CHEVROLET TRAVERSE 2019 Owner's Manual

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 11/1/18
410 OnStar
be misrepresented as being
the original source. Such
altered versions also must not
be misrepresented as being
Info-ZIP releases–including,
but not limited to, labeling of
the altered versions with the
names“Info-ZIP” (or any
variation thereof, including, but
not limited to, different
capitalizations), “Pocket
UnZip,” “WiZ” or“MacZip”
without the explicit permission
of Info-ZIP. Such altered
versions are further prohibited
from misrepresentative use of
the Zip-Bugs or Info-ZIP e-mail
addresses or of the
Info-ZIP URL(s).
4. Info-ZIP retains the right to use the names “Info-ZIP,” “Zip,”
“UnZip,” “UnZipSFX,” “WiZ,”
“Pocket UnZip,” “Pocket Zip,”
and “MacZip” for its own
source and binary releases.

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 10/31/18
Connected Services 411
Connected
Services
Connected Services
Navigation . . . . . . . . . . . . . . . . . . . . 411
Connections . . . . . . . . . . . . . . . . . . 412
Diagnostics . . . . . . . . . . . . . . . . . . . 414
Connected Services
Navigation
Navigation requires a specific
OnStar or connected service plan.
Press
Qto receive Turn-by-Turn
directions or have them sent to the
vehicle’s navigation screen,
if equipped.
Turn-by-Turn Navigation
1. PressQto connect to an
Advisor.
2. Request directions to be downloaded to the vehicle.
3. Follow the voice-guided commands.
Using Voice Commands
During a Planned Route
Functionality of the Voice Command
button, if equipped, may vary by
vehicle and region. For some
vehicles, press
=to open the OnStar app on the infotainment
display. For other vehicles press
=
as follows.
Cancel Route
1. Press
=. System responds:
“OnStar ready,” then a tone.
2. Say “Cancel route.” System
responds: “Do you want to
cancel directions?”
3. Say “Yes.”System responds:
“OK, request completed, thank
you, goodbye.”
Route Preview
1. Press
=. System responds:
“OnStar ready,” then a tone.
2. Say “Route preview.” System
responds with the next three
maneuvers.
Repeat
1. Press
=. System responds:
“OnStar ready,” then a tone.

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 10/31/18
412 Connected Services
2. Say“Repeat.” System
responds with the last direction
given, then responds with
“OnStar ready,” then a tone.
Get My Destination
1. Press
=. System responds:
“OnStar ready,” then a tone.
2. Say “Get my destination.”
System responds with the
address and distance to the
destination, then responds with
“OnStar ready,” then a tone.
Send Destination to Vehicle
Directions can be sent to the
vehicle’s navigation screen,
if equipped.
Press
Q, then ask the Advisor to
download directions to the vehicle’s
navigation system, if equipped. After
the call ends, the navigation screen
will provide prompts to begin driving
directions. Routes that are sent to
the navigation screen can only be
canceled through the navigation
system. See www.onstar.com (U.S.) or
www.onstar.ca (Canada).
Connections
The following services help with
staying connected.
For coverage maps, see
www.onstar.com (U.S.) or
www.onstar.ca (Canada).
Ensuring Security
.
Change the default passwords
for the Wi-Fi hotspot and
myChevrolet mobile application.
Make these passwords different
from each other and use a
combination of letters, numbers,
and symbols to increase the
security.
. Change the default name of the
SSID (Service Set Identifier).
This is your network’s name that
is visible to other wireless
devices. Choose a unique name
and avoid family names or
vehicle descriptions. Wi-Fi Hotspot (If Equipped)
The vehicle may have a built-in
Wi-Fi hotspot that provides access
to the Internet and web content at
4G LTE speed. Up to seven mobile
devices can be connected. A data
plan is required. Use the in-vehicle
controls only when it is safe to
do so.
