power steering fluid CHEVROLET VENTURE 2003 1.G Owners Manual

Service............................................................5-3
Doing Your Own Service Work.........................5-3
Adding Equipment to the Outside of
Your Vehicle..............................................5-4
Fuel................................................................5-4
Gasoline Octane............................................5-4
Gasoline Speci®cations....................................5-5
California Fuel...............................................5-5
Additives.......................................................5-6
Fuels in Foreign Countries...............................5-6
Filling Your Tank............................................5-7
Filling a Portable Fuel Container.......................5-9
Checking Things Under the Hood....................5-10
Hood Release..............................................5-10
Engine Compartment Overview.......................5-12
Engine Oil...................................................5-13
Engine Air Cleaner/Filter................................5-18
Automatic Transaxle Fluid..............................5-20
Engine Coolant.............................................5-23
Radiator Pressure Cap..................................5-26
Engine Overheating.......................................5-26
Cooling System............................................5-29
Power Steering Fluid.....................................5-37
Windshield Washer Fluid................................5-38
Brakes........................................................5-40Battery........................................................5-43
Jump Starting...............................................5-44
All-Wheel Drive..............................................5-50
Bulb Replacement..........................................5-52
Halogen Bulbs..............................................5-52
Headlamps..................................................5-52
Front Turn Signal, Sidemarker and
Parking Lamps..........................................5-54
Taillamps, Turn Signal, Stoplamps and
Back-up Lamps.........................................5-56
Replacement Bulbs.......................................5-57
Windshield Wiper Blade Replacement..............5-58
Tires..............................................................5-60
In¯ation - Tire Pressure.................................5-61
Tire Inspection and Rotation...........................5-62
When It Is Time for New Tires.......................5-63
Buying New Tires.........................................5-64
Uniform Tire Quality Grading..........................5-65
Wheel Alignment and Tire Balance..................5-66
Wheel Replacement......................................5-66
Tire Chains..................................................5-67
Accessory In¯ator.........................................5-68
If a Tire Goes Flat........................................5-70
Changing a Flat Tire.....................................5-71
Compact Spare Tire......................................5-86
Section 5 Service and Appearance Care
5-1

A. Underhood Fuse Block. SeeFuses and Circuit
Breakers on page 5-96.
B. Remote Positive (+) Terminal. See
Jump Starting on
page 5-44.
C. Windshield Washer Fluid Reservoir. See
Windshield
Washer Fluid on page 5-38.
D. Radiator Pressure Cap. See
Radiator Pressure Cap
on page 5-26.
E. Power Steering Fluid Reservoir. See
Power Steering
Fluid on page 5-37.
F. Engine Oil Fill Cap. See
Engine Oil on page 5-13.
G. Engine Oil Dipstick. See
Engine Oil on page 5-13.
H. Transaxle Fluid Dipstick. See
Automatic Transaxle
Fluid on page 5-20.
I. Brake Master Cylinder Reservoir. See
Brakes on
page 5-40.
J. Engine Air Cleaner/Filter. See
Engine Air
Cleaner/Filter on page 5-18.
K. Coolant Recovery Tank. See
Cooling System on
page 5-29.
Engine Oil
If the low engine oil level message appears on the
instrument cluster, it means you need to check your
engine oil level right away. For more information,
see
Low Engine Oil Level Message on page 3-53.
You should check your engine oil level regularly; this is
an added reminder.United States
Canada
5-13

9. Then ®ll the coolant recovery tank to the FULL
COLD mark.
10. Put the cap back on the coolant recovery tank.
Power Steering Fluid
When to Check Power Steering Fluid
It is not necessary to regularly check power steering ¯uid
unless you suspect there is a leak in the system or
you hear an unusual noise. A ¯uid loss in this system
could indicate a problem. Have the system inspected
and repaired. See
Engine Compartment Overview
on page 5-12for reservoir location.
5-37

