The main components of your instrument panel are the following:
A. Side Defroster Outlets. See
Outlet Adjustment on
page 3-22.
B. Air Outlets. See
Outlet Adjustment on page 3-22.
C. Turn Signal/Multifunction Lever. See
Turn
Signal/Multifunction Lever on page 3-6.
D. Instrument Panel Cluster. See
Instrument Panel
Cluster on page 3-27.
E. Windshield Wipers Lever. See ªWindshield Wipersº
under
Turn Signal/Multifunction Lever on page 3-6.
F. Hazard Button. See
Hazard Warning Flashers
on page 3-4.
G. Rear Window Defogger Button (If Equipped). See
ªRear Window Defoggerº under
Climate Control
System on page 3-19.
H. Cruise Control Button (If Equipped). See ªCruise
Controlº under
Turn Signal/Multifunction Lever
on page 3-6.
I. Climate Controls. See
Climate Control System on
page 3-19.
J. Rear Window Washer/Wiper Button (If Equipped).
See ªRear Window Washer/Wiperº under
Turn
Signal/Multifunction Lever on page 3-6.
K. Coinholder (If Equipped). See
Coinholder(s) on
page 2-33.L. Outside Power Mirrors (If Equipped). See
Outside
Power Mirrors on page 2-32.
M. Instrument Panel Brightness Thumbwheel. See
ªInstrument Panel Brightnessº under
Interior Lamps
on page 3-16.
N. Hood Release. See
Hood Release on page 5-10.
O. Instrument Panel Fuse Block. See ªInstrument Panel
Fuse Blockº under
Fuses and Circuit Breakers on
page 5-94.
P. Ignition Switch. See
Ignition Positions on page 2-12.
Q. Cigarette Lighter/Accessory Power Outlet (If
Equipped). See
Accessory Power Outlets on
page 3-18.
R. Power Mode Selector Button (If Equipped). See
ªPower Modeº under
Automatic Transmission
Operation on page 2-16.
S. Shift Lever. See
Shifting Into Park (P) on page 2-25.
T. Ashtray. See
Ashtrays and Cigarette Lighter on
page 3-19.
U. Audio System (If Equipped). See
Audio System(s)
on page 3-39.
V. Vent Shut-off Thumbwheel. See
Outlet Adjustment
on page 3-22.
3-3

Temperature Control:Slide the lever located on the
lower left side to change the temperature. Move it to the
right for warmer air and to the left for cooler air.
Without air conditioning, the air temperature cannot be
less than the outside air temperature.
Air Conditioning (A/C):Press the air conditioning
(A/C) button to turn the air-conditioning system on or off.
When A/C is pressed, an indicator light in the button
will come on to let you know that the air conditioning is
activated.
On hot days, open the windows to let hot inside air
escape; then close them. This helps to reduce the time
it takes for your vehicle to cool down. It also helps
the system to operate more efficiently.
For quick cool down on hot days:
1. Select the vent mode.
2. Select the recirculation mode.
3. Select A/C.
4. Select the coolest temperature.
5. Select the highest fan speed.
The air-conditioning system removes moisture from the
air, so you may sometimes notice a small amount of
water dripping underneath your vehicle while idling
or after turning off the engine. This is normal.Defogging and Defrosting
Fog on the inside of windows is a result of high humidity
(moisture) condensing on the cool window glass. This
can be minimized if the climate control system is
used properly. There are two modes to clear fog or frost
from your windshield. Use the defog mode to clear
the windows of fog or moisture and warm the
passengers. Use the defrost mode to remove fog or
frost from the windshield more quickly.
-(Defog):This mode directs the air between the
windshield, side windows, instrument panel outlets and
the ¯oor outlets. The air-conditioning compressor
will run automatically in this setting without pressing
A/C, unless the outside temperature is at or below
freezing.
1(Defrost):This mode directs the air to the
windshield and the side windows. The air-conditioning
compressor will run automatically in this setting
without pressing A/C, unless the outside temperature is
at or below freezing. Do not drive the vehicle until all
the windows are clear.
3-21

Rear Window Defogger
If your vehicle has this feature, the rear window defogger
uses a warming grid to clear fog from the rear window.
The button is located on
the center of the
instrument panel, near the
vehicle's comfort controls.
The rear window defogger will only work when the
ignition is in ON.
=(Rear Defogger):Press the defogger button to turn
the rear window defogger on or off. An indicator light
in the button will come on to let your know that the rear
window defogger is activated. Be sure to clear as
much snow from the rear window as possible.The rear window defogger will turn off automatically
about 15 minutes after the button is pressed. The
defogger can also be turned off by pressing the button
again or by turning off the engine.
Notice:Using a razor blade or sharp object to clear
the inside rear window may damage the rear
window defogger. Repairs would not be covered by
your warranty. Do not clear the inside of the rear
window with sharp objects.
Outlet Adjustment
Use the air outlets located
in the center and outboard
sides of the instrument
panel, to change the
direction and amount of
the air ¯owing through
the vents.
3-22