1. To retrieve Wi-Fi hotspot information, press
=to open
the OnStar app on the
infotainment display, then
select Wi-Fi Hotspot. On some
vehicles, touch Wi-Fi or Wi-Fi
Settings on the screen.
2. The Wi-Fi settings will display the Wi-Fi hotspot name (SSID),
password, and on some
vehicles, the connection type
(no Internet connection, 3G,
4G, 4G LTE), and signal quality
(poor, good, excellent).
3. To change the SSID or password, press
Qor call
1-888-4ONSTAR to connect
with an Advisor. On some

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 10/31/18
Connected Services 413
vehicles, the SSID and
password can be changed in
the Wi-Fi Hotspot menu.
After initial set-up, your vehicle’s
Wi-Fi hotspot will connect
automatically to your mobile
devices. Manage data usage by
turning Wi-Fi on or off on your
mobile device, using the
myChevrolet mobile app, or by
contacting an OnStar Advisor. On
some vehicles, Wi-Fi can also be
managed from the Wi-Fi
Hotspot menu.
MyChevrolet Mobile App (If
Available)
Download the myChevrolet mobile
app to compatible Apple and
Android smartphones. Chevrolet
users can access the following
services from a smartphone:
. Remotely start/stop the vehicle,
if factory-equipped.
. Lock/unlock doors, if equipped
with automatic locks.
. Activate the horn and lamps. .
Check the vehicle’s fuel level, oil
life, or tire pressure,
if factory-equipped with the Tire
Pressure Monitor System.
. Send destinations to the vehicle.
. Locate the vehicle on a map
(U.S. market only).
. Turn the vehicle's Wi-Fi hotspot
on/off, manage settings, and
monitor data consumption,
if equipped.
. Locate a dealer and schedule
service.
. Request roadside assistance.
. Set a parking reminder with pin
drop, take a photo, make a note,
and set a timer.
. Connect with Chevrolet on social
media.
Features are subject to change. For
myChevrolet mobile app information
and compatibility, see
my.chevrolet.com.
An active OnStar or connected
service plan may be required.
A compatible device, factory-installed remote start, and
power locks are required. Data rates
apply. See www.onstar.com for
details and system limitations.
Remote Services
Contact an OnStar Advisor to
unlock the doors or sound the horn
and flash the lamps.
Marketplace
OnStar Advisors can provide offers
from restaurants and retailers on
your route, help locate hotels,
or book a room. These services
vary by market.
OnStar Hands-Free Calling
Make and receive calls with the
built-in wireless calling service,
which requires available minutes.
Functionality of the Voice Command
button may vary by vehicle and
region. For some vehicles, press
=
to open the OnStar app on the
infotainment display, then select
Hands-Free calling. For other
vehicles press
=as follows.

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 10/31/18
414 Connected Services
Make a Call1. Press
=. System responds:
“OnStar ready.”
2. Say “Call.”System responds:
“Call. Please say the name or
number to call.”
3. Say the entire number without pausing, including a “1”and the
area code. System responds:
“OK, calling.”
Calling 911 Emergency
1. Press=. System responds:
“OnStar ready.”
2. Say “Call.”System responds:
“Call. Please say the name or
number to call.”
3. Say “911”without pausing.
System responds: “911.”
4. Say “Call.”System responds:
“OK, dialing 911.”
Retrieve My Number
1. Press=. System responds:
“OnStar ready.”
2. Say “My number.” System
responds: “Your OnStar
Hands-Free Calling number is,”
then says the number.
End a Call
Press=. System responds: “Call
ended.”
Verify Minutes and Expiration
Press=and say “Minutes” then
“Verify” to check how many minutes
remain and their expiration date.
If equipped, press
=and touch
Account Services to view the
number of remaining minutes,
available Wi-Fi data, and other
account information.
Diagnostics
By monitoring and reporting on the
vehicle's key systems, OnStar
Advanced Diagnostics, if equipped,
provides a way to keep up on
maintenance. Capabilities vary by
model. See www.onstar.com for
details and system limitations.