How to Check Power Steering Fluid
Turn the key off, let the engine compartment cool down,
wipe the cap and the top of the reservoir clean, then
unscrew the cap and wipe the dipstick with a clean rag.
Replace the cap and completely tighten it. Then
remove the cap again and look at the ¯uid level on the
dipstick.
When the engine compartment is hot, the level should
be at the H (hot) mark. When it's cold, the level
should be at the C (cold) mark. If the ¯uid is at the ADD
mark, you should add ¯uid.
What Power Steering Fluid to Use
To determine what kind of ¯uid to use, seePart D:
Recommended Fluids and Lubricants on page 6-17.
Always use the proper ¯uid. Failure to use the proper
¯uid can cause leaks and damage hoses and seals.
Windshield Washer Fluid
What Washer Fluid to Use
When you need windshield washer ¯uid, be sure to read
the manufacturer's instructions before use. If you will
be operating your vehicle in an area where the
temperature may fall below freezing, use a ¯uid that has
sufficient protection against freezing. See
Engine
Compartment Overview on page 5-12for reservoir
location.
5-38

Part D: Recommended Fluids and
Lubricants
Fluids and lubricants identi®ed below by name, part
number or speci®cation may be obtained from your
dealer.
Usage Fluid/Lubricant
Engine OilEngine oil with the American
Petroleum Institute Certi®ed for
Gasoline Engines starburst symbol
of the proper viscosity. To determine
the preferred viscosity for your
vehicle's engine, see
Engine Oil on
page 5-13.
Engine Coolant50/50 mixture of clean, drinkable
water and use only
DEX-COOL
žCoolant. SeeEngine
Coolant on page 5-23.
Hydraulic Brake
SystemDelco Supreme 11 Brake Fluid or
equivalent DOT-3 brake ¯uid.
Windshield
Washer SolventGM Optikleen
žWasher Solvent or
equivalent.
Usage Fluid/Lubricant
Power Steering
SystemGM Power Steering Fluid (GM Part
No. U.S. 1052884, in Canada
993294, or equivalent).
Automatic
TransaxleDEXRON
ž-III Automatic
Transmission Fluid.
Key Lock
CylindersMulti-Purpose Lubricant, Superlube
(GM Part No. U.S. 12346241, in
Canada 10953474, or equivalent).
Chassis
LubricationChassis Lubricant (GM Part No.
U.S. 12377985, in Canada
88901242, or equivalent) or lubricant
meeting requirements of NLGI #2,
Category LB or GC-LB.
Carrier
Assembly Ð
Differential
(Rear Drive
Module) and
Transfer Case
(Power Transfer
Unit)VERSATRAKŸ Fluid (GM Part No.
U.S. 12378514, in Canada
88901045).
6-17

Electrical System (cont.)
Power Windows and Other Power Options......5-96
Windshield Wiper Fuses...............................5-96
Emissions Inspection and Maintenance
Programs...................................................3-48
Engine Coolant Level Check.............................6-10
Engine Oil Additives........................................5-17
Engine Oil and Chassis Lubrication
Scheduled Maintenance................................. 6-6
Engine Oil Level Check...................................6-10
Engine Speci®cations.....................................5-104
Engine..........................................................5-18
Air Cleaner/Filter.........................................5-18
Battery.......................................................5-43
Change Oil Message...................................3-54
Check and Service Engine Soon Light............3-45
Compartment Overview................................5-12
Coolant Heater............................................2-33
Coolant Temperature Gage...........................3-44
Coolant Temperature Warning Message..........3-51
Coolant......................................................5-23
Cooling System Inspection............................6-16
Exhaust.....................................................2-42
Low Oil Level Message................................3-53
Oil .............................................................5-13
Overheating................................................5-26
Starting......................................................2-32
Entering Programming Mode............................2-62
Entertainment System......................................3-92
Cleaning the Video Screen..........................3-105Entertainment System (cont.)
Cleaning Your DVD Player..........................3-105
DVD Distortion..........................................3-103
Entry Lighting.................................................3-18
Erasing HomeLink
žButtons..............................2-50
Exit Lighting...................................................3-19
Exiting Programming Mode...............................2-70
Express-Down Window....................................2-25
Extender, Safety Belt.......................................1-54
Exterior Lamps...............................................3-15
F
Filter.............................................................5-18
Engine Air Cleaner......................................5-18
Finding a PTY Station.....................3-68, 3-75, 3-85
Finding a Station....................3-62, 3-65, 3-73, 3-82
Finish Care....................................................5-91
Finish Damage...............................................5-93
Fixed Mast Antenna.......................................3-105
Flash-to-Pass................................................... 3-9
Flat Tire, Changing.........................................5-71
Flat Tire........................................................5-70
Flip and Fold Rear Seats.................................. 1-7
Fluid.............................................................5-20
Automatic Transaxle.....................................5-20
Power Steering...........................................5-37
Windshield Washer......................................5-38
FM ..............................................................3-104
6