Fuses Usage
P/W Power Windows
DOM Dome Light, Radio Memory
TAILLicense Plate Light,
Clearance/Marker Lights, Instrument
Panel Illumination, Warning Tone
HAZ Hazard Lights, Turn Signal
IGOxygen Sensor Heater, Cruise
Control, Ignition Coil, Meter, G
Sensor
CIGCigar/Cigarette Lighter, Radio,
Power Mirror
D/L Door Locks
STPBrake Light, Horn, Center
High-Mounted Stop Lamp,
Cruise Control
FOG Not Used
DEFRear Window Defogger, DRL,
Heater, Air Conditioning
S/H Not Used
TRNTurn Signal, Back-Up Light,
Hazard Lights
WIPWindshield Wiper/Washer, Rear
Window Wiper/Washer
Fuses for the air bags and the heater/air conditioning
system are located next to the instrument panel
fuse block.
5-95

D
Daytime Running Lamps..................................3-14
Defensive Driving............................................. 4-3
Defogging and Defrosting.................................3-21
Dinghy Towing................................................4-48
Doing Your Own Service Work........................... 5-3
Dolly Towing..................................................4-50
Dome Lamp...................................................3-16
Door
Locks.......................................................... 2-6
Power Door Locks......................................... 2-7
Rear Door Security Locks............................... 2-8
Driver
Position, Safety Belt.....................................1-15
Driver Behavior................................................ 4-2
Driving
At Night.....................................................4-30
City...........................................................4-34
Defensive..................................................... 4-3
Drunken....................................................... 4-4
Environment................................................. 4-2
Freeway.....................................................4-35
Hill and Mountain Roads..............................4-38
In Rain and on Wet Roads...........................4-32
Winter........................................................4-40
Driving Across an Incline..................................4-26
Driving Downhill..............................................4-24
Driving in Mud, Sand, Snow or Ice....................4-28
Driving in Water..............................................4-29Driving On Grades..........................................4-62
Driving on Off-Road Hills.................................4-20
Driving On Snow or Ice...................................4-41
Driving Through Deep Standing Water...............4-33
Driving Through Flowing Water.........................4-34
Driving Uphill..................................................4-21
Driving with a Trailer.......................................4-61
E
Electrical System
Add-On Equipment......................................5-93
Fuses and Circuit Breakers...........................5-94
Emissions Inspection and Maintenance
Programs...................................................3-35
Engine
Air Cleaner/Filter.........................................5-18
Battery.......................................................5-42
Check and Service Engine Soon Light............3-33
Coolant......................................................5-25
Coolant Heater............................................2-15
Coolant Temperature Gage...........................3-32
Cooling System Inspection............................6-28
Drive Belt Routing......................................5-101
Engine Compartment Overview......................5-12
Exhaust.....................................................2-29
Oil .............................................................5-13
Overheating................................................5-28
Starting......................................................2-14
4

Plan Ahead When Possible................................ 7-7
Playing a CD.................................................3-42
Playing the Radio...........................................3-40
Power
Accessory Outlets........................................3-18
Door Locks.................................................. 2-7
Indicator Light.............................................3-37
Steering Fluid.............................................5-37
Windows....................................................2-11
Power Mode..................................................2-20
Power Steering...............................................4-10
Q
Questions and Answers About Safety Belts.........1-13
R
Radiator Pressure Cap....................................5-28
Radio Messages.............................................3-42
Radios..........................................................3-39
Care of Your CD Player...............................3-45
Care of Your CDs........................................3-45
Radio with CD............................................3-40
Setting the Time..........................................3-39
Understanding Reception..............................3-45
Reading Lamps..............................................3-17Rear Axle......................................................5-48
Front Axle (Four-Wheel-Drive) Service............6-29
Rear Combination Lamps.................................5-54
Rear Door Security Locks.................................. 2-8
Rear Seat Operation......................................... 1-5
Rear Seat Outside Passenger Positions.............1-26
Rear Seat Passengers, Safety Belts..................1-26
Rear Window Defogger....................................3-22
Rear Window Washer/Wiper............................... 3-9
Rearview Mirrors.............................................2-31
Reclining Seatbacks.......................................... 1-3
Recreational Vehicle Towing.............................4-47
Remote Keyless Entry System............................ 2-3
Remote Keyless Entry System Operation............. 2-4
Removing the Flat Tire and Installing the
Spare Tire..................................................5-77
Removing the Spare Tire and Tools...................5-74
Replacement Bulbs.........................................5-55
Replacing Brake System Parts..........................5-42
Replacing Restraint System Parts After
a Crash.....................................................1-60
Reporting Safety Defects
Canadian Government..................................7-10
General Motors...........................................7-10
United States Government............................7-10
Restraint System Check...................................6-25
Checking Your Restraint Systems...................1-59
Replacing Restraint System Parts After
a Crash..................................................1-60
10