Features are subject to change. For
updates on feature capabilities, see
my.chevrolet.com. Message and
data rates may apply.

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 10/31/18
Index 415
IndexA
Accessories andModifications . . . . . . . . . . . . . . . . . . 291
Accessory Power . . . . . . . . . . . . . . . 230
Adaptive Cruise Control . . . . . . . . 248
Add-On Electrical Equipment . . . 288
Additional Information OnStar . . . . . . . . . . . . . . . . . . . . . . . 405
Additional Maintenance and Care . . . . . . . . . . . . . . . . . . . . . . 379
Adjustments Lumbar, Front Seats . . . . . . . . . . . . 64
Agreements Trademarks and License . . . . . 200
Air Cleaner/Filter, Engine . . . . . . . 300
Air Conditioning . . . . . . . . . . . 201, 204
Air Filter, Passenger Compartment . . . . . . . . . . . . . . . . . 207
Air Vents . . . . . . . . . . . . . . . . . . . . . . . 206
Airbag System
Check . . . . . . . . . . . . . . . . . . . . . . . . . . 97
How Does an AirbagRestrain? . . . . . . . . . . . . . . . . . . . . . 90
Passenger Sensing System . . . . 92
What Makes an Airbag
Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 90
What Will You See after an Airbag Inflates? . . . . . . . . . . . . . . . 90 Airbag System (cont'd)
When Should an Airbag
Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 89
Where Are the Airbags? . . . . . . . . 87
Airbags Adding Equipment to theVehicle . . . . . . . . . . . . . . . . . . . . . . . . 96
Passenger Status Indicator . . . 141
Readiness Light . . . . . . . . . . . . . . 141
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . 96
System Check . . . . . . . . . . . . . . . . . . 85
Alarm Vehicle Security . . . . . . . . . . . . . . . . 50
Alert Lane Change . . . . . . . . . . . . . . . . . 267
Side Blind Zone (SBZA) . . . . . . 267
All-Season Tires . . . . . . . . . . . . . . . . 327
All-Wheel Drive . . . . . . . . . . . . 237, 310
AM-FM Radio . . . . . . . . . . . . . . . . . . . 181
Antenna . . . . . . . . . . . . . . . . . . . . . . . . 185
Multi-band . . . . . . . . . . . . . . . . . . . . 185
Antilock Brake System (ABS) . . . 237
Warning Light . . . . . . . . . . . . . . . . . 145
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . 362
Interior . . . . . . . . . . . . . . . . . . . . . . . . 366

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 10/31/18
416 Index
Apple CarPlay andAndroid Auto . . . . . . . . . . . . . . . . . . 197
Assistance Program, Roadside . . . . . . . . . . . . . . . . . . . . . . 393
Assistance Systems for Driving . . . . . . . . . . . . . . . . . . . . . . . . 261
Assistance Systems for
Parking and Backing . . . . . . . . . . 258
Audio Theft-Deterrent Feature . . . . . . . 177
Auto Stop
Stop/Start System . . . . . . . . . . . . 227
Automatic Dimming Mirrors . . . . . . . . . . . . . . . . 53
Door Locks . . . . . . . . . . . . . . . . . . . . . 41
Forward Braking . . . . . . . . . . . . . . 263
Headlamp System . . . . . . . . . . . . 170
Transmission . . . . . . . . . . . . . . . . . 233
Transmission Fluid . . . . . . . . . . . 299
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . 235
Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 310
Auxiliary Devices . . . . . . . . . . . . . . . . . . . . . . . 191
Avoiding Untrusted Media Devices . . . . . . . . . . . . . . . . . . . . . . . 185B
BatteryExterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 175
Load Management . . . . . . . . . . . . 174
Power Protection . . . . . . . . . . . . . 175
Battery - North America . . . . 309, 356
Blade Replacement, Wiper . . . . . 311
Bluetooth Overview . . . . . . . . . . . . . . . . 192, 193
Brake Parking, Electric . . . . . . . . . . . . . . 238
System Warning Light . . . . . . . . 144
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 307