Hood............................................................5-10
Checking Things Under................................5-10
Release.....................................................5-10
Horn............................................................... 3-7
How the System Works...................................3-23
How to Add Coolant to the Coolant
Recovery Tank............................................5-31
How to Add Coolant to the Radiator..................5-34
How to Add Fluid Automatic Transaxle Fluid.......5-22
How to Check Automatic
Transaxle Fluid...........................................5-20
How to Check Power Steering Fluid..................5-38
How to Check................................................5-61
How to Inspect the Engine Air Cleaner/Filter.......5-19
How to Use This Manual...................................... ii
How to Wear Safety Belts Properly...................1-35
Hydroplaning..................................................4-18
I
If No Steam Is Coming From Your Engine..........5-28
If Steam Is Coming From Your Engine...............5-27
If the Light Is Flashing.....................................3-46
If the Light Is On Steady.................................3-47
If You Are Stuck in Sand, Mud, Ice or Snow.......4-30
If You Do Decide To Pull A Trailer.....................4-37If You're Caught in a Blizzard...........................4-28
Ignition Positions.............................................2-31
Ignition Transaxle Lock Check..........................6-13
Infants and Young Children, Restraints...............1-58
In¯ation -- Tire Pressure..................................5-61
Inspection......................................................6-16
Brake System.............................................6-16
Engine Cooling System................................6-16
Exhaust System..........................................6-15
Fuel System...............................................6-16
Part C - Periodic Maintenance.......................6-15
Steering, Suspension and Front Drive Axle
Boot and Seal.........................................6-15
Throttle System...........................................6-16
Transfer Care (Power Transfer Unit) and
Carrier Assembly-Differential (Rear Drive
Module) All-Wheel Drive............................6-16
Instrument Panel Brightness.............................3-17
Instrument Panel Fuse Block............................5-97
Instrument Panel.............................................3-36
Cluster.......................................................3-36
Overview..................................................... 3-4
Switchbank.................................................3-21
Interior Lamps Control.....................................3-17
Interior Lamps Override...................................3-17
Interior Lamps................................................3-17
8

M
Maintenance, Normal Replacement Parts..........5-104
Maintenance Schedule.....................................6-10
At Each Fuel Fill.........................................6-10
At Least Once a Month................................6-10
At Least Once a Year..................................6-12
At Least Twice a Year..................................6-11
Brake System Inspection..............................6-16
Engine Cooling System Inspection.................6-16
Exhaust System Inspection...........................6-15
Fuel System Inspection................................6-16
How This Section is Organized....................... 6-3
Introduction.................................................. 6-2
Maintenance Requirements............................. 6-2
Part A - Scheduled Maintenance Services......... 6-4
Part B - Owner Checks and Services.............6-10
Part C - Periodic MaintenanceInspections......6-15
Part D - Recommended Fluids and
Lubricants...............................................6-17
Part E - Maintenance Record........................6-19
Scheduled Maintenance................................. 6-5
Steering, Suspension and Front Drive Axle
Boot and Seal Inspection..........................6-15
Throttle System Inspection............................6-16
Transfer Case (Power Transfer Unit) and
Carrier Assembly-Differential (Rear Drive
Module) All-Wheel Drive Inspection.............6-16Maintenance Schedule (cont.)
Using Your................................................... 6-4
Your Vehicle and the Environment................... 6-2
Maintenance When Trailer Towing.....................4-43
Making Turns.................................................4-41
Malfunction Indicator Light................................3-45
Manual Seats................................................... 1-3
Manual Windows............................................2-24
Matching Transmitter(s) to Your Vehicle............... 2-7
Message.......................................................3-57
All-Wheel Drive Disable Warning....................3-57
Center.......................................................3-50
Change Engine Oil......................................3-54
Charging System Indicator............................3-52
Door Ajar Warning.......................................3-55
Engine Coolant Temperature Warning.............3-51
Low Engine Oil Level...................................3-53
Low Fuel Warning.......................................3-57
Low Oil Pressure.........................................3-52
PASS-Key
žIII Security.................................3-56
Power Sliding Door Warning.........................3-54
Rear Hatch Ajar Warning..............................3-56
Service Traction System Warning...................3-50
Traction Active............................................3-51
Mexico, Central America and Caribbean Islands/
Countries (Except Puerto Rico and U.S. Virgin
Islands) ± Customer Assistance....................... 7-5
10

