cannot shift out of PARK (P), ease pressure on the shift
lever
-- push the shift lever all the way into PARK (P)
and release the shift lever button as you maintain brake
application. Then press the shift lever button and move
the shift lever into the gear you wish. See ªShifting Out
of PARK (P)º in the Index.
REVERSE (R): Use this gear to back up.
NOTICE:
Shifting to REVERSE (R) while your vehicle is
moving forward could damage your transmission.
Shift to REVERSE (R) only after your vehicle
is stopped.
To rock your vehicle back and forth to get out of snow,
ice or sand without damaging your transmission, see
ªStuck: In Sand, Mud, Ice or Snowº in the Index.NEUTRAL (N): In this position, your engine
doesn't connect with the wheels. To restart when you're
already moving, use NEUTRAL (N) only. Also, use
NEUTRAL (N) when your vehicle is being towed.
CAUTION:
Shifting out of PARK (P) or NEUTRAL (N) while
your engine is ªracingº (running at high speed)
is dangerous. Unless your foot is firmly on
the brake pedal, your vehicle could move very
rapidly. You could lose control and hit people
or objects. Don't shift out of PARK (P) or
NEUTRAL (N) while your engine is racing.
NOTICE:
Damage to your transmission caused by shifting
out of PARK (P) or NEUTRAL (N) with the
engine racing isn't covered by your warranty.

2-21
DRIVE (D): This position is for normal driving.
If you need more power for passing, and you're:

Going less than about 15 mph (25 km/h),
push your accelerator pedal about halfway down.

Going about 15 mph (25 km/h) or more,
push your accelerator pedal all the way down.
You'll shift down to the next gear and have
more power.
SECOND (2): This position gives you more power but
lower fuel economy. You can use SECOND (2) on hills.
It can help control your speed as you go down steep
mountain roads, but then you would also want to use
your brakes off and on. In this position, if the power
mode selector switch is turned to P, the transmission
will not downshift into LOW (L).
NOTICE:
Don't shift into SECOND (2) unless you are
going slower than 65 mph (105 km/h) with the
transfer case in FOUR
-WHEEL HIGH (4H),
or 35 mph (55 km/h) with the transfer case in
FOUR
-WHEEL LOW (4L). If you move the
shift lever to a lower gear while driving faster
than the maximum allowable speed for the lower
gear, the transmission will not downshift until
your speed drops below the maximum speed for
the lower gear.
LOW (L): This position gives you even more power but
lower fuel economy than SECOND (2). You can use it on
very steep hills, or in deep snow or mud. If the selector
lever is put in LOW (L), the transmission won't shift
into low gear until the vehicle is going slow enough.

2-22
NOTICE:
Don't shift into LOW (L) at speeds above
40 mph (65 km/h) with the transfer case in
FOUR
-WHEEL LOW (4L). If you move the shift
lever to a lower gear while driving faster than
the maximum allowable speed for the lower gear,
the transmission will not downshift until your
speed drops below the maximum speed for the
lower gear.
NOTICE:
If your rear wheels can't turn, don't try to drive.
This might happen if you were stuck in very deep
sand or mud or were up against a solid object.
You could damage your transmission.
Also, if you stop when going uphill, don't hold
your vehicle there with only the accelerator
pedal. This could overheat and damage the
transmission. Use your brakes to hold your
vehicle in position on a hill.

2-23 Overdrive-Off Switch (If Equipped)
The overdrive-off switch is located on the left side of
the shift lever. When operating under normal conditions,
the vehicle will automatically default to overdrive when
initially started until it is disengaged. If overdrive is
turned off and the vehicle is turned off, when the vehicle
is restarted, overdrive will automatically turn back on.
By operating the overdrive off switch, with the ignition
switch in the ON position, the four
-speed automatic
transmission (three
-speed plus overdrive) can be
converted to a three
-speed automatic transmission.
While in the three
-speed mode, the transmission
will not shift into the overdrive position.To convert the transmission to the three
-speed mode,
push in the overdrive
-off switch and release it. The
OD/OFF indicator light on the instrument panel cluster
will come on. The overdrive
-off switch is for normal
driving, however, it also offers more power and lower
fuel economy than driving in the overdrive position.
Here are some times you might choose to drive with
the overdrive off switch engaged:

When driving on hilly, winding roads.

When going down a steep hill.
To return the transmission to the four
-speed mode,
push in the overdrive
-off switch again. The OD/OFF
indicator light will go off. Disengaging the overdrive
-off
switch is for normal driving with the four
-speed
automatic transaxle. If you need more power for
passing, and you are:

Going less than about 35 mph (55 km/h),
push your accelerator pedal about halfway down.

Going about 35 mph (55 km/h), push your
accelerator all the way down.
If the transfer case shift lever is in the 4L position,
the four
-speed automatic transmission will remain
in the three
-speed mode.

2-24 Power Mode Selector Switch
A power mode selector
switch is included
with the four
-speed
automatic transmission.
When you need more power for climbing hills or quicker
acceleration, press the ªPº (power) switch. The POWER
indicator light on the instrument panel cluster will come
on. For normal driving, press the ªNº (normal) switch.
The POWER indicator light will go off.
The power mode delays the automatic transmission shift
points to allow for higher engine speeds in each gear.
The automatic transmission also has the ability to
provide SECOND (2) gear starts for improved
traction on slippery surfaces.The power mode selector switch must be in the P (power)
mode and the transmission gear selector in SECOND (2),
which will remain in SECOND (2) until you shift the
vehicle to DRIVE (D).Manual Transmission Operation
5-Speed
This is your shift pattern.
Here's how to operate
your transmission:
FIRST (1): Press the clutch pedal and shift into
FIRST (1). Then, slowly let up on the clutch pedal
as you press the accelerator pedal.
You can shift into FIRST (1) when you're going less
than 20 mph (32 km/h). If you've come to a complete
stop and it's hard to shift into FIRST (1), put the shift
lever in NEUTRAL and let up on the clutch. Press the
clutch pedal back down. Then shift into FIRST (1).