Antilock . . . . . . . . . . . . . . . . . . . . . . . 237
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 240
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 308
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 210 Automatic Forward . . . . . . . . . . . 263
Braking System Front Pedestrian (FPB) . . . . . . . 265
Break-In, New Vehicle . . . . . . . . . . 224
Bulb Replacement Headlamp Aiming . . . . . . . . . . . . . 314
Headlamps . . . . . . . . . . . . . . . . . . . 314
Headlamps, Front Turn
Signal, and Sidemarker . . . . . 315 Bulb Replacement (cont'd)
High Intensity Discharge
(HID) Lighting . . . . . . . . . . . . . . . 314
License Plate Lamps . . . . . . . . . 315
Buying New Tires . . . . . . . . . . . . . . . 342
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 128
California Perchlorate Materials
Requirements . . . . . . . . . . . . . . . 291
California Proposition
65 Warning . . . . . . . . . .290, 309, 356, Back Cover
Canadian Vehicle Owners . . . . . . . . 2
Capacities and Specifications . . . . . . . . . . . . . . . . . 386
Carbon Monoxide
Engine Exhaust . . . . . . . . . . . . . . . 232
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . 43
Winter Driving . . . . . . . . . . . . . . . . 218
Cargo Management System . . . . . . . . . 120
Caution, Danger, and Warning . . . . 3
Center Console Storage . . . . . . . . 120
Chains, Tire . . . . . . . . . . . . . . . . . . . . 346

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 10/31/18
Index 417
ChargingWireless . . . . . . . . . . . . . . . . . . . . . . 132
Charging System Light . . . . . . . . . 142
Check Engine Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . 142
Child Restraints
Infants and Young Children . . . . . 99
Lower Anchors and Tethersfor Children . . . . . . . . . . . . . . . . . 105
Older Children . . . . . . . . . . . . . . . . . . 98
Securing . . . . . . . . . . . . . . . . . .113, 115
Systems . . . . . . . . . . . . . . . . . . . . . . 102
Circuit Breakers . . . . . . . . . . . . . . . . 317
Cleaning Exterior Care . . . . . . . . . . . . . . . . . 362
Interior Care . . . . . . . . . . . . . . . . . . 366
Climate Control Systems Dual Automatic . . . . . . . . . . . . . . . 201
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . 204
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Cluster, Instrument . . . . . . . . . . . . . 135
Collision Damage Repair . . . . . . . 396
Compact Spare Tire . . . . . . . . . . . . 354
Compartments
Storage . . . . . . . . . . . . . . . . . . . . . . . .119
Compass . . . . . . . . . . . . . . . . . . . . . . . 128 Connected Services
Connections . . . . . . . . . . . . . . . . . . 412
Diagnostics . . . . . . . . . . . . . . . . . . . 414
Navigation . . . . . . . . . . . . . . . . . . . . .411
Connections Connected Services . . . . . . . . . . 412
Control
Traction and ElectronicStability . . . . . . . . . . . . . . . . . . . . . 241
Control of a Vehicle . . . . . . . . . . . . . 210
Convex Mirrors . . . . . . . . . . . . . . . . . . 52
Coolant Engine Temperature Gauge . . 139
Cooling . . . . . . . . . . . . . . . . . . . . 201, 204
Cooling System . . . . . . . . . . . . . . . . . 301
Courtesy Lamps . . . . . . . . . . . . . . . . 172
Courtesy Transportation Program . . . . . . . . . . . . . . . . . . . . . . . 395
Cruise Control . . . . . . . . . . . . . . . . . . 246 Light . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Cruise Control, Adaptive . . . . . . . . 248
Customer Assistance . . . . . . . . . . . 392
Offices . . . . . . . . . . . . . . . . . . . . . . . . 391
Text Telephone (TTY)Users . . . . . . . . . . . . . . . . . . . . . . . 392
Customer Information Publications OrderingInformation . . . . . . . . . . . . . . . . . . 398 Customer Satisfaction