Passenger Compartment Air Filter.....................3-33
Passing.................................................4-13, 4-41
PASS-Key
žIII Operation..................................2-29
PASS-KeyžIII Security Message.......................3-56
PASS-KeyžIII ................................................2-29
Plan Ahead When Possible................................ 7-8
Playing a Cassette Tape..................................3-77
Playing a Compact Disc..................3-70, 3-79, 3-87
Playing a Speci®c Loaded
Compact Disc.............................................3-88
Playing the Radio...................3-62, 3-65, 3-72, 3-81
Power Steering...............................................4-10
Power...........................................................3-24
Accessory Outlets........................................3-24
Door Locks.................................................2-11
Electrical System.........................................5-96
Rear Quarter Windows.................................2-26
Six-Way Seats.............................................. 1-4
Sliding Door Warning Message......................3-54
Sliding Door................................................2-17
Steering Fluid.............................................5-37
Windows....................................................2-25
Pretensioners, Safety Belt................................1-54
Primary Radio Controls....................................3-99
Programmable Automatic Door Locks.................2-12
Programmable Modes.....................2-62, 2-63, 2-64,
2-65, 2-66, 2-67, 2-68Programming Mode.........................................2-62
Entering.....................................................2-62
Exiting.......................................................2-70
Programming the HomeLink Transmitter.............2-48
Q
Questions and Answers About Safety Belts.........1-34
R
Radiator Pressure Cap....................................5-26
Radio Messages.............................3-64, 3-69, 3-77
Radios..........................................................3-61
AM-FM Radio.............................................3-62
Care of Your Cassette Tape Player...............3-104
Care of Your CD and DVD Player................3-105
Care of Your CDs and DVDs.......................3-105
Radio with Cassette and CD.........................3-72
Radio with CD............................................3-65
Radio with Six-Disc CD................................3-81
Rear Seat Audio................................3-99, 3-101
Setting the Time for Radios with Radio
Data Systems (RDS)................................3-61
Setting the Time for Radios without
Radio Data Systems (RDS).......................3-61
12

Understanding Radio Reception.......................3-104
Uniform Tire Quality Grading............................5-65
United States ± Customer Assistance.................. 7-4
Used Replacement Wheels..............................5-67
Using Cleaner on Fabric..................................5-88
Using HomeLink
ž...........................................2-50
Using RDS....................................3-67, 3-75, 3-84
Using Song List Mode.....................................3-90
V
Vehicle Identi®cation........................................5-95
Number (VIN).............................................5-95
Service Parts Identi®cation Label...................5-95
Vehicle Personalization....................................2-61
Arming and Disarming the Content
Theft-Deterrent System.............................2-68
Automatic Door Locks..................................2-63
Content Theft-Deterrent System.....................2-67
Delayed Illumination and Exit Lighting.............2-62
Entering Programming Mode.........................2-62
Exiting Programming Mode...........................2-70
Last Door Locking and Lockout Deterrent........2-64
Remote Driver Unlock Control.......................2-65
Remote Lock and Unlock Con®rmation...........2-66
Vehicle Storage..............................................5-44
Vehicle............................................................ 4-5
Control........................................................ 4-5
Damage Warnings........................................... ivVehicle (cont.)
Loading......................................................4-34
Symbols......................................................... iv
Ventilation Adjustment......................................3-28
Video Screen.................................................3-95
Visor Vanity Mirror..........................................2-26
Visors...........................................................2-26
W
Warm-Up Shift................................................2-37
Warning Lights, Gages and Indicators................3-35
Warnings......................................................... 3-6
Hazard Warning Flashers............................... 3-6
Other Warning Devices.................................. 3-6
Safety and Symbols......................................... iii
Vehicle Damage.............................................. iv
Washing Your Vehicle......................................5-90
Weatherstrip Lubrication...................................6-11
Weight of the Trailer Tongue.............................4-38
Weight of the Trailer........................................4-37
What Engine Coolant to Use............................5-24
What Kind of Engine Oil to Use........................5-16
What Power Steering Fluid to Use....................5-38
What to Do with Used Oil................................5-18
What Washer Fluid to Use...............................5-38
Wheels..........................................................5-66
Alignment and Tire Balance..........................5-66
Replacement...............................................5-66
17