Procedure . . . . . . . . . . . . . . . . . . . . . 389
D
Damage Repair, Collision . . . . . . . 396
Danger, Warning, and Caution . . . . 3
Data Collection
Infotainment System . . . . . . . . . . 402
OnStar . . . . . . . . . . . . . . . . . . . . . . . 402
Data Recorders, Event . . . . . . . . . 401
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . . . 169
Defensive Driving . . . . . . . . . . . . . . . 210
Delayed Locking . . . . . . . . . . . . . . . . . 41
Devices Auxiliary . . . . . . . . . . . . . . . . . . . . . . 191
Diagnostics
Connected Services . . . . . . . . . . 414
Distracted Driving . . . . . . . . . . . . . . . 209
Dome Lamps . . . . . . . . . . . . . . . . . . . 172
Door Ajar Light . . . . . . . . . . . . . . . . . . . . . 151
Delayed Locking . . . . . . . . . . . . . . . . 41
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Power Locks . . . . . . . . . . . . . . . . . . . . 41
Drive Belt Routing, Engine . . . . . . 388
Drive Systems
All-Wheel Drive . . . . . . . . . . 237, 310

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 10/31/18
418 Index
Driver Assistance Systems . . . . . 256
Driver InformationCenter (DIC) . . . . . . . . . . . . . . . . . . 151
Driver Mode Control . . . . . . . . . . . . 242
Driving Assistance Systems . . . . . . . . . . 261
Characteristics andTowing Tips . . . . . . . . . . . . . . . . . 275
Defensive . . . . . . . . . . . . . . . . . . . . . 210
Drunk . . . . . . . . . . . . . . . . . . . . . . . . . 210
For Better Fuel Economy . . . . . . . 27
Hill and Mountain Roads . . . . . . 218
If the Vehicle is Stuck . . . . . . . . . 220
Loss of Control . . . . . . . . . . . . . . . 212
Off-Road . . . . . . . . . . . . . . . . . . . . . 212
Off-Road Recovery . . . . . . . . . . . .211
Vehicle Load Limits . . . . . . . . . . . 220
Wet Roads . . . . . . . . . . . . . . . . . . . 217
Winter . . . . . . . . . . . . . . . . . . . . . . . . 218
Dual Automatic Climate Control System . . . . . . . . . . . . . . . . 201
E
Electric Parking Brake . . . . . . . . . . 238
Electric Parking Brake Light . . . . 145
Electrical Equipment,
Add-On . . . . . . . . . . . . . . . . . . . . . . . 288 Electrical System
Engine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 318
Fuses and Circuit Breakers . . . 317
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 321
Overload . . . . . . . . . . . . . . . . . . . . . 317
Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 323
Emergency OnStar . . . . . . . . . . . . . . . . . . . . . . . 404
Engine Air Cleaner/Filter . . . . . . . . . . . . . 300
Check Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . 142
Compartment Overview . . . . . . . 293
Coolant Temperature
Gauge . . . . . . . . . . . . . . . . . . . . . . 139
Cooling System . . . . . . . . . . . . . . . 301
Drive Belt Routing . . . . . . . . . . . . 388
Exhaust . . . . . . . . . . . . . . . . . . . . . . 232
Heater . . . . . . . . . . . . . . . . . . . . . . . . 228
Oil Life System . . . . . . . . . . . . . . . 298
Oil Pressure Light . . . . . . . . . . . . 148
Overheating . . . . . . . . . . . . . . . . . . 305
Power Messages . . . . . . . . . . . . . 154
Running While Parked . . . . . . . . 233
Starting . . . . . . . . . . . . . . . . . . . . . . . 226 Entry Lighting . . . . . . . . . . . . . . . . . . . 174
Equipment, Towing . . . . . . . . . . . . . 283
Event Data Recorders . . . . . . . . . . 401
Exit Lighting . . . . . . . . . . . . . . . . . . . . 174
Extended Parking . . . . . . . . . . . . . . . 231
Extender, Seat Belt . . . . . . . . . . . . . . 83
Exterior Lamp Controls . . . . . . . . . 167
Exterior Lighting Battery
Saver . . . . . . . . . . . . . . . . . . . . . . . . . 175
F
FeaturesMemory . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filter, Engine Air Cleaner . . . . . . . . . . . 300
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 169
Flashers, Hazard Warning . . . . . . 171
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 347 Changing . . . . . . . . . . . . . . . . . . . . . 348
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 370
Fluid Automatic Transmission . . . . . . 299
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 308
Washer . . . . . . . . . . . . . . . . . . . . . . . 306
Fog Lamps . . . . . . . . . . . . . . . . . . . . . 172
Folding Mirrors . . . . . . . . . . . . . . . . . . 52
Forward Automatic Braking . . . . . 263

Chevrolet Traverse Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146157) - 2019 - CRC - 10/31/18
Index 419
Forward Collision Alert(FCA) System . . . . . . . . . . . . . . . . . 261
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 399
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Front Pedestrian Braking
(FPB) System . . . . . . . . . . . . . . . . . 265
Front Seats Adjustment . . . . . . . . . . . . . . . . . . . . . 63
Heated and Ventilated . . . . . . . . . . 69
Fuel Additives . . . . . . . . . . . . . . . . . . . . . 273
Economy Driving . . . . . . . . . . . . . . . 27
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 274
Filling the Tank . . . . . . . . . . . . . . . 273
Foreign Countries . . . . . . . . . . . . 273
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 139
Low Fuel Warning Light . . . . . . . 149
Prohibited Fuels . . . . . . . . . . . . . . 272
Recommended . . . . . . . . . . . . . . . 272
Top Tier . . . . . . . . . . . . . . . . . . . . . . 271
Fuses Engine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 318
Fuses and Circuit Breakers . . . 317 Fuses (cont'd)
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 321
Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 323
G
Garage Door Opener . . . . . . . . . . . 164Programming . . . . . . . . . . . . . . . . . 164
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 313
Gauges
Engine CoolantTemperature . . . . . . . . . . . . . . . . 139
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Odometer . . . . . . . . . . . . . . . . . . . . . 138
Speedometer . . . . . . . . . . . . . . . . . 138
Tachometer . . . . . . . . . . . . . . . . . . . 138
Trip Odometer . . . . . . . . . . . . . . . . 138
Warning Lights and
Indicators . . . . . . . . . . . . . . . . . . . 134
General Information Service and Maintenance . . . . . 371
Towing . . . . . . . . . . . . . . . . . . . . . . . . 275
Vehicle Care . . . . . . . . . . . . . . . . . . 290
Glove Box . . . . . . . . . . . . . . . . . . . . . . 119
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 393
H
Hands-Free Phone . . . . . . . . . . . . . 198
Hazard Warning Flashers . . . . . . . 171
Head Restraints . . . . . . . . . . . . . . . . . 61
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . 314
Automatic . . . . . . . . . . . . . . . . . . . . . 170
Bulb Replacement . . . . . . . 314, 315
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . 169
Flash-to-Pass . . . . . . . . . . . . . . . . . 169
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . 314
High-Beam On Light . . . . . . . . . . 150
High/Low Beam Changer . . . . . 169
Lamps On Reminder . . . . . . . . . 150
Heated Rear Seats . . . . . . . . . . . . . . . . . . . . . 73
Steering Wheel . . . . . . . . . . . . . . . 126
Heated and Ventilated Front Seats . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Heated Mirrors . . . . . . . . . . . . . . . . . . . 53
Heater Engine . . . . . . . . . . . . . . . . . . . . . . . . 228
Heating . . . . . . . . . . . . . . . . . . . . 201, 204
High Voltage Devices and Wiring . . . . . . . . . . . . . . . . . . . . . . . . . 316
High-Beam On Light . . . . . . . . . . . . 150
